DEFIANCE ELECTRONICS FUS336 Troubleshooting guide

OPERATION AND MAINTENANCE INSTRUCTIONS
FUS336 DENTAL SYSTEM
DEFIANCE ELECTRONICS, INC.
6206 Hwy. 11 East
Lenoir City, TN 37771
NS13 6520- 01-553 -594|

INDEX TO ILLUSTRATIONS
ILLUSTRATIONS PAGE NO.
1. Unit set up with Air Supply Line and Case
2. Physical dimensions of unit
3. Carrying Case relief Valve
4. Unit in bottom half of Case
5. Bottom of Unit with Stand attached
6. Unit with Hoses stored inside
7. Storage of Automatic Handpiece Holders
8. Installation and location of Manual Instrument
Holders
9. Installation and location of Automatic Handpiece
Holders
10. Installation location of Waste Jar
11. Installation location of 10 ft. Air Supply Tube 9
12. Unit with Instruments installed
13. Drawing of the Saliva Ejector and the HVE
14. Drawing of the Front Control Panel
15. Schematic of the Unit
16. Drawing of the Water Regulator
17. Parts breakdown of the Air Regulator
18. Parts breakdown of the Main Control Block
12
14
16
17
18
19
19. Drawing of the Air and Water Coolant Relay parts
breakdown
20. Drawing of the 3-way Syringe parts breakdown
20
22

21.
225
23)
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
Drawing of the HVE parts breakdown
Drawing of the Muffler Collector parts
breakdown
Drawing of the Saliva Ejector parts breakdown
Drawing of the Front Panel Toggle Valve
Drawing of the Water Tank parts breakdown
Drawing of the Automatic Handpiece Holder and
Micro Control Valve
Drawing of the Pilot Valve and Holder Assembly
(Automatic Handpiece)
Chip Blower Valve trouble shooting
Foot Control Valve trouble shooting
Foot Control Valve parts breakdown
Drawing of Automatic Handpiece Holders on Holder
Bar and parts breakdown
Drawing of Inner Panel with parts breakdown
Drawing of Stand with parts breakdown
The Accessory Kit with parts breakdown
Drawing of the Water Filter
Drawing of Handpiece Tubing and parts breakdown
25
26
27
28
29
30
31
32
33
34
36
37
38
39
40
41

193eM
Axertrxne
107 pue
È
XUEI
лэзем
итехр
оз
posn
st
butz3
fa
soetdpuey
ΠΛΗ
943
07
unnoPA
STOIZUOD
unnoeA
ἀΟΥΟΘΓΗ
PATTES
Su
BTO
ェ
YuoO
a
Учег
тэзем
S9zTInssozg.
Z
ON
oy
que
Meme.
(pasn
3ου)
эрэтариен
1000
I932M
uoytas
мо
-
330
FUETOOI
ToJeM
apetdpuey
poodsubiH
OY
MOTI
\UBTOCO
Te3eA
gsnlpy
MOTJ
FUBLTOOD
ary
9snLpv
”aoafdpueH
pesds
мот
03
тре
элрла
3SnEpV
э2этарчен poadsubrH
i
oz
πἩἙν
sayıda
3snípy
209rdpuex
pesdsybty
saysnta
$э2этариен
OY
ITV
SATIA
SMOYS
afneg

MOTTHA
8ΡΤΟΗ
Jo
uojjog
uo
Lod
MOTTA
ZSPTOH
ofşewoşny
pssdş
MOT
LOG
MOTTAA
50700
909Tdpuey
pasdg
мот
PaAlasqo
ag
3snu
sapos 10709
BUTMOTTOJ
Su
PuTqnI
paTfoo
zfeay
og
ssoetdpueg
ayy
Битчоез
уе
USHA

Pressure Relief V
Low Speed
Automatic
Holder
3-Way Syringe
Waste Jar
Height Adjustment
Knob
Adjustable
Glides
— Frame
E |
10 ft.
Utility
Hose;
Chip
Blower
= Button
E

