DB Audio Raptor Proffessional User manual

Raptor
PROFFESIONAL
PROFFESIONAL
T-Rex
PROFFESIONAL
User Guide

Dear Customer,
Thank you for purchasing this DB Audio Product.
DB Audio is proud to introduce a new series of professional subwoofers designed in
Britain by a team of dedicated engineers our goal is to provide you, our customer,
with the absolute best subwoofer on the market.
Raptor series Features:
?High power handling 300w RMS, 1400w peak power
?Black powder finish steamed basket
?Polyphone cone with 1” rubber edge
?2” hi-temp 4 layer voice coil
?Double stack 70 oz magnet
?2- layer black cone spider
?Dual 2 ohm impedance
?Chrome push terminal
?Rubber gasket
Raptor series Specifications:
Raptor
PROFFESIONAL
1
350
350

Raptor Enclosure Design
10" Subwoofer
Vb..........1.00 Cubic Feet
Tun........29.44Hz F3 29Hz
Port .......3Ø (Diameter) 16.89" Length
Port Velocity........9.54%
Tb.........1.157 Cubic Feet
Material........18mm (0.709") MDF
Raptor
PROFFESIONAL
16.12"
12.5"
18.81"
14.82"
8.16"
16.06"
13.5"
24.56"
15.63"
8.18"
Raptor Enclosure Design
12" Subwoofer (1)
Vb..........1.5 Cubic Feet
Tun........30.75Hz F3 32Hz
Port .......3Ø (Diameter) 8.12" Length
Port Velocity........14.05%
Tb.........1.681 Cubic Feet
Material........18mm (0.709") MDF
Raptor Enclosure Design
12" Subwoofer (2)
Vb..........1.1 Cubic Feet
Tun........29Hz F3 37Hz
Port .......3Ø (Diameter) 15.23" Length
Port Velocity........13.28%
Tb.........1.3 Cubic Feet
Material........18mm (0.709") MDF
16.12"
12.5"
21.10"
14.82"
8.16"
These diagrams are for
illustration purposes only. All
dimensions are approximations.
Please refer to speaker size when
constructing enclosure.
2

T-Rex series Features:
?High power handling 1000w RMS , 3000w peak power
?Black powder finish die cast basket
?Kevlar woven non-press paper cone with EROM foam surround
?3” hi-temp 4-layer voice coil
?Double stacked 200 oz magnet
?Mirror- image multi-layer nomex spider
?Chrome finished T-yoke with logo etched
?Dual 2 ohm impedance
?Chrome push terminal
?Rubber gasket
?Robber magnet boot
T-Rex series Specification:
T-Rex
PROFFESIONAL
3

T-Rex Enclosure Design
10" Subwoofer
Vb..........1.00 Cubic Feet
Tun........31Hz F3 27Hz
Port .......3"Ø (Diameter) 14.46" Length
Port Velocity........15.64%
Tb.........1.148 Cubic Feet
Material........18mm (0.709") MDF
14.88"
13"
19"
14.69"
8"
18"
14.5"
20.76"
16.56"
10"
T-Rex Enclosure Design
12" Subwoofer (1)
Vb..........1.5 Cubic Feet
Tun........29.7Hz F3 28Hz
Port .......4"Ø (Diameter) 19.39" Length
Port Velocity........12.71%
Tb.........1.80 Cubic Feet
Material........18mm (0.709") MDF
T-Rex Enclosure Design
12" Subwoofer (2)
Vb..........1.1 Cubic Feet
Tun........32.74Hz F3 32Hz
Port .......4"Ø (Diameter) 22.55" Length
Port Velocity........13.95%
Tb.........1.418 Cubic Feet
Material........18mm (0.709") MDF
16"
14.5"
19.65"
16.56"
8"
T-Rex
PROFFESIONAL
These diagrams are for
illustration purposes only. All
dimensions are approximations.
Please refer to speaker size when
constructing enclosure.
4

T-Rex Enclosure Design
15" Subwoofer (1)
Vb..........2.00 Cubic Feet
Tun........31.47Hz F3 32Hz
Port ...... (x 2) 4"Ø (Diameter) 26.77" Length
Port Velocity........10.78%
Tb.........2.6 Cubic Feet
Material........18mm (0.709") MDF 20"
17"
23.08"
19.24"
11"
20"
17"
20.33"
19.24"
11"
T-Rex Enclosure Design
15" Subwoofer (2)
Vb..........1.6 Cubic Feet
Tun........33.7Hz F3 35Hz
Port .......(2x) 4"Ø (Diameter) 19.39" Length
Port Velocity........11.54%
Tb.........2.33 Cubic Feet
Material........18mm (0.709") MDF
T-Rex
PROFFESIONAL
These diagrams are for
illustration purposes only. All
dimensions are approximations.
Please refer to speaker size when
constructing enclosure.
5

