Daewoo SDA1061 User manual

1
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to property
or persons.
The manufacturer or vendor cannot be held liable for damages or
injury incurred through improper or incorrect use.
Read and familiarise yourself with all operating instructions
before using this Rice Cooker & Steamer.
Before plugging your unit into the mains, visually check that the
unit is intact and has not suffered any transit damage.
Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
Close supervision is required when using this appliance near
children.
Never leave this appliance within reach of children.
This appliance can be used by children from 8 years and above
if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards
involved.
Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children less
than 8 years.
Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
*Please refer to the warranty section for terms of your extended guarantee.
*

3
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance.
Always use this appliance on a solid, level, non-flammable
surface.
DO NOT use this appliance outdoors.
It is imperative to unplug the power cord after the appliance
has been used, before it is cleaned and whilst being repaired.
If the power cable is damaged, it should only be replaced by
suitable qualified personnel in order to avoid a hazard.
Repairs to electrical appliances should only be performed by
qualified personnel. Improper repairs may place user at serious
risk.
DO NOT operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
DO NOT allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
DO NOT run the mains cable under carpets, rugs, etc.
Always allow the unit to cool before storage or cleaning.
Never place the appliance near to flammable material or high
pressure containers.
This appliance is intended for household use only and should
not be used for industrial purposes.
DO NOT use accessories with this appliance other than those
recommended by the supplier.
DO NOT immerse the appliance or its cord in water or any
other liquids.
DO NOT use this appliance for anything other than its intended
use.
DO NOT push objects into any openings as damage to the

4
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
appliance and/or electric shock may occur.
Ensure appliance is situated in an open area, do not allow it to
come in contact with or place beneath cupboards, curtains,
wall coverings, clothing or other flammable materials.
Unplug after each use. Grasp the plug, not the cord.
DO NOT cover this appliance.
Never place this appliance on an electric, gas, or any other type
of hob.
DO NOT use this appliance with an extension cable.
DO NOT touch hot surfaces. Use the handles and/or knobs
provided.
DO NOT use this appliance with an external timer or separate
remote-control system or any other device that switches the
cooker on automatically.
Disconnect the appliance from the mains after use.
Always disconnect the plug from the mains before cleaning.
Keep away from splashes of water or damp conditions.
DO NOT touch hot surfaces. Accessible surfaces are liable to
get hot during use. Always use the handles provided.
Oven gloves should be worn when using this appliance.
Hot steam may be released when opening and closing the
appliance during use –Risk of scalding!
Avoid moving the appliance whilst it is still hot or contains hot
food or liquids. Turn the appliance off and disconnect from the
mains and let it cool sufficiently before moving it.
Always carry the appliance with both hands. Always use oven
gloves –Burn hazard!
Position the steam vent so that it sends steam away
from the user.
THIS APPLIANCE MUST BE EARTHED

5
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to
applicable provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not
be disposed of with normal household waste and not sent
to landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol provides useful additional information on
the use of this product.
This symbol indicates that the supply uses an alternating
current mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.

6
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Description of Parts –Control Panel (10)
1. Handle
2. Steam Vent
3. Glass Lid
4. Steamer
5. Bowl
6. Rice Cooker Body
7. On/Off Switch
8. Control Panel
9. Measuring Cup
10.Spoon
1
2
3
4
5
6
8
7
4
9
10
11
12
13
11.Warm Light (Illuminates
when cooking has finished)
12.Cook Light (Illuminates
during cooking)
13.Cook Lever (Push the lever
down to cook –pops up
after cooking is
completed).

7
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the First Use of Your Rice Cooker
1.Remove all packing materials and discard responsibly.
2.Ensure all parts are present (if applicable) see Description of Parts above.
3.Wash the Glass Lid (3), Steamer (4) and the Bowl (5) in warm soapy water. Rinse
thoroughly and allow to dry before use.
4.DO NOT Immerse the Rice Cooker Body (6) in water or any other liquid or put it
into a dishwasher.
Whilst using the Rice Cooker for the first time, a little smoke or odour may be
emitted, this is normal and will soon pass.
Hints and Tips for Rice Cooking
Before cooking, place your rice in a sieve and wash thoroughly under a running
tap until the water runs clear and any excess starch is removed.
For best results, only use ordinary rice (Long Grain, Basmati, etc.) rather than
the ‘easy cook’ variety which tends to be stickier and may stick to the base of
the bowl.
The minimum amount of rice that can be cooked is four Measuring Cups (9) of
rice.
The maximum amount of rice and water should never exceed the 1.8L/10 Cup
mark on the Bowl (5) as arrowed below:
Always place the Glass Lid (3) onto the cooker during cooking, ensure that the
Steam Vent (2) is positioned away from the user.
Left: the arrow shows
the maximum amount
of rice and water that
can be cooked in the
Bowl (5).
Right: the arrow
shows the Steam Vent
(2), rotate the Glass
Lid (3) until it is away
from the user.

