Daewoo DV-S103W Series User manual

Video Cassette Player
DV-S103W
PAL NTSC
OWNER MANUAL

DRAWING YOUR ATTENTION
1
Thank you purchasing this VCP, develloped to provide advanced features and functions for high quality performance.
To obtain the best results and to avoid malfunction, PLEASE CAREFULLY READ THE DESCRIPTIONS AND OPERATING
PROCEDURE CONTAINED IN THIS OWNER’S MANUAL PRIOR TO OPERATING THIS VCP.
Caution: To prevent electric shock do not use this polarized plug with an extension cord receptacle or other outlet
unless the blades can be fully inserted to prevent blade exposure.
Warning: This video cassette player should be used with AC 90-250V~, 50/60Hz.
To prevent electric shocks and fire hazards, do NOT use any other power source.
Caution: Any changes or modification in construction of device which are not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
When you are not using the VCP for along period, it is recommended that you disconnect the power cord
from the AC outlet.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE OF THE ENCLOSURE. DO
NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
The lightning flash with arrowhead symbol an equilateral
triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intend to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCKS
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION

IMPORTANT SAFEGUARDS
2
For your protection, please read these safety instructions completely before operating the appliance, and keep this
manual for future reference.
Carefully observe all warnings, precautions, and instructions on the appliance, or the ones described in the
operating instructions and adhere to them.
USE
Power Sources–This set should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type
of electrical power supply at your home, consult
your dealer or local power company. For those
sets designed to operate from AC 90-250V~,
50/60 Hz.
Grounding or Polarization–This set is equipped
with a polarized AC power cord plug (a plug
having one blade wider than the other), or with a
threewire grounding type plug (a plug having a
third pin for grounding).
Follow the instructions below.
Overloading–Do not overload wall outlets,
extension cords or convenience receptacle
beyond their capacity, since this can result in fire
or electric shock.
Object and Liquid Entry–Never push objects of
any kind into the set through openings as they
may touch dangerous voltage points or shart out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the set.
Attachments–Do not use attachments not
recommended by the manufacturer, as they
may cause hazards.
Cleaning–Unplug the set from the wall outlet
before cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampended with water for cleaning the exterior
of the set.
AC 90-250V~?
UNPLUGUNPLUG

3
Water and Moisture–Do not use powerline
operated sets near water-for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool, etc.
Accessories–Do not place the set on an unstable
cart, stand, tripod, bracket, or table. The set may
fall, causing serious injury to a child or an adult,
and serious damage to the set. Use only a cart
stand, tripod, bracket, or table recommended by
the manufacturer.
Ventilation–The slots and openings in the cabinet
are provided for necessary ventilation. To ensure
reliable operation of the set, and to protect it from
overheating, these slots and openings must never
be blocked or covered.
– Never cover the slots and openings with a cloth
or other materials.
– Never block the slots and openings by placing
the set on a bed, sofa, rug or other similar
surface.
Portable Cart Warning–An appliance and cart
combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to
overturn.

4
–Never place the set in a confined space such as
a bookcase, or built-in cabinet unless proper
ventilation is provided.
Power-Cord Protection–Route the power cord in
order not to be walked on or pinched by items
placed upon or against them, paying particular
attention to the plugs, receptacles, and the point
where the cord exits from the appliance.
–Do not place the set over a radiator or heat
register, or where it is exposed to direct sunlight.
In the normal temperature, if you pour a cold
liquid into a glass, water vapour in the air will
condense on the surface of the glass. This is
moisture condensation. The moisture
condensation may occur inside of VCPs, if used in
this condition, it will cause damage to the head
and the tape.
In case of moving the VCP from a cold place to
heated place,
Or the temperature of surroundings goes up due
to room heating switched on.
Or moving the VCP suddenly from air conditioned
room to a place of high temperature of humidity in
summer.
When the moisture condensation occurs inside of
the VCP, NEVER insert the cassette into the
cassette compartment. Remove the cassette, if
loaded, by pressing the STOP/EJECT key. Only
operate the VCP after the moisture condensation
has completely dried out. Normally, it takes about
2 hours.
MOISTURE CONDENSATION
When does the
mositure conden-
sation occur
inside of the VCP?

5
Damage Requiring Service–Unplug the set from
the wall outlet and refer servicing to qualified
service personnel under the following conditions:
–When the power cord or plug is damaged or
frayed.
–If liquid has been spilled or objects have fallen
into the set.
–If the set has been exposed to rain or water.
–If the set has been subjected to excessive shock
by being dropped, or the cabinet has been
damaged.
–If the set does not operate normally when
following the operating instructions, adjust only
those controls that are specified in the operating
instructions. Improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the set to normal operation.
–When the set exhibits a distinct change in
performance, this indicates a need for service.
Servicing–Do not attempt to service the set
yourself as opening or removing covers may
expose you to dangerous voltage or other
hazards.
Refer all servicing to qualified service personnel.
Replacement of parts–When replacement of
parts is required, be sure the service technician
has used replacement parts specified by the
manufacturer that have the same characteristics
as the original parts. Unauthoized substitutions
may result in fire, electric shock, or other hazards.
Safety Check–Upon completion of any service or
repairs to the set, ask the service technician to
perform routine safety checks (as specified by the
manufacturer) to determine that the set is in safe
operating condition.
SERVICE
SERVICE DEPT
ALL SETS RECEIVE
OUR OK
SAFETY CHECK.
FRAYED OR CUT
AC LINE
CRACKED PLUG

