INSTALLATION MANUAL
SPLIT SYSTEM Air Conditioner
RZQ180MY1
RZQ200MY1
00_CV_3P529410-2C.indd 1 12/11/2019 9:06:41 AM

SPLIT System Air Conditioner Installation manual
1
CONTENTS
1. FIRST OF ALL .......................................................................... 1
1-1 Safety precautions............................................................ 1
1-2 Special notice of product.................................................. 2
1-3 Disposal requirements ..................................................... 2
2. INTRODUCTION....................................................................... 2
2-1 Combination ..................................................................... 2
2-2 Spec list............................................................................ 3
2-3 Electricalspecications .................................................... 3
2-4 Accessories...................................................................... 3
3. BEFORE INSTALLATION.......................................................... 3
4. SELECTING INSTALLATION LOCATION ................................. 4
5. PRECAUTIONS DURING INSTALLATION ............................... 7
6. ELECTRICAL WIRING.............................................................. 8
6-1 Example of whole system wiring connection.................... 8
6-2 Precautions to lead out power wiring and
transmission wiring........................................................... 8
6-3 Precautions to power wiring connection........................... 9
6-4 Precautions to wiring connection between units .............. 9
7. REFRIGERANT PIPING CONNECTION ................................ 10
7-1 Installation tools ............................................................. 10
7-2 Selecting piping material ................................................ 10
7-3 Piping protection ............................................................ 10
7-4 Pipe connection.............................................................. 10
7-5 Precautions to refrigerant piping connection.................. 11
7-6 Piping insulation ............................................................. 12
7-7 System piping (length) limitations .................................. 12
7-8 Air tight test and vacuum drying..................................... 13
8. CHARGING REFRIGERANT .................................................. 14
8-1 Before charging refrigerant............................................. 14
8-2 About refrigerant tank..................................................... 14
8-3 Charging refrigerant ....................................................... 14
9. AFTER INSTALLATION COMPLETED ................................... 15
10. ABOUT TEST RUN ................................................................. 15
10-1 Powering on – test run ................................................... 15
10-2 For normal operation...................................................... 16
1. FIRST OF ALL
• Before installing the unit, read this manual thoroughly, and
following the instructions contained in it. After installation, do a
test run to make sure the unit runs properly, and then explain
how to operate and take care of the unit to the customer, using
the operation manual.
• Lastly, make sure the customer keeps this manual, along with
the operation manual, in a safe place.
• This manual does not describe how to install the indoor unit and
the remote controller. Refer to the installation manual included
with the indoor unit for that.
1-1 Safety precautions
Please read the these “Safety precautions” carefully before
installing air conditioning unit and be sure to install it correctly.
After completing the installation, make sure that the unit operates
properly during the start-up operation.
Please instruct the customer on how to operate the unit and keep it
maintained.
Also, inform customers that they should store this installation
manual along with the operation manual for future reference.
After completing installation, conduct a trial operation to check for
faults and explain to the customer how to operate the air conditioner
and take care of it with the aid of the operation manual.
Ask the customer to store the installation manual along with the
operation manual for future reference.
TheprecautionsdescribedhereinareclassiedasWARNINGand
CAUTION, following which is the important safety information, it is
strongly recommended to observe.
Meaning of WARNING and CAUTION notices
WARNING........ Failure to follow these instructions properly
may result in personal injury or loss of life.
CAUTION.........Failure to observe these instructions properly
may result in property damage or personal
injury, which may be serious depending on
the circumstances.
WARNING
• Askyourdealerorqualiedpersonneltocarryoutinstallation
work.
Do not attempt to install the air conditioner yourself. Improper
installationmayresultinwaterleakage,electricshocksorre.
• Install the air conditioner in accordance with the instructions in
this installation manual.
Improper installation may result in water leakage, electric shocks
orre.
• Consult your local dealer regarding what to do in case of
refrigerant leakage, when the air conditioner is to be installed in
a small room, it is necessary to take proper measures so that
the amount of any leaked refrigerant does not exceed the
concentration limit in the event of leakage. Otherwise, this may
lead to an accident due to oxygen depletion.
• Besuretouseonlythespeciedaccessoriesandpartsfor
installation work.
Failuretousethespeciedpartsmayresultintheunitfalling,
waterleakage,electricshocksorre.
• Install the air conditioner on a foundation strong enough to
withstand the weight of the unit.
Afoundationofinsufcientstrengthmayresultintheequipment
falling and causing injury.
• Carryoutthespeciedinstallationworkaftertakingintoaccount
strong winds, typhoons or earthquakes.
Failure to do so during installation work may result in the unit
falling and causing accidents.
• Make sure that a separate power supply circuit is provided for
thisunitandthatallelectricalworkiscarriedoutbyqualied
personnel according to local laws and regulations and this
installation manual.
Aninsufcientpowersupplycapacityorimproperelectrical
constructionmayleadtoelectricshocksorre.
• Makesurethatallwiringissecured,thespeciedwiresareused,
and that there is no strain on the terminal connections or wires.
Improper connections or securing of wires may result in abnormal
heatbuild-uporre.
• When wiring the power supply and connecting the wiring
between the indoor and outdoor units, position the wires so that
the EL.COMPO.BOX lid can be securely fastened.
Improper positioning of the EL.COMPO.BOX lid may result in
electricshocks,reortheterminalsoverheating.
• If refrigerant gas leaks during installation, ventilate the area
immediately.
Toxic gas may be produced if the refrigerant comes into contact
withre.
• After completing installation, check for refrigerant gas leakage.
Toxic gas may be produced if the refrigerant gas leaks into the
roomandcomesintocontactwithasourceofre,suchasafan
heater, stove or cooker.
• Do not directly touch refrigerant that has leaked from refrigerant
pipes or other areas, as there is a danger of frostbite.
• Be sure to switch off the unit before touching any electrical parts.
• Do not allow children to climb on the outdoor unit and avoid
placing objects on the unit.
Injury may result if the unit becomes loose and falls.
• Be sure to earth the air conditioner.
Do not earth the unit to a utility pipe, lightning conductor
or telephone earth lead.
Imperfectearthingmayresultinelectricshocksorre.
A high surge current from lightning or other sources
may cause damage to the air conditioner.
• Be sure to install an earth leakage breaker.
Failure to install an earth leakage breaker may result in electric
shocksorre.
01_EN_3P529410-2C.indd 1 12/11/2019 9:11:56 AM

