Danfoss DHP-AT User manual

MAKING MODERN LIVING POSSIBLE
User Guide
DHP-AT
www.heating.danfoss.com

The English language is used for the original instructions.
Other languages are a translation of the original instructions.
(Directive 2006/42/EC)
© 2011 Copyright Danfoss A/S

Table of Contents
1 Foreword ...................................................................... 4
2Safety precautions ............................................................... 5
2.1 Installation and maintenance ..................................................... 5
2.2 System modifications .......................................................... 5
2.3 Safety valve ................................................................. 5
3About your heat pump ............................................................. 6
3.1 Components ................................................................ 6
3.2 Main functions ............................................................... 6
3.3 Internal electrical heater ......................................................... 8
3.4 Freeze protection ............................................................. 8
4Control system .................................................................. 9
4.1 Keypad .................................................................... 9
4.2 Indicator ................................................................... 9
4.3 Display .................................................................... 10
5 Menu information ................................................................ 11
6 Turning power ON/OFF ............................................................ 12
7 Settings and adjustments ........................................................... 13
7.1 Lock/unlock user interface ....................................................... 13
7.2 Changing operation mode ....................................................... 13
7.3 Adjusting DHW temperature ...................................................... 13
7.4 Changing heat curve and desired room temperature ...................................... 13
7.5 Setting current time ........................................................... 14
7.6 Timer settings ............................................................... 14
7.7 Changing mode from AUTO to MANUAL .............................................. 15
7.8 Adjusting the indoor temperature in MANUAL mode ...................................... 15
7.9 Manual defrosting ............................................................. 15
7.10 Default settings .............................................................. 16
8 Regular checks .................................................................. 17
8.1 Checking operation ............................................................ 17
8.2 Check the water level in the heating circuit ............................................. 17
8.3 Checking safety valves .......................................................... 18
8.4 Cleaning strainer ............................................................. 18
9 References ..................................................................... 19
9.1 Checklist ................................................................... 19
10 Installation protocol .............................................................. 21
11 Service Sheet ................................................................... 22
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 3

1 Foreword
Buying a heat pump from Danfoss is an investment in a better future.
A Danfoss heat pump is classed as a renewable energy source, which means that it is consid-
erate of our environment. It is a safe and convenient solution that provides heating, hot wa-
ter and in certain cases cooling, for your home at a low cost.
We thank you for the confidence that you have shown in us by buying a heat pump from
Danfoss. We hope that you will benefit from it for many, many years to come.
With best wishes
Danfoss Heat Pumps
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
4

2 Safety precautions
2.1 Installation and maintenance
Danger Only authorized installers may install, operate and perform maintenance and repair work on the unit.
Danger Only authorized electricians may modify the electrical installation.
Danger Only authorized refrigeration technicians may perform work on the refrigerant circuit.
2.2 System modifications
Only authorized installers are allowed to perform modifications on the following components:
▪The heat pump unit
▪Water and electrical installations
▪The safety valve
Do not make any constructions / installations that may affect the operational safety of the heat pump.
2.3 Safety valve
The following safety precautions apply to the safety valve in the hot water circuit and corresponding overflow pipe:
▪Do not block the outlet on the overflow pipe from the safety valve.
▪Water expands when it is heated, this means that a small amount of water is released from the system via the overflow pipe.
The water that exits the overflow pipe can be hot! Therefore, allow it to flow to a floor drain where there is no risk of burning your-
self.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 5

3 About your heat pump
3.1 Components
1
2
61
0
57
43
1 Air inlet
2 Air outlet
3 Return line
4 Supply line
5 Operator panel
6 Hot water tank sensor and buffer tank sensor
7 Power supply example (local and national regulations
must be applied)
3.2 Main functions
The heat pump can provide the following functions:
▪House heating for radiators or under-floor heating
▪Domestic Hot Water (DHW)
▪Cooling
▪Defrosting in cold weather conditions
▪Frost protection
▪Legionella prevention
Most of these functions are automatically controlled by the control system according to the need from the household or ambient tem-
peratures.
Cooling must be initiated manually from the key pad by the user. The heat pump behaviour is still automatically controlled by the con-
trol system.
The default function when starting the heat pump for the first time is house heating/DHW automatic mode. The production of hot water
is prioritized. When the hot water temperature reaches the set point, the heat pump automatically switches to house heating or cooling
depending on the user settings.
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
6

