Defy DAW386 User manual

Record in the space below the listed information for future reference. The serial number is
on the serial label located on the inside of the door of the washing machine.
SERIAL NUMBER..................................................................................................................
DATE OF PURCHASE...........................................................................................................
PURCHASED FROM.............................................................................................................
...............................................................................................................................................
The manufacturer strives for continuous improvement. For this reason, the text and
illustrations in this manual are subject to change without notice.
You can rely on Defy. To simplify.
Front Loader Washing Machine
User Manual
DAW386
2820530383_EN/ 13-07-22.(20:51)Document Number :

1 General safety instructions
• Do not force open the locked
loading door. The door will
open immediately after the
washing cycle has ended. If the
door does not open, apply the
solutions provided for “Loading
door cannot be opened.” error in
the Troubleshooting section. In
case of forcing the loading door
to open, the door and the lock
mechanism may get damaged.
• Use detergents, softeners
and supplements suitable for
automatic washing machines only.
• Follow the instructions on the
label of textile products and the
detergent package.
• The water supply pressure
required to run the product is
between 1 to 10 bars (0.1–1 MPa)
• Do not use old or used water inlet
hoses on the new product. It may
cause stains on your laundry.
1.2 Hot surface safety
A
CAUTION!
• The glass of the loading door
gets too hot while washing at
higher temperatures. Therefore,
especially do not allow children
touch the loading door glass
while washing.
This section includes security
instructions which may help prevent
the injuries and material damage risks.
All kinds of warranties shall be invalid if
these instructions are not observed.
1.1 Life and property safety
A
CAUTION!
• Never place the product on a
carpet-covered floor. Otherwise,
lack of airflow beneath the
machine will cause electrical
parts to overheat. This will cause
problems with your product.
• Unplug the product if it is not in
use.
• Always have the installation and
repairing procedures carried out
by the Authorised Service Agent.
The manufacturer shall not be
held liable for damages that may
arise from procedures carried
out by unauthorised persons.
• The water supply and
draining hoses must be
securely fastened and remain
undamaged. Otherwise, there is
the risk of water leakage.
• While there is still water inside
the product, never open the
loading door or remove the filter.
Otherwise, risk of flooding and
injury from hot water will occur.

3 / EN Washing Machine / User Manual
1.3 Children’s safety
A
CAUTION!
• This product can be used
by children at and above 8
years old and by persons
whose physical, sensory or
mental capabilities were not
fully developed or who lack
experience and knowledge
provided that they are
supervised or trained on the
safe usage of the product
and the risks it brings out.
Children should not play with
the product. Cleaning and
maintenance works should
not be performed by children
unless they are supervised by
someone. Children under the
age of 3 should be kept away
unless continuously supervised.
• Packaging materials are
dangerous for the children.
Keep packaging materials in a
safe place away from reach of
the children.
• Electrical products are
dangerous for the children.
Keep children away from the
product when it is in use.
Do not allow them to play
with the product. Use child
lock to prevent children from
intervening with the product.
A
CAUTION!
• Do not forget to close the
loading door when leaving the
room where the product is
located.
• Store all detergents and
additives in a safe place away
from the reach of the children
by closing the cover of the
detergent container or sealing
the detergent package.
1.4 Electrical safety
B
DANGER
• If the product has a failure, it
should not be operated unless
it is repaired by the Authorised
Service Agent! There is the risk
of electric shock!
• This product is designed to
resume operating in the event
of powering on after a power
interruption. If you wish to cancel
the programme, see “Cancelling
the programme” section.
• Plug the product into a
grounded outlet protected by
a 16 A fuse. Do not neglect to
have the grounding installation
made by a qualified electrician.
Our company shall not be
liable for any damages that
will arise when the product
is used without grounding
in accordance with the local
regulations.

4 / EN Washing Machine / User Manual
B
DANGER
• Do not wash the product by
spraying or pouring water onto
it! There is the risk of electric
shock!
• Never touch the power cable
plug with wet hands! Never
unplug by pulling on the cable.
Always press on the plug with
one hand and pull out the plug
by grabbing with the other hand.
• Product should be unplugged
during installation, maintenance,
cleaning and repair procedures.
• If the power cable is damaged,
it must be replaced by the
manufacturer, authorised
service or a similarly
qualified person (preferably
an electrician) or someone
designated by the importer in
order to avoid possible risks.
2.Important instructions for
environment
2.1 Compliance with WEEE Directive
This product complies with EU
WEEE Directive (2012/19/EU).
This product bears a classification
symbol for waste electrical and
electronic equipment (WEEE).
3.Intended use
• This product has been designed for domestic
use. It is not for commercial purposes or it
should not be used out of its intended use.
• The product must only be used
for washing and rinsing of laundry
that are marked accordingly.
• The manufacturer waives any responsibility
arisen from incorrect usage or transportation.
• The service life of your product is 10 years.
During this period, original spare parts will be
available to operate the appliance properly.
• This appliance is intended to be used in
household and similar applications such as:
– staff kitchen areas in shops, offices and other
working environments;
– farm houses;
– by clients in hotels, motels and other
residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of flats or
in launderettes.
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Do not dispose
of the waste product with normal domestic
and other wastes at the end of its service life.
Take it to the collection center for the recycling
of electrical and electronic equipment. Please
consult your local authorities to learn about
these collection centers.
Compliance with RoHS Directive:
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
2.2 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the
packaging materials together with the
domestic or other wastes. Take them to
the packaging material collection points
designated by the local authorities.

