Dahua 5000 Series User manual

Network Keyboard 5000 Series
Quick Start Guide
V2.0.0

Foreword I
Foreword
General
This document mainly introduces appearance, functions and operations of network keyboard
(hereinafter referred to be "the keyboard").
Models
NKB5000, NKB5000-F
Safety Instructions
The following categorized signal words with defined meaning might appear in the manual.
Signal Words
Meaning
DANGER
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
CAUTION
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
TIPS
Provides methods to help you solve a problem or save you time.
NOTE
Provides additional information as the emphasis and supplement to
the text.

Foreword II
Revision History
Version
Revision Content
Release Time
V2.0.0
Add audio adjustment, task management, plan

tour and channel group configuration to local
preview module.
DSS-PRO, DSS-C9100 and DSS-Express

platforms support TV wall and live view.
Add safety baseline V1.4 needs.

Lock the screen with one button.

October 2019
V1.1.0
Update the program

December 2018
V1.0.0
First Release

October 2017
Privacy Protection Notice
As the device user or data controller, you might collect personal data of others, such as face,
fingerprints, car plate number, Email address, phone number, GPS and so on. You need to be
in compliance with the local privacy protection laws and regulations to protect the legitimate
rights and interests of other people by implementing measures, including but not limited to:
providing clear and visible identification to inform data subject the existence of surveillance
area and providing related contact.
About the Manual
The manual is for reference only. If there is inconsistency between the manual and the
actual product, the actual product shall prevail.
We are not liable for any loss caused by the operations that do not comply with the manual.
The manual would be updated according to the latest laws and regulations of related
regions. For detailed information, see the paper manual, CD-ROM, QR code or our official
website. If there is inconsistency between paper manual and the electronic version, the
electronic version shall prevail.
All the designs and software are subject to change without prior written notice. The product
updates might cause some differences between the actual product and the manual. Please
contact the customer service for the latest program and supplementary documentation.
There still might be deviation in technical data, functions and operations description, or
errors in print. If there is any doubt or dispute, please refer to our final explanation.
Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
All trademarks, registered trademarks and the company names in the manual are the
properties of their respective owners.
Please visit our website, contact the supplier or customer service if there is any problem
occurred when using the device.
If there is any uncertainty or controversy, please refer to our final explanation.

Important Safeguards and Warnings III
Important Safeguards and Warnings
The following description is the correct application method of the device. Please read the
manual carefully before use, in order to prevent danger and property loss. Strictly conform to
the manual during application and keep it properly after reading.
Operating Requirement
Do not place and install the device in an area exposed to direct sunlight or near heat
generating device.
Do not install the device in a humid, dusty or fuliginous area.
Keep its horizontal installation, or install it at stable places, and prevent it from falling.
Do not drip or splash liquids onto the device; do not put on the device anything filled with
liquids, in order to prevent liquids from flowing into the device.
Install the device at well-ventilated places; do not block its ventilation opening.
Use the device only within rated input and output range.
Do not dismantle the device arbitrarily.
Transport, use and store the device within allowed humidity and temperature range.
This device has been tested and found to comply with the limits for a Class Adigital device,
pursuant to Part 15 of the FCC Rules and EMC Directive 2014/30/EU. Operation of this
device in a residential area is likely to cause harmful interference, in which case the user
will be required to correct the interference at his own expense.
Power Requirement
Use batteries according to requirements; otherwise, it may result in fire, explosion or
burning risks of batteries.
To replace batteries, only the same type of batteries can be used!
The product shall use electric wires (power wires) recommended by this area, which shall
be used within its rated specification.
Use standard power adapter matched with this device. Otherwise, the user shall undertake
resulting personnel injuries or device damages.
Use power supply that meets SELV (safety extra low voltage) requirements, and supply
power with rated voltage that conforms to Limited Power Source in IEC60950-1. For
specific power supply requirements, please refer to device labels.
Products with category I structure shall be connected to grid power output socket, which is
equipped with protective grounding.
Appliance coupler is a disconnecting device. During normal use, keep an angle that
facilitates operation.