DEFIANCE ELECTRONICS, INC
6206 HWY 11 EAST
LENOIR CITY, TN 37771
615-986-9521
OPERATION AND MAINTENANCE INSTRUCTIONS
FUS336 DENTAL SYSTEM
FEDERAL ITEM IDENTIFICATION
DENTAL OPERATION AND TREATMENT UNIT,
FIELD PORTABLE, AIR OPERATED
NSN: 6520-00-140-7663
6520-01-333-5961
MIL-D-37945A
14 FEB 1991

Defiance warrants its products against defects in material or
workmanship for one year from time of sale. Defiance's sole
obligation under the warranty is to repair, or at its option, to
replace the unit. The buyer shall have no other remedy. (All special,
incidental, and coincidental damages are excluded.) Writen notice of
breach of warranty must be given to Defiance within the warranty
period. The warranty does not cover damage resulting from improper
installation and maintenance, accident or misuse.
NO OTHER WARRANTIES AS TO MERCHANTABILITY
OR OTHERWISE ARE MADE.
DEFIANCE ELECTRONICS INC
6206 HWY 11 EAST
LENIOR CITY, TN. 37771
615-986-9521

DEFIANCE ELECTRONICS
FUS 336, PART NUMBER 030657
OPERATION AND MAINTENANCE INSTRUCTION
This Instruction Manual applies exclusively to equipment purchased by
the United States Defense Personnel Support Center under National
Stock Number 6520-00-140-7663 and 6520-01-333-5961. No other use of
this Manual is authorized by Defiance.

INTRODUCTION
Description of the System
Illustration ............
Equipment Features........
Accessories Provided......
Equipment Not Provided.. a
Performance Characteristics....3
Illustration........
EQUIPMENT SETUP
Preparation for Use..
Safety Precautions..
Storage Data..."
Outdoor Storage..............5
Temperature Limits........
Instructions for Storage.
Inspection. ses O a
Unpacking nd Assembly GN
Illustration...............
OPERATION
Operating Instructions........ 10
Operating Under Adverse
Conditions.................. 10
System Shutdown. cit
Care of the Unit.... 。 ...11
Surface Cleaning...... 11
Surface Disinfecting........11
Cleaning Air Vacuum Sys..... 12
Instrument Sterilization....12
Illustration..........000 00012
Oral Evacuator Tips.......12
PREPARATION FOR STORAGE
Packing the Unit...........0.=13
PRINCIPLES OF OPERATION
Control Function..... 0000 14
Air Coolant Flow Control...... 14
Water Coolant On-Off Toggle...14
Water Coolant Flow Control....14
Auto Handpiece Holder.........14
Handpiece Lock-Out Toggle.....14
Water Pressure On-Off Toggle..14
Water Outlet..................14
Oral Evacuator Flow Control...14
Saliva Ejector Control........14
Foot Control Valve.. ・ ..14
Chip Blower Button. ..14
Illustration...........
……
ㄴ
0.
14
MAINTENANCE
Basic Troubleshooting...... «5.15
Neither of the
Handpieces Work...........15
No Water Coolant from
either Handpiece.......... 15
Insufficient Drive Air
Pressure...
Schematic Diagr A
RegulatorS.............
Pressure Adjustment......... 17
Servicing Air Regulator.....17
Servicing Water Regulator...17
Air Regulator
111. & Parts Breakdown....18
Main Control Block......... ...19
Troubleshooting.............19
111. & Parts Breakdown......19
Manifold, Relay......... ....20
Air and Water Coolant....... 20
Troubleshooting.............20
111. & Parts Breakdown..
Syringe..........,.
Illustration..
Parts Breakdo
Air Vacuum Syst
General...........
HVE Oral Evacuator...
Air Tube Replacement..
Ill. & Parts Breakdown
Muffler Collector.......
Ill. & Parts Breakdown. .
Saliva Ejector....... ㄴㅇ
Ill. & Parts Breakdown
Toggle Valve............
111. & Parts Breakdown
Water Tank...............
111. & Parts Breakdown...
Three
Way
Micro
Valve.........
30
111.
&
Troubleshooting......30
Pilot Valve & Holder Assy
111. & Parts Breakdown.
Chip Blower & Valve......
Troubleshooting....
Foot Control.........
Troubleshooting....
Illustration..........
Parts
Breakdown............