2
CAUTION
• While following the instructions in this installation manual, install
drain piping to ensure proper drainage and insulate piping to
prevent condensation.
Improper drain piping may result in indoor water leakage and
property damage.
• Install the indoor and outdoor units, power cord and connecting
wires at least 1 meter away from televisions or radios to prevent
picture interference and noise.
(Depending on the incoming signal strength, a distance of
1metermaynotbesufcienttoeliminatenoise.)
• Remote controller (wireless kit) transmitting distance can be
shorterthanexpectedinroomswithelectronicuorescentlamps
(inverter or rapid start types).
Installtheindoorunitasfarawayfromuorescentlampsas
possible.
• Make sure to provide for adequate measures in order to prevent
that the outdoor unit be used as a shelter by small animals.
Small animals making contact with electrical parts can cause
malfunctions,smokeorre.Pleaseinstructthecustomerto
keep the area around the unit clean.
• Do not install the air conditioner in the following locations:
1. Where there is a high concentration of mineral oil spray or
vapour (e.g. a kitchen).
Plastic parts will deteriorate, parts may fall off and water
leakage could result.
2. Where corrosive gas, such as sulphurous acid gas, is
produced.
Corroding of copper pipes or soldered parts may result in
refrigerant leakage.
3. Near machinery emitting electromagnetic radiation.
Electromagnetic radiation may disturb the operation of the
control system and result in a malfunction of the unit.
4. Whereammablegasmayleak,wherethereiscarbonbre
or ignitable dust suspensions in the air, or where volatile
ammablessuchaspaintthinnerorgasolinearehandled.
Operatingtheunitinsuchconditionsmayresultinre.
5. Do not climb up the outdoor unit or place objects on it.
Falling or tumbling may result in injury.
6. Do not wash the outdoor or indoor unit with water.
Otherwise,itmaycauseelectricshocksandreharzards.
1-2 Special notice of product
[CLASSIFICATION]
This air conditioner comes under the term “appliances not
accessible to the general public”.
[EMC CHARACTERISTICS]
In a domestic environment this product may cause radio
interference in which case the user may be required to take
adequate measures.
[REFRIGERANT]
This series uses R410A refrigerant.
• The refrigerant R410A requires that strict precautions be
observed for keeping the system clean, dry and tightly sealed.
A. Clean and dry
Strict measures must be taken to keep impurities (including
SUNISO oil and other mineral oils as well as moisture) out of
the system.
B. Tight sealed
Take care to keep the system tight when installing.
R410Acontainsnochlorine,doesnotdestroytheozonelayer
and so does not reduce the earth’s protection against harmful
ultraviolet radiation.
R410A will contribute only slightly to the greenhouse effect if
released into the atmosphere.
• Since R410A is a mixed refrigerant, the required additional
refrigerant must be charged in its liquid state. (If the system is
charged with refrigerant in its gaseous state, due to composition
change, the system will not function normally.)
[DESIGN PRESSURE]
Since design pressure is 4.0MPa or 40bar, the wall thickness of
pipes should be more carefully selected in accordance with the
relevant local and national regulations.
1-3 Disposal requirements
Dismantling of the unit, treatment of the refrigerant, of oil and of
other parts must be done in accordance with relevant local and
national legislation.
2. INTRODUCTION
1. This series uses R410A refrigerant. Be absolutely sure to
comply with “7. REFRIGERANT PIPING CONNECTION”,
because even greater caution is needed to prevent impurities
from entering R410A (mineral oils and water).
2. The design pressure is 4.0MPa which means that piping may
be thicker than conventionally, so please refer to
“7. REFRIGERANT PIPING CONNECTION”.
3. This is a mixed refrigerant, so charge as a liquid when adding
refrigerant.
(If charged as a gas, the composition of the refrigerant may
change, preventing normal operation.)
4. The indoor unit must use R410A. See the catalog for indoor unit
models which can be connected. (Normal operation is not
possible when connected to other units.)
5. The power supply for the RZQ-M models is three phase,
380V-415V,50Hz.
2-1 Combination
• Be sure to connect a dedicated indoor unit. See the catalog
for indoor unit models which can be connected.
01_EN_3P529410-2C.indd 2 12/11/2019 9:11:57 AM

3
2-2 Spec list
Model RZQ180MY1 RZQ200MY1
Refrigerant R410A
Power supply 3N~380-415V50Hz
Cooling capacity
Heating capacity
(kw)
(kw)
18.0
20.0
19.5
22.4
Dimensions
(H × W × D) (mm) 1430 × 940 × 320
Mass (kg) 138
Connection
piping
Gas side (inch)
(mm)
3/4
Ø19.1
Liquid side (inch)
(mm)
3/8
Ø9.5
2-3 Electrical specications
Model RZQ180•200MY1
Power supply
Phase 3N~
Frequency (Hz) 50
Voltage (V) 380-415
Voltage tolerance range (%) ±10
Fuse rated current (A) 25
Outdoor unit maximum running current (A) 18.5
2-4 Accessories
Check if the following accessories are supplied with the unit.
(Remove the front plate and they are in the accessory bag)
Name Operation manual Installation manual Clamp
Quantity 1 pc. 1 pc. 2 pcs.
Shape
Name Gas side accessory
piping (1)
Gas side accessory
piping (2)
Quantity 1 pc. 1 pc.
Shape
Accessory bag
Front plate screw Front plate
3. BEFORE INSTALLATION
[Precautions to remove packaging (L-pillar)]
• Remove the packaging (L-pillar) used to protect the unit while
carrying from the right front part.
Follow the steps below to remove.
1. Remove the front plate screw.
2. Remove the packaging (L-pillar).
3. Installthefrontplatescrewtoxthefrontandtopplates.
Packaging (pallet)
Front plate
Front plate screw
Top plate
Packaging (L-pillar)
[About carrying]
Holdthe2handlesatbothsidesasshowninthegurebelowand
move it slowly.
(Payattentionnottotouchthensattheback.)
Exhaust grille
Outdoor unit
Conner
Inlet holes
Handles
(Front) (Back)
Note
Do not place your ngers into the inlet holes of the casing
while moving the unit. Failure to do so may result in
deformation. Only hold the corner of the unit with your hands.
Usetheaccessoriesorthespeciedpartstoinstalltherequiredparts.
01_EN_3P529410-2C.indd 3 12/11/2019 9:11:57 AM

4
4. SELECTING INSTALLATION LOCATION
(1) Select a location for installation that meets the following
conditions and get the customer’s approval.
• Good ventilation.
• Not disturbing the neighbors.
• No shelters of the small animals.
• Solid enough to support the weight and vibration of the unit
whichcanbeplacedhorizontally.
• Able to avoid raining as much as possible.
• Adequate space kept around the unit for installation.
• Outdoor piping and wiring within the allowable length range.
• Noriskofammablegasleaks.
(2) When installing in locations where there is a possibility of
strong wind, take the following measures.
•
If the strong wind with speed over 5m/s blowing to the exhaust
sideoftheoutdoorunit,thedecreasedairowrateand
re-absorbed exhausted gas (short circuit) etc. by the outdoor
unit will lead to:
- Decreased capability
- Increased frost during heating
- Operation stopped as high pressure increases
• Excessive strong wind continually blowing to the front
exhaust side of the outdoor unit will result in the fan reversing
at a high speed and being damaged. Refer to the
Intake grille
Install the outdoor unit with the
air outlet facing the building
wall, closure or wind shutter.
(Keep adequate space
and installation)
Make the exhaust
direction perpendicular
to the wind direction.
Air outlet
Strong
wind
Strong
wind
(3) When installing in locations where there is heavy snowfall,
take the following measures.
• Block up the base.
• Installsnowhoods(eldsupply).
• Remove the rear suction grille to prevent snow from
accumulatingonthens.
(4) If there is a risk of short circuit for the outdoor unit in the
ambient environment, use air ow direction adjustment
plate (eld supply).
(5) The refrigerant gas (R410A) is nontoxic, nonammable and
safe. It is necessary to take measures against to keep
refrigerant concentration from exceeding allowable safety
limits in a small room in the event of refrigerant leakage.
(6) An inverter air conditioner may cause home appliances
produce noise.
When selecting the location for installation, keep the air
conditioner and wiring a proper distance away from radios,
computersandstereoequipmentasshowninthefollowinggure.
Particularly for location with weak wave reception, be sure to keep
a distance of at least 3m between the indoor unit and the remote
controllers and place the power supply wiring and transmission
wiring in conduits, and connect the conduits to the ground.
In addition, use the shielded wires for all electric wires between
units.
Branch circuit
breaker (over
current circuit
breaker)
Branch circuit
breaker (over
current circuit
breaker)
Outdoor unit
Indoor unit
1.5m or more
1.5m or more
1.5m or more
1m or more
1m or more
Indoor unit
remote
controller
(7) Installation location.
[Precautions to side-by-side installation]
• Inthegurebelow,theconnectionpipingisleadoutfromthe
front and the bottom when installing side by side.
To lead out the piping from the right side of the outdoor unit.
(Unit : mm)
(7)-1 Where there is an obstacle on the suction side:
• No obstacle above
1. Stand-alone installation
•Obstacle on the suction side only
100 or more
•Obstacle on both sides
100 or more
100 or more
100 or more
2. Series installation (2 or more) (note1)
•Obstacle on both sides
100 or more
1000 or more
200 or more
100 or more
300 or more
• Obstacle above, too
1. Stand-alone installation
•Obstacle on the suction side, too
100 or more
1000 or more
500 or less
•Obstacle on the suction side and both sides
1000 or more
150 or more
500 or less
150 or more 150 or more
01_EN_3P529410-2C.indd 4 12/11/2019 9:11:58 AM

