Dahua DHI-ITC952-AF3F User manual

HD Intelligent Enforcement Camera
Web Operation Manual
V1.0.
2
ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD.

Web Operation Manual
I
Foreword
General
This manual introduces the web operations of the HD intelligent enforcement camera (hereinafter
referred to as the "Camera").
Models
HD Intelligent Enforcement Camera Business Type
DHI-ITC952-AF3F ANPR, E-Police, Yield to Pedestrians
DHI-ITC952-AF3F-IR7 ANPR, E-Police, Yield to Pedestrians
DHI-ITC952-AF3F-IR8 ANPR, E-Police, Yield to Pedestrians
DHI-ITC952-RF2D-IR7 ANPR, E-Police, Yield to Pedestrians
DHI-ITC952-RF2D-IR8 ANPR, E-Police, Yield to Pedestrians
DHI-ITC352-AF3F ANPR, Yield to Pedestrians
DHI-ITC352-AF3F-IR7 ANPR, Yield to Pedestrians
DHI-ITC352-AF3F-IR8 ANPR, Yield to Pedestrians
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided, could
result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in property
damage, data loss, reductions in performance, or unpredictable results.
TIPS Provides methods to help you solve a problem or save time.
NOTE Provides additional information as a supplement to the text.
Revision History
Version Revision Content Release Time
V1.0.2 Changed some images. December 2021

Web Operation Manual
II
Version Revision Content Release Time
V1.0.1 Updated model information and cybersecurity recommendations. September 2021
V1.0.0 First release. September 2021
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their face,
fingerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identification
to inform people of the existence of the surveillance area and provide required contact information.
About the Manual
The manual is for reference only. Slight differences might be found between the manual and the
product.
We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or
visit our official website. The manual is for reference only. Slight differences might be found
between the electronic version and the paper version.
All designs and software are subject to change without prior written notice. Product updates
might result in some differences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
If there is any uncertainty or controversy, we reserve the right of final explanation.

Web Operation Manual
III
Table of Contents
Foreword............................................................................................................................................................ I
1 Web Introduction........................................................................................................................................... 1
First-time Login........................................................................................................................................................................... 11.1
Login ............................................................................................................................................................................................... 21.2
Logout ............................................................................................................................................................................................ 31.3
Password Reset ........................................................................................................................................................................... 31.4
Web Functions............................................................................................................................................................................. 41.5
2 Live ................................................................................................................................................................. 6
Video Stream................................................................................................................................................................................ 62.1
Live View........................................................................................................................................................................................ 62.2
Plate Number Recognition ..................................................................................................................................................... 82.3
Plate Snapshot ............................................................................................................................................................................ 82.4
System Functions ....................................................................................................................................................................... 82.5
Functions on the Live Interface ............................................................................................................................................ 82.6
Vehicle Snapshot........................................................................................................................................................................ 92.7
Event List .....................................................................................................................................................................................102.8
3 Playback....................................................................................................................................................... 11
Video Playback ..........................................................................................................................................................................113.1
Viewing Recordings.................................................................................................................................................................123.2
Record Type................................................................................................................................................................................133.3
Time Format ...............................................................................................................................................................................133.4
4 Query............................................................................................................................................................ 14
Image Search .............................................................................................................................................................................144.1
4.1.1 Searching for SD Card Image..................................................................................................................................14
4.1.2 Downloading Attribute ............................................................................................................................................15
4.1.3 PC Picture.......................................................................................................................................................................16
Flow Query .................................................................................................................................................................................164.2
Recording Search .....................................................................................................................................................................174.3
4.3.1 Recording.......................................................................................................................................................................17
4.3.2 Watermark .....................................................................................................................................................................19
5 Settings ........................................................................................................................................................ 20
Camera.........................................................................................................................................................................................205.1
5.1.1 Attributes.......................................................................................................................................................................20
5.1.2 Video................................................................................................................................................................................25
Network .......................................................................................................................................................................................285.2
5.2.1 Configuring TCP/IP .....................................................................................................................................................28
5.2.2 Port...................................................................................................................................................................................30
5.2.3 Configuring Auto Registration...............................................................................................................................31
5.2.4 Configuring 802.1x.....................................................................................................................................................31
Remote Device..........................................................................................................................................................................325.3
Event .............................................................................................................................................................................................325.4
5.4.1 Intelligent Scheme .....................................................................................................................................................33

