Dahua Technology IPC-HDW2249TM-S-IL-0280B User manual

Eyeball Network Camera
Quick Start Guide
V1.0.3
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Quick Start Guide
I
Foreword
General
This manual introduces the functions, configuration, general operation, and system maintenance of
network camera.
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in property
damage, data loss, reductions in performance, or unpredictable result.
Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Time
V1.0.3 Updated the cable information. November 2022
V1.0.2 Updated the description of device detaching and SD card
installation. November 2021
V1.0.1 Updated "Important Safeguards and Warnings." April 2021
V1.0.0 First release. August 2019
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy protection
laws and regulations to protect the legitimate rights and interests of other people by implementing
measures which include but are not limited: Providing clear and visible identification to inform people
of the existence of the surveillance area and provide required contact information.
About the Manual
The manual is for reference only. Slight differences might be found between the manual and the
product.
We are not liable for any loss caused by the operations that do not comply with the manual.
The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper User Manual, use our CD-ROM, scan the QR code or visit
our official website. The manual is for reference only. Slight differences might be found between

Quick Start Guide
II
the electronic version and the paper version.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or errors in
print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and the company names in the manual are the properties
of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem occurred
when using the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Quick Start Guide
III
Important Safeguards and Warnings
This section introduces content covering the proper handling of the device, hazard prevention, and
prevention of property damage. Read carefully before using the device, comply with the guidelines
when using it.
Transportation Requirements
Transport the device under allowed humidity and temperature conditions.
Pack the device with packaging provided by its manufacturer or packaging of the same quality
before transporting it.
Do not place heavy stress on the device, violently vibrate or immerse it in liquid during
transportation.
Storage Requirements
Store the device under allowed humidity and temperature conditions.
Do not place the device in a humid, dusty, extremely hot or cold site that has strong
electromagnetic radiation or unstable illumination.
Do not place heavy stress on the device, violently vibrate or immerse it in liquid during storage.
Installation Requirements
Strictly comply with the local electrical safety code and standards, and check whether the power
supply is correct before operating the device.
Please follow the electrical requirements to power the device.
When selecting the power adapter, the power supply must conform to the requirements of
ES1 in IEC 62368-1 standard and be no higher than PS2. Please note that the power supply
requirements are subject to the device label.
We recommend using the power adapter provided with the device.
Do not connect the device to two or more kinds of power supplies, unless otherwise specified, to
avoid damage to the device.
The device must be installed in a location that only professionals can access, to avoid the risk of
non-professionals becoming injured from accessing the area while the device is working.
Professionals must have full knowledge of the safeguards and warnings of using the device.
Do not place heavy stress on the device, violently vibrate or immerse it in liquid during installation.

Quick Start Guide
IV
An emergency disconnect device must be installed during installation and wiring at a readily
accessible location for emergency power cut-off.
We recommend you use the device with a lightning protection device for stronger protection
against lightning. For outdoor scenarios, strictly comply with the lightning protection regulations.
Ground the function earthing portion of the device to improve its reliability (certain models
are not equipped with earthing holes). The device is a class I electrical appliance. Make sure that
the power supply of the device is connected to a power socket with protective earthing.
The dome cover is an optical component. Do not directly touch or wipe the surface of the cover
during installation.
Operation Requirements
The cover must not be opened while the device is powered on.
Do not touch the heat dissipation component of the device to avoid the risk of getting burnt.
Use the device under allowed humidity and temperature conditions.
Do not aim the device at strong light sources (such as lamplight, and sunlight) when focusing it,
to avoid reducing the lifespan of the CMOS sensor, and causing overbrightness and flickering.
When using a laser beam device, avoid exposing the device surface to laser beam radiation.
Prevent liquid from flowing into the device to avoid damage to its internal components.
Protect indoor devices from rain and dampness to avoid electric shocks and fires breaking out.
Do not block the ventilation opening near the device to avoid heat accumulation.
Protect the line cord and wires from being walked on or squeezed particularly at plugs, power
sockets, and the point where they exit from the device.
Do not directly touch the photosensitive CMOS. Use an air blower to clean the dust or dirt on the
lens.
The dome cover is an optical component. Do not directly touch or wipe the surface of the cover
when using it.
There might be a risk of electrostatic discharge on the dome cover. Power off the device when
installing the cover after the camera finishes adjustment. Do not directly touch the cover and
make sure the cover is not exposed to other equipment or human bodies
Strengthen the protection of the network, device data and personal information. All necessary
safety measures to ensure the network security of the device must be taken, such as using strong
passwords, regularly changing your password, updating firmware to the latest version, and
isolating computer networks. For the IPC firmware of some previous versions, the ONVIF
password will not be automatically synchronized after the main password of the system has been
changed. You need to update the firmware or change the password manually.

