SVS 3000 User manual

3
If your set-up doesn’t include an Auto-EQ
feature, adjust the subwoofer volume control
to level-match to your loudspeakers.
For additional guidance on recommended
crossover settings based on your specific
speakers, visit our Subwoofer Matching tool at
www.svsound.com/merlin, or contact the SVS
Sound Experts.
Set the 3000 In-Wall Subwoofer Amplifier’s volume to -10, then run auto-set-up in
your AV receiver/processor. It is important to re-run your receiver’s auto-calibra-
tion set-up if you are upgrading from another subwoofer.
The front panel features an intuitive all-new user interface with controls for adjusting the subwoof-
er’s primary settings. There function buttons are for Volume, Low Pass Frequency, and Phase.
Simply press the setting you want to change and then use the “+” and “-” buttons to adjust the
settings.
Please note, some DSP settings can only be accessed using the SVS app.
The SVS Subwoofer Control App is the easiest way to
access all the advanced control features available on your
3000 In-Wall Subwoofer Amplifier, from the comfort of
your favorite seat. This includes volume, low pass filter,
room gain, phase, polarity, parametric EQ, custom presets,
and more.
1
Set It Up
System Setup Guide
3000 In-Wall Subwoofer System
Get Control
4
Get Calibrated
HOME / VOLUME
MOVIE
PRESET
LOW PASS FILTER
OPTIONS
-22 10 050
20 40 200 0
6
4
2
0
-2
-4
-6
-8
-10
-12
PEQ1
ACTIVE
PEQ2
ACTIVE
PEQ3
DISABLED
BOOST: 0 dB
Q FACTOR: 1.2
FREQ: 200 Hz
PARAMETRIC EQ
AUTO EQ - START
MIC INPUT
Please see the other Installation Guide for installing the 3000 In-Wall
Subwoofer and installing the 3000 In-Wall Subwoofer Amplifier with or
without the rack mount kit.
Congratulations on choosing the SVS 3000 In-Wall Subwoofer System, a groundbreaking achieve-
ment in architectural subwoofer design. The following steps will guide you through the quick and
easy setup process.
We strongly recommend reading the 3000 In-Wall Subwoofer Owner’s Manual to get the
best possible performance. You’ll find useful information about amplifier placement, connec-
tions, DSP functions and more.
Your SVS 3000 In-Wall Subwoofer Amplifier can be controlled from the
SVS Subwoofer Control App or via the front panel.
Download The App
On The Subwoofer
For iOS, Android, &Amazon Devices
AUTO / ON
UP (+)
LOW PASS FREQUENCY
PHASE
VOLUME
DOWN (-)
REG ISTER
REG ISTER
Register Your New SVS Product:
Thank you for choosing SVS! Registering your SVS product expedites any Sound Experts support requests, confirms your warranty registration and provides a proof of purchase.
Plus, as a registered customer, you’ll be the first to get SVS news and updates.
Register your product now at: www.svsound.com/register

CENTER
REAR FRONT
SUBWOOFER
(SUB1)
LINE LEVEL OUTPUTS
RECEIVER/PREAMP
2
Hook It Up
Need Help?
Line Level Connection – Single LFE Channel
Speaker Level Connection – Single 3000 In-Wall Subwoofer
Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels
Note: Make sure the subwoofer amplifier and all other associated electronics are turned offwhen connecting.
Note: The 3000 In-Wall Subwoofers (Single or Dual) do not need to be installed to proceed with the following amplifier setup steps, though it is highly recommended in-wall rated speaker wire is already installed at
the necessary locations before installation.
For most set-ups, a single RCA subwoofer interconnect cable running from the AV Receiver’s “SUB 1” output to the 3000 In-Wall Subwoofer Amplifier’s “LFE” line level input is all
that’s required to connect the subwoofer to your system.
If you run separate Preamplifier and Power Amplifiers, follow the “Line Level Connection – Stereo Receiver or Preamplifier Left/Right Channels” connection guide below.
Single Subwoofer Systems
A single set of speaker wire is used for a Single Subwoofer system. Connect the speaker wire,
paying attention to polarity, to a single set of 5-way binding posts on the 3000 In-Wall Subwoofer
amplifier.
Dual Subwoofer systems
If connecting Dual 3000 In-Wall subwoofers, simply pull
the rubber cover offto expose the 2nd set of binding
posts on the 3000 In-Wall amplifier. You can now connect
the speaker wire from the first subwoofer to the top pair
of binding posts, and then connect the speaker wire for
the second subwoofer to the bottom pair of binding
posts.
Note: The output from both sets of binding posts are identical, so it does not matter which subwoofer
is connected to the top or bottom pair of binding posts on the amplifier.
Our Sound Experts are standing by to help with subwoofer placement, installation, calibration, AV receiver settings,
room rattle and anything else you need advice about. Just call, email or chat online with our Sound Experts:
[phone] | [email protected] | www.svsound.com
LINE LEVEL OUTPUTS
REAR FRONT
R
L
RECEIVER/PREAMP
Review your product now at: www.svsound.com/review
Review Your New SVS Product:
Your SVS product is built with the highest standards of engineering excellence to achieve stunning sound quality and dynamics. Honest feedback is important to us and others making decisions about audio products. Please share your ownership experience with the SVS community by writing a review today.
RE
VIEW
RE
VIEW
100 - 120V ~ or 200 - 240V ~
50 - 60Hz, 800W
Speaker Level Connection – Dual 3000 In-Wall Subwoofers
100 - 120V ~ or 200 - 240V ~
50 - 60Hz, 800W
Subwoofer 1 Subwoofer 2
