Dallas KA3281/02 User manual

Dallas - 2 Door Mirrored Wardrobe
KA3281/02
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call Customer Helpline 0844 880 6770
Dimensions
Width - 68.1cms
Depth - 50cms
Height - 199.5cms

Cross slot screwdriver
Hammer
Bradawl
Tape measure
5mm
DRILL BIT
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
2
Check you have all the
components and tools listed on
pages 2, 3 and 4.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Dispose of all packaging
carefully and responsibly.
Care and maintenance
Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Tools required
The next page can be cut out and used as reference throughout the assembly.
Keep this page with these instructions for future reference.

Components - Panels - Exploded View
Please check you have all the panels listed below
3
Components - Fittings
Please check you have all the fittings listed below
If you have damaged or missing components,
call the Customer Helpline 0844 880 6770
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may
be supplied than are required.
Plan view of panels on page 4
Hex key x 1
J
5mm Plug x 8
P
Panel pins x 25
F
15mm Screw x 15
E
Metal cam x 8
A
Metal Dowel x 8
B
Wooden dowel x 10
C
50mm Screw x 10
I
642mm Hanging rail x 1
K
22mm Bolt x 4
N
Connector bolt x 2
O
Door stop x 2
Q
128mm Handle x 2
M
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 5550 60 65 70 75 80 85 100 10590 95 110 115 120 125 130 135 140 145 150 155 160 165 170
1
2
3
4
5
6
7
8
9
7
Half cranked
slide hinge and
hinge plate x 6
HC
G
H
AND
Euro screw x 2
R
Hanging rail
socket x 2
L
Angle bracket x 1
D

Door x 2 (188.8 x 33cm)
Components - Panels - Plan View
Please check you have all the panels listed below
4
Left side (198 x 47cm)
Back (189.6 x 66.7cm)
Right side (198 x 47cm)
Top (68.1 x 50cm)
Base (65 x 46.6cm)
Plinths x 2 (65 x 8.7cm)
6
Back rail (65 x 8.7cm)
5
Shelf (65 x 33cm)
4
7
3
2
1
8
9

Assembly Instructions
Step 1
5
Fitting metal dowels
Screw metal dowels
into left hand side
Note: Insert metal dowels as
far as shown.
Do not over tighten.
Step 2
Fitting metal dowels
Screw metal dowels
into right hand side
Note: Insert metal dowels as
far as shown.
Do not over tighten.
Fitting wooden dowels
Knock wooden dowels
into holes to required
depth (see illustration)
Fitting wooden dowels
Knock wooden dowels
into holes to required
depth (see illustration)
C
C
8 mm
C
C
Front edge
Fitting hanging rail socket
Secure hanging rail socket
to left side by first screwing a
euro screw in the top hole
of the socket into locating hole
on left hand side then
secure with a 15mm screw
in the bottom hole
Front edge
Fitting hanging rail socket
Secure hanging rail socket
to right side by first screwing
a euro screw in the top
hole of the socket into locating
hole on right hand side
and secure with a 15mm
screw in the bottom hole.
Repeat process for second
socket.
B
B
B
2
B
3
B
B
B
2
C
B
B
B
B
3
C
C
DO FIRST
DO
SECOND E
L
R
L
2
E
R
E
L
R
2
DO FIRST
DO
SECOND E
L
R
L
3
E
R

6
Assembly Instructions
Step 3
X 2
Step 4
Fitting wooden dowels
a: Knock wooden dowels
into holes in the plinths
to required depth
(see illustration)
b: Knock wooden dowels
into holes in the back
rail to required depth
(see illustration)
Fitting metal cams
Press metal cams firmly
into holes in the base
and shelf
a:
b:
Front edge
Fitting door stops
Screw in door stops into
holes in the top
8
5
6
A
A
A
A
8
4
A
C
C
C
C
6
C
5
C
4
A
A
A
A
1
Q
Q
1
Q
A
A
8 4
8 4

Assembly Instructions
Step 5
7
Step 6
Attaching panels
Position shelf and left side
and secure by turning
cam locks clockwise
Do not over tighten.
Position back rail onto
left side and secure with
a 50mm screw
Do not over tighten.
Cam lock in open
position
Cam lock in closed
position
Attaching panels
a: Position base onto
left side and secure by
turning cam locks
clockwise
Do not over tighten.
Ensure this top
has an edged
surface
Front edge
Front edge
A
4
2
A
2
5
I
8
2
8
A
A
I
J
24
5
A
A
2
4
5

Assembly Instructions
Step 7
8
Step 8
Attaching panels
Secure plinths to the left
side using two 50mm
screws
Do not over tighten. Front edge
5
Plinths must be
supported until
next step
Attaching panels
Important note:
Plinths must be
supported until next
step
Front edge
Attaching panels
Secure right side shelf
and base turning cam
locks clockwise
Do not over tighten.
Secure plinths and back
rail to right side using
three 50mm screws
Do not over tighten.
Front edge
2
I
J
6
2
I
8
2
4
I
J
6
6
I
J
8
3
4
I
J
6
6
I
J
A
A
A
A
34
A
8
6
3
I
5
5

