Daewoo KOC-9Q1T User manual

MICROWAVE
CONVECTION/GRILL OVEN
MODEL NO.
KOC-9Q1T / KOC-9Q1TSL

KOC-9Q1T / KOC-9Q1TSL_2
KOC-9Q1T / KOC-9Q1TSL_3
TABLE OF CONTENTS
About your microwave
Introduction ............................................................................................................................ 03
Before first use........................................................................................................................04
Accessories.............................................................................................................................. 05
Control panel .......................................................................................................................... 06
Before operation
Setting the clock .....................................................................................................................07
Child lock and power save mode...........................................................................................08
Operation
Microwave cooking ................................................................................................................10
Grill cooking ............................................................................................................................11
Convection cooking(with pre-heat).......................................................................................12
Convection cooking(traditional cooking) ..............................................................................13
Combination cooking .............................................................................................................14
Weight defrost mode .............................................................................................................15
Time defrost mode ...............................................................................................................16
Auto cook................................................................................................................................ 17
Speedy cook............................................................................................................................17
Dish warmer (for premium option model only) ..................................................................18
Warm ...................................................................................................................................... 19
Steam cleaning .......................................................................................................................19
Reminder mode(function to remind cooking complete) ....................................................19
Cooking techniques ...............................................................................................................20
Defrosting guide .....................................................................................................................21
Cooking & reheating chart ....................................................................................................22
Vegetable chart ......................................................................................................................23
Safety........................................................................................................................................ 24
Cleaning.................................................................................................................................... 30
Trouble Shooting ...................................................................................................................... 31
Question and answer ............................................................................................................... 32
Technical data........................................................................................................................... 33
Environmental information...................................................................................................... 34
Recipe ...................................................................................................................................... 35

KOC-9Q1T / KOC-9Q1TSL_2
KOC-9Q1T / KOC-9Q1TSL_3
You have chosen a Daewoo Combi- Microwave Oven.
Daewoo offers a variety of quality products that would make your life more
comfortable.
This Combi-Microwave Oven combines the properties of a microwave with those
of a traditional oven. The wide range of programmig options makes it possible to
choose your preparation method precisely.
Operation is easy even so.
The display provides information and helps you with setting.
Please read the user manual very carefully before starting to use the appliance.
Just for your information, the manual also serves as cooking recipy.
Enjoy cooking!
»INTRODUCTION
ABOUT YOUR MICROWAVE

KOC-9Q1T / KOC-9Q1TSL_4
KOC-9Q1T / KOC-9Q1TSL_5
• Put the microwave on a solid, flat surface.
• Ensure that there is adequate ventilation around the microwave. Keep 30 cm of space free at the top. At the back and sides,
keep at least 7.5 cm free.
• Do not cover the ventilation openings.
• The adjustable feet may not be removed.
• Do not place the microwave in the vicinity of heat sources.
• Broadcasting and transmitting equipment such as radios and TVs can affect the working of the microwave.
• Remove the accessories from the microwave and clean them with a mild cleaning agent. Then put the frame back on the shaft.
»Before first use
7.5 cm
7.5 cm
30 cm
7.5 cm
Please note
: Always use the microwave with the frame on the shaft together with a turntable!
Put a heat-resistant dish with 200 ml of water in the microwave. Turn the function dial and select ‘oven’. Set the time to 5 minutes and press the
Start button. This will remove any protective grease used during manufacture. When the 5 minutes are nished, allow the microwave to cool
down, and clean the microwave with warm water. The microwave is now ready for use.
ABOUT YOUR MICROWAVE
When you heat the microwave to a high temperature for the first time, you will notice a ‘new-oven smell’.
Don’t worry, this is normal. If desired, switch on the cooker hood or open a window.
* The minimum height of free space necessary above the top surface
of the oven is minimum 170mm.
NOTE
Cabinet materials must be suitable to withstand temperatures up to 90˚C.
NOTE