Web Operation Manual
IV
5.4.2 Configuring Electronic Police.................................................................................................................................36
5.4.3 Configuring ANPR Snapshot...................................................................................................................................46
5.4.4 Configuring OSD.........................................................................................................................................................54
5.4.5 Configuring Traffic Flow Analysis..........................................................................................................................56
5.4.6 Cutout .............................................................................................................................................................................56
5.4.7 Device Direction..........................................................................................................................................................57
5.4.8 Alarm ...............................................................................................................................................................................57
5.4.9 Abnormality..................................................................................................................................................................59
Peripheral....................................................................................................................................................................................615.5
5.5.1 Extra Device Status.....................................................................................................................................................61
5.5.2 Serial Port Settings .....................................................................................................................................................61
5.5.3 Light Configuration....................................................................................................................................................64
Storage.........................................................................................................................................................................................665.6
5.6.1 Point.................................................................................................................................................................................66
5.6.2 Local.................................................................................................................................................................................66
5.6.3 FTP....................................................................................................................................................................................67
5.6.4 Client................................................................................................................................................................................68
5.6.5 Save Path........................................................................................................................................................................69
5.6.6 Record Control.............................................................................................................................................................70
System..........................................................................................................................................................................................705.7
5.7.1 General............................................................................................................................................................................70
5.7.2 Account Management ..............................................................................................................................................72
5.7.3 Safety...............................................................................................................................................................................79
5.7.4 Default ............................................................................................................................................................................85
5.7.5 Import/Export ..............................................................................................................................................................86
5.7.6 Configuring Auto Maintain .....................................................................................................................................86
5.7.7 System Upgrade..........................................................................................................................................................87
System Information.................................................................................................................................................................875.8
5.8.1 Version Information ...................................................................................................................................................87
5.8.2 Log....................................................................................................................................................................................88
5.8.3 Online User....................................................................................................................................................................89
5.8.4 Work Status ...................................................................................................................................................................89
5.8.5 Legal Information .......................................................................................................................................................90
6 Alarm............................................................................................................................................................ 91
7 FAQ ............................................................................................................................................................... 92
Allowlist Format ......................................................................................................................... 93Appendix 1
Cybersecurity Recommendations............................................................................................. 95Appendix 2

Web Operation Manual
1
1Web Introduction
After mounting the Camera (see details in the user’s manual of the all-in-one enforcement camera),
power on the Camera, connect it to the network and configure its settings, then you can get the
desired detection results.
The actual page might vary depending on the model you purchased and the version of software. The
figures in this manual are only for reference, and might differ from the actual page.
First-time Login1.1
The Camera is delivered in the uninitialized status. You need to initialize the Camera and modify its
default password before it can be used.
Connect the Camera to the network.Step 1
1) Connect the Camera to PC over the Ethernet cable.
2) Keep the IP address of the PC and the camera on the same network segment.
The network segment can be set to 192.168.1.X, but cannot be the same as the factory
default IP of the Camera (192.168.1.108).
3) Execute ping ***.***. ***. *** (device IP) command on PC to check the network
connection.
Enter the IP address of the Camera (192.168.1.108) in the browser address bar, and press theStep 2
Enter key to log in to the web page of the Camera.
On the Device Initialization page, enter your new password.Step 3
Select the Email Address checkbox, and then enter your email address. This helps you resetStep 4
your password when your password is lost or forgotten.
Click Confirm.Step 5
Device initializationFigure 1-1
On the Online Upgrade page, select Auto-check for updates and then click Confirm.Step 6

