Daewoo DSC-30W60N User manual

Service Guide
Model : DSC-30W60N
http : //svc.dwe.co.kr Jun. 2000
DAEWOO ELECTRONICS CO., LTD.
S/G No. : TSC110NES0
CHASSIS : SC-110
DIGITAL HDTV
Relese 1
DSC-30W60N R-V3
General
Power Requirement AC 120V, 60H z
Power Consumption 250W (1.7W in standby)
Dimensions(W/H/D) 890 x573 x560 m m
Weight 64kg
Antenna Two 75 ohm external input terminals for UHF/VHF/Cabl e
One 75ohm external output terminal for Cabl e
RF Band Coverage VHF 2 ~ 13
UHF 14 ~ 69
CATV 1, 14 ~ 12 5
Screen Size 32 inches Pure Flat 16:9 Aspect ratio
Display Format 1920 x1080i (Digital)
Upconversion to 1080i with line doubling (NTSC)
Horizontal Resolution 800 Line s
Sound
Digital Audio Dolby Digital AC-3 / Pro logi c
NTSC Audio Multi-CH TV Stereo (MTS) / Second Audio Program (SAP )
Audio Power 8W / ch (Main L/R, Woofer), 5W / ch (Center, SL, SR )
Number of Inputs / Outputs
A/V In 4 each (Video / L / R)
S-Video In 2 eac h
HD Component Video In 2 each ( Y/ Pb / Pr, R / G / B )
HD Component Audio In 1 each ( L / R / SL / SR / Center / Woofer )
Digital Audio In 2 each ( Coaxial / Optical )
Digital Audio Out 2 each ( Coaxial / Optical )
External Speaker Out 1 each ( SL / SR / Woofer)
Specifications

CAUTION : DO NOT ATTEMPT TO MOOIFY THIS PROOUCT IN AHY WAY.
UNAUTHORIZED MOOIFICATI0NS WILL NOT ONLY VOID THE WARRANTY, BUT MAY
LEAD TO YOUR BEING LIABLE FOR ANT RESULTING PROPERTY DAMAGE OR
USER INJURY. SERVICE WORK SHOULD BE PERFORMED ONLY AFTER YOU ARE
THOROUGHLY FAMILIAR WITH ALL OF THE FOLLOWING SAFETY CHECKS AND
SERVICING GUIDELINES. TO DO OTHERWISE, INCREASES THE RISK OF POTENTIAL
HAZARDS AND INJURY TO THE USER.
SAFETY CHECKS
AFTER THE ORIGINAL SERVICE PROBLEM HAS BEEN CORRECTED, A CHECK SHOULD
BE MADE OF THE FOLLOWING :
SUBJECT : FIRE & SHOCK HAZARD
1. BE SURE THAT ALL COMPONENTS ARE POSITIONED IN SUCH A WAY AS TO AVOID
POSSIBILITY OF ADJACENT COMPONENT SHORTS THIS IS ESPECIALLY IMPORTANT
ON THOSE NODULES WHICH ARE TRANSPORTED TO AND FROM THE REPAIR
SHOP.
2. NEVER RELEASE A REPAIR UNLESS ALL PROTECTIVE DEVICES SUCH AS
INSULATORS, BARRIERS, COVERS, SHIELDS, STRAIN RELIEFS, POWER SUPPLY
CORDS, AND OTHER HARDWARE HAVE BEEN REINSTALLED PER ORIGINAL
DESIGN. BE SURE, THAT THE SAFETY PURPOSE OF THE POLARIZED LINE PLUG
HAS NOT BEEN DEFECTED.
3. SOLDERING MUST BE INSPECTED TO DISCOVER POSSIBLE COLD SOLDER JOINTS,
SOLDER SPLASHES OF SHARP SOLDER POINTS. BE CERTAIN TO REMOVE ALL
LOOSE FOREIGN PARTICLES.