Quick Start Guide
V
Maintenance Requirements
Strictly follow the instructions to disassemble the device. Non-professionals dismantling the
device can result in it leaking water or producing poor quality images. For a device that is required
to be disassembled before use, make sure the seal ring is flat and in the seal groove when putting
the cover back on. When you find condensed water forming on the lens or the desiccant becomes
green after you disassembled the device, contact after-sales service to replace the desiccant.
Desiccants might not be provided depending on the actual model.
Use the accessories suggested by the manufacturer. Installation and maintenance must be
performed by qualified professionals.
Do not directly touch the photosensitive CMOS. Use an air blower to clean the dust or dirt on the
lens. When it is necessary to clean the device, slightly wet a soft cloth with alcohol, and gently
wipe away the dirt.
Clean the device body with a soft dry cloth. If there are any stubborn stains, clean them away with
a soft cloth dipped in a neutral detergent, and then wipe the surface dry. Do not use volatile
solvents such as ethyl alcohol, benzene, diluent, or abrasive detergents on the device to avoid
damaging the coating and degrading the performance of the device.
The dome cover is an optical component. When it is contaminated with dust, grease, or
fingerprints, use degreasing cotton moistened with a little ether or a clean soft cloth dipped in
water to gently wipe it clean. An air gun is useful for blowing dust away.
It is normal for a camera made of stainless steel to develop rust on its surface after being used in
a strong corrosive environment (such as the seaside, and chemical plants). Use an abrasive soft
cloth moistened with a little acid solution (vinegar is recommended) to gently wipe it away.
Afterwards, wipe it dry.

Quick Start Guide
VI
Table of Contents
Foreword............................................................................................................................................................ I
Important Safeguards and Warnings............................................................................................................. III
1 Introduction................................................................................................................................................... 1
Cable............................................................................................................................................................................................... 1
Connecting Alarm Input/Output ......................................................................................................................................... 1
2 Network Configuration ................................................................................................................................. 3
Initializing the Camera ............................................................................................................................................................. 3
Changing the Device IP Address .......................................................................................................................................... 4
Logging in to the Webpage.................................................................................................................................................... 4
3 Installation..................................................................................................................................................... 5
Packing List................................................................................................................................................................................... 5
Dimensions................................................................................................................................................................................... 5
Installing the Camera................................................................................................................................................................ 6
3.3.1 Installation Direction ................................................................................................................................................... 6
3.3.2 Installation Methods.................................................................................................................................................... 6
3.3.3 Detaching the Device.................................................................................................................................................. 7
3.3.4 (Optional) Installing the SD Card ............................................................................................................................ 7
3.3.5 Attaching the Camera................................................................................................................................................. 7
3.3.6 (Optional) Installing the Waterproof Connector ............................................................................................... 9
3.3.7 Adjusting the Lens Angle........................................................................................................................................... 9

Quick Start Guide
1
1Introduction
Cable
Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and
water damage. For the detailed operation, see FAQ manual.
Cables
Table 1-1 Cable information
No. Port Name Description
1 Ethernet port
Inputs 12 VDC power. Please be sure to supply power as instructed in the
Guide.
Device abnormity or damage could occur if power is not supplied correctly.
2 Ethernet port
Connects to network with network cable.
Provides power to the device with PoE.
PoE is available on select models.
3 Alarm I/O Includes alarm signal input and output ports. For detailed information,
see Table 1-2.
4 Audio input Connects to sound-pick-up device to receive audio signal.
5 Audio output Connects to speaker to output audio signal.
Table 1-2 Alarm information
Port Name Description
ALARM_OUT Outputs alarm signal to alarm device.
ALARM_IN Receives the switch signal of external alarm source.
ALARM_GND Ground connection.
Connecting Alarm Input/Output
The camera can connect to external alarm input/output devices through the digital input/output port.
Alarm input/output is available on select models.

