decakila KMHS003W User manual
KMHS003W
HAIR CLIPPER
FIT A COMB ATTACHMENT
Fit one of the Comb attachments by sliding it onto the Clippers as shown.
The comb will click into place when fully engaged.
Fit the small Comb attachment to cut hair lengths in the range 4mm - 16mm
or the large Comb attachment to cut hair lengths in the range 18mm- 30mm.
09
SAFETY GUIDE
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
Do not use the appliance if the blade damaged.
The appliance can become hot during use, only use for a maximum of 30
minutes then allow to cool for 30 minutes.
01
Never use the appliance on any part of the body other than for shaving the
face.
Always check the appliance for damage prior to use. If any damage is
observed, do not use the appliance.
Do not place the appliance on or near a heat sensitive surface.
Do not use the appliance or handle the USB cable with wet hands.
Recharge the appliance using the supplied USB cable only connect to power
supply（must be 5V 1A）.
To protect against electric shock, never allow the appliance or USB cable
with charger to come into contact with water or any other liquid.
Never leave the appliance unattended when connected to the mains power
supply. And keep the appliance dry.
02
Do not attempt to replace the battery.
Do not use for wet shaving - use the appliance only for shaving on dry skin.
Do not throw away the appliance with the normal household waste at the
end of its life, but hand it in at an oicial collection point for recycling. By
doing this, you help to preserve the environment.
03
MAIN COMPONENTS
1.Short Cut Comb ( 4 mm - 16 mm cut)
2. Long Cut Comb ( 18mm - 30 mm cut)
3. Blade Assembly
4. Thinning Control
5. Cutting Length Control
6 On/O Switch
7. Power / Charging Indicator
8. Cleaning Brush
9. Lubricating Oil
10. USB cable
04
1
3
4
5
6
7
2 8
910
CHARGING
05
Before using the appliance charger, ensure that the voltage of your electrici-
ty supply is the same as that indicated on the appliance（5V 1A）or it will
be broken or burned by wrong voltage.
Your clippers contain re-chargeable batteries and may be used cordless for
approximately 45 minutes when the batteries are fully charged.
IMPORTANT NOTE: The batteries must be charged for a minimum of 8
hours for the first charge cycle. This will ensure the maximum life for
the batteries.
CHARGING THE CLIPPERS
Connect the USB cable which is already with adapter to the charging socket
or only connect it to computer or power bank for charging
The Power/Charging indicator on the Clippers will illuminate green.
Leave the Clippers until fully charged for 8 hours.
Aer charging, disconnect the USB cable from the mains to conserve power
and store it in a safe place.
The Clippers are now ready for use.
NOTE: The clippers will only show the green light while in charging or
fully charged, there is no light change function, so please carefully
calculate the full charge time 8 hours for disconnection.
06
07
BATTERY CARE
To ensure maximum life from the batteries in your Rechargeable clippers,
follow these guidelines:
Do not recharge the Clippers between sessions. Wait until the batteries are
exhausted before recharging.
Discharge the appliance completely twice a year (switch on and run until the
Clippers stop).
If the Clippers haven’t been used for a long period of time, discharge the
appliance completely, then fully charge them for 8 hours before use.
Never charge the Clippers for more than 24 hours.
Do not use the Clippers while connected to the Charger, or may cause short
life of battery
08
OPERATING INSTRUCTIONS
Never recharge the appliance in a temperature below 10°C.
Avoid recharging the appliance in direct sunlight or near a radiating heat
source.
WARNING: Never use the appliance on wet hair. it is only designed for
use on dry hair.
When using this appliance for the first time it is advisable to experiment
initially on an area of light hair growth.
10
SETTING THE CUTTING LENGTH
To set the cutting length, rotate the
Cutting Length Control wheel to
set for a shorter or longer cut.
The cutting length is marked on the
side of the comb.
Set the Thinning Control to the le
position to thin hair or to the right
to cut hair.
11
CUTTING HAIR
Before starting, comb the hair in the direction of hair growth as shown
Switch on the Clippers by sliding the On/o switch up toward the ‘O’
position.
Pressing the Comb against the head, start by clipping the sides from the
bottom of the head upwards.
Slowly move the Clippers up towards the top of the head cutting small
amounts at a time.
Repeat step 6 around both sides and the back of the head.
Clip the top of the head from front to back.
NOTE:Do not push the clippers or force the clippers through the hair.
Never use the appliance on any part of the body other than for shaving the
face.
Always check the appliance for damage prior to use. If any damage is
observed, do not use the appliance.
Do not place the appliance on or near a heat sensitive surface.
Do not use the appliance or handle the USB cable with wet hands.
Recharge the appliance using the supplied USB cable only connect to power
supply（must be 5V 1A）.
To protect against electric shock, never allow the appliance or USB cable
with charger to come into contact with water or any other liquid.
Never leave the appliance unattended when connected to the mains power
supply. And keep the appliance dry.
12
CUTTING HAIR
WARNING: The Clipper blades are very sharp when unguarded.
CAUTION: Care should be taken when using the Clippers without the
Clipping guide fitted as the Clippers will remove any hair that comes into
contact with the blades.
Switch o the Clippers.
Do not attempt to replace the battery.
Do not use for wet shaving - use the appliance only for shaving on dry skin.
Do not throw away the appliance with the normal household waste at the
end of its life, but hand it in at an oicial collection point for recycling. By
doing this, you help to preserve the environment.
13
Remove the Comb attachment.
Switch on the Clippers.
Position the Clippers so that only one edge contacts the hair.
Slowly shape the hair around the ears and contour the neckline by position-
ing the blades against the neck and moving downwards.
For final trimming of the hair, fringe or beard, use scissors (not provided).
14
AFTER USE
When you have finished, switch o the Clippers by setting the On/O switch
to the ‘I’ position.
Always clean the blades aer use with the brush provided.
CARE AND CLEANING
The appliance must be unplugged before cleaning.
The black plastic Comb Attachments should be cleaned in running water.
Ensure they are completely dry before using them.
Clean the housing of the Clippers with a so, dry cloth.
The cutting blades should be lightly oiled with the oil provided once every
few haircuts.
15
NOTE:Do not use any harsh detergents, abrasives, solvents or cleaners.
never immerse in water to clean. Dry thoroughly before use.
STORAGE
The appliance should never be stored whilst hot or whilst still connected to
the mains. Always ensure the appliance is switched o, unplugged from the
mains and has cooled down before storing.
DISPOSAL
Before disposing of this appliance, the internal rechargeable battery must
be removed for separate disposal.
NOTE: This process is not reversible, please give it to the professional
team
16
STORAGE
Power supply: 5 V 1A (NiMH rechargeable batteries)
Charging time: approx.8hours
Operating time with fully charged battery: approx. 45 minutes
SPECIFICATIONS
Model: KMHS003W
Noise figure: 72 dB
17
CHARGER, COMPUTER OR POWER BANK
Output rating:5V 1A
This symbol on the product or in the instructions means that
your electrical and electronic equipment should be disposed
at the end of its life separately from your household waste.
There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or
your retailer where you purchased the product.
User guide
www.decakila.com Global Links Technology Co. Pte. Ltd.
Made in China Jiangsu China. 2021.D02