Handpiece Hanger Assy........36
Ill. & Parts Breakdown.....36
Internal Panel.............,.37
111. & Parts Breakdown.....37
Stands... ..2..2..00eccers 38
111. & Parts Breakdown.....38
Accessory Kit........ O
Ill. & Parts Breakdown.....39
Triple Holder Bracket
Ill. & Parts Breakdown.....40
Standard Holder
Ill. & Parts Breakdown.....40
Vacuum Handpiece Holder
111. & Parts Breakdown.....40
Water Filter, Illustration...40
Handpiece Tubing
Connector & Nut Assy.......41
Ill. & Parts Breakdown.....41
Master Parts List.........42-43

INTRODUCTION
Description of the System
The Defiance Unit (I11. 1) is a self-contained mobile dental unit
designed for field or mobile operatory use.
All facilities required for the practice of general dentistry are
provided for both the doctor and the dental assistant. It is built
around Defiance 336V009 automatic control system for two handpieces
with air and water coolant. Water to the slow speed dry handpiece is
blocked ofi. Oral evacuation is provided by a built-in High Velocity
Evacuator and an Air Saliva Ejector (ASE). A pressurized two-quart
tank supplies water for handpiece coolant and the syringe.
The only external connection required is the air supply. A ten foot
air supply hose is furnished for this purpose. It may be connected to
a compressor delivering dry, filtered air at 80-100 psi @ 4 cfm or to
bottled gas (carbon dioxide or nitrogen) regulated to 80-100 psi.
The entire unit can be quickly disassembled and packed into the
polyethylene carrying case for safe transportation and storage.

EQUIPMENT FEATURES
Defiance 336V009 Control System for Two Handpieces
Air Coolant Flow Control
Water Coolant On-Off Toggle
Individual Water Coolant Flow Control for each Handpiece
Individual Drive Air Pressure Adjustment for each Handpiece
Drive Air Pressure Gauge
Disc Type Foot Control with Chip Blower Button
Self-Contained Two-Quart Water Tank
Water Pressure On-Off Toggle
Air Vacuum System, including:
HVE Handpiece Assembly with tubing
HVE Flow Control
Air Saliva Ejector with Solids Separator
ASE Flow Control
Waste Bottle with Solids Separator (336H005)
3-way Syringe with Coiled Tubing (3361101)
Quick-Disconnect Water Outlet (336F012 and 336A006)
Adjustable Height Frame
Polyethylene Carrying Case (336C101)
ACCESSORIES PROVIDED
Two Coiled Handpiece Tubings with Midwest Connectors (3361105)
10 Foot Air Supply Tubing with Quick Disconnects (336T010)
Stainless Steel Dry Cuspidor (336H012)
Stainless Steel Oral Evacuator Tips 3 ea (336H016)
FUS 336 Accessory Kit
Star Futura High Speed Handpiece (3361102)
Star Futura Low Speed Motor (3361103)
Star Low Speed Nose Cone (3361104)
Remote Adapter (336A009)
For Operation and Maintenance Instructions, refer to the manuals
furnished by the handpiece manufacturer.
EQUIPMENT NOT PROVIDED
Air Source, refer to the following: Compressor-Dehydrator for Field
Use, NSN 6520-00-139-1264
Umbilical
for
Connecting
to
Permanent Utilities
_
Tray,
instrument
corrosion
resistant
steel
NSN
6520-00-926-9170.
А“.
Consumable:
Saliva Ejector Mouthpieces, NSN 6520-00-082-2673
25

PERFORMANCE CHARACTERISTICS
The Defiance FUS 336 performance conforms with the following
specifications:
1. High temperature, in compliance with Method 501,
Procedure I, MIL-STD-810D.
2. Low temperature, in compliance with method 502, Procedure
I, MIL-STD-810D.
3. Vibration, in compliance with method 514, catagory 3,
MIL-STD-810D.
4. Shock in compliance with Method 516, Procedure II,
MIL-STD 810D.
Water Tank Capacity: 2 Quart (1.89 Liters)
Waste Bottle Capacity: 2 Quarts (1.89 Liters)
Air Supply Requirements: Dry, Filtered Air or Bottled
| Gas (Nitrogen or CO2), 80-100 psi @ 4 cfm
PHYSICAL SPECIFICATIONS
Height: Adjustable from 23.5 to 32.5 inches
Width: 13.5 inches
Depth: 16 inches
Shipping Weight: 46 lbs. including carrying case
Carrying Case Dimensions; 17.5" x 20.5" x 12"
개
= Mi
+
| 23.5"
to Г]
ILL. 2 32.5"
| a
ANDAN
> 2 fi

