dallmeier DAS-4 Eco Guide

English
Rev. 3.0.0 / 2012-06-15
Installation and Commissioning
External Storage System
DAS-4 Eco

DAS-4 Eco
www.dallmeier.com 2
Information about copyright, trademarks, design patents
© 2012 Dallmeier electronic
The reproduction, distribution and utilization of this document as well as the communication of
its contents to others without express authorization is prohibited. Offenders will be held liable for
the payment of damages. All rights reserved in the event of the grant of a patent, utility model or
design.
We reserve the right to make technical modications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
93051 Regensburg
www.dallmeier.com
[e-mail]
All trademarks identied by ® are registeres trademarks of Dallmeier electronic.
All trademarks identied by *) are trademarks of the following owners:
Microsoft and Windows of Microsoft Corporation headquartered in Redmond, Washington, USA
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identication of thirdparty
trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is
no reason to assume that the respective trademark is unprotected.

DAS-4 Eco
www.dallmeier.com 3
Table of Contents
1 Introduction...................................................................................................4
1.1 Validity.............................................................................................................4
1.2 Documents......................................................................................................4
1.3 Conventions....................................................................................................4
2 Safety Instructions........................................................................................6
3 General Notes................................................................................................8
3.1 Scope of Delivery............................................................................................8
3.2 Transportation and Packaging ........................................................................8
3.3 Proper Usage..................................................................................................8
3.4 Performance Features ....................................................................................9
3.5 Certicates......................................................................................................9
3.6 Warranty .........................................................................................................9
4 Views and Connection Assignments ........................................................10
4.1 Front View.....................................................................................................10
4.2 Connection Assignments ..............................................................................10
5 Installation and Mounting ..........................................................................11
5.1 Requirements at the Installation Site ............................................................11
5.2 Stand-alone Installation of the Unit...............................................................11
5.3 Installation into a 19’’ Standard Rack............................................................11
6 Connection and Start-up............................................................................12
6.1 Connection and Start-up without External Power Supply Unit......................12
6.2 Connection and Start-up with External Power Supply Unit...........................13
6.3 Reboot ..........................................................................................................14
7 Conguration SMAVIA Recording Server.................................................15
8 HDD Management .......................................................................................16
9 HDD Replacement.......................................................................................17
9.1 Conditions.....................................................................................................17
9.2 Localization of the HDD ................................................................................18
9.3 HDD Replacement........................................................................................18

DAS-4 Eco
www.dallmeier.com 4
1 Introduction
1.1 Validity
This document applies to the external storage system DAS-4 Eco in conjunction with SMA-
VIA appliances DMS 2400 and DLS 1600. It has been produced on the basis of software
version 1.0.0.
Pictures in this document may differ from the actual product.
1.2 Documents
Installation and Commissioning (this document)
The document entitled Installation and Commissioning describes installation, mounting,
connection, start-up and exchange of the different modules. General notes on the pro-
ductand technical data are additionally provided.
The target audience of this document is exclusively trained and authorized professionals
(installers).
1.3 Conventions
Various warning words and symbols indicate potential sources of danger.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE indicates practices for preventing property damage, incorrect
congurations or faulty operations.

DAS-4 Eco
www.dallmeier.com 5
The following symbols and various character formats are used to increase the clearness
of the document.
¾Instructions are indicated by arrows (¾).
Expressions in bold and italics indicate a control element on the device (switches or la-
bels) or on its user interface (buttons, menu entries).
Paragraphs in italics contain information on basic principles, special features and efcient
procedure as well as general recommendations.

DAS-4 Eco
www.dallmeier.com 6
2 Safety Instructions
Only use this device if it is technically in proper working order, to the intended purpose and
while keeping safety and potential dangers in mind.
Qualied Personnel
Installation, mounting, connection, commissioning and conguration of the unit may only
be carried out by qualied personnel. This also applies to the maintenance, testing and re-
pair, whereat the regulations of the DIN VDE 0701 series of standards (repair, modication
and inspection of electrical appliances) must be followed.
Regulations
The use of video and audio surveillance systems in general is strictly regulated. Inform
yourself about the applicable laws and regulations regarding data, working and environ-
mental protection before using the unit and ensure compliance with them.
System Components
Only use internal components that have been tested and approved by Dallmeier. Inappro-
priate internal components can cause malfunctions, damages and data loss and can result
in loss of warranty.
RAID System
Devices that are congured with a RAID system for redundant recording always must be
supplied with power via an uninterruptable power supply (UPS). A sudden voltage drop can
damage the RAID system.
Modications
Do not make any modications to the hardware or software that has not been tested and
approved by Dallmeier. Inappropriate modications can cause malfunctions, damages and
data loss and can result in loss of warranty.
Documentation
Carefully and completely read the documents included in delivery. Always observe the
contained instructions, notes and warnings.
Condensation Water
If the unit is brought from a cold to a warm environment, resulting condensation water
can cause malfunctions and damages. In this case wait (up to 8 hours) until the unit has
reached room temperature before commissioning.
Operating Conditions
Unfavourable operating conditions can shorten the life of the unit and can cause malfunc-
tions, damages and data loss and can result in loss of warranty. Observe the specications
given in the technical data, the operating condition requirements and the maintenance
instructions.
Shocks
Shocks can cause malfunctions and damages. The unit may not be moved while in ope-
ration.