5
2. Series installation (2 or more) (note1)
•Obstacle on the suction side and both sides
1000 or more
300 or more
500 or less
100 or more
200 or more
100 or more
1000 or more
(7)-2 Where there is an obstacle on the discharge side:
• No obstacle above
1. Stand-alone installation
500 or more
2. Series installation (2 or more) (note1)
1000 or more
100 or more 100 or more
• Obstacle above, too
1. Stand-alone installation
500 or less
1000 or more
1000 or more
2. Series installation (2 or more) (note1)
500 or less
1000 or more
100 or more
1000 or more
100 or more
(7)-3 Where there are obstacles on both suction and discharge
sides:
Pattern 1
Where the obstacles on the discharge side is higher than the unit:
(There is no height limit for obstructions on the intake side.)
• No obstacle above
1. Stand-alone installation
100 or more
1000 or more
H
L
L>H
2. Series installation (2 or more) (note1)
1000 or more 300 or more
100 or more 100 or more
L>H
L
H
• Obstacle above, too
1. Stand-alone installation
The relations between H, A and L are as follows:
L A
L≤H
0<L≤1/2H 750
1/2H<L≤H 1000
H<L Setthestandas:L≤H.
(Note) Close the bottom of the installation frame to prevent
the discharged air from being bypassed.
A or more 250 or more
L
H
1000 or more
500 or less
2. Series installation (2 or more) (note1)
The relations between H, A and L are as follows:
L A
L≤H
0<L≤1/2H 1000
1/2H<L≤H 1250
H<L Setthestandas:L≤H.
(Note1) Close the bottom of the installation frame to prevent
the discharged air from being bypassed.
(Note2) Only two units can be installed for this series.
A or more 300 or more
L
H
1000 or more
500 or more
100 or more
01_EN_3P529410-2C.indd 5 12/11/2019 9:11:58 AM

6
Pattern 2
Where the obstacles on the discharge side is lower than the unit:
(There is no height limit for obstructions on the intake side.)
• No obstacle above
1. Stand-alone installation
L≤H
1000 or more 100 or more
H
L
2. Series installation (2 or more) (note1)
The relations between H, A and L are as follows:
L A
0<L≤1/2H 250
1/2H<L≤H 300
1500 or more A or more
H
100 or more 100 or more
L
• Obstacle above, too
1. Stand-alone installation
The relations between H, A and L are as follows:
L A
L≤H
0<L≤1/2H 100
1/2H<L≤H 200
H<L Setthestandas:L≤H.
(Note1) Close the bottom of the installation frame to prevent
the discharged air from being bypassed.
(Note2) If the distance exceeds that within the ( ), even L>H,
there is no need to set the base.
1000 or more
(1700)
A or more
H
L
1000 or more
500 or less
2. Series installation (2 or more) (note1)
The relations between H, A and L are as follows:
L A
L≤H
0<L≤1/2H 250
1/2H<L≤H 300
H<L Setthestandas:L≤H.
(Note1) Close the bottom of the installation frame to prevent
the discharged air from being bypassed.
(Note2) Only two units can be installed for this series.
(Note3) If the distance exceeds that within the ( ), even L>H,
there is no need to set the base.
1500 or more
(2200)
A or more
100 or more
H
L
1000 or more
500 or less
(7)-4 Double-decker installation
1. Obstacle on the discharge side (note1)
1000 or more
500 or more
100 or more
A
(Note 1) Do not stack more than two unit.
(Note 2) To prevent the drainage of the upper outdoor unit
frombeingfrozenatthebottom,puttheap(eld
supply) as A part.
(Note 3) Adequate space should be kept between the
upperoutdoorunit’sbottomplateandtheap.
(Note 4) Close the gap A (the gap between the upper and
lower outdoor units) to prevent the discharged air
from being bypassed.
2. Obstacle on the suction side (note1)
300 or more
500 or more
100 or more
A
(Note 1) Do not stack more than two unit.
(Note 2) To prevent the drainage of the upper outdoor unit
frombeingfrozenatthebottom,puttheap(eld
supply) as A part.
(Note 3) Adequate space should be kept between the
upperoutdoorunit’sbottomplateandtheap.
(Note 4) Close the gap A(the gap between the upper and
lower outdoor units) to prevent the discharged air
from being bypassed.
01_EN_3P529410-2C.indd 6 12/11/2019 9:11:59 AM

7
(7)-5 Multiple rows of series installation (on the rooftop, etc.)
1. One row of stand-alone installation
1000 or more
200 or more
2000 or more 100 or more
2. Rows of series installation (2 or more)
The relations between H, A and L are as follows:
L A
L≤H
0<L≤1/2H 250
1/2H<L≤H 300
H<L Cannot be installed.
1500 or more 600 or more 3000 or more A or more
L
100 or more
100 or more
100 or more
100 or more
100 or more
100 or more
H
(Note 1) When install the indoor units side by side, space
more than 100mm needs to be kept around them.
5. PRECAUTIONS DURING INSTALLATION
• To prevent vibration and noise, check the foundation is solid and
level before installation.
• Asshowninthefollowinggure,rmlysecuretheunittoa
stable base using anchor bolts.
(Prepare four sets of M12 foundation bolts, nuts and washers
each which are available on the market.)
• The foundation bolts should be inserted 20 mm.
20
Ground plan
[About drainage handling] : option parts
• Use the drain pipe to drain the water off.
• In the cold areas, drain the water off the outdoor unit freely.
(Ifusingthedrainpipe,thedrainedwaterwillfreezeonthe
foundation and adversely affect the heating effect.)
1. Insert the water drain pan (C) into the 4 projections of the
drain socket (A) and drain cover (B) respectively.
2. Insert the drain socket and the drain cover into the outlets
correspondingly and respectively (insert the drain socket (A)
into water outlet and drain cover (B) into water outlet
and ), then turn them clockwise for 40° around.
(A) Drain socket
projection
DRAIN PLUG KKPJ5G280
(B) Drain socket
projection
(C) Water drain pan
(Insert the drain socket and drain cover
into the water outlets correctly.
Otherwise, it will result in water leakage.)
(Ground plan)
Note
Check if the water drain pan (C) has been clasped to the
projections of the drain socket (A) and drain cover (B) reliably.
Being clasped improperly may lead to water leakage.
Projections
(4 places)
Projections
(4 places)
3. Connect the commercially-sold polyethylene tube
(inner diameter 25mm) to the drain socket (A).
(If the tube is so long that it nearly hangs down, secure it
properly to prevent the tube from being twisted or bent.)
4. Check there is no water leakage from water outlets ,
and .
Note
Ifthewateroutletiscoveredbythehangingbracketoroor,
block up the air conditioner and keep an interspace over
100m under the outdoor unit’s footing.
01_EN_3P529410-2C.indd 7 12/11/2019 9:11:59 AM