4. CHECK FOR PHYSICAL EVIDENCE OF DAMAGE OR DETERIORANN TO PARTS AND
COMPONENTS, FOR FRAYED LEADS, DAMAGED INSULATION (INCLUDING A.C.
CORD), AND REPLACE IF NECESSARY. FOLLOW ORIGINAL LAYOUT, LEAD LENGTH
AND DRESS.
5. NO LEAD OR COMPONENT SHOULD TOUCH A RECEIVING TUBE OR A RESISTOR
RATED AT 1 WATT OR MORE. LEAD TENSION AROUND PROTRUDING METAL
SURFACES MUST BE AVOIDED.
6. ALL CRlTICAL COMPONENTS SUCH AS FUSES, FLAMEPROOF RESISTOR,
CAPACITORS, ETC. MUST BE REPLACED WITH EXACT FACTORY TYPES. DO NOT
USE REPLACEMENT COMPONENTS OTHER THAN THOSE SPECIAL OR MAKE
UNRECOMMENDED CIRCUIT MODIFICATIONS.
7. AFTER RE-ASSEMBLY OF THE STE ALWAYS PERFORM AN A.C. LEAKAGE TEST ON
ALL EXPOSED METALLIC PARTS OF THE CABINET. (THE CHANEL SELECTOR KNOB,
ANTENNA TERMINALS, HANDLE AND SCREWS) TO BE SURE THE SET IS SAFE TO
OPERATE WITHOUT DANCER OF ELECTRICAL SHOCK. DO NOT USE A LINE
ISOLATION TRANSFORMER DURING THIS TEST USE AN A.C. VOLTMETER, HAVING
5000 OHMS PER VOLT OR MORE SENSITIVITY, IN THE FOLLOWING MANNER :
CONNECT A 1500 OHM 10 WATT RESISTOR, PARALLELED BY A .75 MFD. 150V A.C.
TYPE CAPACITOR BETWEEN A KNOWN GOOD EARTH GROUND (WATER POPE,
CONDUIT, ETC) AND THE EXPOSED METALLIC PARTS, ONE AT A TIME. MEASURE
THE A.C VOLTAGE ACROSS THE COMBINATION OF 1500 OHM RESISTOR AND .15
MFD CAPACITOR. REVERSE THE A.C. PLUG AND REPEAT A.C. VOLTAGE
MEASUREMENTS FOR EACH EXPOSED METALLIC PART. VOLTAGE MEASUREMENTS
MUST NOT EXCEED .75 VOLTS R.M.S THIS CORRESPONDS TO 0.5 MILLIAMP A.C.
NAY VALUE EXCEEDING THIS LIMIT CONSTITUTES A POTENTIAL SHOCK HAZARD
AND MUST BE CORRECTED IMMEDIATELY
SUBJECT : GRAPHIC SYMBOLS
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN
EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE SERVICE
PERSONNEL TO THE PRESENCE OF UNINSULATED
"DANGEROUS VOLTAGE" THAT MAY BE OF SUFFICIENT
MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK.
THE EXCLAMATION POINT WITHIN AN EQULATERAL TRIANGLE
IS INTENDED TO ALERT THE SERVICE PERSONNEL TO THE
PRESENCE OF IMPORTANT SAFETY INFORMATION ON SERVICE
LITERATURE.
FUSE SYMBOL IS PRINTED ON PCB ADJACENT TO THE FUSE,
WITH “RISK OF FIRE REPLACE FUSE AS MARKED”. THE SYMBOL
IS EXPLAINED IN THE SERVICE MANUAL WITH THE FOLLOWING
WORDING OR EQUIVALENT.
CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY
WITH SAME TYPE “(6.3A, 125V)” AND
ATTENTION : AFIN D’ASSU UNE PROTECTION PERMANENTE CONTRE LES RISQUES
D’INCENDIE, REMPLACER UNIQUEMENT PAR UN FUSIVLE DE MEME TYPE ET DE
“6.3A, 125V”.
