Welcome
Thank user for purchasing our network keyboard!
This quick start guide is designed to be a reference tool for the operation of userr system.
Before the operation please read the following safeguards and warnings carefully!
Please keep it well for future reference.
4
Important Safeguards and Warnings
1．
．．
．Electrical safety
All installation and operation here should conform to userr local electrical safety codes.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
2．
．．
．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation,
storage and installation.
3．
．．
．Installation
Keep upwards. Handle with care.
Do not place objects on the network keyboard
4．
．．
．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted
repair.
5．
．．
．Environment
The network keyboard should be used in a cool, dry place away from direct sunlight,
inflammable, explosive substances and etc.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
5
1
11
1Overview and Controls
Overview and ControlsOverview and Controls
Overview and Controls
1.1
1.11.1
1.1 Front Panel
Front PanelFront Panel
Front Panel
This series products’ front panel is shown as below. See Figure 1-1.
Figure 1-1
It includes seven panes.
SN Name SN Name
1 Touch panel 4 Shuttle(Outer ring)
Jog(Inner dial)
2
Indication light 5 Function buttons
3 Record playback 6 PTZ control
7 Joystick
1.2
1.21.2
1.2 Function Buttons List
Function Buttons List Function Buttons List
Function Buttons List
Please refer to the following sheet for function button information.
SN Name Symbol Function
Function
key
Number and
character
0-9 It is to input number and character. Click the Shift
button to switch.
ESC Cancel/exit
ENTER Confirm
SHIFT Switch
LOCK Work with SHIFT button to lock/unlock the device.
Indication
light
Working power
indication light
POWER The light becomes on when the keyboard
connects to the power.
Wire network
indication light
LINK The light becomes on when the keyboard connect
to the wire network properly.
6
Indication light
RX/TX The light becomes on when the wire network data
is sending or receiving properly.
Wireless
indication light
WIFI The light becomes ion when it connects to the
wireless network properly.
PTZ
control
PT PTZ shortcut button
GOTO Preset
AUTO PAN Pan
PATTERN Pattern
ZOOM+
PTZ lens zoom in.
ZOOM-
PTZ lens zoom out.
FOCUS+
Focus of the PTZ lens zoom in.
FOCUS-
Focus of the PTZ lens zoom out.
IRIS+
Aperture of the PTZ lens zoom in.
IRIS-
Aperture of the PTZ lens zoom out.
LIGHT
Speed dome light shortcut button
WIPER Speed dome wiper shortcut button.
Decoder CAM Working with the number button to select the input
channel.
MON Working with the number button to select the
output channel.
WIN Working with the number button to select the
output window.
MULT Working with the number button to select the
window split mode.
CAM-G Working with the number button to select the input
group.
MON-G Working with the number button to select the
output group.
DVR
Buttons
TOUR PTZ control, tour.
MULT Window split mode.
DEVC Working with number button to select remote
device.
Record Record/playback.
Stop record Stop record/playback.
Play/pause Play normally when it is backward playing or
in pause mode.
Play when it is in pause mode.
Backward/Pau
se
⊳Play backward when it is in normal playback
or in pause mode.
Click it to pause playback when it plays
backward.
Play previous When playback, click it to play the previous
7
file.
In menu setup interface, user may skip to the
previous item.
Play next When playback, click it to play the next file.
In menu setup interface, user may skip to the
next item.
AUX
buttons
AUX AUX button. Working with number buttons.
MAC Macro setup.
Others Touch panel Display OSD.
Jog AUX menu or function buttons operation.
1.3
1.31.3
1.3 Rear Panel
Rear PanelRear Panel
Rear Panel
This series products’ rear panel is shown as below. See Figure 1-2.
Figure 1-2
Please refer to the following sheet for detailed information.
1 WIFI antenna
2 GND stud
3 RS422/RS485 port
4 Network port
5 VGA port
6 USB port
7 HDMI port
8 Audio output
9 Audio input
10 RS232
11 Power port
12 Power on-off button
8
2
22
2Overview of Navigation and Controls
Overview of Navigation and Controls Overview of Navigation and Controls
Overview of Navigation and Controls
Before operation, please make sure:
The supplying power and the device power are matched.
