Defender Security DFR-MN-215HD User manual

1
21.5” 1080P CCTV LED MONITOR
MODEL: DFR-MN-215HD

2
IMPORTANT SAFETY INFORMATION
Please read these instructions carefully before use and retain for future reference.
• When using electrical appliances basic safety precautions should always be
followed.
• Check that the voltage indicated on the PSU rating plate corresponds with that of
the local network before connecting the appliance to the mains power supply.
• Only use the supplied PSU or one of identical specication.
• The power supply must be connected to a grounded mains supply.
• There are no user serviceable parts in this appliance. Refer all servicing to
qualied personnel.
• Do not operate the unit if you detect smoke or a strange smell coming from the
unit.
• If the screen is cracked or damaged the monitor must be considered scrap and
disposed of under local WEEE regulations.
• Install the appliance on a stable and level surface. Avoid any unstable locations in
order to avoid damage to property or personal damage.
• This monitor is for indoor use only.
• Do not install above a heat source or close to heat generating devices.
• Do not cover or in any way block the ventilation slots.
• Ensure there is ample space surrounding the monitor in order to allow ventilation
and avoid overheating.
• If the monitor is not in use for a long period of time, switch the power off and
unplug the power supply.
• Before cleaning, switch off the power and unplug the power supply.
• When cleaning, use a soft lint-free dry cloth to remove any dust that may have
accumulated.
• Do not use any chemicals, abrasives or solvents that could damage the unit.
OPTIONAL WALL MOUNTING
WHAT’s INCLUDED
• AC Mains cable
• Power Supply Unit
• Monitor
• User Manual
Caution: The wall mount must be capable of supporting the monitor’s net weight.
• To mount your monitor to the wall you need to purchase a suitable VESA wall
mount for the size and weight of the monitor with 100 x 100mm M4 x 8mm screws.
• Place the monitor face down on a protective cloth and attach the wall mount to the
matching captive nuts in the rear of the monitor casing.
• Remove the four screws from each side of the mounting stand and remove the
stand.
• It is advisable to connect all required cables to the monitor before nalising the
mounting to the wall as access to the connection sockets is less restricted.

3
CONNECTIONS
OPERATION
• DC: input from the power supply 12V 4A
• HDMI: Lets you connect a device, such as a DVR with an HDMI or a DVI output.
• HD Analogue 1 IN: BNC connections support CVBS/CVI/TVI/AHD.
• HD Analogue 2 IN: BNC connections support CVBS/CVI/TVI/AHD.
• HD Analogue 2 OUT: Video loop though output. Support HDA2 for coaxial control
protocol pass.
• You can use the side panel buttons in the lower right part of your monitor to
operate many of the monitor’s features or use the remote control.
• POWER: Turns on / off the monitor
• SOURCE: accesses the available video input signals (HDA1/HDA2)
• +/-: Controls left / right, incremental value change within a menu option.
• MENU: Displays the OSD main menu.
• In the main menu, use’+’ or ‘-’ button to highlight the required option, then press
‘MENU’ to select then ‘+’ or ‘-’ to adjust the chosen setting.
• Press ‘MENU’ to return to the previous menu and press again to exit the menu.
DC HDMI OUT IN IN
HD Analogue 2 HD Analogue 1
ON SCREEN MENUS
HDA1/HDA2 and HDMI Input Conguration
1. Picture
PICTURE Setting the image brightness (0-100).
CONTRAST Setting the image contrast (0–100).
SATURATION Setting the image Saturation (0–100).
HUE Setting the image hue (0–100).

4
HDMI
3. Information
2. Menu
HDA1/HDA2
3. Information
Language OSD language selection.
OSD H Pos OSD horizontal position adjustment (0-100).
OSD V Pos OSD vertical position adjustment (0-100).
OSD Time OSD display dwell time selection (5-30s).
Reset OSD setting data reset to factory settings.
Display video format, resolution, and frequency about the current input.
Made in China. PR2 9PP
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
SPECIFICATION
Model DFR-MN-215HD
Screen Size/Aspect ratio 21.5” LED/16:9
Resolution 1920 x 1080 @ 60Hz
Pixel Pitch 0.248 x 0.48mm
Response Time 5 ms
Brightness/Contrast ratio 250cd/m2/1000:1
Viewing angle 178o/178o
Inputs 1 x HDMI/ 2 x BNC
VESA Mounting 100 x 100mm
Power 12V DC 4A
PSU 100-240V AC 50Hz <25W
Operating environment 0-40oC@5-90%humidity
Weight 4.1kg
Man Rev 1.0