5 / EN Washing Machine / User Manual
4 Technical specifications
Supplier name or trademark DEFY
Model name DAW386
Rated capacity (kg) 8
Maximum spin speed (rpm) 1200
Built-in No
Height (cm) 84
Width (cm) 60
Depth (cm) 59
Single Water inlet / Double Water inlet • / -
• Available
Electrical input (V/Hz) 230 V / 50Hz
Total current (A) 10
Total power (W) 2200
Main model code 9211

6 / EN Washing Machine / User Manual
4.1 Installation
C
INFORMATION
• Your washing machine automatically
detects the amount of laundry placed
inside when selecting a program.
• While installing the product, before the
first use, calibration should be done
to ensure that the laundry amount is
detected in the most accurate way.
• To do this, select the Drum Cleaning*
program and cancel the spin function.
Start the program without laundry.
Wait for the program to finish, which
will take about 15 minutes.
*The program name may vary depending on the
model. For the appropriate program selection,
review the program descriptions section.
• Apply to the nearest authorised service
agent for the installation of your product.
• Preparation of the location and electrical,
tap water and waste water installations at
the place of installation is under customer's
responsibility.
• Make sure that the water inlet and discharge
hoses as well as the power cable are not
folded, pinched or crushed while pushing
the product into its place after installation or
cleaning procedures.
• Make sure that the installation and electrical
connections of the product are performed
by authorised service. Manufacturer shall
not be held liable for damages that may
arise from procedures carried out by
unauthorised persons.
• Prior to installation, visually check if the
product has any defects on it. If so, do not
have it installed. Damaged products cause
risks for your safety.
4.1.1 Appropriate installation location
• Place the product on a hard and level floor.
Do not put it onto a carpet with high pile or
other similar surfaces.
• When the washing machine and dryer are
placed on top of each other, their total
weight –when loaded– amounts to 180 kg.
Place the product on a solid and flat floor
that has sufficient load carrying capacity!
• Do not place the product on the power cable.
• Do not install the product in the environments
where the temperature falls below 0 ºC.
• Leaving a gap at the sides of the machine is
suggested to reduce vibration and noise
• On a graduated floor, do not place the
product next to the edge or on a platform.
• Do not place heat sources such as Hobs,
Irons, Ovens, etc. on the washing machine
and do not use them on the product.
4.1.2 Removing packaging reinforcement
Tilt the machine
backwards to remove the
packaging reinforcement.
Remove the packaging
reinforcement by pulling
the ribbon. Do not make
this operation alone by
yourself.
4.1.3 Removing the
transportation locks
1. Loosen all bolts with an appropriate wrench
until they turn freely.
2. Remove the transport safety bolts by
turning them slightly.
3. Insert the plastic covers in the bag
containing the user manual to the openings
on the rear panel.
A
CAUTION!
• Remove the transportation safety bolts
before operating the washing machine!
Otherwise, the product will be damaged.
C
INFORMATION
• Keep the transportation safety
bolts in a safe place to reuse when
the washing machine needs to
be moved again in the future.
• Install the transport safety bolts in reverse
order of the disassembly procedure.
• Never move the product without
the transportation safety bolts
properly fixed in place!

7 / EN Washing Machine / User Manual
4.1.4 Connecting water supply
C
INFORMATION
• It is necessary to have 10 – 80 liters of
water flowing from the fully open tap in
one minute to have your machine run
smoothly. Attach a pressure reducing
valve if water pressure is higher.
C
INFORMATION
• It is also recommended to attach
a pressure reducing valve if you
experience overflow from the detergent
dispenser during water fill between
3.5 to 10 bars (0.35 to 1 MPa).
A
CAUTION!
• Models with a single water inlet should
not be connected to the hot water
tap. In such a case the laundry will get
damaged or the product will switch to
protection mode and will not operate.
1 Tighten the nuts of the hose by hand.
Never use a tool when tightening the nuts.
2 When hose connection is completed,
check whether there is leak problems at the
connection points by opening the taps fully. If
any leaks occur, turn off the tap remove the
nut. Retighten the nut carefully after checking
the seal. In order to prevent the water leaks
and resultant damages, keep the taps closed
when you do not use the product.
4.1.5 Connecting the drain
hose to the drain
• Attach the end of the drain hose directly to
waste water drain, lavatory or bathtub.
A
CAUTION!
• Your drain house will be flooded if the
hose comes out of its housing during
water discharge. Moreover, there is risk of
scalding due to high washing temperatures!
In order to prevent such situations and
make sure that the machine performs water
intake and discharge processes without
any problem, fix the drain hose securely.
40 cm
100 cm
• Connect the drain hose to a minimum height
of 40 cm and a maximum height of 100 cm.
• In case the drain hose is elevated after laying
it on the floor level or close to the ground
(less than 40 cm above the ground), water
discharge becomes more difficult and the
laundry may come out excessively wet.
Therefore, follow the heights described in
the figure.
• To prevent the waste water to go back
into the machine again and to ensure easy
drainage, do not immerse the end of the
hose into the waste water or do not insert
it into the drain for more than 15 cm. If it is
too long, cut it short.
• The end of the hose should not be bent,
it should not be stepped on and the hose
must not be pinched between the drain and
the machine.
• If the length of the hose is too short, use
it by adding an original extension hose.
Length of the hose may not be longer than
3.2 m. To avoid water leak failures, the
connection between the extension hose and
the drain hose of the product must be fitted
well with an appropriate clamp as not to
come off and leak.