2.1
2.12.1
2.1 Login, Logout &
Login, Logout & Login, Logout &
Login, Logout & Shutdown
Shutdown Shutdown
Shutdown
2.1.1 Login
Connect the power to the keyboard, user may see the power indicator light becomes on.
User may see mode selection interface on the LCD after it properly boots up. See Figure
2-1.
Figure 2-1
2.1.1.1 General Mode
Select general mode user may see the login interface. The factory default user name is
admin and password is admin. Please turn the jog (inner dial) to select the user name
and turn the shutter (outer ring) to move the cursor to input the password. Or user may
use the mouse or touch panel to input the password. Click the SHIFT button to switch the
input method. The input method includes number, capitalized character, small character
and etc.
The administrator account has only one user (admin) and the user name is read-only. The
admin can add the ordinary user account and set corresponding devices for each account.
For detailed operation contents, please refer to Chapter 3.2 Admin Operation Menu and
Chapter 3.3 User Operation Menu.
2.1.1.2 Matrix Mode
Select Matrix mode，user may see the corresponding interface. Please input matrix
information here. Please refer to chapter 2.4 for detailed matrix mode operation.
9
2.1.2 Shutdown
After user logged out the system, user may press the power button to turn off the
keyboard.
2.2
2.22.2
2.2 Admin Operation Menu
Admin Operation Menu Admin Operation Menu
Admin Operation Menu
2.2.1 Main Menu
After user login, user may see the main interface includes six buttons: System Settings,
Device Manager, Input Settings, Output Settings, Account and Shutdown.
Tips:
After user login the menu, user may set the menu property.
There are three ways for user.
User may set the device via the touch panel.
User may use the joystick to move the cursor or select the item. After user complete
current setup, user may use the joystick to move the cursor to select other items. For
special menu item, user may follow the prompt to click the ENTER button to confirm
the operation or the ESC button to cancel current setup.
User may connect the mouse to the keyboard to use.
2.2.2 System Settings
The system settings include the following buttons: general settings, network setting,
hardware settings, default, screen calibration, config backup and version.
2.2.2.1 General Settings
In this interface, user may set system time, date, language, name and etc. It includes
the Y-M-D-H-M-S setup. User may move userr cursor to the corresponding position
and then input.
2.2.2.2 Network
There are two ways for user to select: LAN and WLAN.
2.2.2.2.1 LAN
On the wire network interface, user may use the direction keys and number keys to set
IP address, subnet mask, gateway, port(default value 3777), preferred DNS and
alternate DNS. User may use the touch panel or the left/right button to move the cursor
to the corresponding position and then use the number keys to change the setup.
Please note user need to have the router and enable the DHCP function before user
use this function.
2.2.2.2.2 WLAN
The wireless network setup steps are listed below.
1) Click Refresh button, system begins search hotspot again and automatically add
password information and etc (If user have added it in the past).
2) Select hotspot user want to connect and then click Connect button. User may see
WIFI new hotspot setup interface. Please note user need to disconnect current
10
connection if user want to connect again.
3) Click OK button, the WIFI working information can display current connection
status after it successfully established the connection.
2.2.2.3 Hardware Settings
Here user may set key sound, key backlight, auto lock time, screen auto off time and etc.
2.2.2.4 Default
Here user may check the corresponding item to restore factory default setup.
2.2.2.5 Screen Calibration
User may use the screen calibration function if the touch position is not accurate with
the actual position.
Here user may view four + icons. Please follow the prompt in the screen to complete
the calibration. Then user may see the corresponding prompt “Successfully
calibrated.”
2.2.2.6 Backup
From General settings->backup, the admin can go to the USB device backup list
interface.
Import: Please connect the USB device to the USB port and then check the box
before the device name. Click the Import box to import the configuration.
Export: Please connect the USB device to the USB port and then check the box
before the device name. Click the Import box to export the configuration.
System can replace the original file if there are configuration files in the USB device.
Important
Please make sure user configuration file name is “config”; otherwise user may see a
dialogue box says “Invalid configuration file.”
2.2.2.7 Version
In this interface, user may view system version, build date, SN information. User may
also upgrade the system.
Please connect the device to the USB port and then click the Start button to begin the
upgrade operation.
Important
Before the operation, please make sure userr upgrade file name is update.bin.