8
6. ELECTRICAL WIRING
CAUTION
To those doing electrical work
• Do not operate the unit before completing refrigerant piping
connection. (Failure to do so will result in compressor
malfunction.)
• Install the earth leakage circuit breaker. (Since this unit is
equipped with an inverter, to prevent malfunction of the earth
leakage circuit breaker itself, select the breaker that be
capable of handling high harmonics.)
6-1 Example of whole system wiring connection
• Be sure to install the earth leakage circuit breaker to prevent
electricshockandrehazard,etc.
• The electrical wiring must be installed by the trained electricians.
• Perform wiring connection in accordance with “Electrical Wiring
Diagram Label”.
Only conduct the wiring connection after turning off the branch
circuit breaker and the over current circuit breaker.
• Thegroundingimpedancemustbe4Ωorless.
• Set the earth leakage circuit breaker.
• Earth the indoor and outdoor units.
• Do not connect the earth wire to the gas pipes, water pipes,
lightning rods or telephone earth wires.
- Gas pipes:gasleakscancauseexplosionorre.
-
Water pipes : cannot be grounded if hard vinyl pipes are used.
- Telephone earth wires or lightning rods: the ground
potential when struck by lightning may get extremely high.
• Only use the copper wires.
• Be sure to turn off the power supply before performing the
electrical wiring work. Do not switch on the breakers until all
wiring work being completed.
• Install the earth leakage circuit breaker.
(Since this unit is equipped with an inverter, to prevent
malfunction of the earth leakage circuit breaker itself, select the
breaker that be capable of handling high harmonics.)
• Connect the power wiring and the power supply terminal blocks
asshowninthefollowinggureandtightentheclamps.
• Fuse models of the outdoor unit:
F1U (T6.3A/250V)
F6U (T3.15A/250V)
• The unit is equipped with an inverter. Always connect the earth
wire to discharge the unit and eliminate the impact on other
devices by reducing the noise generated from the inverter, and
to prevent the unit casing from being live due to electric leakage.
• Never install a phase advancing capacitor to improve the power
factor. (Installing a phase advancing capacitor will not improve
the power factor, but may cause the capacitor abnormal heating
and accidents.)
• For the wiring, use the designated electric wires and connect
rmly,thensecurethemwiththeaccessoryclampstoprevent
outside force from being applied to the terminal area (terminals
of the transmission wiring and earth wire connected on site).
For details, please refer to 6-3 Precautions to power wiring
connection.
• Do not tie the remaining wires in a bunch and tuck into the unit.
•
Place the electric wires in the conduits or plastic sleeves to prevent
them from being scratched by the edge of the knockout hole.
• Secure the electric wires with the accessory buckles to prevent it
from touching the piping and stop valves (Refer to 6-3 Precautions
to power wiring connection.)
CAUTION
• Use the sheathed wires for the power wiring.
• Do not route the weak electric wiring (remote controller wire
and wiring between units) together with the strong one
outside the air conditioner, keeping them at least 50mm
apart. Otherwise, being affected by the electrical noise
(external noise) may result in malfunction or breakdown.
• Be sure to connect the power wiring to the power supply
terminal blocks and hold it in place in accordance with
6-3 Precautions to power wiring connection.
• Hold the wiring between air conditioner units in place in
accordance with 6-4 Precautions to wiring connection
between units.
• Secure the electric wires using the accessory clamps to
prevent it from touching the piping, etc.
• After connecting the electric wires, lay the wires in a
smooth and regular way to avoid the electronic component
box cover being protruded, then close the cover tightly.
16V
BB
16V
220-240V
Power supply
Power
supply
Remote
controller
Branch circuit
breaker & over
current circuit
breaker (earth
leakage circuit
breaker)
Outdoor unit
Indoor unit
Earth
Earth
380-415V
6-2 Precautions to lead out power wiring and
transmission wiring
Lead out the power wiring (including the earth wire) from the power
wiring outlets at the sides, front or back of the units.
Lead out the electric wires between units from the wiring outlet,
piping outlet or knockout holes in the front of the units.
[Precautions when punching through the knockout
holes]
• Punch through the knockout holes with a hammer.
• After punching through the holes, it is recommended to coat the
holes at the edge and the area around them with anti-corrosion
paint to prevent rusting.
• Before leading the electric wires through the knockout holes,
scrape the burrs around the holes and wrap the wires with the
protective tape.
If small animals might enter the unit,
block off the knockout holes with sealing
material(eldsupply)
Burrs
Terminal block
Knockout holes
Outdoor unit PC board
terminals F1, F2
(TO IN/D UNIT)
Stop valve
mounting plate
Electric wires
between units
Electric wires
between units
Power wiring
(including the earth
wire)
Power wiring
(including the earth
wire)
Power wiring
(including the earth
wire)
When connecting
from the back
When connecting
from the side
When connecting
from the front
Clamps
(accessories)
Keep proper distance
Electric wires
between units
01_EN_3P529410-2C.indd 8 12/11/2019 9:12:00 AM

9
[Precautions for routing power wiring]
• Neverconnecttwoelectricwiresofdifferentsizestoonepower
supply terminal.
(Phenomenons such as loose electric wire connection may
cause abnormal heating.)
• For the electric wires connected to the power supply terminal,
use the crimp-style terminal with insulation sleeve. Otherwise,
connectthewiresofthesamesizetothesidesrespectivelyas
showninthegure.
Power wiring
Crimp-style terminal
Sheathed with the
insulation sleeve
Connect the
wires of the
samesizeto
the sides
respectively.
Never connect
two wires
together.
Never connect
two wires of
differentsize.
Phenomenons such as loose electric wire connection may
cause abnormal heating. Strictly follow the instructions below.
• Usethespeciedelectricwiresandsecurethemrmlywithout
applying external stress to the terminal block.
• Tighten the terminal screws with a suitable screwdriver.
Use of small screwdriver would damage the screw head and
could not achieve the proper tightening effect.
• Secure the terminal screws overtight may break them.
• Refer to the table below for the tightening torque of the terminal
screws.
Tighteningtorque(N•m)
M5 Power supply terminal 2.39~2.91
M4 Shield earthing 1.18~1.44
M3 Internal unit wiring terminal 0.8~0.97
6-3 Precautions to power wiring connection
WARNING
After the fuse is blown, ask the serving agency to replace it.
Do not replace the fuse by yourself. Otherwise, it may cause
accidents such as electric shock.
CAUTION
When using residual current operated circuit breakers, be sure
to use a high-speed type 100 mA rated residual.
Model Phase &
frequency Voltage Fuse rated current
Outdoor unit
maximum running
current
RZQ180∙
200MY1 3N~50Hz 380-415V 25A 18.5A
Note
• Select the power wiring in accordance with the local and
national regulations in your area by referring to the above table.
• Specicationsoftheeldpowerwiringshouldbeincompliance
with IEC60245.
• Use wire type H05VV when the protective conduits are used for
the power wiring.
•
Use wire type H07RNF when the protective conduits are not used.
• Only proceed with wiring work after turning off all the power.
• Always earth the unit in accordance with the local and national
regulations in your area.
Earth wire
Stop valve
mounting plate
Clamps (accessories)
F1
TO IN/D UNIT TO OUT/D UNIT
F2 F1 F2
Shielded part
Keep proper
distance
Electric wires
between units
Earth wire
(yellow/green)
Clamps
(accessories)
Power wiring
Note
After electrical work is completed, check to make sure there are no
loose connections for the connectors of each electrical component
in the electrical component box and the terminals.
6-4 Precautions to wiring connection between
units
• Connect the wiring between units of the single system as
shown in the gure below. (No polarity)
Terminal block (X2M)
Indoor unit
TO IN/D UNIT
F1
F1
F1F2
F2
F2
TO OUT/D UNIT
Using the
shielded 2-core
wire (no polarity)
Connecting to
the power supply
is forbidden
About length of the electric wires between units
Exceeding the following length may result in abnormal signal
transmission. Be sure to observe.
Max. wiring length 300m or less
Total wiring length 600m or less
Max. number of branches 16
01_EN_3P529410-2C.indd 9 12/11/2019 9:12:01 AM