8 / EN Washing Machine / User Manual
4.1.6 Adjusting the feet
A
CAUTION!
• In order to ensure that the product
operates more silently and vibration-
free, it must stand level and balanced
on its feet. Balance the machine by
adjusting the feet. Otherwise, the product
may move from its place and cause
crushing and vibration problems.
• Do not use any tools to loosen the lock
nuts. Otherwise, they will get damaged.
1 Loosen the lock nuts on the feet by hand.
2 Adjust the feet until the product stands in a
stable and balanced way.
3. Tighten all lock nuts by hand again.
4.1.7 Electrical connection
Connect the product to a grounded outlet
protected by a 16 A fuse. Our company shall
not be liable for any damages that will arise
when the product is used without grounding in
accordance with the local regulations.
• Connection must comply with national regulations.
• The wiring for the electrical outlet circuit
must be sufficient to meet the appliance
requirements. Use of a Groud Fault Circuit
Interrupter (GFCI) is recommended.
• Power cable plug must be within easy reach
after installation.
• If the current value of the fuse or breaker
in the house is less than 16 Amps, have a
qualified electrician install a 16 Amp fuse.
• The voltage specified in the "Technical
specifications" section must be equal to
your mains voltage.
• Do not make connections via extension
cables or multi-plugs.
A
CAUTION!
• Damaged power cables must be replaced
by the Authorised Service Agents.
4.1.8 Initial use
Before starting to
use the product
make sure that
the preparations
are made which
are in line with the
“Important Safety
and Environment Instructions” and the
instructions in the “Installation” section.
To prepare the product for washing laundry,
perform first operation in Drum Cleaning
programme. If this program is not available
in your machine, apply the method which is
described in the section 4.4.2.
C
INFORMATION
• Use an anti-limescale suitable
for the washing machines.
• Some water might have remained
in the product due to the quality
control processes in the production.
It is not harmful for the product.
4.2 Preparation
4.2.1 Sorting the laundry
• Sort laundry according to type of fabric,
colour, and degree of soiling and allowable
water temperature.
• Always observe the instructions given on
the garment care labels.
4.2.2 Preparing laundry for washing
• Laundry items with metal attachments
such as, underwiring, belt buckles or metal
buttons will damage the product. Remove
the metal pieces or wash such clothes by
putting them in a laundry bag or pillow case.
• Take out all substances in the pockets such
as coins, pens and paper clips, and turn
pockets inside out and brush. Such objects
may damage the product or cause noise
problem.
• Put small size clothes such as infant's socks
and nylon stockings in a laundry bag or
pillow case.
• Place curtains in without compressing them.
Remove curtain attachment items.
• Fasten zippers, sew loose buttons and
mend rips and tears.

9 / EN Washing Machine / User Manual
are caught in the door. The loading door is
locked while a programme is running. The
door lock will open immediately after the
washing programme has ended. Then you
can open the loading door. If the door does
not open, apply the solutions provided for
"Loading door cannot be opened." error in
the Troubleshooting section.
4.2.5 Correct load capacity
The maximum load capacity depends on the
type of laundry, the degree of soiling and the
desired washing programme.
The product automatically adjusts the water
amount according to the weight of the laundry
put inside it.
A
WARNING
• Comply with the information in the section
“Programme and consumption table”.
When overloaded, product’s washing
performance will drop. Moreover, noise
and vibration problems may occur.
4.2.6 Using detergent and softener
C
INFORMATION
• When using detergent, softener, starch,
fabric dye, bleach and descaling agents;
read the manufacturer’s instructions written
on the package and follow the dosages
specified. Use measuring cup if available.
1
3
2
The detergent drawer
is composed of three
compartments:
– (1) for prewash
– (2) for main wash
– (3) for softener
– ( ) in addition, there
is a siphon piece in the
softener compartment.
Detergent, softener and other cleaning agents
• Add detergent and softener before starting
the washing programme.
• While the washing cycle is in progress, do
not leave the detergent drawer open!
• When using a programme without prewash,
do not put any detergent into the prewash
compartment (compartment no. "1").
• Wash “Machine washable” or “Hand
washable” labelled products only with an
appropriate programme.
• Do not wash colours and whites together.
New, dark coloured cottons release a lot of
dye. Wash them separately.
• Tough stains must be treated properly
before washing.
• Only use the dyes / colour changers and
descaling agents which are appropriate
for machine wash. Always follow the
instructions on the package.
• Wash trousers and delicate laundry turned
inside out.
• Keep laundry items made of Angora wool in
a plastic bag in the freezer for a few hours
before washing. This can reduce piling.
• Laundry that are subjected to materials
such as flour, lime dust, milk powder, etc.
intensely must be shaken off before placing
into the product. Such dusts and powders
on the laundry may build up on the inner
parts of the product in time and can cause
damage.
4.2.3 Tips for energy and water saving
Following information will help you use the
product in an ecological and energy/water-
efficient manner.
• Operate the product in the highest load
capacity allowed for the programme you
have selected, but do not overload. See,
“Programme and consumption table”.
• Observe the temperature instructions on the
detergent packaging.
• Wash slightly soiled laundry at low
temperatures.
• Use faster programmes for small quantities
of lightly soiled laundry.
• Do not use prewash and high temperatures
for laundry that is not heavily soiled or
stained.
• If you plan to dry your laundry in a dryer,
select the highest spin speed recommended
during washing process.
• Do not use more detergent than the
recommended on the detergent packaging.
4.2.4 Loading the laundry
1. Open the loading door.
2. Put the laundry items into the product in a
loose manner.
3 Push the loading door to close until you
hear a locking sound. Ensure that no items

