Dawon E&A Aone Grill User manual

Please read before using.
Thank you for purchasing the Smokeless, Eco-Friendly Aone Electric Grill! Please read the information below before using
the grill in order to ensure safe and correct use of the product.
Assembly
Order
Main
Body
→1 →2 →3 →4 →5 →6 →7
(7) Grill Pan/Multi-pan
(6) Controller
(5) Heat Radiator
(4) Coanda Air Guide
(3) Oil Fence
(2) Suction Fan
Main Body
(1) Oil Tray
1. Without fail! First put water into the oil tray
(approximately 4oz.)
2. (The grill should already be assembled, but follow this if
re-assembling). When assembling the Coanda Air Guide,
press both ends until a “snapping” sound is heard,
correctly attaching it to the body.
3. Match the direction of the arrow indicators on the Heat
Radiator to the direction of the arrow indicators inside the
main body in order to attach it to its correct position.
4. Before using, operate the temperature control knob after
putting food on the grill pan.
5. Since danger of fire exists, be careful and make sure not
to grasp the grill or multi-pan handles with bare hands.
* When using the multi-pan, never operate the suction fan.
There is danger of product damage.
* Be careful of wind, air conditioning, or a fan does not blow in
the direction of the grill. (The effectiveness of the oil mist and
smoke purification system can diminish).
* Before using the AOne Grill, without fail read the User
Manual and then use it safely.
Questions? [e-mail]

1
| Storage | Warranty Attached |
We sincerely appreciate you purchasing this product.
Please keep this User Manual, which includes the Warranty for correct product use and customer
service.
User Manual
Smokeless, Eco-friendly Roaster
Aone Grill
* Specifications of the product are subject to change as product quality improvements are made.

2
Contents
1. Product Configuration & Assembly Procedure……………….3
2. Precautions………………………………………………………5
3. How to Use……………………………………………………….8
4. Items to Check before Applying for Customer Services……11
5. Warranty & Warranty Provisions……………………………...12

3
To all of our Dear Customers
You are kindly requested to become fully acquainted with this User Manual for safe use and handling
of this product. Please keep this User Manual readily available to refer to when the product does not
work as intended or when there is a question about the product.
Product
Specifications
Product Name:
Aone Grill
Model Name:
Aone
Manufacturer:
Dawon E&A Corp.
Rated Voltage:
110V –120V
Power Consumption:
1200W
Weight:
Around 9.07 lbs
Dimension:
11.8 x 20.24 x 5.28
(inches)
Product Configuration & Assembly Procedure
No.
Name
⑦
Grill Pan / Multi-pan
⑥
Controller
⑤
Heat Radiator
④
Coanda Air Guide
③
Oil Fence
②
Suction Fan (Impeller)
Main Body
①
Oil Tray
⑧
Power Cable
Assembly
Procedure
① ②③④⑤⑥⑦⑧

4
Optional Item:
Item Name
Remarks
Multi-pan (includes
Tempered Glass
Lid)
Lid Assembly
① Handle
② Handle Support
③ Glass Lid
④ Rubber Gasket
⑤ Metal Gasket
⑥ Screw
1
2
Assemble / disassemble by taking hold of
handle as shown in the drawing. Make sure the
oil fence reaches the correct position as shown
when assembling the main body.
There are arrow marks on both ends of the
Coanda Air Guide. After attaching Coanda Air
Guide to main body in the direction indicated by
the arrows in the drawing, push both ends to
fully assemble.
3
4
When assembling the radiator to the main body,
attach it firmly to the position that correctly
matches the direction of the arrow indicators
shown in the drawing.
When assembling the controller to the main
body, take hold of the handles on both ends and
assemble / disassemble as shown in the
drawing.