SUBJECT : X-RADIATION
1. BE SURE PROCEDURES AND AND INSTRUCTIONS TO ALL SERVICE PERSONNEL
COVER THE SUBJECT OF X-RADIATION. THE ONLY POTENIAL SOURCE OF X-RAYS
IN CURRENT TV RECEIVERS IS THE PICTURE TUBE HOWEVER, THIS TUBE DOES
NOT EMIT X-RAYS WHEN THE HIGH VOLTAGE IS AT THE FACTORY SPECIFIEDLEVEL
THE PROPER VALUE IS GIVEN IN THE APPLICABLE SCHEMATIC OPERATION AT
HIGHER VOLTAGES MAY CAUSE A FAILURE OF THE PICTURE TUBE OR HIGH
VOLTAGE SUPPLY AND, UNDER CERTAIN CIRCUMSTANCES, AMY PRODUCE
RADIATION IN EXCESS OF DESIRABLE LEVELS.
2. ONLY FACTORY SPECIFIED C.R.T ANODE CONNECTORS MUST BE USED.
DEGAUSSING SHIELDS ALSO SERVE AS X-RAY SHIELD IN COLOR SETS.
AIWAYS RE-INSTALL THEM.
3. IT IS ESSENTIAL THAT SERVICE PERSONNEL HAVE AVAILABLE AN ACCURATE AND
RELIABLE HIGH VOLTAGE METER. THE CALIBRATION OF THE METER SHOULD BE
CHECKED PERIODICALLY AGAINST A REFERENCE STANDARD. SUCH AS THE ONE
AVAlLABLE AT YOUR DISTRIBUTOR.
4. WHEN THE HIGH VOLTAGE CIRCUITRY IS OPERATING PROPERLY THERE IS NO
POSSIBLITY OF AN X-RADIATION PROBLEM. EVERY TIME A COLOR CHASSIS IS
SERVICED, THE BRIGHTNESS SHOULD BE RUN UP AND DOWN WHILE MONITORING
THE HIGH VOLTAGE WITH A METER TO BE CERTAIN THAT THE HIGH VOLTAGE DOES
NOT EXCEED THE SPECIFIED VALUE AND THAT IT IS REGULATING CORRECTLY. WE
SUGGEST THAT YOU AND YOUR SERVICE ORGANIZATION REVIEW TEST
PROCEDURES SO THAT VOLTAGE REGULATION IS ALWAYS CHECKED AS A
STANDARD SERVICING PROCEDURE, AND THAT THE HIGH VOLTAGE READING BE
RECORDED ON EACH CUSTOMER S INVOICE
5. WHEN TROUBLESHOOTING AND MAKING TEST MEASUREMENTS IN A PROOUCT
WITH A PROBLEM OF EXCESSIVE HIGH VOLTAGE, AVOID BEING UNNECESSARILY
CLOSE TO THE PICTURE TUBE AND THE HIGH VOLTAGE SUPPLY. DO NOT OPERATE
THE PRODUCT LONGER THAN IS NECESSARY TO LOCATE THE CAUSE OF
EXCESSIVE VOLTAGE.
6. REFER TO HV, B+ AND SHUTDOWN ADJUSTMENT PROCEDURES DESCRIBED IN
THE APPROPRIATE SCHEMATIC AND DIAGRAMS (WHERE USED).
Improtant Service Notes

1. Entering to Service Mode
1) With the user remote control
Press the button in the following order.
2) With the service remote control
2. Function of each service Mode
1) Screen Voltage Control mode
The vertical deflection is down, and a horizontal line appears on the screen.
2) Video Controls mode
3) White Balance Adjustment mode
4) Sub Brightness Adjustment mode.
5) Exit from Service Mode
Press again to make service mode exit.
