Davey M5138 User manual

Installation and
Operating Instructions
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
The installation of this product should be carried out by a person knowledgable
in swimming pool plumbing requirements following the installation instructions
provided in this manual.
Please pass these instructions on to the operator of this equipment.
Davey Peristaltic Pump
AS Series
Model: M5138

2
Contents
1. Warnings and Tips..............................................................................................3
1.1 Proper use of the Pump ................................................................................3
1.2 Risks..............................................................................................................3
1.3 Toxic and/or Dangerous Liquid Dosage ........................................................4
1.4 Instruction for Diluting Pool Acid ...................................................................4
2. Pump Description................................................................................................5
2.1 Parts Description...........................................................................................5
2.2 Buttons Description .......................................................................................6
3. Installation and Recommendation.....................................................................7
3.1 Recommendations ........................................................................................7
3.2 Accessories Mounting ...................................................................................8
3.2.1 Bracket ........................................................................................................8
3.2.2 Mounting of the Clamp ................................................................................9
3.2.3 Mounting of Injection Valve .........................................................................9
3.2.4 Mounting of the Probe on the Probe Holder..............................................10
3.2.5 Mounting description of Tube on the Injection Valve.................................10
4. Connecting the power and pool pump to your
pH Controller.................................................................................................... 11
5. Commissioning and Operation ........................................................................12
5.1 Calibration Procedure..................................................................................12
5.2 Settings .......................................................................................................13
5.2.1 Adjustment of the Set point .......................................................................13
5.3 Operating Principle......................................................................................14
6. Maintenance.......................................................................................................14
6.1 Replacement of the Peristaltic Tube............................................................14
6.2 Maintenance of the Peristaltic Tube............................................................15
6.3 Maintenance of the Electrode......................................................................15
6.4 Controller Winterising..................................................................................15
6.5 Probe Winterising........................................................................................15
7. Trouble Shooting...............................................................................................16
Davey Repair or Replacement Guarantee............................................................17
In accordance with AS/NZS 60335.2.41 we are obligated to
inform you that this pump is not to be used by children or
inrm persons and must not be used as a toy bu children.

3
1.Warnings and Tips
Please read the warning notices very carefully because they provide
important information regarding safety in installation, maintenance and use
of the pH pump.
• Keep this manual in a safe place, so that it will always be available for
further consultation
• The device complies with N° 89/336/CEE “electromagnetic
compatibility” and N°73/23/CEE “ low voltage ” and also the
subsequent modication N° 93/68/CEE
Note: This pump has been constructed in accordance with best practice.
Product life, electrical and mechanical reliability will be enhanced if it
is correctly used and regularly maintained.
WARNING Any intervention or repair to the internal parts of the pump must
be carried out by qualied and authorised personnel. The manufacturers
decline all responsibility for the consequences of failure to respect this rule.
1.1 Proper use of the Pump
The pump should be used only for the purpose for which it has been
expressly designed namely the dosing of liquids. Any different use is to
be considered dangerous. The pump should not therefore be used for
applications that were not allowed for in its design. In case of doubt, please
refer to the details listed within this document, or contact your point of
purchase or Davey Water Products for further information. The manufacturer
of this product will not be liable for damage deriving from improper,
erroneous or unreasonable use of the pump.
1.2 Risks
• After unpacking the pump, make sure that it is completely sound. In
case of doubt, do not use the pump and contact Davey
•The packing materials (plastic bags, polystyrene, etc.) should be kept
out of the reach of children: As they may constitute a potential source of
danger
• Before you connect the pump make sure that the voltage ratings
correspond to your particular voltage supply. You will nd this value on
the rating plates attached to the pump
• The electrical installation to which the pump is connected must
comply with the local standards enforced in the state or country under
consideration
Use of electrical equipment always implies observance of some basic rules.
In particular:
- Do not touch with wet or damp hands or feet.
- Do not operate the pump with bare feet (example: swimming pool
equipment)
Never connect your pH pump direct to mains power. Always
connect it to the chlorinator power supply so it operates during the
preset ltration time cycles.