5
Precautions
Please become fully acquainted with the below contents and adhere to the methods of use as they
are very important matters associated with product safety.
Warning
Use the designated power cable only. Use of a power cable other than the designated
power cable can result in causing a fire.
Be sure to use the product as rated at 120 V. Using the product at higher voltages other
than 120 V can cause fire or electric shock.
If the power cable is damaged or abnormal in any way, stop using it. Grabbing and pulling
the power cable or bending it by force, when in use, can cause fire or electric shock.
Do not clean or repair the product with the plug connected to an electric outlet. Since
there is the danger of causing electrical shock, be sure to disconnect the electric plug
completely.
Use the product only after checking that the plug does not wiggle and is securely
connected to an electric outlet. If the plug is not securely connected, there are dangers of
electric shock, outbreak of fire, and such.
Make sure that the power cable does not get pressed from or damaged by anything that
is heavy. There are dangers of causing accidents such as electric shock or the outbreak
of fire.
Do not plug or unplug the product with wet hands. Doing so presents the danger of
electric shock.
Make sure that hands or areas of the skin do not come into contact with the hot grill pan
or multi-pan. You might get burned.
Make sure not to hold the handles of the grill pan or multi-pan when they are hot. Use the
handle only after it is in a sufficiently cooled down state. Otherwise, you might get burned.
Do not let cord hang over edge of table or counter, or touch hot surfaces.
Do not use appliance for anything other than intended use.
Warning
Failure to follow these instructions could result in serious
injury or death.
Caution
Failure to follow these instructions could result in serious
injury or damage to the product.
This symbol calls attention to dangerous situations that
can occur and to be cautious.
This symbol shows what not to do.
This symbol indicates things that must always be done.

6
Precautions (cont.)
Make sure that metal objects, chopsticks, etc., are not inserted into the controller hole.
There is danger of electric shock or malfunction. (Particular attention must be paid when
there are children nearby.)
This product is prohibited from being used in places where it can come into contact with
flame, combustible gas, rainwater, or wetness. Doing so can cause electric shock or the
outbreak of fire.
This product is prohibited from being used in places which have an unstable surface, or
placed on a surface covered with a material that reacts to and weakens with heat. Doing
so could result in the outbreak of fire.
Do not place on or near a hot gas or electric burner, or in a heated oven.
Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
Stop using the product in the event when abnormal vibrations or noise occurs.
People who rely on others for assistance due to a physical or mental disability and people
who lack the skills to handle the product should not use it.
Caution
Do not pour water into the controller or allow water to come into contact with it. There are
dangers of short circuit, electric shock, and malfunction.
Do not use anything other than the exclusive-use grill pan and multi-pan. There is danger
of product malfunction.
Disassembling, repairing, and reconfiguring the product by anyone other than this
company’s service professional technician is prohibited. The outbreak of fire or abnormal
functioning can occur.
When attaching or detaching the power cable
to the outlet, be sure to grasp the plug firmly to
attach/detach it. The danger of electric shock
or the outbreak of fire can occur due to a
damaged power cable.
When attaching or detaching the power cable to
the main body of the grill, be sure to grasp the
connector firmly to attach/detach it. The danger of
electric shock or the outbreak of fire can occur
due to a damaged power cable.

7
Major Components of Precaution
Please become fully acquainted with the below contents and adhere to methods of use as they are
very important matters associated with product safety.
Pan (Cooling Fan Motor)
Taking care that the rubber gasket is not damaged, assemble/disassemble by
twisting in the horizontal direction. If contact is not made correctly, the suction
(intake) fan may not function as designed.
Make sure that the square rubber gasket on both ends are correctly fastened
since vibration or noise can occur. Be careful to make sure that the square rubber
gasket does not get damaged.
Make sure that excessive force is not applied to the suction (intake) fan and be
careful not to drop it.
Multi-pan (Hot Pot Pan)
Absolutely do not operate the suction (intake) fan when using the multi-pan. If you
use the multi-pan while the suction (intake) fan is operating, it may cause damage to the
product.
Make sure that the handles of the multi-pan are not touched when they are hot. Do not
touch/hold the handles when it is hot. Touch the handles only when they are sufficiently
cooled down.
When cooking, putting water in the oil tray is recommended even when the multi-pan is
used.
Water Quantity: about 4 oz.
Heat Radiator
Be careful when washing the heat radiator or when it is in use because there is the
danger that its shape can be damaged if too much force is applied to it.
The heat radiator can become scratched, smudged, and chipped. This is normal and will
not affect its functionality.
Square rubber gasket
Square rubber gasket

