Dakota Micro DMOV-RHPAIR User manual

Dakota Micro, Inc.
Rev:06/29/17 Page1of12 Author:CNR

UsersManual
OverView®WirelessComponentsUsersManual
PartNumber(s): RHPAIR,RHTX&RHRX












Reliable Profitable Capable








Alwaysreadthemanualpriortooperatingthisequipment.Also,pleasefollowallsafetysignsandprecautions.
SeetheDakotaMicro,Inc.websiteforinstallationtrainingvideosatwww.dakotamicro.com.

TableofContents

I. BeforeyouInstall 2
II. AvailableKits 2
III. IncludedWirelessComponents 2
IV. StandardFeatures 3
V. PartsofaWirelessSystem 3
A. StandardWirelessInputs(front) 3
B. StandardWirelessInputs(Rear) 3
VI. ExternalAntennas 4
VII. Installation 5‐6
A. InstallationTips 5
B. TransmitterInstallation 6
C. ReceiverInstallation 6
VIII. EmissionsNotifications 7
IX. Specifications 8
X. Warnings 9
XI. ProductWarranty/RepairProcess 10
XII. ConsumerLimitedWarranty 11
XIII. Disclaimer 12
XIV. ContactUs 12
MORE

Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page2of12 Author:CNR
I. BEFOREYOUINSTALL
 Alwaysreadthemanualspriortooperatingthisequipment,&pleasefollowallsafetysignsandprecautions.See
DMwebsiteforinstallationtrainingvideosatwww.dakotamicro.com.

 Inordertobetterunderstandyournewwirelessequipment,werecommendthatyoupowerbothyour
transmitterandreceiverinanindoor,controlledlocation(i.e.fromonesideofaroomtoanother)tobetterget
acquaintedwiththeequipmentbeforeinstallingitinitspermanentlocation.

II. AVAILABLEKITS
PN:DMOV‐RHPAIRKitIncludesPN’s:
DMOV‐RHRX
DMOV‐RHTX

NOTE:Eachtransmittermayonlytransmitsignalfromonecamera,howeveryoumayreceivethatsignalon
multiplereceivers.

III. INCLUDEDWIRELESSCOMPONENTS

(PERPN:DMOV‐RHTX) (PERPN:DMOV‐RHRX)



Description Picture Description Picture
WirelessTransmitter

WirelessReceiver

3dBiWireless
Antenna

3dBiWireless
Antenna

RCAAdaptor

RCAAdaptor

A/CPowerWallPlug
PowerAdaptor
PN:DMAC‐PA

(stylesvarybykit)
A/CPowerWallPlug
PowerAdaptor
PN:DMAC‐PA

(stylesvarybykit) 
12vCigaretteLighter
PowerAdaptor

PN:DMAC‐12v
(stylesvarybykit)
12vCigaretteLighter
PowerAdaptor

PN:DMAC‐12v
(stylesvarybykit) 

Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page3of12 Author:CNR
IV. STANDARDFEATURES
 AllowsforeasywirelessupgradeforyourOverViewsystem
 YourreceiverisconvenientlypoweredfromyourOverViewmonitorformobileapplications
 EasyaccessRCAoutputjacksenableyoutodirectlyviewyourimageonyourowntelevision
 Youcanhaveasmanyas4cameraswireless
 Alltransmitters&receiversareavailableindividually
 WaterproofTransmitterscanbemountedoutsideinhot,coldorwetconditions
 Transmitsonpowerfulandreliable2.4GHzbandwidth
 Optionalantennasallowyoutoviewcamerasupto3+milesaway(withlineofsight)

V. PARTSOFAWIRELESSSYSTEM


A. StandardWirelessInputs(front)
ForadditionalvideofeaturesotherthanOverView®

Transmitter(PN:DMOV‐RHTX)
1. Covered‐Externalaudioinputnotavailableonthismodel
2. Externalvideoinput