4
- Do not leave the equipment exposed to atmospheric agents
- Do not allow the pump to be used by children or unskilled individuals
without supervision
• In case of breakdown or improper functioning of the pump, switch it
off, but do not touch. Contact Davey for technical assistance for any
necessary repairs and insist on the use of original spares. Failure to
respect this condition could render the pump unsafe to use
• When the Davey AS Series pump is not in use for a substantial period
of time, or use is to be discontinued, disconnect the unit from any power
supply
Before carrying out any service on the pump:
1) Disconnect the mains power from the unit and
2) Relieve all the pressure from the pump head or the injection tube
In the event of possible losses on the hydraulic system of the pump
(breakage of the O-ring, the valves or the hoses), stop the pump
immediately and contact Davey.
1.3 Toxic and/or Dangerous Liquid Dosage
To avoid risk from contact with hazardous liquids or toxic fumes, always
adhere to the notes in this instruction manual and wear protective clothing
(gloves, goggles & overalls).
• Follow the instructions of the dosing liquid manufacturer
• Check the hydraulic part of the pump and use it only if it is in perfect
condition
• Use only the correct materials for the tubing, valves and seals to suit the
liquid to be dosed: where possible shield the tubing with PVC conduit
• Before disconnecting the metering pump, make sure to ush out and
neutralise the pump head with the proper reagent liquid
1.4 Instructions for diluting pool acid
The ChloroMatic®Salt Water Chlorinator with pH control, automatically
doses a diluted acid solution into the pool when the pH level needs to be
reduced. The peristaltic pump draws this diluted acid from a container in
which the solution is mixed.
Use the table below to determine what water/acid ratio is recommended for
your pool, in an approved 20 litre Hydrochloric Acid container.
IMPORTANT: KEEP BARE HANDS AWAY FROM POOL ACID AND ALWAYS
USE CAUTION WHEN HANDLING POOL CHEMICALS.

5
2.Pump Description
The Davey Peristaltic pump is characterised by its ability to measure pH
value (between 0 and 14) with its probe placed on the ltration system
that analyses the pool water.
Depending of the measured value, the pump will inject the required
amount of product needed to maintain the balance of the pool water.
2.1 Parts description
Here are the complete contents of the package you received. All parts
will be necessary for the proper operation of your device.
A. Peristaltic pump
B. 4 meters of PVC Cristal tube
C. Electrode/pH Probe & Protective Cap
D. Foot lter
E. Injection valve
F. Clamp DN50 x 2
G. Buffer solution pH7
H. Screws & Masonry plugs for wall mounting
I. Inline electrode holder
J. Shutter washer
A
Fig. 1
B
C D
E
F
F
H
G
I
J
Pool Size
Recommended Water/Acid
Dilution Ratio
Volumes for a Suitable
20 Litre Container
Water (parts) Acid (parts) Water
(Litres)
Hydrochloric
Acid (litres)
Up To 100,000 litres 5 1 17 3
Above 100,000 to 160,000 litres 3 1 15 5
Note: These ratios are based on Hydrochloric Acid strength of 28% and
should not be any greater than this percentage.
Please ensure that you keep the storage area of the acid well ventilated
and ensure you use a suitable container with resistance to Hydrochloric
Acid. These containers can be purchased at pool stores.

6
2.2 Buttons Description
CAL
SET
pH -
1. Press SET to see and adjust the set point.
2. Press CAL allows calibration of the pH level associated to the SET
button to change the value of the set point
3. Value/level of pH in water
4. pH - unit of measure to determine pool water chemical level. pH level
should remain between 7.2 and 7.6
Fig. 2
1 2
3
4