Service Modes
1MUTESELECTMUTE POWER
1,2,3,...,9
S1 : Heat Run
S4 : Video Controls
S8 : Sub Brightness
S2 : Screen Voltage
S5 : Geometry
S9 : Software Version
S3 : Sound Controls
S7 : White Balance
S10 : Factory Setting
Tint : 0 63 31
Brightness : 0 48 24
Contrast : 0 48 24
Color : 0 63 31
Sharpness : 0 63 31
White Balance Control
Drive R 128
G 32
B 128
Bias R 64
G 27
B 64
Initial value
Brightness 24
Initial value
Contrast 22
Color 32
Tint 37VM Limit 64
VM Gain 27

The remote control has the following functions:
1. Power button
Press to turn the HDTV(and other equipment) on
and off.
2. MODE buttons
Press to select which equipment you wish your remote
control to operate:
* SAT(satelite )
* CATV (cable box)
* VC R
* T V
The Mode button you press will light up in red.
3. MENU button
Press once to display the HDTV menus. Press again to
make the menus disappear.
4. SEL ( Select) button
Press to select items on the HDTV menus.
5. Arrow buttons
Press to navigate through the HDTV menus.
6. STAT (Channel Station) button
Press to quickly select chammels to watch on your
HDTV .
7. VOL (Volume) button s
press to raise and lower the volume on your HDTV.
8. Number buttons
Press to directly select channels or to enter the numbers
in the menus.
9. INFO (Information) butto n
Press to see the channel banner that provides information
while viewing your HDTV .
10. V MODE (Video Mode) butto n
Press to select a video mode : Normal, Dynamic,
Cinema or Customer.

34958000300 BOX CARTON
24958200100 BAG P.E
14958100500 PAD BOX CARTON
gPEBKMSD002 PCB BLANKING AS
fPEUNSWD002 PCB CRT AS
ePETASWD002 PCB TERMINAL ANT AS
dPEADMSD002 PCB ATSC DECORDER AS
cPEVDMSD002 PCB VIDEO AS
bPEPWMSD002 PCB POWER AS
aPEMPMSD002 PCB MAIN AS
Special Adjustment (When replacing new circuit boards)
1. DTV Decorder module
1) Before replacing a new module, if seeing OSD menu is possible, record the adjusted data of White Balalce and
Geometry.
2) After replacing the defective module with a new one, memorize the value of data value to the new DTV decoder module
with the service remote control.
3) Perform the Y Level Adjustment.
2. Power assembly
1) After replacing a new assembly, perform Blanking Width Adjustment.
2) X - Radiation Protection Circuit Test
When service has been performed on the horizontal deflection system, high voltage system or B+ system, the Z-Radiation
Protection Circuit Test must be tested for proper operation as followings :
2-1) Operate the HDTV set for at least 15 minutes.
2-2) Perform this test at the normal video and sound.
2-3) Check the cathode voltage of D837. Its voltage should be about 26VDC.
2-4) Connect a resister 24K(1/4W) with parallel to R925.
2-5) Then the set will be shut down, lighting up red to the power indicator.
2-6) If it is not, the circuit of Z-Radiation Protection must be repaired before the set is returned to the customer.
3) The rest adjustment idems art no need to adjust.
3. Main assembly
1) After replacing a new assembly, perform Blanking Width adjustment.
2) The rest adjustments are no need.
g
f
e
d
c
b
a
1
2
3

In the majority of cases, a high definition digital television will need basic adjustments such as high voltage, screen voltage , focus,
white balance, sub brightness, geometry, and blanking width. All adjustments should be performed after heat-running the set for at
least 20 minutes.
1. Press the S1 button on the service remote control, and then full white pattern will appear on the screen.
2. Press again the S1 button, and then the pattern will disappear.
High Voltage Adjustment
1. Operate the set for at least 20 minutes.
2. Connect the probe of high voltage meter to CRT ANODE.
3. Adjust the variable register RV801 on the power assembly so that high voltage may be to be between 29.5KV ~ 30.5KV.
Screen Voltage Adjustment
1. Press the S2 button on the service remote control.
1) Video Input mode will be VIDEO 1.
2) Vertical deflection will be down, and a horizontal line will appear on the screen.
2. Turn the variable screen volume of FBT to adjust screen voltage, at the point that a horizontal line only just appears.