Web Operation Manual
2
LoginFigure 1-2
On the Login page, enter the username (admin) and the password that you set, and thenStep 7
click Login.
Live pageFigure 1-3
For first-time login, click Please click here to download and install the plug-in, and thenStep 8
install the plug-in.
Before installing the plug-in, make sure that ActiveX controls (in Internet Explorer) from
Tools > Internet Options > Security > Custom Level is enabled.
After successfully installing the plug-in, the live view of the Camera is displayed.
If there is no operation for a long time, the system prompts Authorized failed. Please login
again! In this case, you need to log in again.
Login1.2
You can log in to the web by following the steps below. For first-time login, see "1.1 First-time Login".

Web Operation Manual
3
Enter the IP address of the Camera in the browser address bar, and press Enter.Step 1
Enter username and password on the displayed page, and then click Login.Step 2
A box pops up when the username or password is incorrect. See Figure 1-6.
If you enter an invalid username or password five times, the account will be locked for
five minutes.
Invalid username or passwordFigure 1-4
Logout1.3
Click Logout at the upper-right corner of the web page to log out.
You can enter the username and password to log in again.
Password Reset1.4
You can reset your password through email when it is lost or forgotten. Make sure that your email is
correctly entered during initialization (see "1.1 First-time Login"). Email address of admin user can be
modified from Setting > System > Account > Account > Username.
Enter the IP address of the Camera in the browser address bar, and press Enter.Step 1
On the login page, click Forgot password?Step 2
In the pop-up dialog box, click OK.Step 3
Scan the QR code according to the page prompt, and send the scanning result to theStep 4
designated email to acquire security code.
Scan the actual QR code. Do not scan the QR code in this manual.
Enter the security code that you received in the text box of Security code.Step 5

Web Operation Manual
4
Reset passwordFigure 1-5
Click Next.Step 6
Set Password, and enter your new password again in Confirm Password.Step 7
The new password must consist of 8–32 characters, and contain at least two types
from upper cases, lower cases, numbers and special characters (excluding ' " ; : and &).
The new password must be the same as the Confirm Password. Follow the password
security notice to set a high-security password.
Click Ye s.Step 8
Web Functions1.5
You can view real-time video captured by the Camera, set detection rules of number plate
recognition and traffic violations, and play back video recordings and snapshots to trace back events
(if any). Here introduces the overview of each function button on the Live page.
Web function barFigure 1-6
Table 1-1 Web functions
Operation Description
Live Displays real-time video and picture. You can record video and capture images, and
configure video play and picture settings. See "2 Live".
Playback You can play back manual video recordings and videos related to traffic violations to
trace back events (if any). See "3 Playback".

Web Operation Manual
5
Operation Description
Query You can search for images, traffic flow information, and records on this page. See "4
Query".
Setting
You can configure the way that the Camera works, the rules for detecting violations, and
the internet protocol for camera network connection. You can also view version and
system information of the Camera. See "5 Settings".
Alarm You can configure how the Camera responds when alarms occur. See "6 Alarm".
Logout Log out the web page. See "1.3 Logout".

Web Operation Manual
6
2Live
The Live page is displayed after you successfully log in to web. On this page, you can view the live
video image and the captured number plate, take snapshots, view event details, and more.
LiveFigure 2-1
Table 2-1 Description of live page
No. Description No. Description
1 Video stream 5 System functions
2 Live view 6 Functions of the live view
3 Logged plate number 7 Vehicle snapshot
4 Plate snapshot 8 Event list
Video Stream2.1
Main Stream: Make sure that the Camera can record videos and carry out network surveillance
when the network is normal. You can configure main stream resolution within the supported
range of the Camera.
Sub Stream: Replaces main stream to make network surveillance and reduce the network
bandwidth usage when network bandwidth is insufficient.
Protocol: Video surveillance protocol. Currently it only supports TCP.
Fluency: Fluency of viewing the live video. The fluency can be set to High, Middle, Low and
Default (recommended).
Live View2.2
Displays the live video captured by the Camera. You can also click the icons to change the display
mode of live view.