10 / EN Washing Machine / User Manual
• If you are using a program with prewash,
start the machine after adding powder
detergent to the prewash and main wash
compartments (compartments 1 and 2).
• Do not select a programme with prewash if
you are using a detergent bag or dispensing
ball. Place the detergent bag or the dispensing
ball directly among the laundry in the product.
• If you are using liquid detergent, do
not forget to place the liquid detergent
container into the main wash compartment
(compartment no. “2”).
Choosing the detergent type
Detergent type to be used depends on the
washing programme, fabric type and colour.
• Use different detergents for coloured and
white laundry.
• Wash your delicate clothes only with special
detergents (liquid detergent, wool shampoo,
etc.) intended solely for delicate clothes and
at suggested programmes.
• When washing dark coloured clothes and
quilts, it is recommended to use liquid
detergent.
• Wash woollens at suggested programme
with special detergent made specifically for
woollens.
• Please review the programme descriptions part
for suggested programme for different textiles.
• All recommendations about detergents are
valid for selectable temperature range of
programmes.
A
WARNING
• Use only detergents manufactured
specifically for washing machines.
• Do not use soap powder.
Adjusting detergent amount
The amount of washing detergent to be used
depends on the amount of laundry, the degree
of soiling and water hardness.
• Do not use amounts exceeding the dosage
quantities recommended on the detergent
package to avoid problems of excessive
foam, poor rinsing, financial savings and
finally, environmental protection.
• Use less detergent for small loads,
lightly soiled clothes and short duration
programmes, especially in soft water areas.
Using softeners
Pour the softener into the softener
compartment of the detergent drawer.
• Do not exceed the (>max<) level sign on the
softener compartment.
• If the softener has lost its fluidity, dilute it
with water before adding it in the detergent
compartment.
A
WARNING
• Do not use liquid detergents or other cleaning
products other than fabric softeners produced
for washing machines to soften the clothes.
Using liquid detergents
If the product contains a liquid detergent cup:
• Put the liquid detergent container into the
compartment no “2”.
• If the liquid detergent lost its fluidity, dilute
it with water before putting it into the
detergent container.
2
2
If the product is equipped with a liquid
detergent part:
• When you want to use liquid detergent,
press on the point shown to rotate the
apparatus. The part that falls off will function
as a barrier for the liquid detergent.
• If required, clean the apparatus with water
when it is in place or by removing it.
• If you will use powder detergent, the apparatus
must be secured at top position. The fan that
you would see in this position will mix the
powder detergent and help it to dissolve.

11 / EN Washing Machine / User Manual
If the product does not contain a liquid
detergent cup:
• Do not use liquid detergent for the prewash
in a programme with prewash.
• Liquid detergent stains your clothes when
used with "End Time" function that delays
start time. If you are going to use the End
Time function, do not use liquid detergent.
Using gel and tablet detergent
• If the gel detergent thickness is fluidal and
your product does not contain a special
liquid detergent container, put the gel
detergent into the main wash detergent
compartment during first water intake. If
your product contains a liquid detergent
container, fill the detergent into this
container before starting the programme.
• If the gel detergent thickness is not fluidal or
in the shape of capsule liquid tablet, put it
directly into the drum before washing.
• Put tablet detergents into the main wash
compartment (compartment no. "2") or
directly into the drum before washing.
Using starch
• Add liquid starch, powder starch or the
dyestuff into the softener compartment.
• Do not use softener and starch together in a
washing cycle.
• Wipe the inside of the product with a damp
and clean cloth after using starch.
Using limescale remover
• When required, use limescale removers
manufactured specifically for washing
machines only.
Using bleaches
• Select a programme with prewash and add the
bleach at the beginning of the prewash. Do not
put detergent in the prewash compartment. As
an alternative application, select a programme
with extra rinse and add the bleach while the
product is taking water from the detergent
compartment during first rinsing step.
• Do not use bleach and detergent by mixing
them.
• Use just a little amount (approx. 50 ml) of
bleach and rinse the clothes very well as it
causes skin irritation.
• Do not pour the bleach onto the laundry.
• Do not use it with the coloured items.
• When using an oxygen-based bleach, select
a programme which washes the laundry at
a low temperature.
• Oxygen-based bleach can be used together
with the detergent. However, if its thickness
is not the same with the detergent, put the
detergent first into the compartment no. "2"
in the detergent drawer and wait until the
detergent flows while the product is taking in
water. While the product continues taking in
water, add bleach in the same compartment.

12 / EN Washing Machine / User Manual
4.2.7 Tips for efficient washing
Clothes
Light Colours and
Whites Colours Black/Dark Colours
Delicates/
Woollens/Silks
(Recommended temperature
range based on soiling level:
40-90 oC)
(Recommended temperature
range based on soiling level:
cold-40 oC)
(Recommended
temperature range
based on soiling
level: cold -40 oC)
(Recommended
temperature range
based on soiling
level: cold -30 oC)
Soiling Level
Heavily
Soiled
(difficult
stains such
as grass,
coffee, fruits
and blood.)
It may be necessary to pre-
treat the stains or perform
prewash. Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
heavily soiled clothes. It is
recommended to use powder
detergents to clean clay and
soil stains and the stains that
are sensitive to bleaches.
Powder and liquid
detergents recommended
for colours can be used at
dosages recommended
for heavily soiled clothes.
It is recommended to use
powder detergents to clean
clay and soil stains and the
stains that are sensitive to
bleaches. Use detergents
without bleach.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended
for heavily soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
Normally
Soiled
(For example,
stains caused
by body on
collars and
cuffs)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
normally soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for normally
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended for
normally soiled
clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
Lightly
Soiled
(No visible
stains exist.)
Powder and liquid
detergents recommended
for whites can be used at
dosages recommended for
lightly soiled clothes.
Powder and liquid detergents
recommended for colours
can be used at dosages
recommended for lightly
soiled clothes. Detergents
which do not contain bleach
should be used.
Liquid detergents
suitable for
colours and dark
colours can be
used at dosages
recommended for
lightly soiled clothes.
Prefer liquid
detergents produced
for delicate clothes.
Woollen and silk
clothes must be
washed with special
woollen detergents.
4.2.8 Displayed Programme Time
You can see the programme duration on the
display of your machine while selecting a
programme. Depending on the amount of laundry
you have loaded into your machine, foaming,
unbalanced load conditions, fluctuations in power
supply, water pressure and programme settings,
the programme duration is automatically adjusted
while the programme is running.
SPECIAL CASE: At programme start of Cottons
and Cotton Eco programmes, display shows the
duration of half load, which is the most common
use case. After programme starts, in 20-25
minutes actual load is detected by the machine.
And if the detected load is higher than half load;
washing programme will be adjusted accordingly
and programme duration increased automatically.
You may follow this change on the display.

