Defiro DEF-TSV2 User manual
Model: DEF-TSV2
Thermo scanner with facial recognition
1.Wide dynamic binocular live anti-counterfeiting, completely solve the deception of various
photos on various carriers;
2.Support LED intelligent fill light;
3.Support serial port, Wiegand 26, 34 output, output content support configuration;
4.Real-time temperature monitoring, Body temperature tolerance range is accurate to 0.3,
Body temperature detection distance is 0.5-1 meters;
5.Wide dynamic binocular live anti-counterfeiting, completely solve the deception of various
photos on various carriers:
(a)Cloud platform device supports storing 50,000 face photos at the same time (Photo size
is less than 400KB); 1 million identification records(0.45KB); 20,000 pieces live snapshot
photos;
(b)LAN device supports simultaneous storage of 20,000 pieces face photos(The photo size
is calculated according to 100KB), 1 million identification records(Contains the most recent
10,000 pieces live snapshot photos).
1.1:N Face recognition,face library supports 20,000 pieces face photos,
Top1 hit rate is 99.99%;
2.1:1 The accuracy of face and ID comparison is over 99%;
3.Fast recognition:
(a)Face tracking and detection takes about 20ms;
(b)Face feature extraction takes about 200ms;
(c)Live detection face comparison takes 0.2ms;
(d)Feature comparison takes 0.5ms;(10,000 pieces of face photos library, multiple identifi-
cation and take the average value;
4.Support stranger detection, stranger level can be configured;
5.Support face recognition and on-site photo storage during stranger detection;
6.Support HTTP interface docking;
7.Support public network and local area network deployment;
Product Features
Algorithm Brand: MEGVII
8.Support screen display content configuration;
9.Support identification distance configuration.
Dimensions
A Instructions for appearance
The schematic diagram of the gate head is shown in the figure below.
B Instructions for appearance
1. According to the requirements of the installation site, a hole with a diameter of 35 mm is
opened in the middle or front side of the space position on the gate,As shown in the figure,
is the recommended opening location
2. Unscrew the nut at the bottom of the gate head of the gate, pass the cable through the
nut, and remove the nut, as the picture shown
Installation Notes
Note: If the cable interface is different from the illustration, please refer to the next page
for cable supplement (subject to the actual product and wiring diagram)
Note: The position of the hole should be based on the actual application scenario and the
type of gate, 35mm is only a reference value
Single channel gate
3. Under the gate, pass the cable and cable interface through the washer and nut in
sequence, align the nut to the thread and tighten, as shown in the figure
4. Connect the power and network cable, the screen will start
5. Hold the post with both hands and turn it gently to adjust the angle of the gate, as shown
in the figure. According to the recognition interface, adjust the gate head to the proper
recognition angle.
Note: Do not connect the network cable, power cable, etc. at this time to avoid installation
trouble
1. The nut needs to be removed, the tail wire is passed through the stainless steel bracket and
the nut in sequence, and the angle is tightly tightened; it is suitable for program debugging.
2. Place the desktop machine on the desktop, and place the face device on the two "L" card
positions above the bracket, and adjust the angle; it is suitable for visitors at the front desk.
Desktop
1. spiral: Place the white 86 switch bottom box on the wall at 1400mm, the specific height
depends on the actual use, use a pen to mark the four corners of the bottom box, Drill four
holes with a hammer drill and place the rubber plug in the hole, Fix the bottom box with screws,
and then make the cable, this method is exposed; If built-in concealed installation is required,
draw a hole in the four sides of the size of the bottom box drawn on the wall with an impact
drill. It is estimated that cement is inserted inside. After the cement is completely dry, fix the
device to the bottom box with screws. as the picture shows!
Wall-mounted
Note: Before tightening the screws, please ensure that all the tail wires are not crushed by
the screws, causing a short circuit.
2. Wall mounted: Remove the stainless steel wall hanging from the face device, place the
stainless steel plate on the wall at an appropriate height, and mark it with a pen, Four holes are
drilled in the impact drill, the rubber plug is placed in the hole, Use self-tapping screws to fix
the stainless steel plate to the wall first (if the tail wire comes out of the back of the bottom box,
you need to make a proper hole in the wall to facilitate wiring; If the tail wire comes out from the
bottom, you only need to fix and run the wire with a large white plastic wire channel, as shown!
Wall-mounted diagram
8-inch face recognition tailline description
Switch signal Wiegand output
232 signal
Wiegand input
Bottom outlet
NO
WG-D0
WG-D1
GND
12V
COM
GND
WG-D0
WG-D1
232-TX
232-RX
4
5
3
2
1
4
3
2
1
Gate head and tail line(7)
USB 2.0 interface
USB 2.0 interface
12V power input
12V power input
Switch signal
Switch signal
Wiegand input
Wiegand output
Wiegand output
232 signal
21
DC 12V