The heating system is normally configured for automatic house heating/DHW at commissioning. An appropriate heating curve and a
desired room temperature are selected by the installer. The heat pump will adjust the house heating water temperature in accordance
with the outside air temperature. The maximum water temperature for house heating is 50°C. The AUTO mode is for both comfortable
house heating and energy saving.
The heating function can be set to MANUAL mode, then the heat pump will produce a constant supply line temperature following the
setting in the control system.
The picture below shows a simplified view of the recommended heating curves and the temperature working range in AUTO mode.
34
-2 0
-1 8
-1 6
-1 4-1 2-1 0- 8- 6
- 4
- 2024681012
1416
18
2022
2426
48
50
44
46
42
36
38
40
34
32
30
28
26
24
22
20
18
16
14
12
45
1
2
3
4
1 Initial supply line temperature
2 Supply line water temperature
3 Working range in AUTO mode
4 Outdoor ambient air temperature
The recommended heating curves for radiator heating are curves 43-45. The recommended heating curves for under-floor heating are
curves 32-34.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 7

N
The outside air temperature reference point for the heat curves is -6 °C.
Cooling
When the function is manually set to cooling, the machine will lower the indoor temperature. Note that the cooling capacity will de-
crease as the outdoor temperature increases.
Adjustable cooling supply line temperature range: 8-18 °C.
If the supply line water temperature drops below 2 °C the machine will stop. This to prevent inside components from freezing.
Error code 13 will be displayed.
Domestic hot water
The prioritized function is Domestic Hot Water (DHW). When the water temperature reaches the set point, the heat pump automatically
switches to house heating.
Defrosting
The heat pump will calculate and process the best defrosting programme depending on data collected from the temperature sensors.
During defrosting, components will start and stop at intervals (this is normal behaviour).
Defrosting can also be activated manually, this is only recommended when AUTO defrosting is not sufficient. This usually happens in the
temperature interval -5 to +5 °C and when outside air humidity is high. Under these conditions can heavy icing occur.
Legionella prevention
There is an automatic legionella prevention when the heat pump function is set to DHW. The automatic legionella prevention runs at
00:00 every 7:th day of operation. The water in the hot water tank will be heated to 65 °C for 15 minutes, using the hot water tank
electrical heater. This will kill any possible legionella bacteria inside the hot water tank.
3.3 Internal electrical heater
The internal electrical heater is used in situations when the heating from the heat pump is insufficient due to low air temperature or
when the heat pump itself has stopped.
The electrical heater will start in the following conditions:
▪The system discovers insufficient heating from the heat pump.
▪The heat pump stops (for protection) due to a failure, and at the same time, the water temperature has not reached the set point.
▪The heat pump is in defrosting mode.
▪During freezing protection, step 2.
3.4 Freeze protection
As long as there is power supplied to the heat pump, an automatic freeze protection function will prevent inside components from
freezing.
When this protective function is triggered, the controller will display either "Err 18" or "Err 19" depending on the temperature in the
system, this is not a fault. The unit will automatically recover once the conditions in the control system is met.
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
8

4 Control system
The heat pump has an integrated control system which automatically calculates the heat or cooling demands in the house to ensure
desired temperature.
The operator panel has a keypad (4) for user interaction and the information is presented in a display (1) above the keypad (4) and by the
indicator (2) beside the power ON/OFF button (3).
1
2
3
4
CC
Fig. 1: Operator panel
1 Information symbols
2 Indicator
3 Power ON/OFF button
4 Keypad
4.1 Keypad
The keypad is used to navigate through the different menus, to select features and lock / unlock the user settings
10
1
23456
7
89
Fig. 2: Keypad buttons
1 Heating/cooling switch
2 Down
3 Up
4 House heating/cooling (function on/off)
5 Clock
6 Lock/unlock
7 Timer on
8 Timer off
9 Domestic hot water (function on/off)
10 Internal electrical heater
4.2 Indicator
The indicator next to the power ON/OFF button on the operator panel is lit green when power is supplied and the operator panel is
connected to the heat pump. When the heat pump is started (using the power button), it is confirmed by a symbol on the display.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 9

