DB Drive Euphoria F4100 User manual

LIMITED WARRANTY
Euphoria warrants any products purchased in the U.S.A.
from an authorized Euphoria dealer. All products are warranted to
be free from defects in material and workmanship under normal
use and service for a period of two (2) years when the unit is
installed by an authorized Euphoria dealer. Non-authorized
dealer installed products carry a one (1) year parts and labor limit-
ed warranty. This warranty applies to the original purchase only.
Euphoria will either repair or replace (as its option) any
unit that had been found to be defective and under warranty
provided the defect occurs within:
Two (2) years, if purchased through an authorized Euphoria
dealer with original proof of purchase.
This limited warranty periods do not extend to units having been
subjected to misuse, abuse, neglect, or accident. Products that in
Euphoria’s judgment shows evidence of having been altered,
modified, or serviced without Euphoria’s authorization, will be
ineligible under this warranty.
To obtain warranty services please contact your retailer or visit
our website at www.euphoriacaraudio.com for more details.
USER MANUAL
Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
www.euphoriacaraudio.com
F475 : F4100
M750 : M1500 : M2250 : M2750

www.euphoriacaraudio.com

Low Impedance Stability
F475 - 2 Ohm Stereo (4 Channel)
F4100 - 2 Ohm Stereo (4 Channel)
M750 - 1 Ohm Mono
M1500 - 1 Ohm Mono
M2250 - 1 Ohm Mono
M2750 - 1 Ohm Mono
Bass Boost
The DB Drive Euphoria Mono amplifiers feature a variable Bass Boost gain centered at 45Hz that
enables the user to adjust the amount of bass boost needed to achieve the desired amount of low
end response from the subwoofer system.
The DB Drive Euphoria 4 channel amplifiers (F475 & F4100) feature a variable 12dB
slope High Pass crossover for channels 1 and 2. Channels 3 and 4 feature a selectable 3
way 12dB Variable crossover that enable the user to select High Pass, Band Pass or Low
Pass settings.

M750, M1500, M2250 and M2750
M750 - M1500 - M2250 - M2750

F475 - F4100 (M750 – M1500 – M2250 – M2750)

( Mono: M750, M1500, M2250, M2750)( 4 Channel: F475, F4100 )
The M750, M1500, M2250 and M2750 are equipped with a variable 24db slope
Lowpass crossover network and a 24db slope subsonic lter. The mono amps also
feature a variable Bass Boost EQ is set at 45Hz.
In some subwoofer enclosure installations it may necessary to use the Phase Shift
feature. The Phase Shift button sets the Subwoofer signal between 0 degree
setting and 180 degree settings. This will also allow you to ne tune the subwoofer
enclosure depending on vehicle location.
The DB Drive Euphoria 4 channel ampliers (F475 and F4100) feature a 12db Slope crossover
network. Channels 1 and 2 can be used in the High pass setting or full range and channels 3 and
4 feature a selectable 3 way crossover system that can be used in High pass, Bandpass or low
pass settings.
Adjustments and Settings
The F475 and F4100 ampliers are equipped with a variable crossover network that allows you to
select the crossover mode (Highpass—Full Range) and desired crossover point for channels 1
and 2. With a High Pass range between 50Hz and 4 KHz, channels 1 and 2 can be used with a
component tweeter or any type of full range speaker requiring High Pass ltering. Channels 3
and 4 allow you to select between a 3 way completely variable High pass Bandpass or Low pass
setting that can be congured in many dierent ways allowing the user set up the perfect audio
system.
For example if you wish to drive a pair of subwoofers on channels 3 and 4 in the bridged mode,
you can select the LP switch settings on the amplier to lter out the high frequencies. You will
then need to adjust the Lowpass control to the desired frequency setting. This will only send low
frequencies to your subwoofers. If you wish to use the Bandpass crossover lter you must set the
x-over push button switch settings to BP. Once the BP switch setting is selected you will use both
the Lowpass and Highpass controls to lter out the unwanted low and high frequencies to create
the desired Bandpass lter. (The Bandpass crossover is available on only channels 3 and 4) To use
the Highpass lter select the x-over push button switches to the HP setting, this will lter out any
unwanted low frequencies.
Built-in Crossover
12