2.2.3 Device Manager
Click Device manager button, user may see system begins device detect. .
After the detect, user may see device manager interface.
Here user may see controlled device name, IP address, port, device type, status and etc.
User may add, modify and delete the device.
11
IP Search
1) Click IP search button, user may go to the IP search interface.
2) Please click the Refresh button to begin search and user may view the searched
result in the IP search interface.
3) User may check the box to select a device and then input the user name and
password, click the Add button to add a device.
Important
Please make sure the device and the keyboard are in the same network
section. Otherwise the search may fail.
After user searched the device, its initial status is null. User may view the
device current status after user added it. System says the device has been
added means it is in the Device manager list now.
Add
1) Click Add button, system pops up the corresponding interface.
2) Here user may input manufacturer name, device name, IP address, port, user
name and password.
3) Please click the Add button to add current device. User may see the
corresponding dialogue box if user input information is wrong or current device is
offline. User may not save the device on the keyboard if the add operation failed.
4) Click OK button to complete.
Modify and delete
Modify:
Select the device first and then click the Modify button, user may see system pops up an
interface for user to change the information. Here user may modify device SN, port
number, user name and password.
Important
The user name and password here is for the keyboard to login the device. It does not
change the user name and password of the keyboard itself.
Delete
Select the device user want to delete and then click the delete button, user may
remove the device form the list.
2.2.4 Input Settings
Click Input settings button, user may go to the corresponding interface. Here user may
view the device channel information user may control.
Important
The position name is the corresponding channel name of the device.
Sync
Click Sync button, user may system automatically synchronizes the channel name with
the online device.
Modify
Click the Modify button; user may go to modify interface. Here user may change serial
number, main stream and extra stream, and protocol.
12
Important
The SN of the monitor position name shall unique. Otherwise system may pop up a
dialogue box “The channel name shall be unique. Please input again.”
2.2.5 Output Settings
Click output settings button, user may go to the corresponding interface.
Modify
In output settings interface, click Modify button, user may go to the corresponding
interface to change the output SN.
Important
Please make sure the output SN is unique. System may pop up a dialogue box says”
Current input SN already exists, please input again.”
2.2.6 Account
The keyboard account has two levels. One is admin and the other is ordinary user. The
admin can add max 20 users.
The admin account can set keyboard parameter, manage device and ordinary
users. The device management rights include: add/delete/modify device. The user
management rights include: add/delete/modify user, and set devices for each
user.
The user account can only have the operation rights and control the assigned
devices. Each ordinary user may max control 256 devices.
Modify Password
Please select an account and then click the Modify user button; user may go to the
corresponding interface. Here user may change the password.
Add User
Click Add user button, user may go to the corresponding interface to add the new user.
User need to input the user name and password.
Modify User
Select an ordinary user from the list and then click the Modify user button; user may go
to the corresponding interface. Here user may add or delete the device current user
controls.
2.2.7 Shutdown
Click the Shutdown button; user may see system pops up a dialogue for user to
confirm the operation. User may logout the menu, shutdown the device or reboot the
system.
2.3
2.32.3
2.3 User
UserUser
User
Operation
OperationOperation
Operation
Menu
Menu Menu
Menu
2.3.1 Main Menu
The user menu includes: device list, input list, output list, remote operation, advanced
and remote control.
13
2.3.2 Device List
On the Device list interface, user may view the device that current user may control.
2.3.3 Input List
Here user may view the channel information of controlled device.
Please note the position name is the channel name system gets from the device.
Sync
Click the Sync button; the device input list can synchronize the channel device monitor
position name.
Group
Click Group button, user may go to the corresponding interface.
User may select the group SN and then go to the group interface. There are 16 input
groups and user may add/delete the monitor positions. User may also se the tour
interval. This operation is mainly for the decoder group. Please refer to chapter 2.3.5.3
Decoder Operation for detailed information.
2.3.4 Output List
Click Output list button, user may go to the corresponding interface
Group
Click Group button, user may go to the corresponding interface.
User may select the group SN and then go to the group interface. There are 16 output
groups and user may add/delete.
Delete
Check the corresponding box first and then click Delete button, user may delete the
output port from the list.
Add
Click Add button, user may go to the corresponding interface.