4.3 Display
During normal operation, the upper part of the display shows the currently active functions.
The bottom part of the display shows the temperatures in the buffer tank and the hot water tank. If house heating/cooling or DHW has
been turned off, this part of the display will be empty. If the menu system is entered using the keypad or if an error occurs, the appear-
ance of the display will change.
The following information is available:
C
C
16
17
13
12 3 4 5 6 7 8 910 11 12
14
15
1 Heating
2 Cooling
3 Defrosting
4 Internal electrical heater
5 Alarm
6 House heating
7 Domestic Hot Water (DHW)
8 Interface locked
9 Clock
10 Timer on
11 Timer off
12 Current time
13 Indicator for DHW function
14 Indicator for hot water tank electrical heater
15 Hot water tank temperature
16 Buffer tank water temperature
17 Indicator for house heating/cooling function
The display shows the available menus and the default or configured settings.
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
10

5 Menu information
The control system has 30 menus, numbered 00-29. Each parameter in the menu have a default value. Depending on if the operating
mode is AUTO or MANUAL, these values may be adjusted.
When the heat pump is in house heating/DHW automatic operation, the information is presented as in the picture below.
C
C
Viewing other settings
Other settings in the control system can be reviewed by navigating through the 25 available menus.
1. To enter a menu , press for 5 seconds. The menu and parameter digits start to flash.
2. Before the flashing stops, press the or buttons to navigate between the menus.
The current parameter value for a menu setting is displayed in the right-hand side of the window. The default value can be found further
on in this user guide.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 11

6 Turning power ON/OFF
The heat pump is normally started by the installer when installing and commissioning the system. If it is necessary to start or stop the
heat pump, use the power ON/OFF button, (3) on the keypad.
The heat pump is connected to the mains via a safety switch (circuit breaker).
The indicator (2) on the operator panel is lit green when the operator panel is powered on and connected to the control system. If the
heat pump is turned off, only current time is displayed.
When the heat pump is turned on from the operator panel (3), the current operation and status will be displayed.
1
2
3
4
CC
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
12

7 Settings and adjustments
By default, the heat pump function is set to automatic house heating/DHW. The default heat curve is 43 and the desired room tempera-
ture is 20 °C.
The factory configured mode and parameter settings in the control system can be adjusted to fit the current system solution and differ-
ent customer requirements.
N
There is no reset function. If the default factory settings (parameter values) are changed, the only way to re-
turn to the default settings is to manually set the values presented in section Default settings.
7.1 Lock/unlock user interface
To lock or unlock the user interface, press for 5 seconds.
7.2 Changing operation mode
To change the default operation mode, from house heating/DHW AUTO to cooling, press on the key pad. Navigate to Menu 01
and select the desired room temperature using the or buttons.
In the default house heating/DHW AUTO mode, pressing on the keypad more than 5 seconds stops the DHW production and puts
the heat pump in house heating operational mode.
N
The value shown in the display is the present tap water temperature. Press the symbol for less than 5 seconds
and the preset temperature is shown.
If pressing the button for more than 5 seconds, the house heating function is turned off.
N
The value shown in the display is the present house temperature. Press the symbol for less than 5 seconds
and the preset temperature is shown.
7.3 Adjusting DHW temperature
1. To change the default setting of the DHW tank temperature, press . The temperature setting starts to flash.
2. Use the or buttons to change the temperature.
3. Wait 5 seconds (the figures stop flashing) for the temperature value to be set.
7.4 Changing heat curve and desired room temperature
Changing heat curve and desired room temperature is only available in AUTO mode.
Heat curve
1. To select another heating curve, press for 5 seconds.
2. Use or buttons to navigate to Menu 00.
3. Press again.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 13

4. Use or buttons to select a new heating curve (range is 24-50).
5. Press again and wait 5 seconds.
Desired room temperature
1. To select the initial desired room temperature, press for 5 seconds.
2. Use or buttons to navigate to Menu 01.
3. Press again.
4. Use or buttons to select the initial desired room temperature.
5. Wait 5 seconds for the change to be saved.
7.5 Setting current time
1. To change the default time setting, press .
2. While the symbols are flashing adjust the default hour setting by using the or buttons.
3. Press again.
4. Use or buttons to change the default minute setting.
5. Before the flashing stops, press again or wait 5 seconds to save the settings.
7.6 Timer settings
The heat pump can start and stop according to timer settings in the control system.
Setting Timer ON
1. To set Timer ON, press .
2. Use or buttons to change the default hour setting for Timer ON.
3. Press again.
4. Use or buttons to change the default minute setting for Timer ON.
5. Press before the flashing stops or wait 5 seconds.
Setting Timer OFF
1. To set Timer OFF, press .
2. Use or buttons to change the default hour setting for Timer OFF.
3. Press again.
4. Use or buttons to to change the default minute setting for Timer OFF.
5. Press before the flashing stops or wait 5 seconds.
Cancelling Timer settings
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
14

