Asus VW247H User manual

VW247 Series
LED Monitor
User Guide
September 2010

ii
Table of contents
Notices......................................................................................................... iii
Safety information ...................................................................................... iv
Care & Cleaning........................................................................................... v
1.1 Welcome! ........................................................................................ vi
1.2 Package contents........................................................................... vi
1.3 Assembling the monitor base..................................................... 1-1
1.4 Connect cables............................................................................. 1-1
1.4.1 VW247H.......................................................................... 1-1
1.4.2 VW247T/S/D/N ............................................................... 1-2
1.5 Monitor introduction .................................................................... 1-2
1.5.1 Front of the LED monitor................................................. 1-2
1.5.2 Rear of the LED monitor ................................................. 1-7
2.1 Detaching the arm/stand
(for VESA wall mount) ................................................................. 2-1
2.2 Adjusting the monitor.................................................................. 2-2
3.1 OSD (On-Screen Display) menu ................................................. 3-1
3.1.1 Howtorecongure.......................................................... 3-1
3.1.2 OSDFunctionIntroduction.............................................. 3-1
3.2 Specicationssummary.............................................................. 3-1
3.3 Troubleshooting (FAQ)................................................................ 3-2
3.4 Supported Timing List........................................................................3-3
Copyright © 2010 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Notices
Federal Communications Commission Statement
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubject
tothefollowingtwoconditions:
• Thisdevicemaynotcauseharmfulinterference,and
• Thisdevicemustacceptanyinterferencereceivedincluding
interferencethatmaycauseundesiredoperation.
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora
ClassBdigitaldevice,pursuanttoPart15oftheFCCRules.Theselimits
aredesignedtoprovidereasonableprotectionagainstharmfulinterference
inaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withmanufacturer’sinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewill
notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedby
turningtheequipmentoffandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmenttoanoutletonacircuitdifferentfromthatto
whichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
AsanEnergyStar® Partner,ourcompanyhas
determinedthatthisproductmeetstheEnergyStar®
guidelinesforenergyefciency.
Canadian Department of Communications Statement
ThisdigitalapparatusdoesnotexceedtheClassBlimitsforradio
noiseemissionsfromdigitalapparatussetoutintheRadioInterference
RegulationsoftheCanadianDepartmentofCommunications.
ThisclassBdigitalapparatuscomplieswithCanadianICES-003.
Energy Saving on Monitor
ASUSmonitorsupportsenergysavingmode.Ifthemonitordoesnot
detecttheHorizontalsyncsignaland/orVerticalsyncsignal,itwillenter
energysaving(standby)mode.

iv
Whenthemonitorentersenergysaving(standby)mode,thescreenwill
displayblankandthebacklightwillbeturnedoff,andthePowerLEDwill
light“amber”.
FortheindicationofEnergySaving(standby)mode,pleaserefertoyour
userguide.
Safety information
• Beforesettingupthemonitor,carefullyreadallthedocumentationthat
camewiththepackage.
• Topreventreorshockhazard,neverexposethemonitortorainor
moisture.
• Nevertrytoopenthemonitorcabinet.Thedangeroushighvoltages
insidethemonitormayresultinseriousphysicalinjury.
• Ifthepowersupplyisbroken,donottrytoxitbyyourself.Contacta
qualiedservicetechnicianoryourretailer.
• Beforeusingtheproduct,makesureallcablesarecorrectlyconnected
andthepowercablesarenotdamaged.Ifyoudetectanydamage,
contactyourdealerimmediately.
• Slotsandopeningsonthebackortopofthecabinetareprovidedfor
ventilation.Donotblocktheseslots.Neverplacethisproductnearor
overaradiatororheatsourceunlessproperventilationisprovided.
• Themonitorshouldbeoperatedonlyfromthetypeofpowersource
indicatedonthelabel.Ifyouarenotsureofthetypeofpowersupplyto
yourhome,consultyourdealerorlocalpowercompany.
• Usetheappropriatepowerplugwhichcomplieswithyourlocalpower
standard.
• Donotoverloadpowerstripsandextensioncords.Overloadingcan
resultinreorelectricshock.
• Avoiddust,humidity,andtemperatureextremes.Donotplacethe
monitorinanyareawhereitmaybecomewet.Placethemonitorona
stablesurface.
• Unplugtheunitduringalightningstormorifitwillnotbeusedfora
longperiodoftime.Thiswillprotectthemonitorfromdamagedueto
powersurges.
• Neverpushobjectsorspillliquidofanykindintotheslotsonthe
monitor cabinet.
• Toensuresatisfactoryoperation,usethemonitoronlywithULlisted
computerswhichhaveappropriateconguredreceptaclesmarked
between100-240VAC.
• Ifyouencountertechnicalproblemswiththemonitor,contacta
qualiedservicetechnicianoryourretailer.