DAS-4 Eco
www.dallmeier.com 7
Foreign Bodies
If objects or liquids get into the unit, immediately disconnect it from the power supply (pull
out the power plug). Contact the sales partner responsible for your area.
Burnt Smell
If you notice burnt smell or formation of smoke from the unit, immediately disconnect it from
the power supply (pull out the power plug). Contact the sales partner responsible for your
area.
Opening
The housing of the unit may only be opened by qualied personnel for inspection, mainte-
nance and repair.
Disposal
Disconnect the unit from the power supply. Remove all connected devices. Return the unit
to your respective sales partner.

DAS-4 Eco
www.dallmeier.com 8
3 General Notes
3.1 Scope of Delivery
Included in the standard scope of delivery is:
1 x DAS-4 Eco
1 – 4 HDDs (as ordered)
1 x SATA cable
1 x Power supply cable (to be connected to the recorder)
1 x Documentation Installation and Commissioning (CD)
The scope of delivery may differ depending on the ordered equipment or device variant.
The device’s range of functions depends on the ordered equipment or device variant and-
may therefore not correspond with this document’s content. Certain functions and features-
may require an activation that is subject to costs.
3.2 Transportation and Packaging
Store the original packaging for transportation at a later date. Dallmeier electronic is not
esponsible for damage resulting from unprofessional/improper transportation. The good
should only be shipped in their original packaging.
If the original packaging is no longer available, ensure that the packaging used sufciently
protects the unit against damage, moisture, heat and cold.
3.3 Proper Usage
The DAS-4 Eco is a user-friendly and economic storage expansion (JBOD).
The housing of the only 1 HU high device is capable of holding up to 4 SATA HDDs within
lockable slide-in units with a total capacity of max. 8 TB at present. They can be congu-
red for redundant RAID 1 recording via the device.
In case of a hard disk failure, the HDDs’ Easy-Change functionality allows for a quick
replacement of the hard disks from the front side of the device and therefore ensures
the highest degree of maintainability possible. Two redundant high performance fans
guarantee an optimal ventilation. Power is supplied directly via the 12 V DC output of the
device. An additional power supply unit is not necessary.

DAS-4 Eco
www.dallmeier.com 9
3.4 Performance Features
The DAS-4 Eco is especially characterised by the following functions and properties:
• 4 lockable slots for Dallmeier approved and authorised SATA HDDs
• No RAID (JBOD) or RAID 1 (conguration via recorder
• Easy-Change functionality in case of a HDD failure (no hot-plug, no hot-swap)
• 2 redundant high performance fans
• Power supply via recorder (12 V DC output)
• Data transfer via SATA extension interface
• Easy installation (plug & play)
• Practical handling
3.5 Certicates
The following certications were in effect for the external storage expansion DAS-4 Eco
atthe time this document was produced:
• CE
• FCC
• ACA
3.6 Warranty
The terms and conditions valid at the signing of the contract shall apply.

DAS-4 Eco
www.dallmeier.com 10
4 Views and Connection Assignments
4.1 Front View
A B C D
Fig. 4-1
ABlue LED – drive ready
BGreen LED – drive active
CLock
DHDD module
4.2 Connection Assignments
B C DA E
Fig. 4-2
AFan
B SATA interface 5 – 8 (not used)
CSATA interface 1 – 4
D12 V DC IN
E Assignment ODU socket
12 V DC IN

DAS-4 Eco
www.dallmeier.com 11
5 Installation and Mounting
5.1 Requirements at the Installation Site
Unfavorable local conditions may shorten the life of the product or lead to malfunctions.
Do not operate the DAS-4 Eco in places:
• with large scale dust and dirt
• with steam or oil vapors (e.g. kitchen)
• with direct sunlight
• with improper ambient temperature (see technical data)
• near sources of strong radiation, i.e. X-rays, radio transmitters or magnetic elds)
• with corrosive surroundings (e.g. gases or salt water)
5.2 Stand-alone Installation of the Unit
Stand-alone installation of the unitThe DAS-4 Eco is designed to be freely positioned on a
SMAVIA Appliance DLS 1600 or DMS 2400 without further mechanical attachment. As an
option, the DAS-4 Eco can be installed in a 19’’ standard rack.
Fig. 5-1
5.3 Installation into a 19’’ Standard Rack
At least 1 height unit and an installation depth of approx. 60 cm are required for its installa-
tion into a 19’’ standard rack.
In order to ensure adherence to the FCC guidelines, a distanceof 1 height unit must remain
between the SMAVIA Appliance DLS 1600 or DMS 2400 and the DAS-4Eco when installing
the unit into a 19’’ standard rack.