8
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Instructions for use –Rice Cooking Guide
White Rice (Basmati, Long Grain, American, Jasmine, Thai, Risotto, etc.)
Measuring Cups of Rice
Required
Weight of Rice
(approx.) *
Amount of Water
Required
Serves
4
600g
4 Cup mark
5-6
6
900g
6 Cup mark
8-10
8
1200g
8 Cup mark
13-14
10
1500g
10 Cup mark
16-18
Brown Rice and Brown Basmati Rice
#For Brown rice and brown Basmati rice, the amount of water used has to be
increased slightly as shown in the table below:
Measuring Cups of Rice
Required
Weight of Rice
(approx.) *
Amount of Water
Required #
Serves
4
500g
4.5 Cup mark
5-6
6
800g
6.5 Cup mark
8-10
8
(maximum quantity for
brown rice)
1000g
8.5 Cup mark
13-14
*The weight of rice varies between varieties of rice therefore the weights
shown are for guidance only.
The cooking time for the rice is determined automatically by the Rice Cooker
which depends on the quantity of water and rice in the Bowl (5).
Using Your Rice Cooker
1. First fill the Rice Cooker Bowl (5) from the tap with the desired amount of water
for the amount of rice to be cooked – see the ‘Amount of Water Required’
column in the table(s) above.
2. Fill the Bowl with water to the
corresponding ‘CUP mark’ number
according to the tables above.
The equivalent amount of water in Litres
is shown on the opposite scale.

9
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3.Next add the rice to the water according to the amount of water using the
Measuring Cup (9) – following the table above.
4.Place the Rice Cooker Body (6) on a solid, level, heat resistant surface, away from
the edge of the work surface and at a comfortable height for the user. Ensure that
the cooker is not used below cupboards or near curtains, etc.
5.Once the water and rice are added, carefully lower the Bowl (5) into the Rice
Cooker Body (6), turn the bowl gently to the left and right to ensure that it is
correctly settled in place.
6.Place the Glass Lid (3) onto the Bowl (5), ensure
that the Steam Vent (2) is positioned away from
the user:
7. Insert the mains plug (with dry hands) into
the mains socket and switch on (if
applicable).
8.Switch the unit on by pressing the On/Off Switch
(7) on the left-hand side of the unit to the ‘I’
position, the Warm Light (11) will illuminate as
below:

10
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
9. Push the Cook Lever (13) on the Control Panel (10)
down to begin cooking – the Cook Light (12) will
illuminate and the Rice Cooker will begin cooking
the rice.
WARNING! During cooking it is normal for steam to be emitted from the
Steam Vent (2).
WARNING! DO NOT cover the Steam Vent (2) in the lid in order to
prevent boiling over and/or scalding.
10.Once the cooking is complete, the Cook Lever (13) will pop up and the cooker
will switch to warm mode and the Warm Light (11) will illuminate.
11.The rice will be now ready to serve.
Keep the Glass Lid (3) in place after serving to keep the remaining rice in the
bowl warm and fresh also to reduce rice from drying out and/or discolouring:
It is recommended not to keep food warm for too long as it will result in the
rice becoming dry and the flavour may alter.
12.Switch the unit off by pressing the On/Off Switch
(7) on the left-hand side of the unit to the ‘O’
position.
13.After use, unplug the unit from the mains socket
as below:

11
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Instructions for use –Using the Food Steamer (4)
Your Rice cooker is also a Food Steamer.
1. To use your Steamer (4), add water to the
bowl following the steaming guide below
using the small cup supplied.
Place the Bowl (5) inside the cooker, turn
the bowl gently to the left and right to
ensure that it is correctly settled in place.
2. Place the Steamer (4) on the rim of the
Bowl (5).
3. Place the food to be steamed in the
Steamer (4) and fit the Glass Lid (3) onto
the steamer, ensuring that the Steam
Vent (2, arrowed) in the Glass Lid (3) is
facing away from the user:
4. Insert the mains plug into the socket.