10
Precautions to wiring connection between units
• Do not connect the power supply to the single-phase wiring
terminals.
Otherwise, the whole system will be damaged.
• The wiring from the indoor unit must be connected to the PC
board terminal F1/F2 (TO IN/D UNIT) of the outdoor unit.
• For the electric wires between units, after being secured within
the unit, wrap them together with the refrigerant piping connected
locallyusingtheprotectivetapeasshowninthegurebelow.
Liquid side piping
Gas side piping
Electric wires
between units
Insulating material
Protective tape
7. REFRIGERANT PIPING CONNECTION
7-1 Installation tools
To withstand the pressure and prevent entry of any impurities
into the air conditioning system, always use the special
installation tools for R410A.
Multi-purpose
gauge hose
• To withstand the pressure and prevent entry of
any impurities (mineral oils such as specialized
lubricating oil and moisture), be sure to use the
special installation tools for R410A.
(Screw specications for R410A and R407C are
different.)
Vacuum pump
• Make sure that the engine oil in the pump will not
ow backward into the air conditioning system
when the pump stops.
• Use the vacuum pump able to lower the pressure
to -100.7Pa (5Torr, -755mmHg).
7-2 Selecting piping material
• Do not use the pipes covered with sulfur, iron oxide, dust, cutting
oil, moisture or other contamination inside. (Better not to exceed
30mg/10m for the oil inside the pipes).
• Select a thickness for the refrigerant piping in accordance with
the local laws and regulations.
For R410A, the design pressure is 4.0 MPa.
• Use the refrigerant piping with its thickness complying with
Japan’s High-Pressure Gas Control Law (January 2003).
• Thicknessandsize:determinethembasedontheprecautions
forpipingsizeselectionontheback.
• While performing the piping work, make sure that the piping is
within the maximum allowable ranges for length, height in
difference and branch piping length listed on the back.
7-3 Piping protection
• Maintain and protect the piping to prevent moisture from getting
into and the entry of the impurities and dust, etc.
• Pay special caution when penetrating the copper pipes through
the walls till outside.
Location Installation schedule Protection measure
Outdoor
More than a month Pinch
Less than a month
Pinch or seal with tape
Indoor Random
7-4 Pipe connection
• Before removing the pinched piping (large)
1. Remove the valve lid, and check the stop valve is completely
closed.
2. Connect a vacuum gauge to the service port, and check
there is no residual pressure.
3. Cut off the pinched piping (small) with a vice, and check
there is no residual pressure again.
Clamp the lower
part of the cutting
part with the vice,
then wrench from
left to right to cut
off directly.
After cutting off,
check the residual
oil and gas coming
out from the
incision completely.
Cutting part
Piping under
the cutting part
Incision
Cut at the middle
of the pinched
piping (small)
using the vice’s
cutting part.
[ To open ]
1. Open the valve lid and turn the shaft counter clockwise with the
inner hexagon wrench (JISB4648).
2. Turn it until the shaft stops.
3. Tighten the valve lid. (Refer to the column “Tightening torque”
for the tightening torque.)
Service port
Valve lid
On
Off
Pinched piping (large)
Cut off here
Pinched piping
(small)
[ To close ]
1. Open the valve lid and turn the shaft clockwise with the inner
hexagon wrench (JISB4648).
2. Tighten the valve safely until it contacts with the gasket of the
valve body.
3. Tighten the valve lid. (Refer to the column “Tightening torque”
for the tightening torque.)
WARNING
While removing the pinched piping (large), the residual gas and
oil remained in the piping of the valve body may cause the stop
valvecracks,andtheamesofthelattermayresultinburns
also.
• Before brazing the removed pinched piping (large) and eld
piping connection
Take cooling measures for the stop valves (such as wrapping a
wet and dripless cloth to them). Failure to do so will result in
damage to the valve body and cause the system leaks.
• Brazing piping locally (liquid side and gas side)
1. Remove the two piping cover plates under the unit.
2. Whenbrazing,itisnecessarytopenetratetheelectrode
from the front of the unit and the welding torch from the right
sidetobrazewiththeamesfacingoutsideandavoidthe
compressor sound-proof material and other piping.
(Refertothegureonnextpage)
Note
1.Beforebrazing,peeloffthecautionlabelandcheckthere
is no residual tape.
Otherwise,itwilladverselyaffectthebrazing.
2.Brazetheliquidsidepiping(thin)andthegassidepiping
(thick) in order.
Brazingmethodsaresameforthetwo.
01_EN_3P529410-2C.indd 10 12/11/2019 9:12:01 AM

11
Welding torch
Electrode
Right
Front
Compressor sound-proof material
Welding torch
Top view
Gas side
Electrode Liquid side
Flames
• Be sure to charge nitrogen into the pipe when brazing.
Be sure to perform nitrogen purge or nitrogen charge when
brazing.Failuretodothiswillcreatelargequantitiesofoxidelm
on the inside surface of the pipes, which would adversely affect
the valves and compressors in the refrigerating system and
prevent the normal operation.
Note
• Whenchargingnitrogenbeforebrazing,thepressure
regulatormustbesetto0.02MPa(0.2kg•f/cm2or less: as a
slightbreezeonyourcheek).
• Donotchargeotherrefrigerantotherthanthespeciedone
for the refrigerating system.
• Do not charge the air for the refrigerating system.
CAUTION
Donotuseuxwhenbrazingtherefrigerantpiping.
Usethephosphorcopperelectrodewhichdoesnotrequireux
(BCu93P-710/795:ISO 3677).
(Fluxhasextremelyharmfulinuenceonrefrigerantpiping
system.Ifthechlorinebaseduxisused,itwillcausepipe
corrosionorinparticulariftheuxcontainsuorine,itwill
damage the refrigerant oil and adversely affect the refrigerant
piping system.)
Pressure-reducing valve
Locationtobebrazed
Refrigerant piping
Packing
Nitrogen
Nitrogen
Manual valve
• After nishing the piping connection and evacuation, be
sure to open the valves.
Operation with the stop valve closed will result in the
compressor malfunction.
Undersomecircumstances,thesoundofsizzlingwillnotbe
heard even the stop valves have been opened. This is not
malfunction.
7-5 Precautions to refrigerant piping connection
• Theeldpipingcanbeconnectedin4directions.
Front plate
Front plate screw
Piping cover plate
(front) screw
Piping cover plate
Front
Back
Bottom
Side
• While connecting downward, open up round holes (knockout
holes) by drilling through the central parts of the knockout holes
(4 places) with a Ø6mm bit.
Bit Central part of
the knockout hole
Knockout hole
Notch
Notch
• After drilling through the knockout holes, it is recommended to
coat the notches at the edge and the area around them with
anti-corrosion paint to prevent rusting.
• When leading the electric wires through the knockout hole, wrap
the wires with the protective tape to avoid damage.
Connect the piping forward
Gas side accessory
piping (1)
Gas side piping
(eldsupply)
Gas side accessory
piping (2)
Cut the piping to
the required length
Connect the piping backward
Gas side piping
(eldsupply)
Gas side accessory
piping (1)
Gas side accessory
piping (2)
Connect the piping sideward
Gas side piping
(eldsupply)
Gas side accessory
piping (1)
Gas side accessory
piping (2)
Cut the piping to
the required length
01_EN_3P529410-2C.indd 11 12/11/2019 9:12:02 AM

