DEBIX POLYHEX BPC-iMX6ULL-03 User manual
Polyhex Technology Co., Ltd.
2/13
Declaration of conformity
CE
This product has passed the CE test for environment specifications.
FCC
This equipment has been tested and found to comply with the FCC rules.
Technical support and assistance
1. Visit polyhex website http://www.polyhex.net/ where you can find the latest
information about the product.
2. Contact your distributor, sales representative or polyhex’s customer service center
for technical support if you need additional assistance.Please have the following info
ready before you call:
Product name
Description of your peripheral attachments
Description of your software(operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Polyhex Technology Co., Ltd.
3/13
Safety instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any DC outlet before cleaning. Use a damp cloth. Do
not use liquid or spray detergents for cleaning.
4. Keep this equipment away from humidity.
5. Put this equipment on a reliable surface during installation. Dropping it or letting it fall
may cause damage.
6. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
9. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
10. Never pour any liquid into an opening. This may cause fire or electrical shock.
11. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
12. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
13. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW 0° C (0° F) OR ABOVE 70°
C (158° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
14. Due to the sensitive nature of the equipment it must be stored in a restricted
access location, only accessible by qualified engineers.
DISCLAIMER: Polyhex disclaims all responsibility for the accuracy of any statement of this
instruction.
Polyhex Technology Co., Ltd.
4/13
Contents
Chapter 1 Introduction ...................................................................................................................................... 5
1.1 Product introduction .........................................................................................................................5
1.2 Hardware specifications ...................................................................................................................... 5
1.3 Safety Precaution .................................................................................................................................6
Chapter 2 Hardware Function ........................................................................................................................... 7
2.1 Overview ..............................................................................................................................................7
2.2 LED Status Indicator .............................................................................................................................7
2.3 Bluetooth button .................................................................................................................................8
Chapter 3 wiring and installation ...................................................................................................................... 9
3.1 Wiring .................................................................................................................................................. 9
3.2 Installation ......................................................................................................................................... 11
Polyhex Technology Co., Ltd.
5/13
Chapter 1 Introduction
1.1 Product introduction
BPC-iMX6ULL-03 is a RISC architecture platform with high performance, wide
temperature and flexible design. It serves as a gateway connecting inverters and
remote monitoring center in power and energy application, which plays an important
role.
1.2 Hardware specifications
1.2.1 General
Certification: FCC, CE
Dimensions(W x D x H): 107mm x 107mm x 35mm
Power Requirements: USB Type-C DC 5V
Weight: 343g
OS Support: Buildroot
1.2.2 System Hardware
CPU: NXP i.MX 6ULL single core Arm Cortex-A7 792MHz
Memory: 512MB DDR3/DDR3L
Indicators: SYS LED, LAN(LINK, ACT),STAT LED
Storage: 8GB eMMC
1.2.3 System Software
OS Support: Buildroot
1.2.4 I/O Interface
LAN: 1 x 10Mbps/100Mbps RJ45 port
USB Ports: 1 x USB, Rev. 2.0 Host(default)
LED: 1 x SYS LED, 1 x STAT LED
Button: Can be customized(Bluetooth button by default)
SMA RF: 1 x WIFI antenna(2.4GHz, 3dBi), 1 x LoRa antenna(optional),
1 x GPS antenna(optional)
1.2.5 Environment
Humidity: 5 ~ 95%(non-condensing)
Operating Temperature: 0~70℃
Polyhex Technology Co., Ltd.
6/13
Operating Humidity: 20~95%(non-condensing)
1.3 Safety Precaution
The following messages informs how to make each connection. In most cases, you
will simply need to connect a standard cable.
Warning!
Always disconnect the power cord from your chassis whenever you are not
working on it. Do not connect while the power is on. A sudden rush of power
can damage sensitive electronic components. Only experienced electronics
personnel should open the chassis.
Caution!
Always ground yourself to remove any static electric charge before touching
BPC-iMX6ULL-03. Modern electronic devices are very sensitive to electric
charges.Use a grounding wrist strap at all times.Place all electronic
components on a static-dissipative surface or in a static-shielded bag.
Polyhex Technology Co., Ltd.
7/13
Chapter 2 Hardware Function
2.1 Overview
The following figures show the indicators and connectors on BPC-iMX6ULL-03.
Figure1 BPC-iMX6ULL-03 overview
2.2 LED Status Indicator
2.2.1 System Status Indicator
Figure2 system status indicator
Polyhex Technology Co., Ltd.
8/13
LED
Status
Description
SYS (in control)
Lighting
Power is on
off
Power is off
STAT(in control)
blinking
System works normally
off
System works abnormally
2.2.2 Ethernet Status Indicator
Figure3 Ethernet Status Indicator
LED
Color
Description
Link
Orange
Blinking, Ethernet data
being transmitted
Active
Green
Lighting, the Ethernet cable
is plugged in
2.3 Bluetooth button
Figure4 Bluetooth button
By default, press Bluetooth button for 5s, the STAT LED will blink, which indicates the Bluetooth
can be used.
Link
Active
Bluetooth button by default(can be customized)
Polyhex Technology Co., Ltd.
9/13
Chapter 3 wiring and installation
3.1 Wiring
3.1.1 Power Supply Wiring
Figure5 Power supply wiring
BPC-iMX6ULL-03 supports power input DC 5V.
Polyhex Technology Co., Ltd.
10 /13
Type C connector pin assignments
pin
signal
pin
signal
A1
GND
A2
A3
A4
VBUS
A5
CC1
A6
D+
A7
D-
A8
A9
VBUS
A10
A11
A12
GND
B1
GND
B2
B3
B4
VBUS
B5
CC2
B6
D+
B7
D-
B8
B9
VBUS
B10
B11
B12
GND
3.1.2 Communication Ports
3.1.2.1 USB Connector
USB Connector Pin Assignment
Pin
Signal
1
VCC
2
DATA-
3
DATA+
4
GND
Default: UART-MODE
Polyhex Technology Co., Ltd.
11 /13
3.1.2.2 LAN Connector
LAN Connector Pin Assignments
Pin
Assignment
Description
1
TD+
Transmit+
2
TD-
Transmit-
3
RD+
Receive+
4
N/C
Not used
3.2 Installation
Check the BPC-iMX6ULL-03 box pc, Wi-Fi antenna and power adapter after you
receive the product.
Figure6 antenna
Polyhex Technology Co., Ltd.
12 /13
Figure7 BPC-iMX6ULL-03
Connect the antenna to the corresponding antenna interface
Figure8 power adapter
WIFI Antenna
Polyhex Technology Co., Ltd.
13 /13
Figure 9 BPC-iMX6ULL-03 with antenna
Connect the power adapter to the power interface of BPC-iMX6ULL-03
Figure 10 BPC-iMX6ULL-03 with antenna
When you find that the SYS LED is lighting, and the STAT LED is blinking, it means the gateway has been
powered on.