Receiver(PN:DMOV‐RHRX)
1. Covered‐Externalaudiooutputnotavailableonthismodel
2. Externalvideooutput
B. StandardWirelessInputs(rear)

Transmitter(PN:DMOV‐RHTX)
1. PowerOnIndicatorLED
2. DCPowerIN(2000mA)
3. Powerouttocamera.Videosignalinfromcamera.
4. AVchannelselect(4channels)–toggledowntoselect
channel,setTransmitterandReceivertosamechannel.
5. AntennaInput(ReverseSMA)
6. 3dbAntenna

Receiver(PN:DMOV‐RHRX)
1. PowerOnIndicatorLED
2. DCPowerIN(300mA)
3. Powerinfrommonitor.Videosignalouttomonitor.
4. AVChannelSelect(4channels)–Toggledowntoselect
channel,setTransmitterandReceivertosamechannel
5. AntennaInput(ReverseSMA)
6. 3dbAntenna 

NOTE:Onreceiver,nopoweradaptorshouldbeusedwhenpluggedintoOverView®monitor,asthemonitorwillsupplythepower,an
DakotaMicro,Inc.1500mA(orgreater)adaptormustbeusedonOverView®monitorpowerinput.


Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page4of12 Author:CNR

VI. EXTERNALANTENNAS

IncludedAccessory‐Standard3dBiAntenna(includedaccessory)MaximumDistance‐2,000'(feet)
BENEFITS
 Small
 Noextracost
TIPS
 ShorttransmitterandReceiverdistance
 Noadd‐onextensioncable
AvailableAccessory‐MagnetMount5dBiAntennaw/6’cable(PN:DMAC‐WA5)MaximumDistance1‐2miles
BENEFITS
 MagnetMountisgreatformobileapplications
 LowCost
TIPS
 Extrametalplateneededforplasticcabs
 Noadd‐onextensioncable
AvailableAccessory‐8dBiOmni‐DirectionalAntennaw/20’cable(PN:DMAC‐WA8)MaximumDistance2‐3miles
BENEFITS
 Sturdyconstruction
 Additionalextensioncablesavailable
TIPS
 Omni‐directionalsignaloperateslikea“fan”so
thatthesignalwillnotbereceived/transmitted
directlybeloworabove

AvailableAccessory‐8dBiDirectionalAntennaw/20’cable(PN:DMAC‐WA8P)MaximumDistance4‐5miles
BENEFITS
 Fulltransmissionaimedinonedirection
 Canbemountedonsideofbuildings
TIPS
 Transmitsand/orreceivesinonedirectiononly

AntennaNotes:LineofsightisVERYimportantwiththiswirelessequipment.Ifthewirelessistobeusedinabuildingwithsteel
sheeting,orifitistobeusedinanareawhereobstructionsneedtobeclearedforlineofsitesignal,youmayneedtouseoneofthe
abovelistedavailableaccessoryantennas.Theuseofanyantennaotherthanonesspeciallytunedtothefrequencyofthewirelesswill
likelyresultinpoorperformanceandmaycausedamagetotheunit.Whenselectinganantennaitishighlyrecommendedtomatchthe
antennaonbothtransmitterandreceiverforbestresults.


Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page5of12 Author:CNR

VII. INSTALLATION

A. InstallationTips
 TheDakotaMicrowirelessadd‐onisapowerfulwirelessaudio/videotransmitter,whichwillallowyoutoviewareasout
ofreachofcables.Inselectingalocationforthetransmitterusethefollowingguidelines.Trainingvideosareavailableon
theDakotaMicrowebsiteatwww.dakotamicro.com.

 Locationwithin2,000feetofreceiverlocation(unlessusinglargerantennas).