v
Care & Cleaning
• Beforeyouliftorrepositionyourmonitor,itisbettertodisconnectthecables
andpowercord.Followthecorrectliftingtechniqueswhenpositioningthe
monitor.Whenliftingorcarryingthemonitor,grasptheedgesofthemonitor.
Donotliftthedisplaybythestandorthecord.
• Cleaning.Turnyourmonitoroffandunplugthepowercord.Cleanthemonitor
surfacewithalint-free,non-abrasivecloth.Stubbornstainsmayberemoved
withaclothdampenedwithmildcleaner.
• Avoidusingacleanercontainingalcoholoracetone.Useacleanerintended
forusewiththeLED.Neverspraycleanerdirectlyonthescreen,asitmaydrip
insidethemonitorandcauseanelectricshock.
The following symptoms are normal with the monitor:
• Thescreenmayickerduringtheinitialuseduetothenatureoftheuorescent
light.TurnoffthePowerSwitchandturnitonagaintomakesurethatthe
ickerdisappears.
• Youmayndslightlyunevenbrightnessonthescreendependingonthe
desktoppatternyouuse.
• Whenthesameimageisdisplayedforhours,anafterimageoftheprevious
screenmayremainafterswitchingtheimage.Thescreenwillrecoverslowlyor
youcanturnoffthePowerSwitchforhours.
• Whenthescreenbecomesblackorashes,orcannotworkanymore,contact
yourdealerorservicecentertoxit.Donotrepairthescreenbyyourself!
Conventions used in this guide
WARNING:Informationtopreventinjurytoyourselfwhentryingto
completeatask.
CAUTION:Informationtopreventdamagetothecomponentswhen
tryingtocompleteatask.
IMPORTANT:InformationthatyouMUSTfollowtocompleteatask.
NOTE:Tipsandadditionalinformationtoaidincompletingatask.

vi Chapter1:ProductIntroduction
Wheretondmoreinformation
Refertothefollowingsourcesforadditionalinformationandforproductand
softwareupdates.
1. ASUS websites
TheASUSwebsitesworldwideprovideupdatedinformationonASUS
hardwareandsoftwareproducts.Refertohttp://www.asus.com
2. Optional documentation
Yourproductpackagemayincludeoptionaldocumentationthatmayhave
beenaddedbyyourdealer.Thesedocumentsarenotpartofthestandard
package.
1.1 Welcome!
ThankyouforpurchasingtheASUS®VW247SeriesLEDmonitor!
ThelatestwidescreenLEDmonitorfromASUSprovidesacrisper,broader,and
brighterdisplay,plusahostoffeaturesthatenhanceyourviewingexperience.
Withthesefeatures,youcanenjoytheconvenienceanddelightfulvisual
experiencethattheVW247Seriesbringsyou!
1.2 Package contents
CheckyourVW247SeriesLEDpackageforthefollowingitems:
LED monitor
Monitorstandandbase
SupportCD
QuickStartGuide
Powercord
VGAcable
DVIcable(VW247H/T/N)
Audiocable(VW247H/T/S)
Ifanyoftheaboveitemsisdamagedormissing,contactyourretailer
immediately.

1-1ASUSLEDMonitorVW247Series
1.3 Assembling the monitor base
To assemble the monitor base:
1. Havethefrontofthemonitorfacedownonatable.
2. Insertthestandtothemonitorwhichshowsasbelowpicture.
3. Connectthebasewiththemonitor.Aclickindicatesthatthebasehasbeen
connectedsuccessfully.
4. Adjustthemonitortotheanglethatismostcomfortableforyou.
Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damagetothemonitor.
12 3
1.4 Connect cables
Connect cables which you need.
1.4.1 VW247H
12
3
4
5
6
7
1AC-INport
2HDMI-INport
3DVIport
4VGAport
5AudioLine-inPort
6Earphone-outport
7HDMISPDIFOUT

1-2 Chapter1:ProductIntroduction
1.4.2 VW247T/S/D/N
1234
1AC-INport
2AudioLine-inPort(VW247T/S)
3DVIport(VW247T/N)
4VGAport
1.5 Monitor introduction
1.5.1 Front of the LED monitor
1.5.1.1 VW247H/T
457
1 2 36
1. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phasebylongpressingthisbuttonfor2-4seconds(forVGAmodeonly).

