Daewoo KOR-7LBKC User manual

MICROWAVE OVEN
USER MANUAL
MODEL NO. KOR-7LBKC / 7LBKR / 7LBKB / 7LBKM / 7LBKW
Customer Helpline Number : 0118 925 2525
Spare Parts : 0844 557 0270 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk
HOW TO TURN ON THE OVEN AT FIRST





DESUK_KOR-6LBR5S(영).indd 2 15. 5. 22. 오후 3:17

MICROWAVE OVEN
USER MANUAL
Customer Helpline Number : 0118 925 2525
Spare Parts : 0844 557 0270 or www.4daewoo.co.uk / DAEWOO ELECTRONICS Web Site www.daewooelectronics.co.uk
How to unbox / install / maintain microwave -
http://www.youtube.com/watch?v=UdbpMO7VG0w
HOW TO TURN ON THE OVEN AT FIRST
DESUK_KOR-6LBR5S(영).indd 3 15. 5. 22. 오후 3:17

KOR-6LBR5S_2
KOR-6LBR5S_3
About your microwave
Introduction ............................................................................................................................ 03
Before first use........................................................................................................................04
Features diagram.................................................................................................................... 05
Control panel .......................................................................................................................... 06
Operation procedure .............................................................................................................07
Zero standby function ........................................................................................................... 08
Controls
Turning ac power on & off the oven .....................................................................................09
Weight defrosting ...................................................................................................................10
Time defrosting.......................................................................................................................10
Cooking in one stage .............................................................................................................11
Timer ...................................................................................................................................... 11
Easy cooking............................................................................................................................12
Auto cook ............................................................................................................................... 12
Child safety lock ...................................................................................................................... 13
To set power save mode ........................................................................................................13
To stop the oven while the oven is operating ......................................................................13
Operation
Care of your microwave oven ............................................................................................... 14
Before you call for service .....................................................................................................14
Cooking instructions ..............................................................................................................16
Microwaving principles ......................................................................................................... 17
How microwaves cook food .................................................................................................. 17
Conversion charts .................................................................................................................. 17
Cooking techniques ............................................................................................................... 18
Defrosting guide .....................................................................................................................19
Cooking & reheating chart ....................................................................................................21
Vegetable chart ......................................................................................................................22
Safety........................................................................................................................................ 23
Cleaning ................................................................................................................................... 27
Trouble shooting ..................................................................................................................... 28
Question and answer ............................................................................................................... 29
Technical data........................................................................................................................... 30
Environmental information...................................................................................................... 31
Table of contents
DESUK_KOR-6LBR5S(영).indd 2 15. 5. 22. 오후 3:17

KOR-6LBR5S_2
KOR-6LBR5S_3
About Your Microwave
You have chosen a Daewoo Microwave Oven.
Daewoo offers a variety of quality products that would make your life more
comfortable.
This microwave oven combines the properties of a microwave with those of a
traditional oven.
Please read the user manual very carefully before starting to use the appliance.
Just for your information, the manual also serves as cooking recipe.
Enjoy cooking!
»INTRODUCTION
DESUK_KOR-6LBR5S(영).indd 3 15. 5. 22. 오후 3:17

KOR-6LBR5S_4
KOR-6LBR5S_5
About Your Microwave
• Put the microwave on a solid, flat surface.
• Ensure that there is adequate ventilation around the microwave. Keep 30 cm of space free at the top. At the back and sides,
keep at least 7.5 cm free.
• Do not cover the ventilation openings. Do not forget to remove protective film, if applied.
• The adjustable feet may not be removed.
• Do not place the microwave in the vicinity of heat sources.
• Broadcasting and transmitting equipment such as radios and TVs can affect the working of the microwave.
• Remove the accessories from the microwave and clean them with a mild cleaning agent.
»Before first use
7.5 cm
7.5 cm
30 cm
7.5 cm
The minimum height of free space necessary above the top surface
of the oven is minimum 170mm.
NOTE
DESUK_KOR-6LBR5S(영).indd 4 15. 5. 22. 오후 3:17

KOR-6LBR5S_4
KOR-6LBR5S_5
»Features diagram
About Your Microwave
1. Door latch-Latches on when door is closed. If the door is opened while the oven is operating, the magnetron will
automatically shut off.
2. Door seal-The door seal prevents microwaves escaping from the oven cavity.
3. Oven cavity
4. Wave guide cover-Protects the microwave outlet from splashes of cooking foods.
5. Safety interlock system-Prevents the oven from operating while the door is opened.
The oven will only operate with the door fully closed. When the door is open, the oven turns off and will only start again
after the door is closed.
6. Control panel
7. Glass cooking tray-Made of special heat resistant glass. The tray can be easily removed for cleaning. Make sure it is
correctly positioned (indentation) before operating. Place food in a suitable container (dish) on the tray.
8. Roller guide-Supports the glass cooking tray and allows food to rotate for even cooking.
9. Door screen-Allows viewing of food.
The screen is transparent to light, but prevents microwaves escaping.
DESUK_KOR-6LBR5S(영).indd 5 15. 5. 22. 오후 3:17