Please check the corresponding output port and then click the Add button.
2.3.5 Remote Operation (Network Connection)
Basic operation
Keyboard lock: It is to lock the keys and mouse. The keys, joystick and touch panel
are all null once user lock the keyboard. User need to click the unlock button to
unlock the keyboard.
Keyboard lock/unlock button: Click LOCK+SHIFT button within 3 seconds.
The keyboard lock operation has the highest priority in the shortcut operations.
During any operation in any interface, click the LOCK+SHIFT button, user may lock
the keyboard.
Delete: During the keyboard remote operation, ESC button have the delete function.
User may use it to remove the latest input number.
Important
The keyboard becomes lock after the screen auto turns off.
14
2.3.5.1 Shortcut Operation
Remote operation
User may view current selected output channel on the left pane. Here user may select
window display mode, the decoded input channel of each window and set other shortcut
ways. User may view current input information and some shortcut setup on the right pane.
2.3.5.2 Local Preview
Local preview is to decode and playback the signal from the input channel at the keyboard
local-end. User may implement other shortcut operations during the local preview
process.
Please follow the steps listed below.
1) Input number 0+MON, select the local preview operation.
2) Input number i+MULT, select the window display amount. System now supports
1/4/8/9 /16-window mode.
3) Input number j+WIN, select the output window j.
4) Input number k+CAM, it is to output the signal from the channel k to window j via the
keyboard decode.
For example, 0+MON+4+MULT+2+WIN+1+CAM means: Display in 4-window mode;
output the video from channel 1 to the window 2 to preview.
Note
Input Number j+WIN+0+CAM, it can stop local preview function of window j.
Select one window and click （NEXT）or （PREV）, user may increase or decrease
the previous local decode video source number and then output it to current select
window.
2.3.5.3 Decoder Operation
Window split Mode
Here is for user to set the window display mode. It is to output the selected channel to the
specified windows.
Please follow the steps listed below.
1) Input number i+MON, it is to select the output channel i. Please note 0+MON is the
keyboard local preview.
2) Input number j+MULT, it is to output the signal from channel i to display in j-window
mode.
Output to the video wall
It is to display the signal from the selected channel via the decode output channel.
Please follow the steps listed below.
1) Input number i+MON, it is to select output channel i.
2) Input number j+WIN, it is to select current output window.
3) Input number k+CAM, it is to output the input signal from channel k to the video wall
via the output channel i of window j.
15
If user want to enable local video preview function, there are two ways:
Input number j+WIN to select window and click ENTER button, click ENTER button
again to close current preview.
Input number j+WIN.
Select one window and click （NEXT）or （PREV）, user may increase or decrease
current video channel number and then output it to current select window.
Note
Input number j+WIN+0+CAM, user may stop dynamic decode function of window j.
Output decoded video group to the video wall (Input group->output channel).
The function of the decoder is to output a selected group via the output decoded channel.
Detailed function:
When the channel n in the group is smaller than the output channel window amount
m, it is to decode dynamically. System outputs the input channel from the group to
display in the windows respectively.
When the channel nin the group is larger than the output channel window amount m,
it is to realize the tour function from group to screen. The output channel window mis
one output group and system decodes and outputs the input channel mby once.
System repeats the output until the remaining input channel amount is smaller than
the m.
Please follow the steps listed below.
1) Input i+MON, it is to select output channel i.
2) Input j+CAM-G, it is to output current input group j via the output channel i.
Decoded video group to the video wall (Input group->output window)
User may refer to the above contents for detailed information. The difference is that user
need to select a window for the output channel. User need to set the input channel of the
input group to one window of the output channel to enable the tour function. If there is only
one input channel, it is just like the dynamical decode in the output window.
Please follow the steps listed below.
1) Input i+MON, it is to select the output channel i.
2) Input j+WIN, select the window j for current output channel.
3) Input k+CAM-G, select to output the current input group k to the output channel
window j to enable the tour function.
Decode video to the video wall (Input group->output group)
User may refer to the above contents for detailed information. If the channel amount n in
the input group is smaller than or equal to the output window amount m in the output
group (for example, output group 1 has two output channels, and each output channel has
4-window. There is total 8-window. Here user need to compare n and 8.). It is to decode
the signal from the input channel to the output channel respectively. If the nis larger than
m, system decodes and outputs m output channel until the remaining input channel is
smaller than m.