7
3.Installation Recommendations
3.1 Recommendations
• Install the pump in a dry place and well away from sources of heat
and in environments not exceeding 45°C. The operating minimum
temperature depends on the liquid to be pumped, bearing in mind that it
must always remain in a liquid state
• Carefully observe any standards in force in your state, territory or
country, as to electrical installation regulations and requirements
• The Davey AS Series pump will be in operation only when your ltration
pump is running
WARNING
• It is important to keep a minimum distance of 200mm
between the probe “C“ and the injection valve “E”
• The injection valve “E” must be placed last in the pipework
hydraulic installation
• In the case of an installation with redox and pH regulation,
it is advised to put the two sensors side by side and the
pH injection before chlorine injection to minimise the risk of
scale deposition on the chlorine injection
• For optimal service life of your peristaltic pump tube, it is
advised not to exceed a pressure of 1 bar and under no
circumstances exceed a pressure of 1.5 bar
• The pH probe must be located before any other device
such as a heater or an electrolyser
Please refer to the enclosed Davey ChloroMatic or Sanitiser
Installation & Operating Instructions for the “Injection Valve”
and “pH probe” location and positioning.

8
3.2 Mounting the Pump
3.2.1 Bracket
• Use mounting accessories « H » to x the bracket of the pump
• Remove the bracket on the pump by sliding it down
• Locate the bracket in the space chosen and mark the holes
• Drill the holes as required
(3mm for timber walls & 6mm for masonry walls)
• Fix the bracket to the wall
• Slide and secure pump into the bracket
Fig. 4
pH Pump
Mounting
Bracket

9
3.2.2 Mounting of the Probe clamp
3.3.3 Mounting of Injection Valve
Fig. 5
Fig. 7
Fig. 6
Fig. 8
Oring
A nut
Put Teon tape
on threads
Next
Pierce the top wall of the pipe
work through the clamp:
- Ø 8mm for the injection valve
- Ø 14 mm for the electrode/pH
probe.
This assembly is xed on the pipe
work.
E

10
3.2.5 Mounting description of the Tube on the Injection Valve
Fig. 10
A nut
Disk brake
Washer seat
Oring
Bracket
A nut
The PVC tube
A nipple
3.2.4 Mounting of the pH Probe into the Probe Holder
After removing the protective cap from the probe, you need to insert all
the parts as shown in the Fig.9.
Once the probe has been constructed as indicated in Fig.9, tighten
the probe nut without crimping the probe body. Push the probe
approximately 20mm into the pipe work so that the probe tip is
approximately halfway into the pipe work. Connect the probe lead to
the BNC terminal on the pump. (Fig.10)
The hydraulic hose is placed in the same way on the foot lter and on
the pump.
1. Slide the tube through the nut
2. Put the tube at the bottom of the conical nipple
3. Screw the nut by hand onto the nipple
Fig. 9
Fig. 11

11
4.Connecting the power and pool pump to your
pH Controller
Connection diagram for the ESC pH Pump System
The ESC pH pump system should ideally be plumbed and connected up as
shown in the diagram below.
Never connect your pH pump direct to mains power. Always
connect it to the chlorinator power supply so it operates during the
preset ltration time cycles.
If your pool pump is plugged into your Chlorinator:
Step 1. Remove the pump plug from the Chlorinator pump power socket.
(Usually at the bottom of the Chlorinator)
Step 2. Plug the 3 pin male piggy back plug on your pH pump into the
Chlorinator pump power socket.
Step 3. Plug your pool pump into the female piggy back socket on the
back of the pH pump power socket.
Flow
Flow
Example of
ESC50
NB: The pH probe must be located
before a heater or an electrolyser.

12
5.Commissioning and Operation
5.1 Calibration Procedure
This operation is used to set the sensor response reading of the pH and
peristaltic pump.
Some important points
• To ensure the probe signal remains as accurate as possible, please
follow the procedure as listed below during the commissioning of the
pool and every 3-4 weeks thereafter, or as required.
• The procedure is renewed in case of abnormal consumption of
chemicals.
1) Remove the
protective cap
of the probe and
keep it for reuse
at the time of
winterising
2) Rinse the
probe in tap
water for at least
20 minutes
Steps:
Before carrying out the calibration of the probe,
remember to:
• Stop the ltration pump
• Close the isolation valves, if tted
• Remove the probe from the probe holder
• Put the shutter washer (g. 12) in to close off
the hole in the probe holder
• Open the isolation valves, if tted
• Turn on the ltration pump and check that the
ON/OFF switch (I/O) of the AS Series
pump is switched to “I”
• Carry out the calibration of the probe and
repeat the previous actions to put the probe
back in place. As described in 3.2.4
Nut
Disk brake
Washer seat
Shutter Washer
Oring
Fig. 12
Probe
Protective
Cap