12
Connect the piping downward
Gas side piping
(eldsupply)
Gas side accessory
piping (1)
Cut the piping to
the required length
Precautions to piping connection
• Make sure the connection pipe does not come into contact with
the terminal cover of the compressor.
Adjusttheheightasshowninthebelowguretopreventthe
insulation material on the liquid side piping from contacting with
the cover.
In addition, make sure the connection pipe does not come into
contact with the compressor’s bolts and shell plate.
• If there is a possibility that the condensed water on the stop valve
mightowintotheindoorunitthroughgapsbetweenthe
insulation material and piping because the outdoor unit is located
higher than the indoor unit, caulk the gaps at the connection.
Compressor
Terminal cover
Caulking, etc.
Insulation material Bolt
[How to prevent entry of small animals]
• Caulk the piping through holes with putty or insulation material
(eldsupply)asshowninthebelowguretopreventgaps.
(For the outdoor unit, entry by insects could cause short circuit
of the electrical component box.)
Putty or insulation
material
(eldsupply)
7-6 Piping insulation
• If temperature within the ceiling exceeds 30ºC and the humidity
over RH 80%, thicken the insulation material of the refrigerant
piping. (Thickness at least 20mm)
(Condensation might form on the surface of the insulation
material.)
• The connection piping (liquid side, gas side) and the refrigerant
branch kit must be insulated.
(Otherwise, it may cause water dripping.)
(Be sure to use the insulation material with high-heat-
resistance performance as the gas side piping can reach
temperature of about 120ºC)
CAUTION
For piping connected locally, wrap the insulation material
till the root segment of the stop valve. The naked piping
may result in condensation and burns.
7-7 System piping (length) limitations
Example of connection
Main piping
between
indoor unit and
outdoor unit
Outdoor unit
Indoor unit
H1
Maximum allowable length
• Between outdoor unit and indoor unit.
Actual piping length Piping length between outdoor unit and
indoorunit≤100m
Total piping length Total piping length from outdoor unit to all indoor
units≥10m,≤300m
Allowable height difference
• Between outdoor unit and indoor unit.
Difference in height
Difference in height between outdoor unit
andindoorunit(H1)≤50m
(Max. 40m if the outdoor unit is in the lower part)
Selecting the piping size
[Precautions to select connection piping]
If the equivalent piping length between outdoor unit and indoor unit
isover90m,sizeofthemainpipeonthegassideandliquidside
must be increased.
Inaddition,dependingonthedistanceoftherefrigerantpiping,size
of the main pipe also can be increased if capability decreased.
[Gas side] Ø19.1mm→Ø22.2mm [Liquid side] Ø9.5mm→Ø12.7mm
Main pipe Indoor unit
Outdoor unit
Sizeincrease
Note
Toincreasethesizeofthepipingjoint(Ø19.1mm→Ø22.2mm and
Ø9.5mm→Ø12.7mm), connect it using joints of different apertures
(eldsupply).
In addition, connection part should be set beside the outdoor unit
(behind the 1st bending outside the unit).
01_EN_3P529410-2C.indd 12 12/11/2019 9:12:02 AM

13
How to calculate the additional refrigerant to be
charged
Additional refrigerant to be charged: R(kg)
(R should be rounded off in units of 0.1 kg.)
R=
(
Total length of
liquid side piping
sizeatØ12.7
)
×0.12 +
(
Total length of
liquid side piping
sizeatØ9.5
)
×0.059 +
(
Total length of
liquid side piping
sizeatØ6.4
)
×0.022
7-8 Air tight test and vacuum drying
Preparation
[Tools required]
Multi-tube
pressure
gauge charge
hose valve
• To prevent entry of any impurities and insure
sufcientpressureresistance,alwaysusethespecial
tools dedicated for R410A.
• To connect to the service port of the stop valves or
the refrigerant charge port, use the charge hose with
a pushing stick.
Vacuum pump
• Use a vacuum pump able to evacuate the system to
-100.7 kPa (5Torr, -755mmHg) or less for vacuum
drying.
• Takecarethepumpoilneverowsbackwardintothe
refrigerant pipe during the pump stops.
Check the following after piping connection is nished.
Air tight test
Always use nitrogen. (Refer to Stop valve operation procedure for
service port’s position.)
[Procedure]
Pressurizetheliquidsidepipingandthegassidepipingto4.0MPa
(do not exceed 4.0 MPa). If the pressure does not drop within 24
hours, the system passes the test.
If there is a pressure drop, check for leaks. (Discharge the nitrogen
afterconrmingthereisnoleakage.)
Vacuum drying
Use a vacuum pump able to evacuate the system to -100.7 kPa
(5Torr, -755mmHg) or less.
[Procedure]
Evacuate the system from the liquid side piping and gas side piping
using a vacuum pump for more than 2 hours to -100.7 kPa or less.
Keep the system under this condition for more than 1 hour, check if
the vacuum gauge indication rises or not.
(If it rises, the system may either contain moisture inside or have
gas leak.)
If moisture might enter the piping (e.g. if doing work during the
rainy season, if the actual work takes long enough that condensation
may form on the inside of the pipes, if rain might enter the pipes
during work, etc.)
Afterperformingthevacuumdryingfor2hours,pressurizeto
0.05MPa(vacuumbreakdown)withnitrogengas,thendepressurize
down to -100.7 kPa or less and hold for an hour using the vacuum
pump (vacuum drying).
(Ifthepressuredoesnotreach-100.7kPaevenafterdepressurizing
for at least 2 hours, repeat the vacuum breakdown-vacuum drying
process.) After vacuum drying, maintain the vacuum for an hour and
make sure the pressure does not rise by monitoring with a vacuum
gauge.
Vacuum pump
Indoor unit
Outdoor
unit
Field piping
system
Valve
(open)
Pressure-reducing valve
Liquid side stop valve (close)
Gas side stop valve (close)
Charge hose
Stop valve service port
Nitrogen
Note
Be sure to shut off the liquid side and gas side stop valves.
Otherwise, it may cause refrigerant leakage of the outdoor unit.
Stop valve operation procedure
Precautions to stop valve operation
• Name of each part should be know before operating the stop
valve(asshowinthebelowgure)Whenshipped,thestop
valve is left closed.
• Use proper tools.
Sincethestopvalveofthisunitisnotaringsealedtype,
remove it forcibly may result in damage to the valve body.
• When using the service port, adopt charge hose.
• After tightening the cap, check if the refrigerant leaks.
Service port
Shaft
Valve lid
<Liquid side>
To open
<Gas side>
To open
Shut off valve operation procedure
Prepare two inner hexagon wrenches.
To open
1. Put the inner hexagon wrench to the valve shaft and turn it
counterclockwise.
2. Turn it until the shaft stops. The valve is opened.
To close
1. Put the inner hexagon wrench to the valve shaft and turn it
clockwise.
2. Turn it until the shaft stops. The valve is closed.
About valve lid
• Be sure to tighten the valve lid after valve operation is
completed.
About service port
• Operate with the charge hose with a pushing stick.
• Be sure to tighten the valve lid after operating.
Tightening torque
Look through the table below for the stop valve tightening torque.
[Specications]
Liquid side stop valve Ø9.5mm
Gas side stop valve Ø19.1mm
01_EN_3P529410-2C.indd 13 12/11/2019 9:12:03 AM