Web Operation Manual
7
: Adjust the image to original size or appropriate window.
: Click it to switch to big window. Click it again to exit big window.
Big windowFigure 2-2
: Click it to open image adjustment window on the right, meanwhile the button turns
to . Click to close the image adjustment window.
: Click it and the image is displayed at 100%, and the button turns to . Click
to switch back to original size.
: Click it to enable smart track detection. Number plate, vehicle bounding box, and other
smart tracking information will be displayed in the video image.
: Click it and the window is displayed in full screen; double-click or right-click to exit full
screen.

Web Operation Manual
8
Table 2-2 Image adjustment
Icon Name Description
Brightness Adjust the overall image brightness. Change the value when the image
is too bright or too dark. The range is from 0 to 128 (64 by default).
Contrast Change the value when the image brightness is suitable, but contrast is
not enough. The range is from 0 to 128 (64 by default).
Hue
Adjust the image hue. For example, change red into blue. The default
value is made by the light sensor and normally it does not have to be
adjusted. The range is from 0 to 128 (64 by default).
Saturation Adjust the vividness of the colors, without influencing
the overall
brightness of the image. The range is from 0 to 128 (64 by default).
— Click it to restore brightness, contrast, saturation, and hue to their
default values.
In this image adjustment window, you can only adjust image brightness, contrast, hue, and
saturation of local web. To adjust system brightness, contrast, hue and saturation, go to Setting >
Camera > Camera Attribute > General.
Plate Number Recognition2.3
Displays the plate number recognized by the Camera in real-time when a vehicle passes.
Plate Snapshot2.4
Displays the snapshot of a license plate when a vehicle passes.
System Functions2.5
Click the icons to set system functions, which include playback, video recording and snapshot query,
intelligent rules setting, alarm event setting, and system logout. See more details in the following
chapters.
Functions on the Live Interface2.6
Set functions on the Live page, and then the system will display the desired information on the Live
page.

Web Operation Manual
9
Table 2-3 Function description of the Live page
Icon Name Description
ANPR
Receive
Select the checkbox, and the Camera automatically receives
vehicle snapshots and detects event information
triggered by
sources such as radar or video detection, and displays such
snapshots and information at the lower part of the page.
The snapshots are saved in the storage path defined by Setting >
Storage > Destination > Save Path.
Record
Type Select the format of video recordings (dav by default).
Manual
Snapshot
Click it, and the Camera takes a snapshot when a vehicle passes.
The snapshot is saved in the storage path.
Enable ANPR Receive first.
To change the storage path of snapshots, go to Setting >
Storage > Destination > Save Path.
Snapshot
Click it, and a snapshot is taken, even when there is no vehicle
passing. The snapshot is saved in the path defined by Setting >
Storage > Destination > Save Path.
Digital
Zoom
Click and drag to select any area in the video window, and then the
area will be zoomed into. In any area of the video window, click
or right-click to exit.
Video
Recording
Click it to start recording. Click again to stop recording and
the recorded video will be saved to the set path.
The Camera will keep recording until the web page is closed or you
log out if the recording is not manually stopped.
Easy Focus
Click it to start auto focus, local focus, and license plate check for the
monitoring image.
ANPR Receive and Plate Check cannot be enabled at the same
time.
Vehicle Snapshot2.7
Select ANPR Receive, and then snapshots will be displayed when vehicles pass.

Web Operation Manual
10
Event List2.8
Select ANPR Receive, and the event information will be displayed, including number, event types,
capture time, lanes, plates, vehicle color, speed, vehicle signs, and vehicle types.

Web Operation Manual
11
3Playback
Click the Playback tab, and then you can play back video recordings stored on the TF card of the
Camera.
To set the record strategies, see "5.6.6 Record Control".
PlaybackFigure 3-1
Table 3-1 Functions
No. Description No. Description
1 Video playback 3 Record type
2 Playback file 4 Time format
Video Playback3.1
When playing back video recordings, you can control the video playing status with the following
icons.