13
5.2 Settings
Functions Factory Settings
Unit of measure pH
Set point 7.4
Type of regulation Acid- reduce the pH by dosage of an acid (pH-)
pH 7 calibration To an accuracy more than 0.2 pH
Proportional regulation* Factory function
* Proportional: Dosage adjusted according to different cycles time/breaks. At the approach
of the set point, the pump reduces its time of dosing.
5.2.1 Adjustment of the Set Point
The calibration of AS Series is completed;
It is now ready to measure the pH of your pool.
3) Next immerse
the probe in the
pH 7 solution, stir
around in bottle
and leave it in the
solution being
careful not to
touch the probe
or the cable.
4) After a period of at least one minute,
the stabilized value is displayed. Press the
CAL button until the display shows CAL
ashing then release. The quality of the
probe reading is then briey displayed.
When you press the SET button,
the value of the set point is
displayed.
To change the value of the set
point, press SET and press CAL
by pulse. Each pulse changes
the pH value by 0.1 pH,
between 7.0 and 7.6.
CAL
SET
pH -
CAL
SET
pH -
CAL
SET
pH -

14
5.3 Operating Principle
The Davey Peristaltic pump adjusts its dosage in proportion to the
demand. It will dose less if the displayed measure is near the set point. In
normal operation, the AS Series pump will increase its ‘non operational’
time period proportional to the required dosage demand. That is why the
device often has the pump off. This is normal.
Adjust the pH slowly to preserve the natural quality of your water.
After 30 minutes without pressing the keys, the backlight turns off to save
energy. A short press on SET or CAL turns it on again.
6.Maintenance
6.1 Replacement of the Peristaltic Tube
Follow steps 1 to 10 as shown
1.
5.
9.
Fig. 13
2.
6.
10.
3.
7.
4.
8.

15
6.2 Maintenance of the Peristaltic Tube and Roller Holder
The Peristaltic Pump uses a roller holder and a “squeeze” tube to pump
the acid into the pool. This tube is perishable and must be replaced
periodically. We recommend replacement approximately once per year.
The tube should be visually inspected regularly for leaks or damage.
It is recommended that the roller holder be periodically inspected and
replaced every 2 years.
6.3 Maintenance of the probe
Over time, in addition to the normal wear of the probe, according to use
and water quality more or less calcareous, measurement will deteriorate.
A thin layer of limestone with other elements present in the pool water will
deposit on the sensing element of the probe. To overcome this problem,
it is advisable to use the cleaning solution for electrode/pH probe and
redox AYACSOLNET01 and follow the procedure on the suppliers’ bottle.
6.4 Controller Wintering
Only in areas where subzero temperatures are experienced
• During winterising, you must protect the peristaltic tube
• It is advisable to remove the peristaltic tube and ush it with fresh
water. Once complete ensure the tube is completely dry and re-install
as shown on page 13, Fig 13, 5.1
6.5 Probe Wintering
• During winterising, the probe must be removed from of the installation
and pipe work
• The protection cap as shown on page 11, must be lled with fresh
water a 1/3 of the way up
• Place the probe into the protection cap and water and store in a safe
place until after the winter period is over. (Re-install as shown on page
10, gure 9)

16
7. Trouble Shooting
Error Reasons How to solve it
CAL Err
If this error is displayed
during the calibration
phase and cycle it is as
a result of:
1). Your pH probe is not
working properly
2). Your buffer solution
is polluted
3.) You have water/
oxidisation in the
probe connector
1). Change the probe
2). Change the buffer
solution
3). Change over the
probe
Alarm Alr Err
If the pH is lower than
pH 5 or above pH 9, this
alarm will be displayed
and dosing will be
stopped.
Adjust your water
parameter manually so
that it comes back to the
required value of these
parameters:
- Total alkalinity
- TH (hardness)
- pH
The dosing pump will
restart as soon as the
pH reading
If trouble persists, please contact Davey or your nearest Davey
Dealer for assistance.