1. To cancel timer settings, press either or .
2. Press before the flashing stops.
7.7 Changing mode from AUTO to MANUAL
1. To change from AUTO to MANUAL mode, press for 5 seconds.
2. Press or to navigate to Menu 02.
3. Press the again.
4. Press to select value 0 for MANUAL mode.
5. Press again or wait 5 seconds.
6. To lock the mode, press for 5 seconds.
7.8 Adjusting the indoor temperature in MANUAL mode
In MANUAL mode, the control system can only adjust the water out temperature which in turn will affect the room temperature.
1. To change the water temperature. press and adjust the temperature with the or buttons.
2. Press again to return to idle state.
7.9 Manual defrosting
Manual defrosting should only be initiated when the automatic defrosting function is not sufficient (heavy icing on the outdoor unit).
To start a manual defrosting cycle, press and simultaneously for 5 seconds. If all defrost conditions are fulfilled, the defrost
symbol
will be displayed in the information window. An air temperature below 15°C is required and the compressor must have been
running for at least 10 minutes.
N
If the defrost symbol disappears almost
immediately, the defrosting criteria are
not met and defrosting will not start.
When the defrosting cycle is finished, the symbol
will disappear from the information window.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 15

7.10 Default settings
The following table shows the default settings in the control system:
Menu Description Default value Range
00 Auto heating curve (value 43 relates to the number of the curve and
has no units of measure, A indicates that it is in automatic mode only) A43 A24—50
01 Initial (desired) room temperature 20 °C 15—25 °C
02 House heating mode 1 1=Auto
0=Manual
03 Defrostning cycle 40 min 30—90 min
04 Coil temperature threshold for starting defrosting -6 °C From -20 °C to +5 °C
05 Coil temperature threshold for stopping defrosting 13 °C 1—30 °C
06 Maximum defrosting period 12 min 1—15 min
07 Domestic hot water hysterisis setting (i.e number of degrees below
setpoint where the DHW will start again) 5 °C 1—20 °C
08 Heating hysterisis setting (i.e number of degrees below setpoint
where the heating will start again) 2 °C 1—20 °C
09 Overheating of electronic expansion valve in heating mode 2 °C From -20 °C to +20 °C
10 Overheating of electronic expansion valve in cooling mode 3 °C From -20 °C to + 20 °C
11 Time delay for compressor start-up after power-up (for example, after
a power cut-off) 1 min* 1—10 min
12 Circulation pump operation mode 1 1=Switched off when heating temper-
ature has been reached.
0=Continuous operation
13 Internal electrical heater operation during defrosting 1 1= Turned on
0=Turned off
14 Automatic legionella protection function 1 1=Activated
0=Deactivated
15 Internal electrical heater start option 0 0=Auto
1=Air-temperature condition set in
menu 16
2=Water temperature condition set in
menu 17
3= Conditions 1 and 2 must be met
16 Air temperature restriction for when internal electrical heater can
manually be started, that is, must be lower than this value. -5 °C From -15 °C to +7 °C
17 Additional hysterisis in relation to menu 08 for when internal electri-
cal heater can manually be started. 2 °C 0—13 °C
18 Additional temperature hysterisis for hot water tank electrical heater
in relation to menu 07 for when the electrical heater will start. 5 °C 0—20 °C
19 Hot water tank electrical heater startup delay 30 min 30—90 min
20 Return water temperature Measured value From -30 °C to +99 °C
21 Supply water temperature Measured value From -30 °C to +99 °C
22 Coil temperature in heating mode (T7) Measured value From -30 °C to +99 °C
23 Coil temperature in cooling mode (T8) Measured value From -30 °C to +99 °C
24 Air temperature (T1) Measured value From -30 °C to +99 °C
25 Hot water tank temperature (T3) Measured value From -30 °C to +99 °C
26 Buffer tank temperature (T2) Measured value From -30 °C to +99 °C
27 Return gas temperature of compressor (T5) Measured value From -30 °C to +99 °C
28 Exhaust gas temperature of compressor (T4) Measured value From -30 °C to +99 °C
29 Shows the number of the operation steps of expansion valve Measured value 100—470 steps
* Should not be modified.
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
16