Table of Contents IV
Table of Contents
Foreword.................................................................................................................................................... I
Important Safeguards and Warnings.................................................................................................... III
1 Introduction............................................................................................................................................ 1
Overview....................................................................................................................................... 11.1 Key Module................................................................................................................................... 21.2 Port Introduction............................................................................................................................ 3
1.3 1.3.1 Rear Panel Ports ................................................................................................................ 3
1.3.2 Side Panel Port................................................................................................................... 5
2 Start and Shutdown .............................................................................................................................. 6
Start............................................................................................................................................... 62.1 Shutdown...................................................................................................................................... 62.2 Lock Screen.................................................................................................................................. 62.3
3 Quick Configuration.............................................................................................................................. 7
Initialization ................................................................................................................................... 73.1 Login Interface .............................................................................................................................. 73.2 Main Interface ............................................................................................................................... 7
3.3 Settings Interface.......................................................................................................................... 83.4 Network Settings........................................................................................................................... 93.5 3.5.1 Wired Network.................................................................................................................... 9
3.5.2 Wi-Fi...................................................................................................................................11
Adding Device............................................................................................................................. 123.6 3.6.2 Manual Add....................................................................................................................... 13
3.6.3 Auto Search ...................................................................................................................... 16
4 System Configurations....................................................................................................................... 18
Preview........................................................................................................................................ 184.1 4.1.1 Icons of Preview Interface................................................................................................ 18
4.1.2 Channel Grouping............................................................................................................. 19
4.1.3 Video on Wall.................................................................................................................... 21
4.1.4 PTZ Control ...................................................................................................................... 23
4.1.5 Scheme Management ...................................................................................................... 23
4.1.6 Patrol Config..................................................................................................................... 25
4.1.7 Snapshot........................................................................................................................... 27
4.1.8 Recording.......................................................................................................................... 28
4.1.9 Snapshot and Recording Settings.................................................................................... 28
4.1.10 Playback of Recorded Videos ........................................................................................ 31
Playback...................................................................................................................................... 324.2 TV Wall........................................................................................................................................ 344.3 4.3.1Adding TV Wall through Matrix Web Interface .................................................................34
4.3.2Adding TV Wall through Decoder Web Interface.............................................................. 36
4.3.3 Adding Device................................................................................................................... 38
4.3.4 Video on Wall.................................................................................................................... 38

Table of Contents V
4.3.5 TV Wall Icon Description .................................................................................................. 39
4.3.6 PTZ Control ...................................................................................................................... 40
4.3.7 Adding Tasks..................................................................................................................... 40
4.3.8 Configuring TV Wall.......................................................................................................... 41
Platform....................................................................................................................................... 434.4 4.4.1 Adding Devices and Video Wall........................................................................................ 43
4.4.2 Video on Wall.................................................................................................................... 48
4.4.3 Icons of Platform Interface................................................................................................ 51
4.4.4 PTZ Control ...................................................................................................................... 52
4.4.5 Adding Task....................................................................................................................... 52
PTZ Control................................................................................................................................. 524.5 4.5.1 Call.................................................................................................................................... 53
4.5.2 Settings............................................................................................................................. 54
4.5.3 SD Menu........................................................................................................................... 55
4.5.4 Auxiliary Function.............................................................................................................. 56
Settings....................................................................................................................................... 564.6 4.6.1 Device Management......................................................................................................... 57
4.6.2 General Settings............................................................................................................... 57
4.6.3 Account............................................................................................................................. 63
4.6.4 System.............................................................................................................................. 68
Extension .................................................................................................................................... 724.7 Cybersecurity Recommendations................................................................................... 75
Appendix 1

Introduction 1
1 Introduction
Overview1.1
The network keyboard can add TV wall, display videos on the TV wall, and carry out PTZ
control.
For appearance of network keyboard, see Figure 1-1. For details, see Table 1-1.
AppearanceFigure 1-1
Table 1-1 Icon description
No.
Icon
Function
1
Power
Working power indicator light.
Green light turns on when working power of
network keyboard is normal.
Network
Network indicator light.
Green light turns on when the keyboard is
connected to network normally.
Alarm
Alarm indicator light.
Red light turns on in case of alarms.
2
/
Zoom in/zoom out PTZ lens.
/
Increase/decrease the focus of PTZ lens.
/
Increase/decrease the iris of PTZ lens.
Shortcut key to control speed dome light.
Shortcut key to control speed dome wiper.
3
—
Touch screen, showing keyboard screen menu.