 Lineofsite,meaningthatthereisnoobstruction,suchasabuildingortreebelt.Shorterrangesfewerthan300feet,are
lesscriticalof“lineofsite”.However,steelbuildingsandsteelwallswillinterferewiththesignal.Wallsconstructedof
woodandsheetrockaremoretransparenttothesignal.Theabilityforthesignaltopenetrateglassdependsuponifthe
glassisleadlined.Thereareseveralenvironmentalconditions,suchashighpoweredelectricallines,otherwireless
devicesignalsfromcellphonecompanies,governmentagenciesandradiostations;forexample,thatmayaffectthe
rangeoftransmission.ThereforeDMcannotguaranteeanyspecificranges.

 Standardtransmittersandreceiversmustbeinstalledindoorsinadrylocation.Forsteelbuildings,youmustusean
externalantenna.Waterprooftransmittersmaybeinstalledoutsideintheweather/rain.

 YoumayuseAgCam®cablestomountcameraupto160feetfromtransmitter.HoweverDakotaMicro,Inc.power/video
cablesarenotabletocarryaudiosignal.Ifyourequireaudio,youmustobtainspecialcablesfromyourdealer.



Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page6of12 Author:CNR

B. TransmitterInstallation
WhenbeingusedwithanOverView®Camera:
1) Attachsupplied3dBiantenna(1)oroptional
largeraccessoryantenna(detailsonpage4of
manual).
2) PlugintheprovidedA/Cpoweradaptorintorear
oftransmitter(2),thenplugintooutlettopower.
3) PlugtheOverView®cameradirectlyintothe
wirelesscamerainput(3)
4) Extensioncablesmaybeusedtolocatethe
cameraawayfromthetransmitterforadistance
ofupto160feet.
5) Thetransmittermusthaveonlyoneinputusedat
atime;eitherbyfrontRCAinputsorcamerainput
(3).
C. ReceiverInstallation
WhenbeingusedwiththeDakotaMicro,Inc.
monitor:

1) PlugtheOverViewconnectorintooneofthe
availablemonitorconnectors(1).
2) Powerthemonitorasinstructedinthemanual
(2).OnlyusetheACadaptorsuppliedwithyour
monitor.





IMPORTANT:Powermustbeavailableforboththetransmitterandreceiver.Useonlytheprovidedpowersupplyordamagewill
occur.DONOTusethefrontinputsandtheOverView®(rear)inputatthesametime,asseriousdamagewilloccurtothe
transmitter.However,bothoftheoutputsofthereceivermaybeusedatonetimeforsimultaneousdisplayonaTVand
OverView®monitor.Donotallowthetransmitterorreceivertogetwet.



Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page7of12 Author:CNR

VIII. EMISSIONSNOTIFICATIONS

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.
Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipment
generatesusesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning
theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
 Reorientorrelocatethereceivingantenna.
 Increasetheseparationbetweentheequipmentandreceiver.
 Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
 Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
InordertocomplywithFCCrulesforprotectionagainstradiofrequencyexposure,thisdevicemustbeinstalledinamannerto
provideaminimumseparationof20cm(8”)betweentheantennaandallpersons.

ChangesormodificationsnotexpresslyapprovedbyDakotaMicrocouldvoidtheuser'sauthoritytooperatetheequipment.

Canada
Thisdevicehasbeendesignedtooperatewithanantennahavingamaximumgainof15dBi.Antennashavingahighergainisstrictly
prohibitedperregulationsofIndustryCanada.Therequiredantennaimpedanceis50ohms.

Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcauseinterference,and(2)thisdevicemustacceptany
interference,includinginterferencethatmaycauseundesiredoperationofthedevice.

Toreducepotentialradiointerferencetootherusers,theantennatypeanditsgainshouldbesochosenthattheEquivalent
IsotropicallyRadiatedPower(EIRP)isnotmorethanthatrequiredforsuccessfulcommunication.

TheinstallerofthisradioequipmentmustensurethattheantennaislocatedorpointedsuchthatitdoesnotemitRFfieldinexcess
ofHealthCanadalimitsforthegeneralpopulation;consultSafetyCode6,obtainablefromHealthCanada’swebsitewww.hc‐
sc.gc.ca/rpb.


Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page8of12 Author:CNR
IX. SPECIFICATIONS

A. Transmitter 
Frequency Ch1‐2.411GHz/CH2‐2.431GHz/CH3‐2.451GHz/CH4‐2.471GHz@100mw
Channel 4Selectablechannels
VideoInputSignal

Video‐1Vp‐p(NTSC/PAL)
Audio‐1Vp‐p(NTSC/PAL)
VideoInputImpedance Video‐75ohms
Audio‐600ohms(NTSC)/10Kohms(PAL)
A/VConnections A/Vjack‐RCAtoRCAlinejacks(notavailableonWaterproofversion)
Or‐OverView®cameraplug
Antenna DipoleAntenna(Detachable:Optionalantennasavailable)
OperatingVoltage DC9V‐12V/1500mApoweradaptor
TempLimit Nottoexceed120°F
B. Receiver
Frequency Ch1‐2.411GHz/CH2‐2.431GHz/CH3‐2.451GHz/CH4‐2.471GHz@100mw
Channel 4selectablechannels
A/VConnections A/Vjack‐RCAtoRCAlinejacks
Antenna DipoleAntenna(Detachable:Optionalantennasavailable)
OperatingVoltage DC9V‐12V/1500mApoweradaptor(use1200Maadaptorwhenusedw/OverViewmonitor)



Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page9of12 Author:CNR
X. WARNINGS

 WhenselectingacamerasystemfromDakotaMicro,besuretoutilizetheappropriatesystemforyouruse.AgCamand
EnduraCamcamerasaredesignedforhighimpact,moisture,vibrationandavarietyofotherroughconditions.
OverViewcamerasandkitcomponentsaredesignedforlightuse,lowvibrationandlowmoisture.OverView
equipmentisnotwarrantedwhenusedinsituationsoutsideoftheabovementionedparameters.Wealwaysrequest
thatcustomerskeepinmindthatourlessexpensiveOverViewproductlineischeaperbecauseitdoesnotfeaturethe
reliabilityanddurabilityofourAgCamandEnduraCamlines.Thewarrantyavailableontheseproductsreflectthat
durability.

 Toavoidelectricalshockandmaintainoptimalfunctionality,donotopentheenclosures.Highvoltagemaybepresent
andtherearenouserserviceablepartsinside.Allwarrantieswillbevoidshouldanyenclosuresbetamperedwithin
anyway.

 Donotuseanyharshchemicalsolvents,cleaningagentsorcorrosivedetergenttocleanawaydirtonthesurfaceofthe
screenorlens.

 OnAgCamandEnduraCamproducts,thephoto‐chromiccameralenseshavebeenmadeimpact‐resistantandhave
beendrop‐balltestedaccordingtoSec.3.84,21CRFBUTARENOTUNBREAKABLE.Becausetheyhavebeenhardened
chemically,theyshownostresspattern.Inspectyourlensesfrequently.Chippedorscratchedsurfaceswillreduce
protection.Suchlensesshouldbereplacedonlybythemanufacturer.

 Powertocamerasisnotinterruptedbyturningoffmonitor;12vpowersourcemustbeterminatedwhennotinuseto
avoidbatterydrain.Toavoidthisproblembesurewhenhardwiringaunit,useafusedcircuit.

 DonotuseyourDakotaMicrocamerasystemforanythingotherthanlegalsurveillanceandobservationuses.Dakota
Micro,Inc.isnotliableforanyillegalornefarioususage.


Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page10of12 Author:CNR
XI. PRODUCTWARRANTY/REPAIRPROCESS

1. ForTechnicalSupportcall1701‐538‐4403ORemail[e-mail]

2. Technicianwillassistintroubleshootingproductmalfunction.

3. Ifproductmalfunctioncannotberemediedandarepairisdeemednecessary,TechnicianwillissueaRepairAuthorization
(RA)number.
IMPORTANTNOTE:
TheTechnicianwillnoteontheRAformiftherepairAPPEARStobeawarrantyornon‐warrantyissuebasedoncustomerdescription
oftheissuesathand.Nofinaldeterminationcanbemadeuntilinspectionandtestingoftheequipmentiscompletedatthefactory.