17
Davey®Repair or Replacement Guarantee
In the unlikely event that this Davey product develops any malfunction within one year of the date of
original purchase due to faulty materials or manufacture, Davey will at our option repair or replace it
for you free of charge, subject to the conditions below.
Should you experience any diculties with your Davey product, we suggest in the rst instance that
you contact the Davey Dealer from which you purchased the Davey product. Alternatively you can
send a written letter to Davey at the addresses listed below. On receipt of your claim, Davey will seek
to resolve your diculties or, if the product is faulty or defective, advise you on how to have your
Davey product repaired, obtain a replacement or a refund.
Your Davey One Year Guarantee naturally does not cover normal wear or tear, replacement of product
consumables (i.e. mechanical seals, bearings or capacitors), loss or damage resulting from misuse
or negligent handling, improper use for which the product was not designed or advertised, failure to
properly follow the provided installation and operating instructions, failure to carry out maintenance,
corrosive or abrasive water or other liquid, lightning or high voltage spikes, or unauthorized persons
attempting repairs. Where applicable, your Davey product must only be connected to the voltage
shown on the nameplate.
Your Davey One Year Guarantee does not cover freight or any other costs incurred in making a claim.
Please retain your receipt as proof of purchase; you MUST provide evidence of the date of original
purchase when claiming under the Davey One Year Guarantee.
Davey shall not be liable for any loss of prots or any consequential, indirect or special loss, damage
or injury of any kind whatsoever arising directly or indirectly from Davey products. This limitation
does not apply to any liability of Davey for failure to comply with a consumer guarantee applicable
to your Davey product and does not aect any rights or remedies that may be available to you under
Consumer Legislation in your state, territory or country.
If in Australia, you are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Should your Davey product require repair or service after the guarantee period; contact your nearest
Davey Dealer or phone the Davey Support Centre on the numbers listed below.
For a complete list of Davey Dealers visit our website (davey.com.au) or call:
AUSTRALIA
Head Office
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 232 839
Fax: [phone]
Email: [email protected]
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: [phone]
Email: [email protected]
Website: daveynz.co.nz
EUROPE
ZAC des Gaulnes
355 Avenue Henri Schneider
69330 Meyzieu, France
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: daveyeurope.eu
INTERNATIONAL
Australian Head Office
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: davey.com.au
® Davey is a trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017.
NORTH AMERICA
Ph: [phone]
Email: [email protected]
Website: daveyusa.com
MIDDLE EAST
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: daveyuae.com

18
NOTES :

19

20
AUSTRALIA
Head Office
6 Lakeview Drive,
Scoresby, Australia 3179
Ph: 1300 232 839
Fax: [phone]
Email: [email protected]
Website: davey.com.au
Davey Water Products Pty Ltd
Member of the GUD Group
ABN 18 066 327 517
NEW ZEALAND
7 Rockridge Avenue,
Penrose, Auckland 1061
Ph: 0800 654 333
Fax: [phone]
Email: [email protected]
Website: daveynz.co.nz
EUROPE
ZAC des Gaulnes
355 Avenue Henri Schneider
69330 Meyzieu, France
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: daveyeurope.eu
INTERNATIONAL
Australian Head Office
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: davey.com.au
® Davey is a trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017.
NORTH AMERICA
Ph: [phone]
Email: [email protected]
Website: daveyusa.com
MIDDLE EAST
Ph: [phone]
Fax: [phone]
Email: [email protected]
Website: daveyuae.com
* Installation and operating instructions are included with the product when purchased new.
They may also be found on our website.
P/N 402616-4