Quick Start Guide
2
Connect the alarm input device to the alarm input end of the I/O port.
The device collects different statuses of the alarm input port while the input signal is idling
and being grounded.
Device collects logic "1" when the input signal is connected to +3 V to +5 V or idling.
Device collects logic "0" when the input signal is grounded.
Alarm input
Connect the alarm output device to the alarm output end of the I/O port. The alarm output is
an open-drain output, which works in the following modes.
Mode A: level application. The alarm outputs high and low level signals, and the alarm
outlet is OD, which requires external pull-up resistance (10 K Ohm typical) to work. The
maximum external pull-up level is 12 V, maximum port current is 300 mA, and the default
output signal is high-level (external pull-up voltage). The default output signal switches
to low- level when an alarm is triggered (As long as the operating current is below 300
mA, the output low-level voltage is lower than 0.8 V).
Mode B: switch application. Alarm output is used to drive the external circuit, the
maximum voltage is 12 V and the maximum current is 300 mA. If the voltage is higher
than 12 V, use an additional electric relay.
Alarm output
Log in to the webpage, and then configure the alarm input and alarm output in alarm settings.
The alarm input on the webpage corresponds to the alarm input end of the I/O port.
There will be high level and low level alarm signals generated by the alarm input device
when an alarm occurs. Set the input mode to "NO" (default) if the alarm input signal is
logic "0", and to "NC" if the alarm input signal is logic "1".
The alarm output on the webpage corresponds to the alarm output end of the device,
which is also the alarm output end of the I/O port.

Quick Start Guide
3
2Network Configuration
Device initialization and IP setting can be finished with the ConfigTool or on webpage. For more
information, see web operation manual.
Device initialization is available on select models, and it is required at first-time use and after
device is being reset.
Device initialization is available only when the IP addresses of the device (192.168.1.108 by
default) and the PC stay on the same network segment.
Plan usable network segment properly to connect the device to the network.
The following figures are for reference only.
Initializing the Camera
Search for the device that needs to be initialized through ConfigTool.
1) Double-click ConfigTool.exe to open the tool.
2) Click Modify IP.
3) Select the searching way, and then click OK.
4) Select one or several cameras in uninitialized status, and then click Initialize.
Select the devices to be initialized, and then click Initialize.
If you do not provide the email address for password reset, you can reset the password only
through XML file.
Password setting
Select Auto-check for updates as needed, and then click OK to initialize the device.
If initialization failed, click to see more information.

Quick Start Guide
4
Click Finish.
Changing the Device IP Address
You can change IP address of one or multiple devices in one time. This section is based on
changing IP addresses in batches.
Changing IP addresses in batches is available only when the corresponding devices have the
same login password.
Search for the device whose IP address needs to be changed through ConfigTool.
1) Double-click ConfigTool.exe to open the tool.
2) Click Modify IP.
3) Select the searching way, enter the username and password, and then click OK.
The username is admin, and the password should be the one you set while initializing
the device.
Select the devices whose IP addresses need to be changed, and then click Modify IP.
Configure IP address.
Static mode: When you select Static, you need to enter Start IP, Subnet Mask, and
Gateway. The IP addresses of the devices will be modified successively starting from the
first IP entered.
DHCP mode: If the DHCP server is available on the network, when you select DHCP, the
IP address of devices will be automatically obtained through the DHCP server.
The same IP address will be set for multiple devices if you select the Same IP checkbox.
Click OK.
Logging in to the Webpage
Open IE browser, enter the IP address of the device in the address bar, and then press the Enter
key.
If the setup wizard is displayed, finish the settings as instructed.
Enter the username and password in the login box, and then click Login.
For the first-time login, click Click Here to Download Plugin, and then install the plugin as
instructed.
The home page is displayed when the installation is finished.

Quick Start Guide
5
3Installation
Packing List
The tool required for the installation such as electric drill is not provided in the package
The operation manual and related tool information are contained in the disk or the QR code.
Packing list
Dimensions
Dimensions (mm [inch])

Quick Start Guide
6
Installing the Camera
3.3.1 Installation Direction
Installation direction
3.3.2 Installation Methods
Installation methods

Quick Start Guide
7
3.3.3 Detaching the Device
Detach the device
3.3.4 (Optional) Installing the SD Card
Pull the power plug off before installing or removing the SD card.
Press and hold the RESET button for 10 s to reset the camera.
Install the SD card
3.3.5 Attaching the Camera
Make sure the mounting surface is strong enough to hold at least three times of the weight of the
device and bracket.

Quick Start Guide
8
Cable going through the mounting surface
Cable going through the side cable tray

Quick Start Guide
9
3.3.6 (Optional) Installing the Waterproof Connector
This part is needed only when there is waterproof connector in the package and the device is used
outdoors.
Install the waterproof connector
3.3.7 Adjusting the Lens Angle
Adjust the lens angle

Quick Start Guide