Focus Adjustment
1. Tune on Retma pattern.
2. Turn the variable focus volume of FBT so that the center area of screen is sharp scanning line.
3. Turn the variable volume R522 on the CRT assembly so that the edge of screen may be sharp scanning line.
White Balance Adjustment
1. Input the Black & white signal to the HD Component jack on the rear panel.
<Black & White Pattern>
2. The color temperature is the following.
x=0.270 6 0.005 y=0.270 6 0.005
Color temperature : 10500 8K
3. Light Area Adjustment
1) Press S7 button.
2) On the center of light area, attach the sensor of a white balance meter.
3) To be Y=125, turn the Light Beam control volume on the White & Black pattern generator.
4) To adjust the white balance of light area, select Drive R, G, B with CHANNEL Up or Down buttons, and adjust individual
vales with VOLUME Up or Down buttons.
Light Area Check
Dark Area Check
3. Light Area Adjustment
1) Press S7 button.
2) On the center of light area, attach the sensor of a white balance meter.
3) To be Y=125, turn the Light Beam control volume on the White & Black pattern generator.
4) To adjust the white balance of light area, select Drive R, G, B with CHANNEL Up or Down buttons, and adjust individual
vales with VOLUME Up or Down buttons.
General Adjustment

Blanking Width
1.Tune on NTS Retma pattern.
2. Press Screen mode on the remote control, and then slelct Normal mode.
3. To be symmetrical the screen, adjust Blanking Width with rotating the variable volume RU19 on the Blanking Board.
Y Level Adjustment (to DTV Decoder module)
1. Tune on SMPTE Color Bar signal.
2. Connect a scope probe to pin 9 of PW06V.
3. Adjust RV900 such as the following figure so that the amplitude of Y level may be 0.7Vp-p.

Connection Diagram
Circuit Diagram

Signal Flow Diagram
R G B VM
YPbPr
MAIN L/R
AUDIO
NTSC A/V MAIN L/R MAIN L/R C SL SR WOOFER
SPEAKER
HD SIF C.V Y C
L/R MAIN L/R
CENTER
SL,SR
WOOFER
MAIN ASS'Y
ATSC ASS'YVIDEO ASS`Y
CRT ASS'Y
VIDEO

WARNING : BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION
PRECAUTION”,”SAFETY PRECAUTION” AND “PRODUCT SAFETY
NOTICE” ON THIS MANUAL.
LOC PARTCODE PART NAME DESCRIPTION REMARKS
ZZ110 PEACPWD002 ACCESSORY AS DSC-3260N
30 49586110W1 MANUAL INSTRUCTION DSC-3260N
40 4958900001 MANUAL QUICK GUIDE DSC-3260N
ZZ120 PEBCSHD002 COVERBACKAS DSC-3260N
M211 4952100100 COVERBACK FR HIPS PAINT
M540 4855420200 SPEC PLATE PE FILM
M591 4951900100 DECOSPKRAS FR HIPS PAINT
M781 4857817630 CLOTHBLACK FELT400X20X0.7
M782 4857817611 CLOTHBLACK FELT200X20X0.7
ZZ130 PEPKCPD002 PACKINGAS DSC-3260N
M641 6520010100 STAPLEPIN 18M/M JD O 1
M681 4851712701 BAND AS 3.3M
M801 4958000100 BOXCARTON DW-3
M811 4958100100 PAD EPS
M821 4858218700 BAGP.E FOAM+LDPET0.5X1880X1380
ZZ131 48519A4410 CRT GROUND NET 3301H-1015-2P
ZZ132 58G0000114 COILDEGAUSSING DC-3200
ZZ140 PECACAD002 CABINET AS DSC-3260N
V901 49A96332C1 W76 19F350X94
M201A 4856015820 SCREWCRTFIX SWRM+SK5 L=35
M201B 4856215401 WASHERRUBBER CRT1.0
M201C 7128301212 SCREWTAPPING T2S WAS 3X12 MFZN BK
M201D 4857817610 CLOTHBLACK FELT300X20X0.7
