This chapter provides installation instructions for the hardware components of
the APC ECHO 5. The APC ECHO 5 is sold in two options; accordingly the full
package contents will differ:
APC ECHO 5
APC ECHO 5 together with Offset Dish
If any of listed items are missing or damaged, please contact your
reseller.
APC ECHO 5 Package Contents
The figure below displays APC ECHO 5 package contents:
Figure 1 –ECHO 5 Package Contents
Item
Component Name
Quantity
A
APC ECHO 5
1
B
Quick Installation Guide
1
C
PoE
1
D
Power Cord
1
E
Cable Gland
1
F
Grounding Screw
1

Quick Installation Guide Installation
deliberant Page 10
Offset Dish Package Contents
This description of the package contents applies on purchases
ECHO 5 together with Offset Dish only.
The figure below displays package contents of the offset ECHO 5 dish (60cm):
Figure 2 –Offset Dish Package Contents
Item
Component Name
Quantity
G
Dish Reflector
1
H
Taping Screw 4x13mm
1
I
Screw M4x20mm
2
J
Nut M4 for Device Holder
2
K
Screw M6x25mm
1
L
Plastic Insert Cap
2
M
Nut M8
4
N
Spring Washer ID=6.5mm
2

Quick Installation Guide Installation
deliberant Page 11
Item
Component Name
Quantity
O
Washer ID=6mm
2
P
Screw M6x70mm
2
Q
Flange Nut M6
3
R
Nut M6
4
S
Metal Arm
1
T
Dish Holder
1
U
ADJ (angle adjust) Bracket
1
V
U-bolt
2
W
Clamp Bracket
2
X
Device Holder
1
Y
Screw M6x12mm
4
Z
Washer ID=8mm
4
AA
Spring Washer ID=8mm
4
AB
Plastic cable tie
3
APC ECHO 5 Hardware Introduction
This hardware description provides instructions of installation
for complete package of APC ECHO 5 together with Offset
Dish.

Quick Installation Guide Installation
deliberant Page 12
Figure 3 –ECHO 5 with Offset Dish Overview
The base of the APC ECHO 5 unit’s housing is made from the metal for heat
dissipation and contains:
6 LEDs: power LED, LAN activity LED and 4 LEDs for device RSSI level
indication
Ethernet cable gland
Ethernet + PoE connector
Grounding stud
Figure 4 –ECHO 5 Overview
The APC ECHO 5 label contains with following information:
Model name.
Serial Number
ETH MAC address
FCC ID
IC ID
Figure 5 –APC Label
Product size and shape are subject to change without notice,
and actual product appearance may differ from that depicted
in the user guide.

Quick Installation Guide Installation
deliberant Page 13
LEDs
The APC ECHO 5 has 6 LEDs located on the back panel: power, LAN and 4
RSSI LEDs (refer at the Figure 4 –ECHO 5 Overview for details). The various
states of the LEDs indicate different connection operations as follows:
LED
Color
Status
Indication
Power
Green
On
The APC is active/working
Off
No power on APC
LAN
Green
On
LAN connection exists.
Blinking
Indicates the traffic on LAN interface.
Off
No LAN connection.
RSSI
(1, 2, 3, 4)
Yellow
On
The RSSI level has reached the
appropriate threshold level (default
RSSI threshold levels: 10, 25, 35, 50)
Off
The RSSI level has not reached the
appropriate threshold level
Assembling APC ECHO 5 with Offset Dish
Step 1. Install ECHO 5 by tightening Plastic Holder (item X) with two Screws
M4x20mm and two Nuts M4 (items Iand J). Connect Ethernet cable
into the ECHO 5 and tighten it with Cable Gland (item E):
It is recommended to use STP, Cat5e, 24AWG, solid copper
conductor (NOT copper wrap aluminum) Ethernet cable.

Quick Installation Guide Installation
deliberant Page 14
To ensure a successful ground, it is
recommended to solder the metal drain
wire to the shielded RJ45 connector, as
this provides a more reliable grounding.
Step 2. Attach the Plastic Insert Caps (item L)at the ends of the Metal Arm
(item S):
Step 3. Attach the Plastic Holder together with ECHO 5 to Metal Arm (item S)
using the Screw M6x25 (item K) and Flange Nut M6 (item Q):
Step 4. Attach the Dish Reflector (item G)to the Dish Holder (item T)using
four Screws M6x12mm (item Y)and four Nuts M6 (item R):

Quick Installation Guide Installation
deliberant Page 15

Quick Installation Guide Installation
deliberant Page 16
Step 5. Attach the Metal Arm (together with ECHO 5) to the Offset Dish using
the Taping Screw 4x13mm (item H):
It is recommended to secure the Ethernet cable on the metal
arm with plastic cable ties (item AB) to avoid damage of the
Ethernet port of the ECHO 5.
ECHO 5 with Dish Assembly Mounting on
Pole
The APC ECHO 5 with Offset Dish is supplied with mounting kit for pole
installation (40-60mm diameter). Use the following procedure to mount the
device on a pole:
Step 1. Fasten the Angle Adjust Bracket (item U) to the Dish Holder using
two Screws M6x70mm (item P), and two Flange Nuts M6 (item Q)
with two Washers ID=6mm (item O) and with two Spring Washers
ID=6.5mm (item N).

Quick Installation Guide Installation
deliberant Page 17
Step 2. Attach the Dish Assembly to the pole using the two U-Bolts (item V),
two Clamp Brackets (item W),four Washers ID=8mm (item Z), four
Spring Washers ID=8mm (item AA) and four Nuts M8 (item M):
Step 3. Connect the APC to a PoE power source: connect an Ethernet cable
coming from Ethernet port on the APC ECHO 5 to the POE port of
the PoE Adapter, then connect other Ethernet cable from your LAN
to the Ethernet port labeled LAN on the PoE Adapter and power up
the device:

Quick Installation Guide Installation
deliberant Page 18
Step 4. After the unit is powered-on, the green Power LED must be on (refer
at the respective section LEDs). Dependently on link quality, up to
four yellow LEDs will switch on indicating that link between two units
was established successfully.

Quick Installation Guide Installation
deliberant Page 19
ECHO 5 Grounding
The APC ECHO 5 must be grounded before connecting power to protect
against lightning.
Step 1. The grounding cable must be attached to the grounding stud and
fixed with the grounding screw (item Fin the Figure 1 –ECHO 5
Package Contents):
Grounding recommendations:
Use the grounding cable to connect the device housing
with the grounding stake.
Use conductor larger than 6 AWG.
Keep grounding cable as short as possible.

Quick Installation Guide Installation
deliberant Page 20
ECHO 5 with Dish Assembly Adjustment
The ECHO 5 Offset Dish has an elevation scale on the holder which allows
adjust dish to the correct elevation angle. Assuming that elevation angle of the
link is 0 degrees, point the marks on the ADJ mounting bracket (item Uon the
Figure 2 –Offset Dish Package Contents) at 0 degrees on lower scale (90
degrees on upper scale) and then firmly tighten the nuts:
Use lower scale on the bracket for change dish elevation
angle up (therefore the upper scale is for aligning dish
elevation angle down).