PROFFESIONAL
XTINCT series Features:
?High power handling 1500 W RMS , 5000 W peak power
?Red finish die cast basket
?Kevlar woven non-press paper cone with EROM foam surround
?3” hi-temp 4-layer voice coil
?Triple stacked 300 oz magnet
?Mirror image multi-layer nomex spider
?1” ultra-thick top washer
?Dual 2 ohm impedance
?Chrome push terminal
?Rubber gasket
Rubber magnet boot
EXTINCT series Specification:
?
6

Xtinct Enclosure Design
12" Subwoofer (1)
Vb........... 0.9" Cubic Feet
Tun........36Hz F3 34Hz
Port ...... (x2) 3"Ø (Diameter) 26.29"
Length
Port Velocity........21.27%
Tb.........1.27 Cubic Feet
Material........18mm (0.709") MDF
(recommended 25mm (1.0") MDF)
17"
14"
16.95"
16.12"
9"
18"
14.5"
20.76"
16.56"
10"
Xtinct Enclosure Design
12" Subwoofer (2)
Vb..........1.5 Cubic Feet
Tun........33Hz F3 27Hz
Port .......4"Ø (Diameter) 14.63" Length
Port Velocity........21.79%
Tb.........1.76 Cubic Feet
Material........18mm (0.709") MDF
(recommended 25mm (1.0") MDF)
Xtinct Enclosure Design
15" Subwoofer
Vb..........1.1 Cubic Feet
Tun........30.4Hz F3 30Hz
Port .......(2x) 4"Ø (Diameter) 29.05" Length
Port Velocity........16.21%
Tb.........2.725 Cubic Feet
Material........18mm (0.709") MDF
(recommended 25mm (1.0") MDF)
21"
16.5"
23.35"
19.29"
11"
PROFFESIONAL
These diagrams are for
illustration purposes only. All
dimensions are approximations.
Please refer to speaker size when
constructing enclosure.
(Note: If using the recommended
25mm (1") MDF, please add this
amount to the enclosure dimensions)
7

How to connect your subwoofer
This section offers instructions on connecting your subwoofer in a mono and stereo
configuration.
Each side of the voice coil is 2 ohm each. Most amplifiers are 4 ohm stable in mono.
Please connect using diagrams and descriptions below.
(Note: Please consult your amplifier user guide when connecting)
1.
Sub Right)
Positive to Negative (Sub Left to
2.
Negative to Negative (
Amp)
Positive to Positive (Sub Left to
Amp)
Sub Right to
Connection in Series
Connection in parallel
2.Positive to Positive ( Amp)
Negative to Negative ( Amp)
1.Positive to Positive (Sub Left to Sub
Right)
Negative to Negative (Sub right to
Left Sub)
Sub to
Sub to
Right
Left
2.Positive to Positive (Amp to Sub1 Left)
Positive to Positive (Sub1 Left to Sub2 Right)
Negative to Negative (Amp to Sub1 Right)
Negative to Negative (Sub1 Left to Sub2 Right)
1.Negative to Positive (Sub1 Left to Sub1 Right)
Negative to Positive (Sub2 Left to Sub2 Right)
Connection in parallel using two subs in stereo
9

Recommended Amplifiers:
Inphase IPA 1001 Bridged Connect Sub in 4ohm
Raptor
PROFFESIONAL
IPA 1001 Bridged Connect Sub in 4ohmInphase
If connecting 2 Subwoofers Use IPA 2001D or IPA1601
10"
12"
T-Rex
PROFFESIONAL
IPA 1601 Bridged Connect Sub in 4ohmInphase
IPA 1601 Bridged Connect Sub in 4ohmInphase
10"
12"
15" IPA 1601 Bridged Connect Sub in 4ohmInphase
If connecting 2 Subwoofers Use IPA 4001D
PROFFESIONAL
IPA 2001D Connect Sub in 1ohmInphase
12"
15" IPA 2001D Connect Sub in 1ohmInphase
10
For further details on recommended
amplifiers please visit:-
www.inphaseaudio.co.uk

Manufactured and distributed by
Inphase International Limited
www.inphaseinternational.co.uk
www.db-audio.us