M201E 4857817610 CLOTHBLACK FELT300X20X0.7
M211A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M211B 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M211C 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M211D 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M211E 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M230 4952300200 PANELAV FRHIPS BK
M353 97P4602700 CLAMP CORD POLYETHYLENEBLK
M353A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
M561 4955600100 MARKBRAND ALT1.0 DIA-CUTTING
M682 4856816300 CLAMP WIRE NYLON 6 (V0)
SP01A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
SP02A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
ZZ200 PEFMSJD002 MASKFRONTAS DSC-3260N
M201 4952000100 MASKFRONT FR HIPS PAINT
M251 4952500100 GRILL SPKR R PS SHEET T0.4
M252 4952500200 GRILL SPKR L PS SHEET T0.4
S601 4958300310 SPEAKERASL 10W 8 OHM K128/101999B
S601A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
S602 4958300110 SPEAKERUNIT 5W 8OHM H114/101999B
S602A 7128301212 SCREWTAPPING T2S WAS 3X12 MFZN BK
S603 4958300210 SPEAKERASR 10W 8 OHM K128/101999B
S603A 7122401612 SCREWTAPPTITE T2STRS 4X16 MFZN BK
S604 4958300410 SPEAKERTWEETER 5W 8 OHM K128/101999B
S604A 7122401412 SCREWTAPPING T2STRS 4X14 MFZN BK
S605 4958300410 SPEAKERTWEETER 5W 8 OHM K128/101999B
S605A 7122401412 SCREWTAPPING T2STRS 4X14 MFZN BK
ZZ290 PEMPMSD002 PCBMAINMANUAL AS DSC-3260N
C410 CEXF2E101V CELECTRO 250V RSS 100MF 16X31.5
C419 CMXL2E105J CMYLAR 250VMEU 1MF J
C424 CMXL2E105J CMYLAR 250VMEU 1MF J
C433 CMXL2E105J CMYLAR 250VMEU 1MF J
C445 CEYF1H222C CELECTRO RUS50V 2200MF 18*35.5
C468 CMXM2A334J CMYLAR 100V0.33MF J BULK
C476 CMYH3D332J CMYLAR 2KVBUP 3300PF J
C477 CMYH3D332J CMYLAR 2KVBUP 3300PF J
C479 CMYE2G364J CMYLAR 400V PU 0.36MF J
D408 DRU3AM---- DIODE RU3AM(HIGHSPEED)
D417 DFMLG12S-- DIODE FML-G12S
D420 DRU3AM---- DIODE RU3AM(HIGHSPEED)
D423 DFMRG5H--- DIODEDAMPER FMRG5H
D423A 4857027904 HEATSINK ALEX (AN0DIZE)
D423B 7174301011 SCREWTAPPTITE TT2RND 3X10 MFZN
D424 DRF1------ DIODE RF-1
D425 DRF1------ DIODE RF-1
D436 1NJM431L-- IC REGULATOR NJM431L
I401 1NE555---- IC TIMER PD NE555
I402 1UPC1884BC IC H/V OSC UPC1884BCT
I403 1KF353---- IC OPAMP KF353
I404 1KF353---- IC OPAMP KF353
I405 1LM358---- IC KA358
I407 1NE555---- IC TIMER PD NE555
I408 1MC7812--- IC REGULATOR MC7812 12V 1A (KA7812)
I409 1MC7812--- IC REGULATOR MC7812 12V 1A (KA7812)
I409A 4857031201 HEATSINK AL6063S
I409B 7174300811 SCREWTAPPTITE TT2 RND 3X8 MFZN
I410 1KA7809--- IC REGULATOR KA7809
I410A 4857027802 HEATSINK ALEX
I410B 7174300811 SCREWTAPPTITE TT2 RND 3X8 MFZN
I411 1KF353---- IC OPAMP KF353
LOC PARTCODE PARTNAME DESCRIPTION REMARKS
“ “ : The shaded areas in the schematic diagram and the parts list have especial characteristics important for safety and should be replaced only with types
identical to those in the original circuit or specified in the part list. Before replacing any of those components, read carefully the PRODUCT SAFETY
NOTICE on this manual. Do not degrade the safety of reciever through improper servicing.