Please follow the steps listed below.
16
1) Input m+MON-G, it is to select the output group m.
2) Input n+CAM-G, it is to output the input group nto the output group mto enable the
tour function.
2.3.5.4 Playback of the decoder record
It is to control the output channel to playback the record file of the decoded input channel
remotely. User need to select the output channel and input channel and set the
corresponding playback time.
Please follow the steps listed below.
1) Input i+MON, it is to select the output channel i.
2) Input j+WIN, it is to select the window of current output channel.
3) Input k+CAM, select input channel k. User may skip to the next step if current channel
already decodes in current playback channel.
4) Click (PLAY/PAUSE), user may go to the decoder record file playback setting
interface. (Right now, there is no playback in current window).
5) Set playback start time and end time. Please input the time (second-minute-hour) and
select the day-month-year. Click the OK button to begin the playback.
6) During the playback process, user may click (PLAY/PAUSE）to pause current
operation, click ▀(STOP) to stop playback.
Figure 2-2
If user click (PLAY/PAUSE）or ▀（STOP）without selecting a window, system begins
or stops playback of the first window by default.
Important
Right now, system supports control decoder playback remotely. It does not support the
local playback function.
2.3.5.5 PTZ
In the PTZ control mode, user may use the network keyboard to control the PTZ operation.
The interface is the same as when user are controlling via the Web. User may view the
17
video from the control channel on the left pane and the PTZ control interface on the right
pane.
User may input number i+PT to open PTZ operation interface. The number iis the
channel number user input.
The PTZ interface is shown as below. See Figure 2-3.
Figure 2-3
User may input the number (Step, preset and etc) from the panel. User may use the
keyboard to control the PTZ, zoom, and use joystick to control the direction. User may
also use mouse and touch panel. User may use the touch panel to control the positioning
and PTZ.
Please refer to the following sheet for detailed information.
Button Function
Number Input step, preset and etc.
Joystick Control PTZ direction.
Shuttle (Outer ring)/ / Zoom +/-
Jog(Inner dial)/ / Focus +/-
/ Aperture+/-
Light
Wiper
18
GOTO Preset
PATTERN Pattern start /Stop
TOUR Tour start /Stop
AUTOPAN Pan start /Stop
ESC Esc
2.3.5.6 Audio Talk
User may use the audio talk function to realize the bidirectional talk between the keyboard
and the selected device.
Here we use “a+AUX” to enable the audio talk function. See chapter 2.3.9.3 for audio talk
function setup.
In the local preview mode, user may follow the steps listed below.
1) Input number i+WIN, user may select channel of one device for current window.
2) Input number a+AUX, it is to enable the bidirectional talk with the selected window.
Click AUX to exit audio talk.
Important
In the local preview mode, input number a+AUX, user may enable the bidirectional talk
with device in the first window.
In any mode
Input number i+DEVC, it is to select device on the keyboard device list.
Input number a+AUX, it is to enable the bidirectional talk with the specified device.
Click AUX button to stop the bidirectional talk.
Figure 2-4
2.3.5.7 Snapshot
The snap function can only be valid in preview mode. The snap picture saved in the USB
device or a FTP server. Please refer to chapter 2.3.9.3 for snapshot setup.
19
Please follow the steps listed below.
1) Input number i+WIN, it is to select the window i for the output channel.
2) Input a+AUX (Please make sure user have set a+AUX as the snap shortcut button) or
button at the top of the joystick to enable network snap.
If user click the snapshot shortcut button directly, system snapshots the video in the first
window by default.
2.3.5.8 Record
The USB device record has two types: local preview record and remote channel record.
See Figure 2-5 and Figure 2-6.
Local preview record: During the preview process, select preview window to record.
Remote channel record: User may select an input a channel name to record.
Please follow the steps listed below.
Local preview record: Input number i + WIN + REC (Please make sure user are in
preview mode.).
Remote channel record: Input number j+ CAM+ REC.
If user click the record shortcut button directly, system records the video in the first window
by default.
User may click ▀(STOP) to stop record.
Figure 2-5
Table of contents
Other Dante Keyboard manuals