PREPARATION FOR USE
1. Be sure the Water Pressure On-Off toggle is turned OFF. Press the
vent button on the water tank to ensure that there is no air pressure
in the tank. Remove the cap and fill the tank then reinstall the
water tank cap.
2. Install the sterilized syringe tip, HVE tip, and saliva ejector
mouthpiece.
3. Connect the air supply tubing to a supply of dry, filtered air or
bottled gas (nitrogen or CO2) regulated to 80-100 psi.
4. Turn the Water Pressure On-Off toggle ON, then check the air and
water pressure gauges. Air pressure should be 60 to 80 psi on the
internal panel, and the water pressure should be 40 psi + 5.
Instructions for adjusting air and water pressures are in the
Maintenance section.

SAFETY PRECAUTIONS
Providing
that
the
instructions
given
in
the
manual
are
followed,
the
Defiance
FUS
336
presents
no
operations
safety
hazards,
and
no
special
safety
precautions
are
required.
Observe
the
normal
precautions
associated
with
the
standard
dental
practices
and
procedures.
STORAGE DATA
INDOOR STORAGE--Unit may be stored for extended periods (Up to three
years) at ambient temperatures of 70 F. E
OUTDOOR STORAGE--Outdoor storage is not recommended-Unit is sealed in
a vaporproof, air relief valve equipped polyethylene case which will
provide protection from the elements, hovever, long term unprotected
storage should be avoided.
TEMPERATURE LIMITATIONS--Short term high 150 F, Low-50 FP.
INSTRUCTIONS FOR STORAGE FACILITIES--Unit should be stored at 70 F
with low humidity, inspection is required annually. No special
packing or preservation is required.
INSPECTION
1. During the assembly of the unit, check for obvious external damage
such as cracked carrying case or dented unit.
2. Check the contents of the Accessory Kit against the Accessories
Provided.
32 Inspect the handpiece holders for cracks or breakage.
4, Check the frame by adjusting it to several different heights.
5. Check the entire unit carefully for loose or missing hardware.
6. After connecting the FUS 336 to an air supply and filling and
pressurizing the water tank, make a thorough inspection for air or
water leaks.
UNPACKING AND ASSEMBLY
1. Push air relief valve button (Ill. 3) on the carry case.
TEL. 3

2. Unlatch the case, and remove the lid and protective foam pad
(111 4).
3. Lift the unit from the carrying case.
4. Use the Allen wrench from the accessory kit to remove the screw
that secures the frame base to the underside of the unit.
(111. 5)
5. Use the same screw to attach the upright to the frame base.
6. Stand the frame upright and install the unit to the upright.
Tighten the thumbscrew.
7. The foot control is stored on the underside of the unit (Ill. 6).
Remove it, and carefully draw the foot control tubing from inside the
unit.
8. Lift off the top of the Defiance FUS 336. Loosen the thumbscrews
that secure the instrument hanger bar assemblies upside down in the
unit (I11.7).
9. Move the hanger bar assemblies to the outside of the unit and
install them, as shown in Ill. 8 and 98, or in the alternate holes
lower on the side of the unit.
10. Uncoil the saliva ejector and HV Evacuator handpiece tubings, anc
feed them out through the bottom of the unit. Hang the saliva ejector
tip and HV Evacuator handpiece in the hangers, as shown in Ill. 8.
11. Feed the handpiece tubings and syringe out through the bottom of
the unit, and place them in the hangers. (ILL. 9)
2. Install the handpiece on their tubings.
13. Install waste screen, screw the HVE waste container onto the
bottom of the HVE assembly (Ill. 10).
14. Connect the 10-foot air supply tubing to the quick disconnect on
the short supply tubing under the unit. (111. 11)

ILL. 6
Ego

7 ILL.
8 ILL.
9
ILL.

ILL. 10
ILL. 11