“ “ : Part recommended for stock.
!
CAUTION
Service Part List (DSC-30W60N)
!
!
!
!
R
R
!
R
R
R
I412 1TDA8172-- ICV-OUT TDA8172
I412A 4857028207 HEATSINK ALEX BK
I412B 7174300811 SCREWTAPPTITE TT2 RND 3X8 MFZN
I413 1KA7809--- ICREGULATOR KA7809
I414 1KA7805--- ICREGULATOR KA7805
I601 1CXA1315P- IC CONVERTER CXA1315
I602 1LA7220--- ICSWITCH LA7220
I603 1LA7220--- ICSWITCH LA7220
I605 1UPC1406HA IC UPC1406HA
I606 1UPC1406HA IC UPC1406HA
I607 1TA8256H-- ICAMP TA8256H
I607A 4857027534 HEATSINK ALEXBK
I607B 7174300811 SCREWTAPPTITE TT2 RND 3X8 MFZN
I608 1TA8256H-- ICAMP TA8256H
I608A 4857027534 HEATSINK ALEXBK
I608B 7174300811 SCREWTAPPTITE TT2 RND 3X8 MFZN
I609 1TDA7317-- ICAUDIO TDA7317
JP02 4959100250 JACK PIN BOARD DPAM-9913
JP03 4959100550 JACK PIN BOARD DPAE-9867
L401 58CD000002 COILCHOKETRANS DTL-04M
L403 58HD000001 COILH-LINEARITY DCL-20U
L406 58CD000001 COILCHOKE DCC-01M
M351 4953500100 HOLDERCORD FRHIPS BK
M351A 7122401412 SCREWTAPPING T2S TRS 4X14 MFZN BK
M381 4853812800 FRAME MAIN PCB FRHIPSBK
M381A 7128301212 SCREWTAPPING T2S WAS 3X12 MFZN BK
M381B 7128301212 SCREWTAPPING T2S WAS 3X12 MFZN BK
M721A 7122401412 SCREWTAPPING T2S TRS 4X14 MFZN BK
PA09S 4950711002 CONNECTOR SMH250-11+YT250+USW=600
PA12D 4950708003 CONNECTOR SMH250-08+YT250+USW=300
PA13D 4950706006 CONNECTOR SMH250-06+YT250+USW=300
PA15P 4950713002 CONNECTOR SMH250-13+YT250+ULW=550
PW01V 4859280820 CONNWAFER TAC-L13X-A1
PW02V 4859280820 CONNWAFER TAC-L13X-A1
PW03V 4859280820 CONNWAFER TAC-L13X-A1
PW04V 4859280820 CONNWAFER TAC-L13X-A1
PW14P 4859235620 CONNWAFER YW025-13
PW16P 4859235820 CONNWAFER YW025-15
P405 4959203120 CONNWAFER TBL-P05P-C1
Q407 T1RFS634-- FET IRFS634
Q407A 4957000700 HEATSINK ALEX
Q407B 7174301011 SCREWTAPPTITE TT2 RND 3X10 MFZN
Q418 T1RFS830-- FET IRFS830
Q423 T1RFS830-- FET IRFS830
Q423A 4857027700 HEATSINK ALEX BK
Q423B 7174301011 SCREWTAPPTITE TT2 RND 3X10 MFZN
Q425 T2SC5422-- TR 2SC5422
LOC PART CODE PARTNAME DESCRIPTION REMARKS
Q425A 4857027534 HEATSINK ALEXBK
Q425B 7174301011 SCREWTAPPTITE TT2 RND 3X10 MFZN
Q425C 4857619500 INSU PLATE SILICON RUBBER T0.3
R476 RW02Z478J- RWIREWOUND 2W 0.47 J
R481 RX05V229J- RCEMENT 5W 2.2 OHM J VERTICAL
R506 RW02Z828J- RWIREWOUND 2W 0.82 OHM
SW401 5S40403035 SWLEVER JRS-1301
T401 5DU0000024 TRANSPULSE DTP-01A
T402 58CD000002 COILCHOKETRANS DTL-04M
T403 5DD0000021 TRANSDRIVE DTD-01A
T404 5DU0000024 TRANSPULSE DTP-01A
T405 5DY0000023 TRANSDUMMY DTL-02M
U101 4959700350 TUNER TAUG-H005P
X401 4850L02310 RESONATORCERA CSB503F30
ZZ200 PEMPJ2D002 PCB CHIP MOUNT B AS DSC-3260N