1-3ASUSLEDMonitorVW247Series
• Usethishotkeytoswitchfromsixvideopresetmodes(SceneryMode,
StandardMode,TheaterMode,GameMode,NightViewMode,and
sRGBMode)withSPLENDID™VideoIntelligenceTechnology.
• ExittheOSDmenuorgobacktothepreviousmenuastheOSDmenu
isactive.
2. Button:
• Pressthisbuttontodecreasethevalueofthefunctionselectedormove
tothenextfunction.
• ThisisalsoahotkeyforVolumeadjustment.
3 MENUButton:
• Pressthisbuttontoenter/selecttheicon(function)highlightedwhilethe
OSDmenuisactivated.
4. Button:
• Pressthisbuttontoincreasethevalueofthefunctionselectedormove
tothepreviousfunction.
• ThisisalsoahotkeyforBrightnessadjustment.
5 . InputSelectButton:
• UsethishotkeytoswitchfromVGA,DVI,HDMIinputsignals.(for
VW247H)
Press (InputSelectbutton)todisplayHDMIsignalafteryouconnectcable
withthemonitor.(forVW247H)
6. PowerButton:
• Pressthisbuttontoturnthemonitoron/off.
7. PowerIndicator
Status Description
Blue ON
Amber Standbymode
OFF OFF

1-4 Chapter1:ProductIntroduction
1.5.1.2 VW247S
457
1 2 36
1. Button:
• Usethishotkeytoswitchfromsixvideopresetmodes(SceneryMode,
StandardMode,TheaterMode,GameMode,NightViewMode,and
sRGBMode)withSPLENDID™VideoIntelligenceTechnology.
• ExittheOSDmenuorgobacktothepreviousmenuastheOSDmenu
isactive.
2. Button:
• Pressthisbuttontodecreasethevalueofthefunctionselectedormove
tothenextfunction.
• ThisisalsoahotkeyforVolumeadjustment.
3 MENUButton:
• Pressthisbuttontoenter/selecttheicon(function)highlightedwhilethe
OSDmenuisactivated.
4. Button:
• Pressthisbuttontoincreasethevalueofthefunctionselectedormove
tothepreviousfunction.
• ThisisalsoahotkeyforBrightnessadjustment.
5. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phase(forVGAmodeonly).
6. PowerButton:
• Pressthisbuttontoturnthemonitoron/off.
7. PowerIndicator
Status Description
Blue ON
Amber Standbymode
OFF OFF

1-5ASUSLEDMonitorVW247Series
1.5.1.3 VW247D
457
1 2 36
1. Button:
• Usethishotkeytoswitchfromsixvideopresetmodes(SceneryMode,
StandardMode,TheaterMode,GameMode,NightViewMode,and
sRGBMode)withSPLENDID™VideoIntelligenceTechnology.
• ExittheOSDmenuorgobacktothepreviousmenuastheOSDmenu
isactive.
2. Button:
• Pressthisbuttontodecreasethevalueofthefunctionselectedormove
tothenextfunction.
• ThisisalsoahotkeyforContrastadjustment.
3 MENUButton:
• Pressthisbuttontoenter/selecttheicon(function)highlightedwhilethe
OSDmenuisactivated.
4. Button:
• Pressthisbuttontoincreasethevalueofthefunctionselectedormove
tothepreviousfunction.
• ThisisalsoahotkeyforBrightnessadjustment.
5. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phase(forVGAmodeonly).
6. PowerButton:
• Pressthisbuttontoturnthemonitoron/off.
7. PowerIndicator
Status Description
Blue ON
Amber Standbymode
OFF OFF

1-6 Chapter1:ProductIntroduction
1.5.1.4 VW247N
457
1 2 36
1. Button:
• Automaticallyadjusttheimagetoitsoptimizedposition,clock,and
phasebylongpressingthisbuttonfor2-4seconds(forVGAmodeonly).
• Usethishotkeytoswitchfromsixvideopresetmodes(SceneryMode,
StandardMode,TheaterMode,GameMode,NightViewMode,and
sRGBMode)withSPLENDID™VideoIntelligenceTechnology.
• ExittheOSDmenuorgobacktothepreviousmenuastheOSDmenu
isactive.
2. Button:
• Pressthisbuttontodecreasethevalueofthefunctionselectedormove
tothenextfunction.
• ThisisalsoahotkeyforContrastadjustment.
3 MENUButton:
• Pressthisbuttontoenter/selecttheicon(function)highlightedwhilethe
OSDmenuisactivated.
4. Button:
• Pressthisbuttontoincreasethevalueofthefunctionselectedormove
tothepreviousfunction.
5 . InputSelectButton:
• UsethishotkeytoswitchfromVGA,DVIinputsignals.
6. PowerButton:
• Pressthisbuttontoturnthemonitoron/off.
7. PowerIndicator
Status Description
Blue ON
Amber Standbymode
OFF OFF