4. Toensurefastandeffectiverepairs,customerisrequiredtosend:
 DakotaMicroProductthatTechnicianhasrequested/deemednecessaryintheproperdiagnosisandrepairof
malfunction.Thismayincludesomeorallcomponentsofthekit.
 Original/Copyofpurchasereceipt.
 ForserializeditemsONLY;Ifacopyoftheoriginalpurchasereceiptcannotbeprovided,thenDAKOTAMICROwilluse
theproductmanufacturedate.
 Customerinformation,includingreturnaddress&phonenumber.Ifthephonenumberisnotincluded,thecustomer
willbesentaletterrequestingtheneededinformation.
 RANumberprovidedbyDakotaMicroTechnicalSupport
 ShippingandassociatedcoststoshipproducttoDMfactorytobebornebythecustomerunlessotherwisespecified.

5. Customershouldmailproductto:
DakotaMicro,Inc.
RA#XXXXX
8659148thAve.SE
Cayuga,ND58013

6. UponreceiptandevaluationofproductatDakotaMicroFactory,itwillbeestablishediftherepairiswarrantyornon‐
warranty.Ifrequested,customerwillbecalledandnotifiedofanyapplicablecharges.

7. Iftherepairsaredeemednon‐warranty,andrequireaservice/repairfeeofanykind,acreditcardnumberwillberequested
byOrderProcessingaftertherepairiscompleted.

8. Ifcustomerisunabletobecontactedoverthecourseof3weeksregardingrequirednon‐warrantyrepairs,productwillbe
returned,unrepaired,tothecustomer.

9. Anyproductreturnedwithoutproperdocumentationmaybereturnedatcustomer’sexpense.

10. Productreturnedwithunconfirmedproblemswillbeassesseda$60evaluationfeeperunit

11. Returnshippingcostswillbebornebythepartyatfault;inotherwords,ifDakotaMicrodeterminesthatthedefective
productwascoveredunderwarranty,DakotaMicropaystheshippingcharges.IfDakotaMicrodeterminesthatitwasthe
customersfault,thecustomerwillpayshippingcharges.Ifaparticularcircumstancecannotbedeterminedthanthecostof
shippingchargeswillbedecidedonadiscretionarybasisdependingonthesituationathand.



Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page11of12 Author:CNR

XII. CONSUMERLIMITEDWARRANTY

Subjecttothedisclaimer,limitationsandotherdirectionsstatedhereafter,DakotaMicro,Inc.warrantsthattheProductwillbefreefromdefectsin
materialandworkmanshipforperiodsasstatedhereafterfromthedateoforiginalpurchase.THISWARRANTYISEXPRESSLYMADEINLIEUOF
ANYANDALLOTHERWARRANTIES,EXPRESSORIMPLIED,INCLUDINGTHEIMPLIEDWARRANTIESOFMERCHANTABILITYORFITNESS.THE
EXCLUSIVEREMEDYOFTHEBUYERISLIMITEDTOREPAIRORREPLACEMENTOFTHEPRODUCT.EXCEPTASSTATEDINTHISWARRANTY,
DAKOTAMICROSHALLNOTBELIABLEFORANYLOSS,INCONVENIENCE,ORDAMAGE,INCLUDINGDIRECT,SPECIAL,INCIDENTAL,OR
CONSEQUENTIALDAMAGES,RESULTINGFROMTHEUSEORINABILITYTOUSETHEPRODUCT,WHETHERRESULTINGFROMBREACHOF
WARRANTY,NEGLIGENCE,STRICTLIABILITYOFANYOTHERLEGALTHEORY.Anyoralstatementsorrepresentationsmadebyanyonewhichare
contrarytooratvariancewiththetermsstatedinthisLIMITEDWARRANTYarevoid.