CC401 HCQK820JCA CCHIPCERA 50V CH 82PF J 2012
CC402 HCQK681JCA CCHIPCERA 50V CH 680PF J 2012
CC403 HCBK472KCA CCHIPCERA 50V X7R 4700PF K 2012
CC404 HCTAH109MB CCHIPTANTAL 25V 1MF M 3216
CC405 HCQK221JCA CCHIPCERA 50V CH 220PF J 2012
CC406 HCBK102KCA CCHIPCERA 50V X7R 1000PF K 2012
CC407 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC408 HCBK682KCA CCHIPCERA 50V X7R 6800PF K 2012
CC409 HCQK391JCA CCHIPCERA 50V CH 390PF J 2012
CC410 HCQK390JCA CCHIPCERA 50V CH 39PF J 2012
CC411 HCQK221JCA CCHIPCERA 50V CH 220PF J 2012
CC412 HCQK821JCA CCHIPCERA 50V CH 820PF J 2012
CC413 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC414 HCQK391JCA CCHIPCERA 50V CH 390PF J 2012
CC415 HCBK471KCA CCHIPCERA 50V X7R 470PF K 2012
CC416 HCQK101JCA CCHIPCERA 50V CH 100PF J 2012
CC419 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC420 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC421 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC422 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC423 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC424 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC425 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC426 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC427 HCTBF100MB CCHIPTANTAL 16V 10MF M 3528 TS
CC428 HCBH104KCA CCHIPCERA 25V X7R 0.1MF K 2012
CC606 HCTAJ478MB CCHIPTANTAL 35V 0.47MF M 3216TS
CC607 HCBK102KCA CCHIPCERA 50V X7R 1000PF K 2012
CC608 HCBK102KCA CCHIPCERA 50V X7R 1000PF K 2012
CC609 HCTAH109MB CCHIPTANTAL 25V 1MF M 3216
CC610 HCBK102KCA CCHIPCERA 50V X7R 1000PF K 2012
CC611 HCBK102KCA CCHIPCERA 50V X7R 1000PF K 2012
LOC PARTCODE PARTNAME DESCRIPTION REMARKS
!
!
!
!
R
!
R
!
R
!
R
!
R
R
CC612 HCBK102KCA C CHIP CERA 50VX7R 1000PF K2012
CC613 HCBK102KCA C CHIP CERA 50VX7R 1000PF K2012
CC614 HCBK102KCA C CHIP CERA 50VX7R 1000PF K2012
CC615 HCBK102KCA C CHIP CERA 50VX7R 1000PF K2012
CC617 HCTAH109MB C CHIP TANTAL 25V1MFM 3216
CC618 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC619 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC620 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC621 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC622 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC623 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC624 HCTAH109MB C CHIP TANTAL 25V1MFM 3216
CC625 HCTBH479MB C CHIP TANTAL 25V4.7MFM 3528
CC626 HCBH103KCA C CHIP CERA 25VX7R 0.01MF K2012
CC630 HCBH104KCA C CHIP CERA 25VX7R 0.1MF K2012
CC631 HCBH104KCA C CHIP CERA 25VX7R 0.1MF K2012