1-7ASUSLEDMonitorVW247Series
1.5.2 Rear of the LED monitor
all Mount
Screw holes for
VESA W
1.5.2.1 VW247H
234567
1
1 AC-IN port
2 HDMI-IN port
3 DVI port
4 VGA port
5 Line-in port
6 Earphone-out port
7 HDMI SPDIF OUT
1.5.2.2 VW247T/S/D/N
234
1
1 AC-IN port
2 Line-in port(VW247T/S)
3 DVI port(VW247T/N)
4 VGA port

2-1 Chapter2:Setup
2.1 Detaching the arm/stand
(for VESA wall mount)
ThedetachablestandoftheVW247SeriesLEDmonitorisspeciallydesignedfor
VESAwallmount.
To detach the arm/stand:
1. Havethefrontofthemonitorfacedownonatable.
2. Presstheplasticreleasebuttonontherearofthemonitorshowsasbelow
picture.
3. Detachthestandfromthemonitor.
Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damagetothemonitor.
• TheVESAwallmountkit(100x100mm)ispurchasedseparately.
• UseonlytheULListedWallMountBracketwithminimumweight/load20
Kg(Screwsize:M4x12mm).

2-2ASUSLEDMonitorVW247Series
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortableforyou.
• Holdthestandtopreventthemonitorfromfallingwhilechangingitsangle.
• Youcanadjustthemonitor’sanglefrom-5˚to20˚.
-5 ~ 20

3-1 Chapter3:GeneralInstruction
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
1. PresstheMENUbuttontoactivatetheOSDmenu.
2. Pressandtonavigatethroughthefunctions.Highlightandactivate
thedesiredfunctionbypressingtheMENUbutton.Ifthefunctionselected
hasasub-menu,pressandagaintonavigatethroughthesub-menu
functions.Highlightandactivatethedesiredsub-menufunctionbypressing
theMENUbutton.
3. Pressandtochangethesettingsoftheselectedfunction.
4. ToexittheOSDmenu,pressthe button.Repeatstep2andstep3to
adjustanyotherfunction.
3.1.2 OSD Function Introduction
1. Splendid
Thisfunctioncontainssixsub-functionsthatyoucanselectforyour
preference.EachmodehastheResetselection,allowingyoutomaintain
yoursettingorreturntothepresetmode.
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Scenery Mode
Standard Mode
Theater Mode
Game Mode
Night View Mode
sRGB
• Scenery Mode:Thisisthebestchoiceforsceneryphotodisplayingwith
SPLENDID™VideoIntelligenceTechnology.

3-2ASUSLEDMonitorVW247Series
• Standard Mode:Thisisthebestchoicefordocumenteditingwith
SPLENDID™VideoIntelligenceTechnology.
• Theater Mode:Thisisthebestchoiceformoviewatchingwith
SPLENDID™VideoIntelligenceTechnology.
• Game Mode:ThisisthebestchoiceforgameplayingwithSPLENDID™
VideoIntelligenceTechnology.
• Night View Mode:Thisisthebestchoiceforplayingdark-scenegame
orwatchingdark-scenemoviewithSPLENDID™VideoIntelligence
Technology.
• sRGB
IntheStandardMode,theSaturation,ColorTemp.,SkinTone,Sharpness,and
ASCRfunctionsarenotuser-congurable.
InthesRGB,theSaturation,ColorTemp.,SkinTone,Sharpness,Brightness,
ContrastandASCRfunctionsarenotuser-congurable.
2. Color
Selecttheimagecoloryoulikefromthisfunction.
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup
Brightness
Contrast
Saturation
Color Temp.
90
80
50
User Mode
Natural
OFF
Skin Tone
Smart View
• Brightness:Theadjustingrangeisfrom0to100.The buttonis
alsoahotkeytoactivatethisfunction.
• Contrast:Theadjustingrangeisfrom0to100.
• Saturation:Theadjustingrangeisfrom0to100.
• Color Temp.:Containsthreepresetcolormodes(Cool,Normal,Warm)
andoneUserMode.
• Skin Tone:ContainsthreecolormodesincludingReddish,Natural,and
Yellowish.
• Smart view:TheversatileviewingpositionswithSmartViewTechnology
IntheUserMode,colorsofR(Red),G(Green),andB(Blue)are
userconfigurable;theadjustingrangeisfrom0~100.