Web Operation Manual
12
Table 3-2 Video playing description
Icon Function Description
Play and pause
: The video is paused or not being played.
: The video starts playing.
Stop Stop playing video.
Play by frame Play by frame.
Slow Slow down.
Fast Speed up.
Viewing Recordings3.2
You can view recordings by following the steps below.
Playback fileFigure 3-2
Set File Type and data source (Data Src), and set record time.Step 1
The data source is Hard disk (here referred to as TF card) by default. No video will be played
if there are no videos stored on the TF card.
Click a day with blue shading, and a colored progress bar is displayed on the timeline.Step 2
Date with blue shading means there are recordings on this day.
Point to this day, and the color turns to orange.
Select this day, and the color turns to green.
Click any time on the progress bar, and the system plays back videos starting from that time.Step 3
TimelineFigure 3-3
Click , and videos recorded on a selected day will be displayed in a list.Step 4

Web Operation Manual
13
Playback fileFigure 3-4
Table 3-3 Playback file description
Parameter Description
Search for all the video files within the selected period.
Click it to download files to local.
Click it to go back to the calendar page, where you can search and play back
videos of other periods.
Double-click a file in the list, and the file will be played with information displayed such asStep 5
the file size, start time, and end time.
Record Type3.3
Select a record type, and then only files of the selected types will be displayed on timeline and in the
file list.
Record typeFigure 3-5
Time Format3.4
Displays time in different formats. You can click each time format to play back the videos in 24-hour
mode, 2-hour mode, 1-hour mode, and 30-minute mode respectively.
Time formatFigure 3-6

Web Operation Manual
14
4Query
You can search for snapshots, vehicle flow, and video recordings on the Query page.
Image Search4.1
4.1.1 Searching for SD Card Image
On the SD Card Image page, you can search for and download the images stored in the TF card of
the Camera.
Make sure the TF card is inserted into the Camera; otherwise, there might be no results.
Select Query > Image Search > SD Card Image.Step 1
SD card imageFigure 4-1
Configure the parameters, and then click Search.Step 2
Table 4-1 SD picture parameters
Parameter Description
Begin Time Set the begin time and the end time to define a period, and then you can search for
images stored on the TF card within this period.
End Time
Event Type
All Picture: Search for all snapshots.
Mix Events: Search for snapshots related to events, which include but are not
limited to ANPR, Cross Solid White Line, and Wrong-way Driving.
Vehicle Sign Search for snapshots by the selected vehicle sign.
You can select All, Unknown or a specific vehicle sign.
Lane Select the capture lane.

Web Operation Manual
15
Parameter Description
Speed Range Select the Speed Range checkbox, and set the speed range to search for images of
vehicles within the defined speed range.
Record
Interval The length of a recorded video associated with the snapshot that you want to save.
Plate Select the Plate checkbox, and then enter the plate number to search for images
related to this plate.
This icon is displayed next to the traffic violation snapshot when Related Record is
enabled in Advanced Parameter (except ANPR) under Setting > Event > ANPR
Snap > Rule Config).
Select the images that you need, and click Open to view the images in photo viewer.Step 3
Select the images that you want to download, and then click Download.Step 4
Select the path to save the images, and the system starts downloading the images to yourStep 5
PC.
4.1.2 Downloading Attribute
You can configure the image information.
Select Query > Image Search > Downloading Attribute.Step 1
Set Download Snapshot by to download snapshots based on their Creation Time orStep 2
Capture Time.
Select Download Mode.Step 3
Selected File: Download the selected snapshots.
Selected Time: Download all images captured during the set time period. You can set
the time in the SD Card Image tab.
Select cutouts that you want to download from All, Plate Cutout, Binarized Plate,Step 4
Assistant Driver Face (cutout of front-seat passenger’s face), Driver Face,and Vehicle
Body Matting.
Name the snapshots. Click Help… to view the image naming rule. Click Restore to go backStep 5
to default.
Click Confirm.Step 6