DAS-4 Eco
www.dallmeier.com 12
6 Connection and Start-up
NOTE
No recording to the external storage system DAS-4 Eco.
The DAS-4 Eco is not hot-pluggable. The DMS/DLS must be turned off
before connecting the DAS-4 Eco.
6.1 Connection and Start-up without External Power Supply Unit
Connection
¾Shut down the DMS/DLS.
¾Turn off the DMS/DLS.
¾Disconnect the DMS/DLS from the power supply (pull out the power plug).
¾Connect the DAS-4 Eco to the DMS/DLS by means of the SATA cable.
¾Connect the DAS-4 Eco to the DMS/DLS by means of the power supply cable.
Fig. 6-1 SMAVIA appliance DLS 1600
Fig. 6-2 SMAVIA appliance DMS 2400
Commissioning
¾Reconnect the DMS/DLS to the power supply.
¾Turn on the DMS/DLS.
The status LEDs of the DAS-4 Eco will be lit (blue).
After the initialization and boot process of the recorder has been completed the DAS-4
Ecois ready for use.

DAS-4 Eco
www.dallmeier.com 13
6.2 Connection and Start-up with External Power Supply Unit
As an option, power can be supplied to the DAS-4 Eco via an external power supply unit.
NOTE
Possible damage to the DAS-4 Eco.
Check the output voltage of the power supply unit used beforeconnection
and start-up. The output voltage must match therated voltage of the DAS-4
Eco.
Connection
¾Shut down the DMS/DLS.
¾Turn off the DMS/DLS.
¾Disconnect the DMS/DLS from the power supply (pull out the power plug).
¾Connect the DAS-4 Eco to the DMS/DLS by means of the SATA cable.
Fig. 6-3 SMAVIA appliance DLS 1600
Fig. 6-4 SMAVIA appliance DMS 2400
Commissioning
NOTE
No recording to the external storage system DAS-4 Eco.
The DAS-4 Eco is not hot-pluggable. Connect the DAS-4 Ecoto the power
supply before commissioning the DMS/DLS.
¾Connect the DAS-4 Eco to the power supply by means of the external power supply unit.
The status LEDs will be lit (blue).
¾Now reconnect the DMS/DLS to the power supply.
¾Turn on the DMS/DLS.
After the initialization and boot process of the recorder has been completed the DAS-4 Eco
is ready for use.

DAS-4 Eco
www.dallmeier.com 14
6.3 Reboot
If power is supplied to the DAS-4 Eco via the DMS/DLS, the right starting sequence willau-
tomatically be adhered to in case of a reboot.
However, if power is supplied to the DAS-4 Eco via an external power supply unit, thest-
arting sequence must be adhered to on every occasion in case of a reboot (see section
Connection and Start-up with Wxternal Power Supply Unit).
There is no image recording if the DMS/DLS is commissioned before the DAS-4 Eco.
To ensure adherence to the starting sequence, a programmable socket strip must be usedif
power is supplied via an external power supply unit.
NOTE
Possible loss of data and/or damage to the HDDs.
Always operate the DAS-4 Eco using a UPS (uninterruptible power supply)
and a programmable socket strip.

DAS-4 Eco
www.dallmeier.com 15
7 Conguration SMAVIA Recording Server
The SMAVIA Recording Server must be congured before recording to the DAS-4 Eco.
¾Log on the SMAVIA Recording Server as administrator.
¾Open the Harddisk Management dialogue via Setup > Recording > HDD Manage-
ment.
¾In the Rec. column, check the checkboxes of the corresponding HDDs.
Fig. 7-1
The available disk space for recording has thus increased by the capacity of the HDDs
inthe DAS-4 Eco.
¾Now dene the allocation of disk space for each individual camera/track.
¾Open the Recording Settings dialogue via Setup > Recording > Cameras.
¾In the HDD % column, dene the allocation of disk space for each individual camera/
track.
¾Conrm with OK.
For detailed information on the Recording settings dialogue, refer to the documentation
Conguration SAMVIA Recording Server.