8
How to Use
01
Preparation for
Cooking
A. Check all around the product.
Clear away all flammable or non-heat-resistant items within the
range of 1 ft.
B. Put water into the oil tray.
* Water Quantity: About 4 oz.
C. Since the suction fan can cause vibration, place the product on a flat
surface.
02
How to Cook
A. Cooking Meat (Using the Grill Pan)
1. After putting the meat on the grill pan, set the temperature
controller to the MAX level, turn on the suction fan switch at the
same time, and add ingredients. (After heating up, issues of
odor, smoke, popping grease, etc., can occur when adding
cooking ingredients.)
2. Adjust the temperature controller knob appropriately to properly
cook.
B. Cooking Fish (Using the Grill Pan)
1. Put fish on the grill pan and then turn on the suction fan switch
before heating.
2. Set the temperature control knob to level 2-3.
3. Turn the fish over on the grill pan after about 10 minutes, and
continue cooking the fish for about 8 minutes. (Cook
appropriately according to the size and variety of fish.)
C. Cooking Using the Multi-pan
1. If the lid is kept on until just before a broth comes to boil, it
helps to shorten the completion time of what is being cooked.
2. If cooking with the lid covered, as the broth comes to a boil, it
may start to spill over. Slowly open the lid and continue
cooking.
Absolutely do not operate the suction fan when using the
multi-pan. Otherwise you might get burned.
D. Cautions When Cooking
1. Do not pour cold water onto the pan when the pan is hot. The
pan may become deformed.
2. When cooking using the grill pan, try to cut the food
ingredients that are added so they are below the air-intake
holes in order for the oil mist purging system to be effective.
When side dishes, such as vegetables are to be cooked on
the grill pan using other cooking tools, use them in a
height lower than the position of the air vent and put them
near the air-intake holes.
03
After Cooking
A. Cautions When Cleaning the Product
1. Unplug the product first, and clean it after it has cooled down.
2. The pan is hot right after cooking so there is the danger that it
will cause burns. Clean the product after the pan has sufficiently

9
cooled down.
3. Each component, beginning with the grill pan and multi-pan,
can be cleaned using kitchen detergent, sponge, wash cloth,
etc. The product can be damaged if metal brushes, abrasive
powder, sharp brushes, and such are used to clean the
components.
4. Use only neutral detergent for cleaning.
5. Make sure to dispense the oil tray and oil fence before cleaning
When moving the product without taking it apart, the grill’s
main body can become contaminated or the suction fan
damaged due to residual substance (oil) in the oil pan and oil
fence. Since cleaning can be difficult due to neglecting
residual substance (oil) for long periods of time, clean the
product in warm water after using it once it has sufficiently
cooled off. Clean the product parts with warm water after the
cooking is finished and the hot parts cool enough.
Cleaning the Suction Fan
After cleaning the suction fan wings using a neutral (soft) detergent, in the
area between the indicated in the picture above, dry it
sufficiently to prevent damage to the suction fan.
Be careful not to let water come into contact with the motor area,
including the electric parts to prevent damaging the suction fan.
Also, be careful not to damage the square rubber gasket at both
ends.
B. Drying
1. After removing the residue and water from the controller and
suction fan, allow them to dry on their own. There is danger of
product failure when attaching components that have not dried
completely.
2. Do not dry components directly over a fire. There are dangers
of product discoloration, warping, and outbreak of fire.
03
After Cooking
C. Storage
1. Once cooking is complete, turn the temperature controller to the
OFF position and disconnect the power cable for storage.
Square rubber gasket
Square rubber gasket

10
2. Store the product in the storage case or box so that is does not
get damaged.
3. Since moisture, dirt, bugs, and such can cause product
damage, be sure to store the product indoors.
4. Periodically remove dirt and dust from the power cord plug.
An outbreak of fire can occur due to dirt and dust build-up on
the plug.
Heat-resistant Rubber Packing
If the heat-resistant rubber packings intalled in 4 places of the main body, as
shown in the figure above, are removed, the grill’s main body may become
warped due to high temperature. Be careful to make sure that the heat-
resistant rubber packings attached to the main body do not become
damaged or lost.