14
[Tightening torque]
Size
(mm)
Tightening torque N·m (turn clockwise to close)
Shaft (stop valve body) Cap (valve lid) Service port
Ø9.5 5.4~6.6 Inner hexagon
wrench 4mm 13.5~16.5
11.5~13.9
Ø19.1 27.0~33.0 Inner hexagon
wrench 8mm 22.5~27.5
8. CHARGING REFRIGERANT
WARNING
• Be sure to inform other installers or attach the front panel
well before you leaving with the power supply turned on for
the outdoor unit.
(Raise the front panel as high as possible during installation
to clamp it with the top panel.)
8-1 Before charging refrigerant
• Check the following works are completed in accordance with the
installation manual.
• Piping work
• Electrical work
• Air tight test and vacuum drying
8-2 About refrigerant tank
• Check whether the tank has a siphon pipe before charging and
place the tank properly so that the refrigerant is charged in the
liquidphase(seethegurein8-3 Charging refrigerant).
8-3 Charging refrigerant
Electric shock warning
• Never touch other parts excluding the push buttons of the PC
board (A1P) during setting.
• There is a risk of electric shock if you touch wrong, since this
operation must be performed with the power on.
CAUTION
• Use protective equipment (groves and goggles) when charging
the refrigerant.
• To prevent the liquid hammer, the refrigerant must not be
charged over the allowable maximum amount.
• Do not perform the refrigerant charging operation when indoor
unit is under construction.
• Beware the fan running when opening the front panel.
The fan may continue rotating after the outdoor unit stops.
Note
• The refrigerant charge port is connected to the unit piping.
When shipped, the unit’s piping is charged with refrigerant, take
care when attaching the charge hose.
• After refrigerant charging is completed, secure the refrigerant
chargeportcaptightly,toatighteningtorqueof11.5~13.9N∙m.
• See stop valve operation procedure under “7. REFRIGERANT
PIPING CONNECTION” for details on Stop valve operation
procedure.
• When the refrigerant charging operation is completed or
paused, close the valve of the refrigerant tank immediately. If the
tank valve is left open, the amount of refrigerant which is
properly charged may be off the point. Because even if the air
conditioner stops, the refrigerant will be charged into the unit
under the residual pressure.
Stand the tank upright
and charge.
(Due to the siphon pipe
within the tank, there is
no need to turn over the
tank to charge).
Stand the tank
upside-down and
charge.
Charge refrigerant using tank with siphon pipe Charge refrigerant using other tanks
1. Calculate the refrigerant charge according to “How to calculate
the refrigerant to be charged” in “7. REFRIGERANT PIPING
CONNECTION”.
2. After completing vacuum drying, discharge the air in the charge
hose, then open the valve and charge the refrigerant of the
calculated amount in the liquid phase from the liquid side stop
valve service port.
3. Close the valve after completing refrigerant charging.
Note) If it is impossible to charge the amount calculated
according to above procedure, charge the refrigerant
again using procedure on the right.
State of the stop valves and valve A
• For operation instructions of the stop valves. refer to Stop valve operation
procedure in “7. REFRIGERANT PIPING CONNECTION”.
R410A tank
(with siphon pipe) Liquid side
stop valve
Valve A
Gauge
Indoor unit
Outdoor
unit
Gas side
stop valve
Stop valve
service port
ON/OFF state of the valve A and stop valves Valve A Liquid side
stop valve
Gas side
stop valve
Before starting charging OFF OFF OFF
During charging operation ON OFF OFF
If the refrigerant of the calculated amount is not charged fully
Perform refrigerant charging operation according to the following
procedure to charge refrigerant. For settings of refrigerant charging
operation, refer to the “Service Precautions” label attached under
the front panel of the electronic component box.
[Procedure]
1. Turn on the power supply of all indoor and outdoor units of the
system.
2. Open the gas side and liquid side stop valves and perform
refrigerant charging operation. (Open the valve A immediately
after compressor starts up.)
3. Afterchargingaspeciedamountofrefrigerant,pressthe
RETURN button (BS3) on outdoor unit’s PC board (A2P) to
stop refrigerant charging operation.
4. Close the valve after completing charging operation.
State of the stop valves and valve A
• For operation instructions of the stop valves. refer to Stop valve operation
procedure in “7. REFRIGERANT PIPING CONNECTION”.
• The service port (for refrigerant charging) is within the outdoor unit.
• Sincetheunitislledwithrefrigerantwhenshippedoutofthefactory,take
care while installing the charge hose.
• Be sure to close the service port cover (for refrigerant charging) after
completing refrigerant charging. Tightening torque of the service port cover is
11.5 ~ 13.9 N·m.
R410A tank
(with siphon pipe)
Service port
(for refrigerant charging)
Valve A
Gauge
Indoor unit
Outdoor
unit
Gas side stop valve
Liquid side stop valve
Stop valve
service port
ON/OFF state of valve A and stop valves Valve A Liquid side
stop valve
Gas side
stop valve
Before starting charging OFF ON ON
During charging operation ON ON ON
01_EN_3P529410-2C.indd 14 12/11/2019 9:12:03 AM