Introduction 2
No.
Icon
Function
4
Navigation bar.
Homepage.
Return.
5
Fn
Function key. It is line scanning by default.
Preset
Make PTZ control, and configure preset point.
Tour
Make PTZ control, and tour between points.
Aux
Auxiliary key. It is pattern by default.
6
—
Includes remote control lever, auxiliary menu and
function operation.
Key Module1.2
Key module is not available in platform preview mode.
F1 cannot be called in platform TV wall mode.
After key module is connected to network keyboard through USB or Bluetooth successfully,
green light at the upper right corner will be on for 10s and then turn off. For appearance of key
module, see Figure 1-2. For details, see Table 1-2.
When key module is connected with network keyboard, turn on main switch at the side of key
module. For Bluetooth connection, default Wi-Fi network name is "KEYBOARD".
Key moduleFigure 1-2
Table 1-2 Key description
Key
Example
Function
F1
Number 1 to 16 +F1
Call No. 1 to 16 plans quickly. It applies to
preview and TV wall functions.
View the plan numbers on the Plan
Management interface.
F2
Number 1 to 16 +F2
Call No. 1 to 16 MAC plans quickly.
View the Mac plan numbers on the MAC
interface.
F3
Press F3
Reserved.
F4
Press F4
Reserved.

Introduction 3
Key
Example
Function
Mode
Operation mode switch.
It is operation mode at
present.
Reserved.
0–9
Number 0–9
—
Screen
123 + Screen
Select screen.
Window
3 + Window
Focus on the third window of present screen.
Split
4 + Split
Divide present screen into 4 splits.
Press
Delete 1 digit from number buffer zone. The
icon is similar to squares.
(Camera group)
123 +
Drag No. 123 camera group onto the current
window for automatic tour of videos in the
channel.
(Camera)
567 +
Drag No. 567 camera onto present window.
0 + camera means to turn off present video
source.
Preset
2 + Preset
Call No. 2 preset.
Tour
5 + Tour
Call No. 5 tour.
PTZ
—
In case of USB power supply, press and hold
the button to turn on and off the backlight.
Scan
3 + Scan
Call No. 3 scan.
Pattern
4 + Pattern
Call No. 4 pattern.
Rotate
Press
Press it once to start rotation, and then press
it again to stop rotation.
Exit
—
Reserved.
Confirm
—
Reserved.
(Switch) previous
channel
KEY_ previous channel
Present focus window channel reduces by 1.
The icon is similar to squares.
(Next channel)
KEY_ next channel
Present focus window channel adds by 1.
The icon is similar to squares.
2+
Play back videos of No. 2 channel.
Port Introduction1.3
1.3.1 Rear Panel Ports
For rear panel ports, see Figure 1-3. For details, see Table 1-3.

Introduction 4
Rear panel portFigure 1-3
Table 1-3 Rear panel port description
Number
Name
Description
1
Wi-Fi port
Connect Wi-Fi antenna.
2
Grounding stud
Grounding.
3
USB2.0
Connect mouse and USB.
4
RS–232
Connect serial port.
5
Alarm input/output port
For details, see Table 1-4.
6
Network port
Connect the network.
7
USB3.0
Connect mouse and USB.
8
Microphone
Connect microphone.
9
Earphone
Connect earphone.
10
HDMI1–HDMI4
Connect devices with HDMI port, such as display
screen.
11
Power port
Connect power cord to supply power.
12
Power button
Turn on and off the power supply.
For alarm input and output port, see Figure 1-4. For details, see Table 1-4.
Alarm input and output portFigure 1-4
Table 1-4 Alarm input and output port description
Name
Description
1–4
Alarm input port.
Reserved. The software does not support at present.
12V
12V DC 4A power.
G
Grounding.
A, B
Connect PTZ through RS–485.