KOC-9Q1T / KOC-9Q1TSL_4
KOC-9Q1T / KOC-9Q1TSL_5
▶How to use the accessories of cooking
Glass Turntable Metal rack Dish-Warm rack
(Premium option model only)
• All Cooking modes.
• Grill cooking
• Convection cooking
• Combination cooking
• Auto cooking menu 1~4. • Dish warming
»Accessories
①Display
②Control panel
③ Door handle
①
③
②
1. Glass Turntable - Centre the tray on the roller guide when using the
microwave features. Place food or microwave-safe cookware directly on the
glass turntable.
NOTE : The Glass Turntable can be found attached to the left polystyrene packing
material in the carton.
2. Roller Guide - The roller guide must be in place when using the oven.
IMPORTANT : The roller guide must be placed at the centre of the oven
cavity.
3. Metal Rack - Centre the rack on the glass tray when using the grill cooking,
convection cooking, and auto cooking menus.

KOC-9Q1T / KOC-9Q1TSL_6
KOC-9Q1T / KOC-9Q1TSL_7
↘ DISPLAY WINDOW
①Display : Cooking time, power level, program
indicators and present time are displayed.
MW ( ): When blinking, the oven is operating in
MICROWAVE COOK mode.
Grill ( ): When blinking, the oven is operating in
GRILL mode.
Combi ( ): When blinking, the oven is operating
in COMBI mode.
Convection ( ): When blinking, the oven is
operating in CONVECTION mode.
Defrost ( ): When blinking, the oven is operating in
DEFROST mode.
Auto-cook ( ): When blinking, the oven is
operating in AUTO COOK mode.
Warm ( ): When blinking, the oven is operating in
WARM mode.
Steam Cleaning ( ): When blinking, the oven is
operating in STEAM CLEANING mode.
gram ( ): When blinking, the oven is operating in
weight input mode.
↘ BUTTONS
②
Auto cook : Used to cook or reheat.
③MW : Used to set power level of the microwave.
④Defrost : Used to defrost foods.
⑤Grill : Used to select grill mode.
⑥Combi : Used to select combi mode.
⑦Convection : Used to select convection mode and
selected temp.
⑧Clock : Used to set clock.
⑨STEAM CLEANING : Used to clean the inside of the
oven
⑩Warm : Used to keep the food warm.
⑪Time set pad : Used to set time, weight and
quantity.
⑫START/SPEEDY COOK : Used to start a program or a
speedy start(each press adds 30 seconds of
microwave cooking time).
⑬STOP/CLEAR : Used to stop the oven operation or to
delete the cooking data.
»Control panel

KOC-9Q1T / KOC-9Q1TSL_6
KOC-9Q1T / KOC-9Q1TSL_7
You can check the current time while cooking is in progress by pressing the
Clock button.
BEFORE OPERATION
When your oven is plugged in, the display will show “ :0” and a tone will sound. If the AC power goes off and comes back on, the
display will show “:0”.
Your oven has a multiple(12hr/24hr) clock system. To set the clock, follow the procedure below.
Example : To set 5:30 AM in a 24hr clock system.
1. Press Clock button once.
The display will show “ 12H ”. This is a 12 hour clock system.
2. Press Clock button once more, the display shows “24H”.
This is a 24hour clock system. If you want 12hour clock system, omit this step.
3. Turn the dial knob to set the hour number “5:”.
The hour digit starts blinking, the colon will light.
4. Press Clock button. “5:00” shows in display.
The minute digit starts blinking, the colon and hour number will light.
5. Turn the dial knob until “5:30” shows in the display window.
6. Press Clock button. The colon starts blinking.
If you selected the 12hour clock system, this digital clock allows you to set the
time from 1:00 to 12:59.
If you selected the 24hour clock system, this digital clock allows you to set the
time from 0:00 to 23:59.
»SETTING THE CLOCK
NOTE