3-3 Chapter3:GeneralInstruction
3. Image
YoucanadjusttheimageSharpness,AspectControl,ASCR,Position(VGA
only),andFocus(VGAonly)fromthismainfunction.
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup Focus
Sharpness
Aspect Control
ASCR
50
Full
Position
OFF
• Sharpness:Adjuststhepicturesharpness.Theadjustingrangeisfrom0
to 100.
• Aspect Control:Adjuststheaspectratioto“Full”,“4:3”,or“OverScan”
(OnlyavailableforHDMIinput).
• ASCR:SelectONorOFFtoenableordisabledynamiccontrastratio
function.
• Position:Adjuststhehorizontalposition(H-Position)andthevertical
position(V-Position)oftheimage.Theadjustingrangeisfrom0to100
(OnlyavailableforVGAinput).
• Focus:ReducesHorizonal-linenoiseandVertical-linenoiseoftheimage
byadjusting(Phase)and(Clock)separately.Theadjustingrangeisfrom
0to100(OnlyavailableforVGAinput).
Phaseadjuststhephaseofthepixelclocksignal.Withawrongphase
adjustment,thescreenshowshorizontaldisturbances.
Clock(pixelfrequency)controlsthenumberofpixelsscannedbyonehorizontal
sweep.Ifthefrequencyisnotcorrect,thescreenshowsverticalstripesandthe
imageisnotproportional.
4. Input Select
SelecttheinputsourcefromVGA,DVI,orHDMI (“DVI” for VW247H/T/N
only,“HDMI” for VW247Honly).
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup
VGA
DVI
HDMI

3-4ASUSLEDMonitorVW247Series
5. System Setup
Adjuststhesystemconfiguration.
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup Language
Information
Splendid Demo Mode OFF
OFF
50
English
Volume
ECO Mode
OSD Setup
1/2
All Reset
VW247
Splendid
Color
Input Select
Move Menu Exit
System Setup
2/2
• Splendid Demo Mode:ActivatethedemomodefortheSplendid
function.
• Volume: Theadjustingrangeisfrom0to100. isahotkeytoactivate
thisfunction.
• ECO Mode:Power-savingmode
• OSD Setup:Adjuststhehorizontalposition(H-Position),andthevertical
position(V-Position)oftheOSD.Theadjustingrangeisfrom0to100.In
theOSDTimeoutselection,youcanadjusttheOSDtimeoutfrom10to
120.
• Language:Thereareelevenlanguagesforyourselection,including
English,German,Italian,French,Dutch,Spanish,Russian,Traditional
Chinese,SimplifiedChinese,Japanese,andKorean.
• Information:Displaysthemonitorinformation.
• All Reset:Selects“Yes”torevertallsettingstothefactorydefaultmode.

3-1 Chapter2:Setup
3.2 Specicationssummary
Model VW247H VW247T VW247N VW247S VW247D
PanelSize 23.6”W(59.8cm)
TrueResolution 1920x1080(FullHD)
Brightness(Typ.) 300cd/m2
ContrastRatio(Typ.) 1000:1
ASUSSmartContrast
Ratio(ASCR) 10000000:1
ViewingAngle
(CR≥10) 170°(H)/160°(V)
ColorSaturation
(NTSC) 72%
DisplayColors 16.7M
Response Time 5ms(On/Off)
PowerConsumption ONMode:<35W,StandbyMode:<0.2W,OffMode:<0.2W
StereoSpeaker 2Wx2
RMS
2Wx2
RMS -- 2Wx2 RMS --
HDMIinput Yes -- -- -- --
DVIinput Yes Yes Yes -- --
D-Subinput Yes Yes Yes Yes Yes
AudioLine-in Yes Yes -- Yes --
EarphoneOutput Yes -- -- -- --
SPIDIFoutput Yes -- -- -- --
VoltageRating AC100-240V
Tilt -5°~+20°
VESAWallMounting 100x100mm
Phys.Dimension
(WxHxD) 568.9x409.1x220mm
BoxDimension
(WxHxD) 630x404x190mm
*Specicationsaresubjecttochangewithoutnotice.