DakotaMicrowill,atitsoption,eitherrepairthedefectorreplacethedefectiveProductorpartthereofwithaneworremanufacturedequivalent
atnochargetothepurchaserforpartsorlaborfortheperiodofthree(3)yearsforAgCam®/EnduraCam®andInnoPro®cameras;two(2)yearsfor
AgCam®/EnduraCam®monitors,andWirelesscomponents;TwelveMonths(12)forallOverviewCameras&Monitors,cablesandallother
accessories.
TheDakotaMicrolimitedwarrantyperiodsoutlinedaboveapplythroughouttheUnitedStatesandCanadaonly.Aone(1)yearmaximumlimited
warrantyforallProductsappliestoallothergeographiclocationsunlessotherwisestatedinwritingbyDakotaMicro.
ThislimitedwarrantydoesnotapplytoanyissuesconnectedwithappearancethathavenorelationtotheperformanceoftheProductnortoany
Producttheexteriorofwhichhasbeendamagedordefaced,whichhasbeensubjectedtoimpropervoltageorothermisuse,abnormalserviceor
handling,orwhichhasbeenalteredormodifiedindesignorconstruction.
Inordertoenforcetherightsunderthislimitedwarranty,thepurchasershouldfollowthestepssetforthinthecompleteDakotaMicro“Warranty
&RepairPolicy”listedonpage11‐sectionXI,andprovideproofofpurchasetoDakotaMicro.
NeitherthesalespersonnelofDakotaMicronoranydealeroranyotherpersonisauthorizedtomakeanywarrantiesotherthanthosedescribed
herein,ortoextendthedurationofanywarrantiesbeyondthetimeperiodsdescribedherein.
ThewarrantiesdescribedhereinshallbethesoleandexclusivewarrantiesandremediesprovidedbyDakotaMicro.Correctionofdefects,inthe
mannerandfortheperiodoftimedescribedherein,shallconstitutecompletefulfillmentofallliabilitiesandresponsibilitiesofDakotaMicrotothe
purchaserwithrespecttotheProduct,andshallconstitutefullsatisfactionofallclaims.InnoeventshallDakotaMicrobeliableorinanyway
responsibleforanydamagesordefectsintheProductwhichwerecausedbyrepairsorattemptedrepairsperformedbyanyoneotherthanDakota
Micro.
Somestatesdonotallowthelimitationorexclusionofincidentalorconsequentialdamages,sosaidlimitationmaynotapplytoyou.
Anyactionatlaw,suitinequity,orotherjudicialproceedingfortheenforcementofanyrightprovidedforhereinorotherwise,orwithrespectto
anyclaimthatapurchasermayhaveagainstDakotaMicroshallbeinstitutedonlyintheCourtsoftheStateofNorthDakota,eitherinthestate
districtcourtlocatedinWahpeton,NorthDakotaorinFederalDistrictCourtlocationinFargo,NorthDakota.Withoutregardtoconflictsoflaw
principles,thelawsofthestateofNorthDakotashallgoverntheinterpretationandenforcementofthetermsofthisLimitedWarrantyandall
aspectsoftherelationshipbetweenDakotaMicroandthepurchaser.
Thiswarrantygivesyouspecificlegalrightsandyoumayalsohaveotherrights,whichmayvaryfromstatetostate.


Dakota Micro, Inc. DMOV-RHUserManual
Rev:06/29/17Page12of12 Author:CNR

XIII. DISCLAIMER

DakotaMicroInc.products,specifications,pricingandprogramsaresubjecttochangewithoutpriornotice.DakotaMicro
Inc.reservestherighttomakedesignchangesatanytimewithoutobligationtoretroactivelyinstallthemonpreviouslysoldunits.
XIV. CONTACTUS
Dakota Micro, Inc.
8659148thAve.SE.
Cayuga,ND58013
ManagementSystemRegisteredtoISO9001

www.dakotamicro.com