12
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Switch the unit on by pressing the On/Off
Switch (7) on the left-hand side of the unit to
the ‘I’ position, the Warm Light (11) will
illuminate as below:
6. Push the Cook Lever (13) on the Control Panel (10)
down to begin cooking – the Cook Light (12) will
illuminate and the Rice Cooker will begin heating
the water.
Do not allow the bowl to run dry during steaming – add water if necessary. See
cooking guide table below:
Vegetables steaming guide*
Vegetable
Quantity of Water
Steaming time
Asparagus
¾ Cup
10 Minutes
Broccoli
½ Cup
5 Minutes
Cabbage
1 ¼ Cups
15 Minutes
Carrots
1 ¼ Cups
15 Minutes
Cauliflower
1 ¼ Cups
15 Minutes
Sweetcorn
1 ¼ Cups
15 Minutes
Aubergine
1 – 1 ½ Cups
20 Minutes
Green Beans
1 ¼ Cups
15 Minutes
Spinach
¾ Cup
10 Minutes
Squash
¾ Cup
10 Minutes
1. *The steaming guide above is for reference only; ensure the food is cooked
after steaming.

13
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2. Most vegetables absorb only a small amount of water, there is no need to
increase the amount of water with a larger portion of vegetables.
3. Always keep the lid on whilst the food is being steamed. Removing the lid
during cooking will cause a loss of steam and heat which will result in a longer
cooking time. If it is necessary to raise the lid during cooking, adding a little
water will restore the cooking time.
Fish steaming guide*
Fish
Quantity of Water
Steaming time
Sole 10-12oz (275-350g)
¾ Cup
7-8 Minutes
Lemon Sole 10-12oz (275-350g)
¾ Cup
7-8 Minutes
Plaice 10-12oz (275-350g)
¾ Cup
7-8 Minutes
White Fish (Cod, Haddock, Hake,
etc.) 6-7oz (175-200g)
½ Cup
8-10 Minutes
1.*The steaming guide above is for reference only; ensure the food is cooked
after steaming.
2.Take care not to overcook fish otherwise it will lose consistency.
3.Fish is cooked when it flakes easily and is no longer translucent.
4.Fish will continue to cook for a while after it has been removed from the heat.
5.Always keep the lid on whilst the food is being steamed. Removing the lid
during cooking will cause a loss of steam and heat which will result in a longer
cooking time. If it is necessary to raise the lid during cooking, adding a little
water will restore the cooking time.
6.Once the steaming is complete, the cooker will go into keep warm
mode indicating the food is cooked and will be kept warm.
7.After use, switch the unit off by pressing the
On/Off Switch (7) on the left-hand side of the
unit to the ‘O’ position.
8.Finally, unplug the unit from the mains socket
as below:

14
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cleaning and Maintenance
Always disconnect the Rice Cooker and Steamer from the mains before cleaning.
DO NOT clean any part of your Rice Cooker and Steamer in a dishwasher.
Remove bowl, lid and steamer (if used) and wash them in warm soapy water and
rinse thoroughly.
Clean outside of the Rice Cooker and Steamer with a clean damp cloth. Never
clean any part of the cooker with harsh or abrasive cleaners.
Keep the underside of bowl and surface of heater plate free of food, etc. to
prevent fouling of the base mechanism.
DO NOT submerge any part of cooker in water or any other liquids.
To clean the heating plate, remove any large debris by hand then wipe clean
with a damp cloth. Allow to dry completely before re-using.
If the lever is difficult to press down, do not force it, this will occur when the
bowl is not fully inserted into the cooker unit or when cooking has completed
Technical Data
Model Number
SDA1061
Rated Voltage
220-240V AC ~ 50-60Hz
Rated Power
700W
Protection Class
I (This Appliance must be Earthed)
Capacity
1.8 Litres
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead and
should the fuse need replacing, you must use an ASTA approved one (conforming
to BS 1362 of the same rating). If in doubt, consult a qualified electrician who will
be pleased to do this for you. If you need to remove the plug –DISCONNECT
FROM THE MAINS –and then cut it off the mains lead and immediately dispose
of it safely. Never attempt to reuse the plug or insert it into a socket outlet as
there is a danger of electric shock.
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.

15
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste and not sent to landfill. Please
ensure it is taken to a suitable facility for disposal. Check with
your Local Authority or retailer for recycling advice or visit
www.recycle-more.co.uk, enter your postcode to find out your
nearest recycling site.

16
Rice Cooker & Steamer
SDA1061
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
• Theproduct must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS
EU Rep: Euromagppie Ireland Ltd. DO5 X006
www.esgltd.com