KOC-9Q1T / KOC-9Q1TSL_8
KOC-9Q1T / KOC-9Q1TSL_9
Child lock : The Child Lock function helps to prevent accidents from children operating the oven without being monitored by the
parents.
Power save mode : This function is used for saving energy.
»CHILD LOCK AND POWER SAVE MODE
To set child lock
1. Press the STOP/CLEAR button.
“: 0” or clock appears in the display.
2. Press and hold the STOP/CLEAR button for 3 seconds.
A beep sounds and the display shows “ Loc ” for 3 seconds.
Now the oven cannot be operated.
3. To cancel child lock simply repeat procedure 2.
The oven will beep.
The oven is again available for normal use.
To set power save mode
1. Press the STOP/CLEAR button.
“: 0” or clock appears in the display.
2. Press and then hold the Clock button for 3 seconds.
The display will turn off and a beep sounds.
To operate the oven in power save mode, press any key or turn the knob.
Then “:0” or clock will be shown and the operation of all function keys will be
the same as in the normal mode.
But if there is no operation within 10 seconds in clear mode or while
manipulating the key, all the contents of display will disappear.
3. To cancel the power save mode, simply repeat the setting procedure.
The power save mode will be canceled and a beep sounds.
The oven is again available for normal use.

KOC-9Q1T / KOC-9Q1TSL_8
KOC-9Q1T / KOC-9Q1TSL_9
Please read this OPERATION section for the proper safety information and the operating instructions before using the oven.
Prior to setting the controls, place one cup of water in the oven, in a heat-proof glass measuring cup, for testing purposes.
The oven could be damaged if you operate the oven in microwave mode without anything in the cavity.
TIPS
When the cooking time has elapsed the oven beeps three times and "End" appears on the display. The glass turntable stops and
the oven-light turns off. The oven will continue to beep every one-minute until either the STOP/CLEAR button is pressed or the
door is opened. Opening the door while cook is in progress will cause the oven to stop and any displayed countdown will pause.
If the START/SPEEDY COOK button is pressed, the countdown will resume. If the STOP/CLEAR button is pressed, the cook will
cancel. The oven can display the set cooking time in 10 second steps (up to 5 minutes cooking time), in 30 second steps (up to 10
minutes cooking time), and in 1 minute steps (up to 60 minutes cooking time).
When the door is opened after cooking, the cooling fan may start to operate for 5 minutes to cool down the inside of oven.
(Display shows "cool" and " :0 or clock")
Also note that when the Cooling mode operates, lamp, tray, and fan runs at the same time and “cool” shows on the display.
NOTE
OPERATION

KOC-9Q1T / KOC-9Q1TSL_10
KOC-9Q1T / KOC-9Q1TSL_11
Power level percentage Output
P-HI 100% 900W
P-90 90% 810W
P-80 80% 720W
P-70 70% 630W
P-60 60% 540W
Power level percentage Output
P-50 50% 450W
P-40 40% 360W
P-30 30% 270W
P-20 20% 180W
P-10 10% 90W
P-00 0% 0W
▶Power level table
1. Touch the MW pad once. MW indicator ( ) lights.
“P-HI”(POWER HIGH) shows in display.
2. Select the appropriate power level by pressing the MW pad again until the
corresponding percentage is displayed. Refer to the power level table below
for further details.
3. Touch the time set pad to set the cooking time.
For a cooking time of 5 minutes 30 seconds, Touch the time set pads to set
5:30. ( up to 59 minutes 90 seconds can be set)
“5:30” shows in display.
4. Touch the START/SPEEDY COOK pad.
The oven light comes on and the turntable starts rotating.
Cooking starts and the time in the display will count down.
»MICROWAVE COOKING
This microwave cooking method allows you to cook food for a desired time. In addition to the maximum power level(100%),
you can select different microwave power from 9 other levels, 10% to 90% for the foods that require slower cooking.
If you have used the appliance for grilling, convection or combination cooking, let the oven cool down before using again.
Never switch the microwave oven on when it is empty.
The oven will automatically work on 100% microwave power if a cooking
time is entered without the power level previously being selected.
You can check the power level while cooking is in progress by pressing the
MW button.
NOTE
OPERATION