6
IMPORTANT NOTES
•Audio-visual material may include works of copyright which must NOT be recorded without the authority of the owner of copyright.
•Note that main voltage is supplied to the unit whenever the main plug is connected to the supply socket.
•To avoid the risk of fire or electric shock, do not expose the unit to rain or moisture.
•Do not attempt to open the cabinet. There are no user-serviceable parts inside. Refer all servicing to qualified service personnel.
•Keep the unit away from radiators or other sources of heat.
•Do not operate or store the unit close to strong magnetic fields.
•Do not spill liquid of any kind onto the unit. If liquid is accidently spilled onto the unit, immediately remove the main plug from the
supply socket, and consult a qualified service engineer.
•Avoid places subjected to strong vibration.
•Do not place anything heavy on the VCP.
•Use the video cassette player in a horizontal (flat) position only.
•Before operating, remove any paper wrapping which may have been affixed to the player during manufacturing.
DO NOT COVER VENTILATION OPENINGS ON TOP AND SIDES OF THE PLAYER DURING OPERATION.
•When a cassette is inserted into the loading compartment, the power is switched on automatically as long as the power cord is
plugged into an AC outlet. DO NOT force a cassette into the compartment when the power cord is unplugged.
•Keep the player and video cassette away from strong magnetic fields.
•After playing a video cassette, remove it from the player. DO NOT move the player with a cassette in the compartment.
•Store video cassettes in their sleeves or cases and position vertically.
•If a cassette has been subjected to cold temperature, allow it to warm to room temperature before recording or playback.
For your protection, record the model and serial numbers of your
video cassette player here. In the event your player requires servicing
or is stolen, you may need this information. You may also wish to clip
or staple your sales receipt to this page.
Model Number:
Serial Number:
Date Purchased:
Store’s Name and Address:

7
ACCESSORIES
2. REMOTE CONTROL 3. RF CABLE 4. BATTERIES (AAA SIZE)
1. INSTRUCTION MANUAL
OWNER'S MANUAL

INTRODUCTION
8
CONGRATULATIONS on your purchase of a new VHS VCP.
This VCP is an existing, new VCP designed to satisfy all your VHS tape play and recording needs.
And, with proper used and care, your new VCP will offer many year of viewing enjoyment.
Just a few of the feature include.
• NTSC PLAYBACK ON PAL TV:
You can playback not only PAL tape but NTSC tape on PAL TV.
• LINE RECORDING (REAR OR FRONT AV JACK )
• NTSC 3.58 RECORDING & PLAYBACK
You can record not only PAL/MESECAM but NTSC (3.58).
• QUICK START
Various operation keys operate quickly when each of them is pressed.
• DIGITAL AUTO TRACKING
This VCP plays clear pictures without special operations.
• AC POWER SUPPLY (AC 90-250V~)
• DC (12V) POWER SUPPLY
• COMPLETE SAFETY DEVICE
When this VCP is not in normal condition, it stops operating automatically for self-protection.
• SELF PICTURE ADJUSTMENT
Since the HEAD DRUM rotates regularly depending on the voltage change or tape condition, the picture is always
stable.
• ENCORE FUNCTION
Press the ENCORE key on the remote control to watch the desired picture once more during playback.
• BUILT-IN WIDE RANGE MODULATOR (CH. 22- CH. 40)
• BUILT-IN MULTI RF OUT MODULATOR (PAL-G/K/I)
• AUTO REPEAT SEARCH FUNCTION
If you press the A.REPEAT key during playback,the tape will be replayback after rewinding .
• 2 STEP PICTURE SEARCH

TABLE OF CONTENTS
9
NOTE: This Video Cassette Player is compatible with any Video Cassette Player bearing the VHS mark. The VCP is
designed to expand your opportunities for home viewing and not for any usage which might violate the copyright laws.
Save the original shipping carton and packing materials; they will come in handy if you ever have to ship your VCP. For
maximum protection, repack the set as it was originally packed at the factory.
DRAWING YOUR ATTENTION........................................................................................................................................1
IMPORTANT SAFEGUARDS...........................................................................................................................................2
INTRODUCTION..............................................................................................................................................................8
TABLE OF CONTENTS ...................................................................................................................................................9
IDENTIFICATION...........................................................................................................................................................10
TO GET STARTED.........................................................................................................................................................17
CLOCK SETTING ..........................................................................................................................................................18
VIDEO CHANNEL SETTING..........................................................................................................................................19
BASIC OPERATION.......................................................................................................................................................20
SPECIAL OPERATION...................................................................................................................................................24
PICTURE ADJUSTMENT...............................................................................................................................................27
VIDEO SYSTEM.............................................................................................................................................................28
RECORDING TV PROGRAMS.......................................................................................................................................29
BEFORE CALLING SERVICE PERSONNEL..................................................................................................................33
SPECIFICATIONS..........................................................................................................................................................34