13 / EN Washing Machine / User Manual
4.3 Operating the product
4.3.1 Control panel
1 - Programme Selection knob (Uppermost
position On / Off)
2 - Display
3 - Delayed Start Button
4 - Programme Follow-up indicator
5 - Start / Pause button
6 - Auxiliary function button 3
7 - Auxiliary function button 2
8 - Auxiliary function button 1
9 - Spin Speed Adjustment button
10 - Temperature Adjustment button
GentleCare
Synthetics
Down Wear
On / Off Cottons
Daily Express
Xpress Super Short
Mix 40
Spin+Drain
Hygiene
Lingerie
Rinse
Spin
End
Cancel
Ready
Wash
DAW 386
Cottons Eco
Rinse
Outdoor
Sports
Woollens
Hand Wash
Dark Care
Jeans
Shirts
60°
1200
20°
90°
40°
30°
1000
800
600
Start/
Pause
Extra
Rinse
PrewashSpin Fast+
Temp.
˚C
1 2 3 4
57 68910
4.3.2 Preparing the machine
1.Make sure that the hoses are connected tightly.
2.Plug in your machine.
3.Turn the tap on completely.
4.Place the laundry in the machine.
5.Add detergent and fabric softener.
4.3.4 Programme and consumption table
EN 2Auxiliary functions
Programme
Max. Load (kg) Water Consumption (l) Energy Consumption (kWh) Max. Speed***
Prewash Fast+ Extra Rinse AntiCrease+
Selectable temperature
range °C
Cottons
90 8 93,0 2,3 1200 ••••Cold - 90
60 8 93,0 1,7 1200 ••••Cold - 90
40 8 90,0 1,1 1200 ••••Cold - 90
Cottons Eco
60** 8 54,0 1,100 1200 Cold - 60
60** 4 43,5 0,700 1200 Cold - 60
40** 4 43,5 0,665 1200 Cold - 60
Synthetics 60 3 70,0 1,2 1200 • • • •Cold - 60
40 3 68,0 0,8 1200 • • • •Cold - 60
Daily Express / Xpress Super Short
90 8 67,0 2,2 1200 • • •Cold - 90
60 8 67,0 1,2 1200 • • •Cold - 90
30 8 65,0 0,2 1200 • • •Cold - 90
Daily Xpress / Xpress Super Short +
Fast+ 30 2 41,0 0,2 1200 • • •Cold - 30
Mix 40 40 3,5 72,2 0,8 800 • • • Cold - 40
Woollens / Hand Wash 40 1,5 55,0 0,6 1200 • Cold - 40
GentleCare 40 3,5 51,0 0,7 800 • Cold - 40
Outdoor / Sports 40 3,5 45,0 0,5 1200 • Cold - 40
Dark Care / Jeans 40 3 86,4 0,9 1200 • • * •Cold - 40
Lingerie 30 1 72,0 0,3 600 * Cold - 30
Down Wear 60 2 81,0 1,8 1000 • 40-60
Shirts 60 3 66,0 1,7 800 • • • •40-60
Hygiene 90 8 137,0 2,8 1200 *40-90
Drum Cleaning+ 90 - 84,0 2,6 600 90
4.3.3 Programme selection and
tips for efficient washing
1.Select the programme suitable for the type,
quantity and soiling degree of the laundry
in accordance with the "Programme and
consumption table" and the temperature
table below.
2.Select the desired programme with the
Programme Selection knob.

14 / EN Washing Machine / User Manual
• : Selectable
* : Automatically selected, no canceling.
** : Energy Label programme (SANS 1695)
***: If maximum spin speed of the machine is
lower then this value, you can only select up
to the maximum spin speed.
- : See the programme description for
maximum load.
C
INFORMATION
• Please check installation section of user
manual before the first use of your product
• Water and power consumption may vary
subject to the changes in water pressure,
water hardness and temperature, ambient
temperature, type and amount of laundry,
selection of auxiliary functions and spin
speed, and changes in electric voltage.
• You can see the washing duration
on the display of your machine while
selecting a programme. Depending
on the amount of laundry you have
loaded into your machine, there may
be a difference of 1-1.5 hours between
the duration shown on the display and
the actual duration of the wash cycle.
Duration will be automatically updated
soon after the washing starts.
• The auxiliary functions in the table may vary
according to the model of your machine.
• Auxiliary function selection modes can be
changed by the manufacturing company.
Existing selection modes can be removed
or new selection modes can be added.
4.3.5 Main programmes
Depending on the type of fabric, use the
following main programmes.
•Cottons
You can wash your durable cotton laundry
(sheets, bedlinen, towels, bathrobes,
underwear etc.) in this programme. When
the quick wash function button is pressed,
programme duration becomes notably shorter
but effective washing performance is ensured
with intense washing movements. If the
quick wash function is not selected, superior
washing and rinsing performance is ensured
for your heavily soiled laundry.
• Synthetics
You can wash your laundry (such as shirts,
blouses, synthetic/cotton blended fabrics etc.)
in this programme. The programme duration
gets notable shorter and washing with high
performance is ensured. If the quick wash
function is not selected, superior washing and
rinsing performance is ensured for your heavily
soiled laundry.
•Woollens / Hand Wash
Use to wash your woolen/delicate laundry.
Select the appropriate temperature complying
with the tag of your clothes. Your laundry will
be washed with a very gentle washing action in
order not to damage the clothes.
4.3.6 Additional programmes
For special cases, additional programmes are
available in the machine.
C
INFORMATION
• Additional programmes may differ
according to the model of the machine.
• Cottons Eco
Use to wash your normally soiled, durable cotton
and linen laundry. Although it washes longer than
all other programmes, it provides high energy
and water savings. Actual water temperature may
be different from the stated wash temperature.
When you load the machine with less laundry
(e.g. ½ capacity or less), periods in programme
stages may automatically get shorter. In this case,
energy and water consumption will decrease
more, providing a more economic wash.

