Datexel PRODAT-04 User manual

Via monte Nero, 40/B – 21049 TRADATE (VA) ITALY
P one: [phone] Fax:[phone] - e-mail:[email protected] - www.datexel.it
Configuration interface for
serial ports RS-232
GENERAL DESCRIPTION
T e configuration interface PRODAT-04 allows to program, by dedicated software, all t e DATEXEL devices of t e SMART and SLIM series using bot fixed
workstations and laptops wit communication serial ports RS-232 on board.
An internal battery is available for t e eventual supply of t e transmitter on programming; t e battery's output voltage is provided on t e connector J4; t e same
voltage is used to power t e interface w en t e output voltage of t e serial port is lower of t e minimum voltage value necessary to t e rig t working of t e
device (± 7Vdc).
T e 1500 Vac galvanic isolation between t e lines of input/power supply and output is obtained by means of opto-couplers on t e data lines and a DC/DC
converter on t e power supply.
By t e dedicated cable (CVPR-03) it is possible to configure t e Intrinsically Safe devices.
Wit t e PRODAT-04 are provided t e standard cable CVP or t e cable CVPR-03, t e CD-ROM containing t e drivers to install t e programming software and
two Jack connectors for t e terminals J3 and J4.
T e configuration interface PRODAT-04 is in compliance wit t e Directive 2004/108/EC on t e Electromagnetic Compatibility.
EATURES
- Adapt to configure the devices of SMART and SLIM series
- Galvanic isolation between the transmission and receiving sides
- Internal battery
- Connector for external supply input
- Connector for external supply output
- EMC compliant – CE mark
- Programming of the DATEXEL devices, on field too
USER INSTRUCTIONS
A) Use with Standard devices.
The device on programming must be always powered as shown on its technical data-sheet.
T e interface PRODAT-04 must be connected to t e serial port RS-232 by pin-to-pin cable to t e connector J1 ; connect t e ' CVP ' cable from t e connector J2
to t e PRGM connector of t e device on programming.
It is also possible to power t e device on programming using t e internal battery (only for transmitters) connecting t e connector J4 to power supply terminal of
t e transmitter.
B) Use with Intrinsically Safe devices.
The device on programming must be always connected in according to the Safety Specifications reported on the technical data-sheet of the device .
The configurable devices are the following:
- DAT 1010 IS , DAT 1010 IS/HT;
- DAT 1015 IS , DAT 1015 IS/HT;
- DAT 1065 IS , DAT 1065 IS/HT;
- DAT 2015 IS , DAT 2015 IS/HT;
- DAT 4035 IS , DAT 4035 IS/HT.
T e connection diagrams A and B are s own on next page in t e section “PRODAT-04: Connections”.
To use t e PRODAT-04 refer to t e section “Installation Instructions”.
PRODAT-04
Type of battery ( Optional ) 6LF22 / 9 Vdc
External supply ( Optional ) 10 ÷ 30 Vdc (Transmitters)
18 ÷ 30 Vdc (Converters)
Current consumption < / =10 mA
RS-232 connection (pin-to-pin cable) DB9 connector
CVP/CVPR-03 connection 4 ways RJ11 plug
External supply IN connection 2.1 mm JACK connector
External supply OUT connection 2.5 mm JACK connector
Galvanic isolation among t e ways 1500 Vac, 50 Hz, 1 minute
Electromagnetic Compatibility Emission: EN 61000-6-3
Immunity: EN 61000-6-1
Operative temperature 0 ÷ 40 °C
Storage temperature (wit out battery) -20 ÷ 60 °C
Relative Humidity (not condensing) 0 ÷ 90 %
Weig t about 250 g.
Optional accessories - CVPR03 for t e programming of SMART
series DAT xxxx IS modules suitable for
application in azardous areas
TECHNICAL SPECI ICATIONS (Typical at 25 °C and in nominal conditions)

Datexel s.r.l. reserves its rig t to modify totally or in part t e c aracteristics of its product wit out notice at any time .
ED.07.09 REV.00
INSTALLATION INSTRUCTIONS
Follow t e next steps to use t e interface PRODAT-04.
- Connect t e PRODAT-04 to t e COM port of Personal Computer and to t e device on programming.
- Insert t e CD-ROM in t e apposite driver .
- Control t e COM port number w ere t e device is connected.
- Power t e device on programming.
- Install and run t e desired configuration software.
PRODAT-04: CONNECTIONS
ISOLATIONS STRUCTURE
Input side (RS-232) Output side( PGRM )
Ext Pow
In (J3)
Ext Pow
Out (J4)
HOW TO ORDER
To order t e device PRODAT-04 indicate t e following code.
ORDER CODE:
PRODAT-04
CONNECTOR
J1
J2
J3
J4
FUNCTION
RS-232 Connector
RJ11 4 ways plug for CVP cable connection
Jack connector for external supply input.
Jack connector for supply output.
P E R S O N A L
C O M P U T E R
D I A G R A M “ A ”
P R O D A T - 0 4
E X T E R N A L
P O W E R S U P P L Y
1 8 ÷ 3 0 V d c
C O N V E R T E R
J 1 J 2
J 3 J 4
C V P C A B L E
P E R S O N A L
C O M P U T E R
D I A G R A M “ B ”
P R O D A T - 0 4
( O P T I O N A L )
1 0 ÷ 3 0 V d c
T R A N S M I T T E R
J 1 J 2
J 3 J 4
C V P ( C V P R - 0 3 ) C A B L E
P R G M
PRGM
U S B
U S B
E X T E R N A L
P O W E R S U P P L Y
22
100 61
MECHANICAL DIMENSIONS (mm)
CONNECTION TABLE
P o s i t i v e
T e r m i n a l N e g a t i v e
T e r m i n a l
CONNECTORS J3 / J4 POLARITY