Dimensions
F475
F4100
M750
M1500
M2250
M2750
Height
2.28" / 58mm
2.28" / 58mm
2.28" / 58mm
Width
7" / 178mm
7" / 178mm
7" / 178mm
7" / 178mm
Length
10" / 254mm
2.28" / 58mm
2.28" / 58mm
7" / 178mm10.8" / 274mm
7.6"/ 193mm
9.2" / 234mm
10.8" / 274mm
2.28" / 58mm 7" / 178mm
13" / 330mm
Power (RMS) @ 14.4 VDC , THD .04% 4Ω:
Power (RMS) @ 14.4 VDC , THD 1% 2Ω:
Power (RMS) @ 14.4 VDC , THD 1% 4Ω Bridgeable:
Power Supply Input Voltage:
THD (1kHz @ 4Ω):
Bandwidth (-3 dB):
Damping Factor (1kHz @ 4Ω):
S/N Rao (as weighted @ 1 Volt):
Input Sensivity:
Minimum Load Impedance:
Input:
Channel 1-2 Filter Slope:
Channel 1-2 Filter Range:
Channel 3-4 Filter Slope:
Channel 3-4 Filter Range:0Hz)
4 x 75W
4 x 95W
2 x 300W
11VDC to 15VDC
0.04%
18Hz - 22KHz
100
99db
.20MV - 7.0V RMS
2Ω
Pre In RCA
12dB
(FR = Un-filtered)
(HP = 50Hz - 4KHz)
HP @ 12db St. , LP/BP @ 12dB St.
(HP = 50Hz ~ 4KHz) (BP = 32Hz ~ 4KHz)
(LP = 32Hz ~ 250Hz)
Power (RMS) @ 14.4 VDC , THD .04% 1Ω:
Power (RMS) @ 14.4 VDC , THD 1% 2Ω:
Power Supply Input Voltage:
THD (1kHz @ 4Ω):
Bandwidth (-3 dB):
Damping Factor (1kHz @ 4Ω):
S/N Rao (as weighted @ 1 Volt):
Input Sensivity:
Minimum Load Impedance:
Input:
Output:
Mono Low Pass Filter Slope:
Low Pass Filter Range:
Sub-sonic Filter Slope:
Sub-sonic Filter Range:
Bass Boost @45Hz:
1 x 750W
1 x 325W
11VDC to 15VDC
0.04%
10Hz - 220Hz
126
99db
.20MV - 7.0V RMS
1Ω
Pre In RCA
Pre out RCA Full Range
12dB
40Hz ~ 200Hz
12dB
10Hz ~ 40Hz
0 ~ 12db
Power (RMS) @ 14.4 VDC , THD .04% 1Ω:
Power (RMS) @ 14.4 VDC , THD 1% 2Ω:
Power Supply Input Voltage:
THD (1kHz @ 4Ω):
Bandwidth (-3 dB):
Damping Factor (1kHz @ 4Ω):
S/N Rao (as weighted @ 1 Volt):
Input Sensivity:
Minimum Load Impedance:
Input:
Output:
Mono Low Pass Filter Slope:
Low Pass Filter Range:
Sub-sonic Filter Slope:
Sub-sonic Filter Range:
Bass Boost @45Hz:
1 x 2250W
1 x 1125W
11VDC to 15VDC
0.04%
10Hz - 220Hz
126
99db
.20MV - 7.0V RMS
1Ω
Pre In RCA
Pre out RCA Full Range
12dB
40Hz ~ 200Hz
12dB
10Hz ~ 40Hz
0 ~ 12db
4 x 100W
4 x 150W
2 x 400 W
11VDC to 15VDC
0.04%
18Hz - 22KHz
100
99db
.20MV - 7.0V RMS
2Ω
Pre In RCA
12dB
(FR = Un-filtered)
(HP = 50Hz - 4KHz)
HP @ 12db St. , LP/BP @ 12dB St.
(HP = 50Hz ~ 4KHz) (BP = 32Hz ~ 4KHz)
(LP = 32Hz ~ 250Hz)
1 x 1500W
1 x 750W
11VDC to 15VDC
0.04%
10Hz - 220Hz
126
99db
.20MV - 7.0V RMS
1Ω
Pre In RCA
Pre out RCA Full Range
12dB
40Hz ~ 200Hz
12dB
10Hz ~ 40Hz
0 ~ 12db
1 x 2750W
1 x 1375W
11VDC to 15VDC
0.04%
10Hz - 220Hz
126
99db
.20MV - 7.0V RMS
1Ω
Pre In RCA
Pre out RCA Full Range
12dB
40Hz ~ 200Hz
12dB
10Hz ~ 40Hz
0 ~ 12db
M2250 M2750
M1500
F4100
F475
M750
PROBLEM LOOK FOR SOLUTION
No Output Blown fuse Replace
Bad RCA Cable(s) Replace
+12V at power terminal Check connection
+12V at remote terminal Check connection
Grounding point are clean and tight Check for ground w/meter
Head unit’s fader not in center position Set to center position
Master and slave settings Confirm correct setting
Low Output Check level adjustments
Re-adjust Bad RCA cable(s) Replace
Improper level matching Re-adjust
Master and slave settings Confirm correct settings
Engine Noise Grounding points are clean and tight Check for ground w/meter
Ground all components at same point Ground at same point
Try different grounding point Change for better ground
Bad RCA cable(s) Replace
Use high quality shielded RCA cables Rejects inducted noise
Low vehicle charging system and/or battery Fix and/or replace
Red protection L.E.D. illumintaed Speaker short Check speakers connection
for short circuit
Speaker grounding out Make sure speaker wires do
not touch chassis ground
Impedance too low Check speaker impedance
Overheating Check mounting location for
adequate air circulation.
Speaker impedance too low