DAS-4 Eco
www.dallmeier.com 16
8 HDD Management
The Hard disk management shows all the hard disks and drives ttedin the recorder or
connected externally. Individual HDDs can be enabled and disabled for the recording pro-
cess.
All hard disk drives are enabled for recording in the default conguration
¾Open the Harddisk Management dialogue via Recording > HDD Management.
Fig. 8-1
The various drives are displayed separately by category (bus system) in a structure tree.
The total capacity available for recording is shown at the top right.
To enable or disable a hard disk drive for recording, check or uncheck the checkbox in the
Rec column.
RAID Systems
It is possible to deactivate RAID. The various HDD’s must be activated manually for recor-
ding, as described above.
With RAID-1 an even number of hard disks with equal capacity must be used for the DAS-4
Eco. Those hard disks do not have to match the storage capacity of the hard disks used in
the recording device.
¾To change the conguration, select one of the options offered.
¾Conrm with OK.
NOTE
If any changes are made to the RAID settings, all recordings must be de-
leted.
The Standard button can reset all RAID settings. All HDD’s that are currently connected
will again be available for conf-guration

DAS-4 Eco
www.dallmeier.com 17
9 HDD Replacement
The interchangeable drawer units are mounted on the frontside of the device. This ensures
maximum service friendliness for replacing a hard disk drive.
Despite this high level of service friendliness, the conditions listed below must be observed
to maintain device and data security!
NOTE
Please observe the conditions set out below to the letter when you wish to
change a hard disk drive in the recorder. Failure to do so will result in the
warranty being voided.
9.1 Conditions
Service Case
Service case means the replacement of a defective or failed HDD. Please note that a drive
may only be replaced by trained personnel who have been authorized to do so by Dallmei-
er electronic. Contact the Dallmeier Support Team if necessary.
Also note that the interchangeable drawer units of the device are not designed for cy-
clical replacement (external long term archiving) of the hard disk drives. In addition the
interchangeable drawer units are designed for a maximum of 200 connection cycles.
Switch off Device
The interchangeable drawer units on the device are not hot-pluggable or hot-swappab-
le. The device must therefore be switched off before an HDD drawer unit can be changed.
Tested and Approved Hard Disk Drives
Use only hard disk drives that have been tested and approved by Dallmeier to replace a
defective or failed HDD.
HDDs that have not been tested and approved may cause malfunctions and may even
cause damage to the device, for example:
• Recording loss caused by incompatibility
• Power pack defect caused by excessive power consumption
• Overheating of the recorder caused by excessive heat generation
The current list of hard disk drives that have been tested and approved by Dallmeier elec-
tronic is shown in the partner forum.
Capacity of the new HDD
For technical reasons it is necessary that the capacity of a new hard disk drive to be larger
than (or precisely the same as) that of the old one. The decisive point is not the normally
specied gross capacity (GB) but the number of sectors.

DAS-4 Eco
www.dallmeier.com 18
Correct Interchangeable Drawer Unit
It is essential that you ensure that you insert the HDD drawer unit back into the original
interchangeable drawer unit. If you install it in another interchangeable drawer unit all the
data and pictures may be lost and a full new installation procedure may be required.
Contact the Dallmeier Support Team if you are in any doubt.
9.2 Localization of the HDD
In the event of a hard disk drive defect, you can fnd the hard disk drive that must be repla-
ced using the SMAVIA Viewing Client GUI.
¾Open the Info dialogue via Setup > System > Info > HDD status.
Fig. 9-1
The defective HDD is displayed in red.
9.3 HDD Replacement
NOTE
Risk of data loss and/or damage to the HDD module.
Before removing the HDD, ensure that both device and DAS-4 Eco are de-
energized.
NOTE
Damage to components at risk from electrostatic discharge caused by tou-
ching them.
Ensure that you are electrostatically discharged (earthed) before you touch
the module.
Wear suitable ESD shoes or an earth strap.

DAS-4 Eco
www.dallmeier.com 19
¾Shut down the SMAVIA Viewing Client.
¾Ensure that none of the LEDs on the device and the DAS-4 Eco are lit.
¾Switch off the SMAVIA Viewing Client.
¾Pull the device mains plug.
¾Release the HDD drawer unit using the wrench supplied.
Fig. 9-2
¾Pull the HDD drawer unit out carefully.
Fig. 9-3
¾Undo the 4 screws on the underside of the HDD drawer unit.
Fig. 9-4
¾Remove the defective HDD.
¾Secure the HDD drawer unit to the new HDD.
¾Use only the original screws supplied.
¾Ensure that the HDD and HDD drawer unit are ush atthe rear.

DAS-4 Eco
www.dallmeier.com 20
Fig. 9-5
¾Insert the HDD drawer unit into the guide rail.
Fig. 9-6
¾Slide the HDD drawer unit carefully into the housing.
¾Ensure that you slide it straight.
¾Do not use any force.
Fig. 9-7
¾The front cover on the HDD drawer unit must be ush with the edge of the housing.
¾Reconnect the mains plug.
¾Start the device.
If you have satisfed all the conditions, the HDD will be initialized when the device is started.
After this it will be ready for use and the recording process will continue.