15 / EN Washing Machine / User Manual
• Hygiene+
Applying a steam step at the beginning of the
programme allows to soften the dirt easily.
Use this programme for your laundry (baby
clothes, bed sheets, bedlinen, underwear,
etc. cotton items) that requires an anti-allergic
and hygienic washing at high temperature
with intensive and long washing cycle. The
high level of hygiene is ensured thanks to the
steam application before the programme, long
heating duration and additional rinsing step.
• Programme was tested by “The British Allergy
Foundation“ (Allergy UK) with the 60°C
temperature option selected and it was
certified in terms of its efficacy in eliminating
allergens in addition to bacteria and mould.
Allergy UK is the brand of the
British Allergy Association. Seal of
Approval is created to guide
people that require recommendation
about a product that the related
product restricts / reduces /
eliminates the allergens or reduces the allergen
content significantly in the ambient where allergy
patients exist. It aims to provide assurance that
the products are tested scientifically or examined
in a way to provide measurable results.
•GentleCare
You can wash your delicate clothes such as
cotton/synthetic blended knitwear or hosiery in
this programme. It washes with more delicate
washing action. Wash your clothes whose
colour you want to preserve either at 20degrees
or by selecting the cold wash option.
• Daily Express / Xpress Super Short
Use this programme to wash your lightly soiled
or unspotted cotton clothes in a short time. The
programme duration can be reduced up to 14
minutes when the quick wash function is selected.
When the quick wash function is selected,
maximum 2 (two) kg of laundry must be washed.
• Dark Care / Jeans
Use this programme to protect the colour of your
dark-coloured garments or jeans. It performs
high performance washing with special drum
movement even if the temperature is low. It is
recommended to use liquid detergent or woolen
shampoo for dark coloured laundry. Do not wash
your delicate clothes containing wool or etc.
• Mix 40
Use to wash your cotton and synthetic clothes
together without sorting them.
• Shirts
This programme is used to wash the shirts
made from cotton, synthetic and synthetic
blended fabrics altogether. It reduces wrinkles.
Steam is applied at the end of the programme to
help the wrinkle reducing function. The special
spin profile and steam applied at the end of the
programme reduce the wrinkles on your shirts.
When the quick wash function is selected, the
Pre-treatment algorithm is executed.
• Apply the pre-treatment chemical on your
garments directly or add it together with
detergent when the machine starts to take water
from the main washing compartment. Thus, you
can obtain the same performance as you obtain
with normal washing in a much shorter period of
time. Usage life of your shirts increases.
• Outdoor / Sport
You can use this programme to wash sports and
outdoors garments that contain cotton/synthetics
mix and water repellent covers such as gore-tex
etc. It makes sure your garments are washed
gently thanks to special rotating movements.
• Lingerie
You can use this programme to wash delicate
garments that are suitable for hand wash and
delicate women‘s underwear. Small amount of
garments must be washed in a washing net.
Hooks, buttons etc. must be done up and zips
must be zipped up.
• Down Wear
Use this programme to wash your coats, vest,
jackets etc. containing feathers with a “machine-
washable” label on them. Thanks to special
spinning profiles, it is ensured that the water
reaches the air gaps amongst the feathers.
Steam is applied at the end of the programme
to soften bulky laundry such as towels.

16 / EN Washing Machine / User Manual
4.3.7 Special programmes
For specific applications, select any of the
following programmes.
•Rinse
Use when you want to rinse or starch separately.
• Spin&Drain
You can use this function to remove the water on
the garment of drain the water in the machine.
Before selecting this programme, select the
desired spin speed and press Start / Pause
button. First, the machine will drain the water
inside of it. Then, it will spin the laundry with
the set spin speed and drain the water coming
out of them.
If you wish to drain only the water without
spinning your laundry, select the Pump+Spin
programme and then select the No Spin
function with the help of Spin Speed
Adjustment button. Press Start / Pause button.
C
INFORMATION
• Use a lower spin speed for delicate laundries.
4.3.8 Temperature selection
Whenever a new programme is selected,
the recommended temperature value for
the selected programme appears on the
temperature indicator.
To decrease the temperature, press
the Temperature Adjustment button.
Temperature will decrease gradually.
Temperature level lights will not turn on
when the cold level is selected.
C
INFORMATION
• If the programme has not reached
the heating step, you can change
the temperature without switching
the machine to Pause mode.
4.3.9 Spin speed selection
Whenever a new programme is selected, the
recommended spin speed of the selected
programme is displayed on the spin speed indicator.
To decrease the spin speed, press the Spin
Speed Adjustment button. Spin speed decreases
gradually. Then, depending on the model of the
product, "Rinse Hold" and "No Spin" options
appear on the display. When "No Spin" is selected,
the rinse level indicator lights will not turn on.
Rinse hold
If you are not going to unload your clothes
immediately after the programme completes, you
can use rinse hold function to keep your laundry
in the final rinsing water in order to prevent them
from getting wrinkled when there is no water in
the machine. Press Start / Pause button after this
process if you want to drain the water without
spinning your laundry. Programme will resume
and complete after draining the water.
If you want to spin the laundry held in water, adjust
the Spin Speed and press Start / Pause button.
The programme will resume. Water is drained,
laundry is spun and the programme is completed.
C
INFORMATION
• If the programme has not reached
the spinning step, you can change
the speed without switching the
machine to Pause mode.
4.3.10 Auxiliary function selection
Select the desired auxiliary functions before starting
the programme. Furthermore, you may also select
or cancel auxiliary functions that are suitable to
the running programme without pressing the Start
/ Pause button when the machine is operating.
For this, the machine must be in a step before the
auxiliary function you are going to select or cancel.
If the auxiliary function cannot be selected or
canceled, light of the relevant auxiliary function will
blink 3 times to warn the user.
C
INFORMATION
• If a second auxiliary function conflicting
with the first one is selected before starting
the machine, the function selected first
will be canceled and the second auxiliary
function selection will remain active.
• An auxiliary function that is not compatible
with the programme cannot be selected.
(See, "Programme and consumption table")
• Auxiliary Function buttons may vary
according to the model of the machine.
4.3.10.1 Auxiliary functions
• Prewash
A Prewash is only worthwhile for heavily soiled
laundry. Not using the Prewash will save
energy, water, detergent and time.
C
INFORMATION
• Prewash without detergent is
recommended for tulle and curtains.