15
9. AFTER INSTALLATION COMPLETED
Be sure to check the following after installation
1. Precautions during installation
Refer to 5. PRECAUTIONS DURING INSTALLATION.
2. Incorrect power wiring connection and loose screws
Refer to 6-3 Precautions to power wiring connection.
3. Incorrect transmission wiring connection and loose screws
between units
Refer to 6-4 Precautions to wiring connection between units.
4. Incorrect refrigerant piping
Refer to 7. REFRIGERANT PIPING CONNECTION.
5. Pipingsizeandinsulation
Refer to 7-2 Selecting piping material, 7-6 Piping insulation.
6. Stop valves
Check if the liquid side and gas side stop valves are opened.
7. Record refrigerant charge
Keep a record in the “Refrigerant charge” in the “Service
Precautions” label.
8. Insulation test on main power circuit
•Use500Vinsulationtester.
•Donotuseitinlowvoltagecircuit.(Connectionwiring
between units, etc.)
CAUTION
To those doing piping work
• Be sure to open the stop valves after completing wiring
connection. (Operation with the stop valve closed will
result in compressor malfunction.)
10. ABOUT TEST RUN
To start smoothly, a crankcase heater is equipped to the unit.
To power up the crankcase heater, be sure to turn on the
power supply 6 hours before operation.
WARNING
Be sure to inform other installers or attach the
front panel well before leaving with the power
supply turned on for the outdoor unit.
(Raise the front panel as high as possible during
installation to clamp it with the top panel.)
Before powering on
• Indoor unit connected with the outdoor unit will operate
automatically after powering on.
To ensure safety, check the indoor unit installation has been
completed.
10-1 Powering on – test run
• Makesuretoperformatestrunrstafterinstallation.(Iftheunit
is operated with the indoor unit’s remote controller but without
performing test run, the malfunction code test “U3” will be
indicated on the display of the remote controller and the unit will
not operate normally.)
• After turning on the power supply, do not touch any parts
excluding button switches and changeover switches when
setting the outdoor unit’s PC board (A1P).
(For positions of the button switches (BS1~5) and changeover
switches (DS1-1~4) on PC board, refer to the “Service
Precautions” label.)
• Check the state of the outdoor units and fault wiring with this
operation.
1. • Attach the front panel of the
outdoor unit.
• Turn on the power supply of
the outdoor and indoor units.
CAUTION
To power up the crankcase heater
in advance, be sure to turn on the
power supply 6 hours before
operation.
2. • Remove the front panel of the outdoor unit.
• Check LED display of the outdoor unit’s PC board (A1P), to observe whether
data transmission is normal.
LED display
(factory setting)
SERVICE
MONITORING
LAMP
MODE
READY /
ABNORMAL IND MASTER SUB LOW NOISE
DEMAND
HAP H1P H2P H3P H4P H5P H6P H7P
j h h i h h h h
LED display: hLight OFF iLight ON jFlashing
Don’t touch the parts other than button switches and changeover switches
of the PC board (A1P) during setting. Failure to do so may result in electric
shock.
3. •
If customer wishes to perform
LOW NOISE operation or
DEMAND operation, perform
setting with the push buttons
(BS1~5) on outdoor unit’s PC
board (A1P).
(See the “Service Precautions”
label for details.)
Power supply has been turned on for
outdoor unit, be careful to avoid electric
shock.
• Set the push buttons (BS1~5) after
making sure the microcomputer normal
monitoring lamp has been ON.
• For setting method, see the “Service
Precautions” label attached to the front
panel of the outdoor unit.
(Be sure to keep a record of the setting
items in the “Service Precautions” label.)
4. •
Check whether the gas side
and liquid side stop valves
have been opened.
Open them if they are closed.
CAUTION
Operation with the stop valve
closed may result in compressor
malfunction.
5. Press TEST button (BS4) for
5 seconds or more to perform
test run.
See Test run precautions on
the “Service Precautions” label
for details.
• This display of the remote controller
indicates symbol if test run during this
operation.
• Ask other installers to perform test run or
attach the front panel before having to leave
the outdoor unit working alone.
• Test run is automatically stopped after about
15 minutes (maximum 30 minutes)
operation. (When charging the refrigerant of
calculated amount, test run is automatically
stopped after 30 minutes (maximum 1 hour)
operation.)
• If there is a malfunction code on the display
of the remote controller, please check the
malfunctioncodedetailsonpage16andx
the malfunction. After that, push and hold
the RESET button for 5 seconds.
Then make sure to perform a test run again.
• After test run is completed, If there is no
malfunction code on the display of the
remote controller, the unit can perform
normal operation 3 minutes later.
6. Be sure to attach the front panel of the outdoor unit after test run is completed.
[About test run]
• If the system is started within 12 minutes after turning on
the power supply using the remote controller, H2P will light
up and the compressor will not operate.
Before operating, always check whether the symbols indicated
on the LED display are those in the table under 10-1 Powering
on – test run 2.
• In order to ensure uniform refrigerant distribution, it may take up
to around 10 minutes for the compressor to start up after the
unit starting operation. This is not malfunction.
• Be sure to perform malfunction check for all indoor units.
After completing test run, operate the system normally with the
remote controller.
• Test run cannot be performed when the unit is in other modes
such as refrigerant recycling mode.
• Never perform test run with suction pipe thermistor (R2T),
discharge pipe thermistor (R3T) and pressure sensor (S1NPH,
S1NPL) removed. Failure to do so will result in compressor
damaged.
01_EN_3P529410-2C.indd 15 12/11/2019 9:12:03 AM

16
10-2 For normal operation
[About normal operation check]
• The compressor will not restart in about 5 minutes even if the
ON/OFF button of the remote controller is pressed.
• When the system operation is stopped by the remote controller,
the outdoor unit may continue operating for future 1 minute at
maximum.
• If any check operation was not performed through test run at
rstinstallation,themalfunctioncode“U3”willbedisplayed.In
this case, perform check operation in accordance with
10-1 Powering on – test run.
[Malfunction codes displayed on the remote controller]
(check the remote controller connected with the indoor unit)
Malfunction
code
Installation error Solution
e3 The outdoor unit stop valve is
left closed
Open the gas side and liquid
side stop valves.
f6 The refrigerant is overcharged
Recalculate the piping length
and refrigerant charge, and
recover the excessive refrigerant
with a refrigerant recovery
device, to bring the refrigerant
amount to a normal level.
e4
The outdoor unit stop valve is
left closed
Open the gas side and liquid
side stop valves.
Therefrigerantisinsufcient
Check if the refrigerant has
been charged.
Recalculate the additional
refrigerant charge based on
thepipinglengthandrellto
the adequate amount.
f3
The refrigerant is overcharged
Recalculate the piping length
and refrigerant charge, and
recover the excessive refrigerant
with a refrigerant recovery
device, to bring the refrigerant
amount to a normal level.
The outdoor unit stop valve is
left closed
Open the gas side and liquid
side stop valves.
Therefrigerantisinsufcient
Check if the refrigerant has
been charged.
Recalculate the additional
refrigerant charge based on
thepipinglengthandrellto
the adequate amount.
u2 Undervoltage power supply Check if the power voltage is
normal while powering on.
u3 Not performing test run Perform test run.
u4 No power is supplied to
outdoor unit
Properly connect the power
cord of the outdoor unit.
ua
Not using dedicated indoor unit Check if the indoor unit is
special. If not, replace it.
Multiple indoor units are
connected.
Only 1 indoor unit which forms
a matched pair can be
connected to this model.
The indoor units able to be
paired are listed below.
180 Class: FDYQN180LCV1
200 Class: FDYQN200LCV1
uf
The outdoor unit stop valve is
left closed
Open the gas side and liquid
side stop valves.
Not properly connecting the
designated indoor unit’s piping
and wiring to the outdoor unit.
Check if the designated indoor
unit’s piping and wiring have
been properly connected to
the outdoor unit.
uh
No wiring connected between
units Wiring between units
short-circuit
Properly connect the wiring
between units to the terminal
F1 · F2 (TO IN/D UNIT) on the
outdoor unit’s terminal board.
• Forthecasewithcentralizedcontrollerused,refertothe
installation manual included with it under service manual.
[No display on the remote controller]
• Connection and communication error occured between the
indoor unit and the remote controller. Check wiring connection
for the broken and loose.
CAUTION
To those doing piping work, To those doing electrical work
• After test run is completed, check whether the casing of the
units has been attached and whether the screws have been
tightened before transferring the air conditioner to your
customer.
01_EN_3P529410-2C.indd 16 12/11/2019 9:12:03 AM

17
MEMO
01_EN_3P529410-2C.indd 17 12/11/2019 9:12:03 AM

3P529410-2C M19N103A (1912) HT
The two-dimensional bar code is
a manufacturing code.
00_CV_3P529410-2C.indd 2 12/11/2019 9:06:41 AM
