DB Drive NEO1.5K User manual

Due to continuous improvement of the product the Specifications are subject to change without notice.
TM
DB DRIVE warrants any products purchased in the U.S.A.
from an authorized DB DRIVE dealer. All products are warranted to be
free from defects in material and workmanship under normal use and
service for a period of (1) year when the unit installed by an authorized
DB DRIVE dealer. Non-authorized dealer installed products carry a (1)
year parts and labor limited warranty. This warranty applies to the origi-
nal purchase only.
DB DRIVE will either repair or replace (as its option) any unit
that has been found to be defective and under warranty provided the
defect occurs within:
One (1) year if purchased through an authorized DB DRIVE dealer.
This limited warranty does not extend to units that have been
subjected to misuse, abuse, neglect, or accident. Products that in DB
DRIVE’s judgment shows evidence of having been altered, modified,
or serviced without DB DRIVE’s authorization, will be ineligible under
this warranty.
To obtain warranty service please contact your retailer or see
our website www.dbdrive.net for more details.
All warranty claims must be handled directly through the
authorized DB Research dealer they were originally purchased from

monoblocks
4 channels

NEO4
NEO1.5K
(2 Ohm Minimum)
(1 Ohm Minimum)
(2 Ohm Minimum)

Due to continuous improvement of the product the Specifications are subject to change without notice.
9 10
Input Voltage @ 12 - 14.4 VDC
@ 4 Ohm
@ 2 Ohm
@ 4 Ohm Bridged
THD (1kHz @ 4Ω):
Bandwidth (-3 dB):
Damping Factor (1k Hz @ 4Ω):
S/N ratio ( as weighted @ 1 Volt):
Input Sensitivity:
Minimum Load Impedance:
Input :
Channel 1-2 filter range:
Channel 3-4 filter range:
Variable Bass Boost:
Input Voltage @ 12 - 14.8 VDC
@ 1 Ohm
@ 2 Ohm
THD (1kHz @ 4Ω):
Bandwidth (-3 dB):
Damping Factor (1k Hz @ 4Ω):
S/N ratio ( as weighted @ 1 Volt):
Input Sensitivity:
Minimum Load Impedance:
Input :
Mono Low Pass filter slope:
Low Pass filter range:
Sub - Sonic Filter Slope:
Sub - Sonic Filter Range:
Bass Boost @45 Hz:
NEO4
4 x 125W
4 x 250W
2 x 500W
0.04%
18Hz- 22KHz
100
99db
.20MV - 5.0V RMS
2Ω
Pre in RCA
55Hz - 750Hz
55Hz - 750Hz
45Hz @ 0 ~ 12dB
NEO1.5K
1 x 750W
1 x 350W
0.04%
18 - 150Hz
126
99db
.20MV - 5.0V RMS
1Ω
Pre in RCA
12dB
30Hz ~ 150Hz
12dB
15Hz ~ 55Hz
0 ~ 12dB