17 / EN Washing Machine / User Manual
• Fast+
When this function is selected, the durations of
the relevant programmes get shorter by 50%.
Thanks to the optimised washing steps,
high mechanic activity and optimum water
consumption, high washing performance is
achieved in spite of the reduced duration.
• Extra Rinse
This function enables the product to make
another rinsing in addition to the one already
made after the main wash. Thus, the risk for
sensitive skins (babies, allergic skins, etc.) to
be effected by the minimal detergent remnants
on the laundry can be reduced.
4.3.10.2 Functions/Programmes
Selected by Pressing the Function
Buttons for 3 Seconds
• Drum Clean
Press and hold the auxiliary function button 1 for
3 seconds to select the programme. Use regularly
(once in every 1-2 months) to clean the drum and
provide the required hygiene. Steam is applied
before the programme to soften the residues in the
drum. Operate the programme while the machine
is completely empty. To obtain better results, put
powder lime-scale remover for washing machines
into the detergent compartment no. “2”. When the
programme is over, leave the loading door ajar so
that the inside of the machine gets dry.
C
INFORMATION
• This is not a washing programme.
It is a maintenance programme.
• Do not run the programme when there
is something in the machine. If you try to
do so, the machine detects that there is
load inside and aborts the programme.
• Child Lock
Use Child Lock function to prevent children
from tampering with the machine. Thus you can
avoid any changes in a running programme.
C
INFORMATION
• If the Programme Selection knob is
turned when the Child Lock is active,
"Con" appears on the display. The
Child Lock does not allow any change
in the programmes and the selected
temperature, speed and auxiliary functions.
• Even if another programme is selected
with the Programme Selection knob
while the Child Lock is active, previously
selected programme will continue running.
To activate the Child Lock:
2. Pres and hold the Auxiliary Function button
for 3 seconds. C03, C02, C01 will appear on
the display respectively while you keep the
button pressed for 3 seconds. Then, while
the light of the Auxiliary Function button 2
is flashing, "Con" will appear on the display
indicating that the child lock has been activated.
If you press any button or turn the Programme
Selection knob when the Child Lock is active,
same phrase will appear on the display.
To deactivate the Child Lock:
Press and hold the Auxiliary Function button 2
for 3 seconds while a programme is running.
C03, C02, C01 will appear on the display
respectively while you keep the button pressed
for 3 seconds. Then, while the light of the
auxiliary function button 2 is flashing, "COF" will
appear on the display indicating that the child
lock has been deactivated.
C
INFORMATION
• In addition to the method above, to
deactivate the Child Lock, switch the
Programme Selection knob to On / Off
position when no programme is running,
and select another programme.
• Child Lock is not deactivated after power
failures or when the machine is unplugged.

18 / EN Washing Machine / User Manual
• AntiCrease+
If you press and hold the auxiliary function button
3 for 3 seconds, this function will be selected
and the programme follow-up light of the relevant
programme will turn on. When this function is
selected, the drum will rotate for up to eight hours
to ensure that the clothes do not crease at the end
of the programme. At any time during these eight
hours, you can cancel the programme and unload
the machine. Just press any button or turn the
programme selection knob to end the function. The
programme follow-up light will remain on even if you
end the function by pressing any button. If you end
the function by turning the programme selection
knob, the programme follow-up light will remain on
or go off depending on the selected programme.
If you do not cancel the function by pressing the
Auxiliary Function button 3 for 3 seconds, it will be
used in the next washing cycles as well.
4.3.11 Delayed Start
With the Delayed Start function the startup
of the programme may be delayed up to 19
hours. Delayed start time can be increased by
increments of 1 hour.
C
INFORMATION
• Do not use liquid detergents when
you set Delayed Start! There is the
risk of staining of the clothes.
1. Open the loading door, place the laundry
and put detergent, etc.
2. Select the washing programme,
temperature, spin speed and, if required,
the auxiliary functions.
3. Set the desired time by pressing the
Delayed Start button.
4. Press Start / Pause button. The delayed start
time you have set is displayed. Delayed start
countdown starts. “_” symbol next to the delayed
start time moves up and down on the display.
C
INFORMATION
• Additional laundry may be loaded
during the delayed start period.
5. At the end of the countdown, duration of
the selected programme will be displayed.
“_” will disappear and the selected
programme will start.
Changing the delayed start period
If you want to change the time during countdown:
1. Press the Delayed Start button. Time will
increase by 1 hour each time you press the
button.
2. If you want to decrease the delayed start
time, press Delayed Start button repeatedly
until the desired delayed start time appears
on the display.
Canceling the Delayed Start function
If you want to cancel the delayed start countdown
and start the programme immediately:
1. Set the Delayed Start period to zero or turn the
Programme Selection knob to any programme.
Thus, Delayed Start function will be canceled.
The End/Cancel light flashes continuously.
2. Then, select the programme you want to
run again.
3. Press Start/Pause button to start the
programme.
4.3.12 Starting the programme
1. Press Start/Pause button to start the
programme.
2. Programme follow-up light showing the
startup of the programme will turn on.
C
INFORMATION
• If no programme is started or no button is
pressed within 1 minute during programme
selection process, the machine will switch
to Pause mode and the illumination level
of the temperature, speed and loading
door indicator lights will decrease. Other
indicator lights and indicators will turn off.
Once the Programme Selection knob is
rotated or any button is pressed, indicator
lights and indicators will turn on again.
4.3.13 Progress of programme
Progress of a running programme can be
followed from the Programme Follow-up
indicator. At the beginning of every programme
step, the relevant indicator light will turn on and
light of the completed step will turn off.
You can change the auxiliary functions, speed
and temperature settings without stopping
the programme flow while the programme
is running. To do this, the change you are
going to make must be in a step after the
running programme step. If the change is not
compatible, relevant lights will flash for 3 times.