11
Items to Check Before Applying for Customer Service
If there is anything wrong with the product, please contact the customer service center. Please check
the below questions and answers before requesting repair.
No.
Inquiry
Solution
1
The temperature control
knob lamp does not
light.
(Power problem)
When the temperature control knob lamp does not light up or
the grill pan (or multi-pan) does not get hot even though the
temperature control knob is switched on, first check to make
sure that the power cable is properly connected between the
main body and the electric outlet. If the product still does not
function, check to confirm that the components are assembled
in the correct order.
2
Smoke is not being
ventilated well.
The effectiveness of the oil mist purification system is
diminished and odors can occur if external airflows, like
natural wind, electric fans, air conditioners, and such blow in
the direction of the grill.
Issues of odors and smoke can arise due to adding food
ingredients on the grill after the grill has heated up. In order to
remove smoke and odor effectively, do not preheat the grill.
Turn on the suction fan function immediately after putting meat
or fish on the grill.
Check that the oil tray is correctly attached to the main body. It
is possible that the suction function is diminished due to a gap
(space) between the main body and the suction pan.
Smoke suction may not take place as it is supposed to if the
food ingredients put on the grill are too thick. Since blowing
winds can push against food ingredients on the grill and cause
smoke to escape outside of the scope of the air circulation
system flow, cut all added food ingredients to the appropriate
size for cooking.
3
Continuous smoke when
cooking fish
When the grill’s temperature is high, the smoke can cause
watery and burning eyes and odor spreads. When grilling fish,
set the temperature control knob to level 2-3.
4
The inside of the
product becomes caked
with oil
Check to make sure that the Coanda Air Guide and the oil
fence are properly attached in the correct place. Since oil
(water) can spill to the lower part of the grill’s body when
moving the product with oil (water) remaining in the oil pan, be
sure to move it after disassembling the oil fence from the oil
pan.

12
Warranty & Warranty Provisions
Product Warranty
Warranty No.:
Product Name
Aone Grill
Warranty Period: 1
Year
Model Name
Aone
Purchase Date
Month Day Year
Name of Buyer
Name of Seller
Address
Address
Telephone
Telephone
* For warranty service and customer service, please be sure to fill out this form when purchasing the
product.
No.
Warranty
Standards
Description
1
Criteria
Repair service, exchange and refund for the product having the
model name Aone are subject to the relevant regulations of each
country.
2
Scope
a) This product warranty is limited and applicable to the Aone
Grill product.
b) Any defect occurring under normal use in accordance with
the User Manual shall be repaired or the relevant product
shall be replaced free of charge for one year form the date
of purchase. Customers can apply to the Customer
Service Center or other desingated service centers by
region or country for warranty service.
3
Exceptions
a) Exchange or refund is not available in below cases;
-Box has been opened or destroyed
-Product is damaged or a part of the product is lost due
to customer’s misuse of the product,
-Product value has been significantly reduced by the
customer’s use of the product
b) Repair service fee will be charged to the customer even
within the warranty period in below cases:
-Malfunction or damage of the product caused by the
customer’s misuse, error, or neglect.
-Malfunction or damage of the product caused by the
repair, disassembly, or modification performed by a third
party other than the designated sevice center.
4
Repair Out of
Warranty Period
Upon request for making repair after the warranty period expired, the
customer may bear the burden of repair costs and travel expenses.
5
Information Privacy
Policy
a) Dawon E&A Co., Ltd. (“Dawon”) or its authorized local
partner companies may use or record customer’s personal
information in detail for answering questions, taking care of
repair service, and/or verification of service availability.
b) Dawon and its authorized local partner companies will not
share the customer’s personal information with other third
parties except in the following cases;
-Repair service or other verification works are left to
other third parties
-When required by law
c) If you have any questions about the privacy policy, please
contact us through our Customer Service Center or the
designated service centers.

13
14, Dolgoji-ro 23-gil, Seongbuk-gu, Seoul, Republic of Korea
Imported and Distributed
exclusively by
Aone Grill America, Inc.
www.aonegrillamerica.com
e-mail: [e-mail]