KOR-6LBR5S_6
KOR-6LBR5S_7
»Control panel
About Your Microwave
1. Display - Cooking time, power level and indicators are displayed.
2. Defrost- Used to defrost foods by weight or time.
3. Power- Used to set power level.
4. Timer - Used to set the timer.
5. Auto cook- Used to cook using a program or to reheat.
6. Dial knob- Used to set the time and weight.
7. Stop/Clear- Used to stop the oven operation or to erase all entries.
8. Start/Easy cook-Used to start the oven operation and also increase the reheat time by 30 seconds.
9. Eco button-Used to turn the AC power on the oven.
DESUK_KOR-6LBR5S(영).indd 6 15. 5. 22. 오후 3:17

KOR-6LBR5S_6
KOR-6LBR5S_7
»Operation procedure
This section includes useful information about oven operation.
1. Plug power supply cord into a 230V 50Hz power outlet.
2. After placing the food in a suitable container, open the oven door and put it on the glass tray.
The glass tray and roller guide must always be in place during cooking.
3. Shut the door. Make sure that it is firmly closed.
4. Set required programme and time, then press Start.
5. Once cooking is complete take care removing container as it will be hot.
WATTAGE OUTPUT CHART
•The power-level is set by pressing the Power button. The chart shows the display, the power level and the percentage of power.
Press Power button Power level (Display) Approximate Percentage of Power
once P-HI 100%
twice P-80 80%
3 times P-60 60%
4 times P-40 40%
5 times P-20 20%
The oven light turns on while the oven is working.
The oven door can be opened at any time during
operation. The oven will automatically shut off.
Each time a button is pressed, a BEEP will sound to
acknowledge the press.
The oven automatically cooks on full power unless set to a
lower power level.
The display will show nothing when the oven is plugged in,
press and hold the Eco pad until display is turned on and
beep sounds.
When the Stop/Clear button is pressed during the oven
operation, the oven stops cooking and all information
retained. To erase all information press the Stop/Clear
button once more. If the oven door is opened during the
oven operation, all information is retained.
If the Start button is pressed and the oven does not operate,
check the area between the door and door seal for
obstructions and make sure the door is closed securely. The
oven will not start cooking until the door is completely
closed or the program has been reset.
1
2
3
4
5
6
7
Make sure the oven is properly installed and plugged
into the electrical outlet.
DESUK_KOR-6LBR5S(영).indd 7 15. 5. 22. 오후 3:17

KOR-6LBR5S_8
KOR-6LBR5S_9
• If you insert plug into a socket, the oven is STANDBY POWER “0” mode. So the display shows nothing. To cancel STANDBY
POWER “0” mode, press and hold Eco button until display is turned on and beep sounds.
(Because the oven is turned power off automatically after 10 minutes without using.
The display shows nothing.)
• Standby power is the electric power consumed by electronic appliances without operating on inserting the plug into a socket.
• STANDBY POWER “0” is a function reducing standby power consumption.
• This product can save energy in a standby mode, by setting the STANDBY POWER "O" mode.
To turn on the oven, press and hold Eco button until display is turned on and beep sounds after plugging in.
The oven goes to STANDBY POWER “0” mode automatically after 10minutes without using or press and hold STOP/CLEAR button until
display is turned off.
Press and hold Eco button again until display is turned on and beep sounds, you can use the oven.
To cancel the STANDBY POWER "0" mode.
(The oven is turned power on.)
»Zero standby function
DESUK_KOR-6LBR5S(영).indd 8 15. 5. 22. 오후 3:17

KOR-6LBR5S_8
KOR-6LBR5S_9
ECO
STOP/CLEAR
CONTROLS
When the oven is first plugged in , the display will show nothing.
»Turning ac power on & off the oven
1. Press and hold the Eco button until
display is turned on and beep sounds.
The oven is turned AC power on.
2. Touch and hold the STOP/CLEAR button
until display is turned off. The oven is
turned AC power off.
If the AC power ever goes off, the display is disappeared until the power comes back on to press and hold the Eco button
until display is turned on and beep sounds.
The oven is turned power off automatically after 10 minutes without using.
NOTE