Assembly Instructions
Step 9
9
Step 10
Attaching panels
Secure top to left and
right sides using four
50mm screws
Do not over tighten.
Back of unit
A to B = C to D
Front
edge
Important note:
Two people required to
turn unit over
Square up unit
Using a tape measure,
ensure the distance from top
left corner to bottom right
corner is equal to the
distance from top right corner
to bottom left corner
F
9
F
9
Attaching back panels
Position back panel onto
the back of the unit and
secure using panel pins
9
3
1
I
J
I
J
I
J
I
J
I
3
4
2
1
2
F
9
F
F

Assembly Instructions
Step 11
10
Step 12
Important note:
Two people required to
stand unit upright
BACK OF
DOOR
X 2
Attaching door hinges
Attach hinge and plate
and onto door using
15mm screws
Repeat for the other door
Attaching hanging rails
Position hanging rail into
hanging rail sockets by
pushing rail down and sliding
into hanging rail sockets on
both left and right sides
(see illustration)
L
K
7
2
G
G
G
H
H
H
3
F
F
F
7
G
H
AND
H7
F
G
7
F
F
G
H
AND
G
H
AND
G
H
AND
Important note:
Two people required to
position doors
Hanging doors
Position the door hinge and
plate and onto left
side then screw into the
location holes
(see illustration)
Repeat for the other door on
right side
G H
2
323
G
H
AND
7
LK
32 &
K
L

Assembly Instructions
Step 13
11
Aligning doors
a: To move doors up and
down: loosen screws shown
and adjust to suit, once doors
are aligned re-tighten screws
b: To move doors side to side:
loosen screw shown and adjust
to aligned
c: To move in and out: loosen
screw shown and adjust to
aligned and re-tighten screws
a:
b:
c:

Assembly Instructions
Step 14
12
Step 15
Important note:
To join the robes
together, carefully drill
through the holes as
shown. It is best joining
together in position,
before attaching to a
wall.
Connecting to another robe
Drill though the holes in robe
sides using a 5mm drill bit.
(see illustration)
Position robes together and
screw together using
connecting bolts
(see illustration)
(Illustration shown without
doors)
Attaching door handles
Fix handles to door
using 22mm bolts
(Illustration shown without
right hand door)
DO FIRST
DO SECOND
1
E
D
Important note:
It is essential that this
product is fixed to a wall
using the bracket
supplied
Fixing Safety bracket
Postion safety bracket
centrally on the back
edge of the top secure
using screw
Secure to wall using a
suitable fixing
(not supplied)
O
2
7
1
E
D
3
M
N
7
2
3
2
O
1
E
D
M
N
7
M
N

13
Address: Support Desk, KD Products Ltd, Redwither Tower,
Wrexham Industrial Estate, Wrexham, LL13 9XT
Tel: [phone] e-mail: [e-mail]
Dallas 2 Door Mirrored Robe
Alaska Birch / Wisconsin Walnut
Thank you for your purchase!!!
In the unlikely event that this product has missing or damaged parts, please fill in the form below and send
it to the address above, fax to 01978 661848, or e-mail it to [e-mail].
The phone line is available for advice on assembly and is open between 8am to 5pm,
Monday to Thursday, 0844 880 6770.
Please tick either damaged or missing box and enter the quantity required.
Code : A3282B
A3281WW
Note: please allow 14 working days for delivery of replacement parts
Your details:
Name: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Address: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Postcode: _ _ _ _ _ _
Day Tel: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Eve Tel: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
e-mail: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Date of purchase: _ _ _ _ _ _ _ _ Batch number: _ _ _ _ _ _ _ Stock code:_ _ _ _ _ _ _ _ _ _
Catalogue no: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Colour: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
From which catalogue did you purchase this item: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
All the fields marked with * are essential to process your request correctly.
*
*
*
*
*
*
Customer helpline
Damaged Damaged Quantity Order
Code
MissingProductQuantity Order
Code
S140
B156 Base
X138
X142 Back rail
Plinth
T244
R307 Rh side
L296 Lh side
Top
MissingProduct
Shelf
KA3281/02
K65
K344
K329
K310
128mm Bar Handle
Hanging rail socket
K251 Hanging rail
K30 Allen key
50mm Hex screw
K51 Angle bracket
K58
K24
K16 15mm Screw
Panel pins
Metal dowel
K46
K59 Metal cam
30mm Wooden dowel
Assembly guide
Guide
Code
Guide
Code
Connector bolts
K128
22mm Bolts
5mm Plug
K55
Door stop
K302
C234 Back
D187 Mirrored Door
K342
K343
Half cranked slide on hinge plate
Half cranked slide on hinge
▼ ASSEMBLED ▲
K144
5x8 mm Euro Screws
A
B
C
D
E
F
G
H
I
3
4
5
6
1
2
8
J
K
L
M
O
N
P
R
9
7
Q