8 Regular checks
8.1 Checking operation
During normal operation, the alarm indicator is hidden to show that everything is OK. When an alarm is triggered, the alarm indicator
flashes and at the same time an error code is shown in the display.
Check the alarm indicator regularly to ensure that the appliance is work-
ing correctly. In the event of an alarm the heat pump will, if possible, sup-
ply heating to the house, primarily with the compressor, secondarily with
the internal electrical heater.
The hot water production will stop to indicate that something notewor-
thy has occurred.
Error code Description
00 Communication failure
01 Return water sensor (T9) failure
02 Supply water sensor (T8) failure
03 Water flow switch protection
04 Phase sequence error (only applies to 3-phase models)
05 Excessive temperature difference protection of supply and return water
06 Internal electrical heater overheat protection
07 Condenser overheat protection
08 Hot water tank sensor (T3) failure
09 Buffer tank sensor (T2) failure
10 High pressure protection
11 Low pressure protection
12 Supply water temperature too high
13 Supply water temperature too low
14 Return gas temperature sensor (T5) failure
15 Exhaust gas temperature sensor (T4) failure
16 Exhaust gas temperature overheat protection
17 Null
18 Frost protection, step 2 (non-fault)
19 Frost protection, step 1 (non-fault)
20 Air temperature sensor (T1) failure
21 Heating coil sensor (T7) failure
22 Cooling coil sensor (T6) failure
23 Exceeded operation range warning (non-fault)
8.2 Check the water level in the heating circuit
The line pressure of the installation must be checked once a month.
The external manometer (if available) must show a value between 1-1.5 bar. If the value is below 0.8 bar, when the water in the heating
system is cold, the water must be topped up (applies in the event of an empty expansion tank).
Ordinary tap water can be used when topping up the heating system. In certain exceptional cases, the water quality may be poor (for
example very hard water) and is not suitable for filling the heating system. If unsure, contact your installer.
N
The closed expansion tank contains an air filled bladder that absorbs variations in the heating system’s vol-
ume. Under no circumstances may it be drained of air.
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 17

8.3 Checking safety valves
Warning If the safety valves are not checked regularly, the water tank might be damaged.
Both safety valves must be checked at least four times a year to prevent lime deposits clogging the mechanism.
Both safety valves is checked by turning the cap a quarter of a turn clockwise until the valve lets out some water through the overflow
pipe. If a safety valve does not work properly, it must be replaced. Contact your installer.
The safety valve in the water tank protects the enclosed heater against over pressure in the water tank. It is mounted on the cold water
inlet line, its outlet opening is facing downwards.
The safety valve lets out small amounts of water when the water tank is being charged, especially if a lot of hot water was used previous-
ly. This is a normal behaviour.
The opening pressure of the safety valves is not adjustable.
8.4 Cleaning strainer
N
The heat pump must be switched off at the external main switch before cleaning can be started.
N
The strainer must be cleaned twice a year after installation. The interval can be extended if there is evidence
that cleaning twice a year is not necessary.
N
Have a cloth at hand when opening the strainer cover as a small amount of water usually escapes.
1
432
1. Shut off tap
2. Cover
3. Strainer
4. O-ring
Clean the strainer as follows:
1. Switch off the heat pump.
2. For the heat circuit strainer - remove the insulation around the filler valve.
3. Turn the shut-off taps to the closed position (see figure).
4. Unscrew the cover and remove it.
5. Remove the strainer.
6. Rinse the strainer.
7. Reinstall the strainer.
8. Check that the o-ring on the cover is not damaged.
9. Screw the cover back into place.
10. Turn the shut-off tap to the open position.
11. For the heat circuit strainer - reinstall the insulation around the filler valve.
12. Start the heat pump.
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
18

9 References
9.1 Checklist
Positioning
□ Surface adjustment
□ Drainage (avoiding water on pedestrian crossings)
Pipe installation
□ Pipe connections in accordance with the diagram
□ Flexible hoses
□ Bleeding
□ Strainer
□ Pipe insulation
□ Open radiator valves
□ Leak test
Electrical Installation
□ Circuit-breaker
□ Fuse
Commissioning
□ Bleeding
□ Settings control system
□ Manual test components
□ Manual test different operating conditions
□ Noise check
□ Function test safety valve
□ Function test mixer valve
□ Trimming the heating system
Customer information
□ Contents of this manual
□ Safety precautions
□ Control computer, function
User Guide DHP-AT
Danfoss Heating Solutions VUGFC20202 19

□ Settings and adjustments
□ Regular checks
□ Reference to service requirement
□ Warranties and insurances
User Guide DHP-AT
VUGFC20202 Danfoss Heating Solutions
20