19 / EN Washing Machine / User Manual
C
INFORMATION
• If the machine does not pass to the spinning
step, Rinse Hold function might be active or the
automatic unbalanced load detection system
might be activated due to the unbalanced
distribution of the laundry in the machine.
4.3.14 Loading door lock
There is a locking system on the loading door of
the machine that prevents opening of the loading
door in cases when the water level is unsuitable.
Loading door light will start flashing when the
machine is switched to Pause mode. Machine
checks the level of the water inside. If the level is
suitable, Loading Door light illuminates steadily within
1-2 minutes and the loading door can be opened.
If the level is unsuitable, Loading Door light
turns off and the loading door cannot be
opened. If you are obliged to open the Loading
Door while the Loading Door light is off, you
must cancel the current programme. See.
"Cancelling the programme"
4.3.15 Changing the selections
after programme has started
Switching the machine to pause mode
Press the Start / Pause button to switch the
machine to pause mode while a programme
is running. The light of the step which the
machine is in starts flashing in the Programme
Follow-up indicator to show that the machine
has been switched to the pause mode.
Also, when the loading door is ready to be
opened, Loading Door light will also illuminate
continuously in addition to the programme step light.
Changing the auxiliary function, speed and
temperature
Depending on the step the programme has
reached, you can cancel or select the auxiliary
functions. See, "Auxiliary function selection".
You can also change the speed and
temperature settings. See, "Spin speed
selection" and "Temperature selection".
C
INFORMATION
• If no change is allowed, the
relevant light will flash 3 times.
Adding or taking out laundry
1. Press Start / Pause button to switch the
machine to pause mode. The programme
follow-up light of the relevant step during
which the machine was switched into the
pause mode will flash.
2. Wait until the Loading Door can be opened.
3. Open the Loading Door and add or take out
the laundry.
4. Close the Loading Door.
5. Make changes in auxiliary functions,
temperature and speed settings if necessary.
6. Press Start / Pause button to start the machine.
4.3.16 Cancelling the programme
To cancel the programme, turn the Programme
Selection knob to select another programme.
Previous programme will be cancelled. End /
Cancel light will flash continuously to notify that
the programme has been canceled.
Your machine will end the programme when you
turn the Programme Selection knob; however,
it does not drain the water inside. When you
select and start a new programme, the newly
selected programme will start depending on the
step the previous programme was canceled in.
For example, it may take in additional water or
continue to wash with the water inside.
C
INFORMATION
• Depending on the step where the
programme was canceled in, you may have
to put detergent and softener again for
the programme you have selected anew.
4.3.17 End of programme
“End” appears on the display at the end of the
programme.
1. Wait until the loading door light illuminates
steadily.
2. Press On/Off button to switch off the machine.
3. Take out your laundry and close the loading door.
Your machine is ready for the next washing cycle.
4.3.18 Your machine features
"Standby Mode".
After you switch on your machine with On-Off
button, if no programme is started or no other
procedure is performed at the selection step or
no action is taken within approx. 2 minutes after
the selected programme ends, your machine will
switch to energy saving mode automatically. The
brightness of the indicator lights will decrease.
Also, if your product has a display that shows
programme time, this display will be completely
turned off. If you turn the Programme Selection
knob or touch any button, lights and display
will switch back to previous condition. The
selections which you make when exiting from
the energy efficiency may change. Please check
the correctness of your selections before starting
the programme. If necessary, please make your
settings again.This is not an error.

20 / EN Washing Machine / User Manual
4.4 Maintenance and cleaning
Service life of product extends and frequently
experienced problems will be reduced if it is
cleaned at regular intervals.
4.4.1 Cleaning the detergent drawer
Clean the detergent
drawer at regular intervals
(every 4-5 washing cycles)
as shown below in order
to prevent accumulation of
powder detergent in time.
Lift the rear part of the siphon to remove it as
illustrated.
If more than normal amount of water and
softener mixture starts to gather in the softener
compartment, the siphon must be cleaned.
1 Press the dotted point on the siphon in the
softener compartment and pull towards you
until the compartment is removed from the
machine.
2. Wash the detergent drawer and the
siphon with plenty of lukewarm water in a
washbasin. In order to prevent the residues to
contact your skin, clean it with an appropriate
brush by wearing a pair of gloves.
3 Insert the drawer back into its place after
cleaning and make sure that it is seated well.
4.4.2 Cleaning the loading
door and the drum
For products with drum cleaning programme,
please see Operating the product -
Programmes.
C
INFORMATION
• Repeat Drum Cleaning process
in every 2 months.
• Use an detergent / anti-limescale
suitable for the washing machines.
After every washing
make sure that no foreign
substance is left in the
drum.
If the holes on the bellow shown in the figure is
blocked, open the holes using a toothpick.
C
INFORMATION
• Foreign metal substances will cause
rust stains in the drum. Clean the
stains on the drum surface by using
cleaning agents for stainless steel.
A
WARNING
• Never use steel wool or wire wool.
These will damage the painted,
chromated and plastic surfaces.
4.4.3 Cleaning the body
and control panel
Wipe the body of the machine with soapy
water or non-corrosive mild gel detergents as
necessary, and dry with a soft cloth.
Use only a soft and damp cloth to clean the
control panel.
4.4.4 Cleaning the water intake filters
There is a filter at the end of each water intake
valve at the rear of the machine and also at
the end of each water intake hose where they
are connected to the tap. These filters prevent
foreign substances and dirt in the water to
enter the washing machine. Filters should be
cleaned as they do get dirty.
1. Close the taps.
2. Remove the nuts of the water intake hoses
to access the filters on the water intake
valves. Clean them with an appropriate
brush. If the filters are too dirty, remove
them from their places with a pliers and
clean in this way.
3. Take out the filters on the flat ends of the
water intake hoses together with the gaskets
and clean thoroughly under running water.
4. Replace the seals and filters carefully and
tighten their nuts by hand.
