Dell Inspiron 24 5000 Series User manual

Inspiron 24 5000
Service Manual
Computer Model: Inspiron 24-5475
Regulatory Model: W15C
Regulatory Type: W15C001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make
better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or
loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Copyright ©2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other
trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be
trademarks of their respective owners.
2017 - 05
Rev. A00

Contents
Before working inside your computer........................... 10
Before you begin .....................................................................................10
Safety instructions....................................................................................11
Recommended tools................................................................................ 12
Screw list................................................................................................. 12
After working inside your computer..............................15
Technical overview....................................................... 16
Inside view of your computer................................................................... 17
System board components ..................................................................... 18
Removing the back cover.............................................20
Procedure............................................................................................... 20
Replacing the back cover.............................................22
Procedure................................................................................................22
Removing the stand..................................................... 23
Prerequisites............................................................................................23
Procedure................................................................................................23
Replacing the stand..................................................... 25
Procedure............................................................................................... 25
Post-requisites........................................................................................ 25
3

Removing the hard drive.............................................. 26
Prerequisites............................................................................................26
Procedure............................................................................................... 26
Replacing the hard drive.............................................. 29
Procedure............................................................................................... 29
Post-requisites........................................................................................ 29
Removing the inner frame............................................30
Prerequisites........................................................................................... 30
Procedure................................................................................................ 31
Replacing the inner frame............................................ 34
Procedure................................................................................................34
Post-requisites........................................................................................ 34
Removing the camera.................................................. 35
Prerequisites........................................................................................... 35
Procedure............................................................................................... 35
Replacing the camera...................................................37
Procedure................................................................................................37
Post-requisites.........................................................................................37
Removing the microphones..........................................38
Prerequisites............................................................................................38
Procedure............................................................................................... 38
Replacing the microphones..........................................40
Procedure............................................................................................... 40
Post-requisites........................................................................................ 40
4

Removing the power-button board............................... 41
Prerequisites............................................................................................ 41
Procedure................................................................................................ 41
Replacing the power-button board...............................43
Procedure................................................................................................43
Post-requisites........................................................................................ 43
Removing the front bezel ............................................45
Prerequisites........................................................................................... 45
Procedure............................................................................................... 46
Replacing the front bezel............................................. 48
Procedure............................................................................................... 48
Post-requisites........................................................................................ 48
Removing the system-board shield.............................. 49
Prerequisites........................................................................................... 49
Procedure............................................................................................... 49
Replacing the system-board shield............................... 51
Procedure................................................................................................ 51
Post-requisites......................................................................................... 51
Removing the chassis fan............................................ 52
Prerequisites........................................................................................... 52
Procedure............................................................................................... 52
Replacing the chassis fan.............................................54
Procedure............................................................................................... 54
Post-requisites........................................................................................ 54
5

Removing the speakers................................................55
Prerequisites........................................................................................... 55
Procedure .............................................................................................. 55
Replacing the speakers................................................ 57
Procedure ...............................................................................................57
Post-requisites........................................................................................ 57
Removing the side I/O-board.......................................59
Prerequisites........................................................................................... 59
Procedure............................................................................................... 59
Replacing the side I/O-board....................................... 62
Procedure............................................................................................... 62
Post-requisites........................................................................................ 63
Removing the coin-cell battery.................................... 64
Prerequisites........................................................................................... 64
Procedure............................................................................................... 64
Replacing the coin-cell battery.................................... 66
Procedure............................................................................................... 66
Post-requisites........................................................................................ 66
Removing the memory modules................................... 67
Prerequisites............................................................................................67
Procedure............................................................................................... 68
Replacing the memory modules................................... 70
Procedure................................................................................................70
Post-requisites......................................................................................... 71
6

Removing the solid-state drive.....................................72
Prerequisites............................................................................................72
Procedure................................................................................................73
Replacing the solid-state drive..................................... 74
Procedure................................................................................................74
Post-requisites........................................................................................ 75
Removing the wireless card..........................................76
Prerequisites............................................................................................76
Procedure................................................................................................77
Replacing the wireless card..........................................79
Procedure................................................................................................79
Post-requisites........................................................................................ 80
Removing the processor heat-sink................................81
Prerequisites............................................................................................ 81
Procedure for computers with discrete graphics..................................... 82
Replacing the processor heat-sink............................... 84
Procedure............................................................................................... 84
Post-requisites........................................................................................ 84
Removing the processor.............................................. 85
Prerequisites........................................................................................... 85
Procedure............................................................................................... 86
Replacing the processor.............................................. 88
Procedure............................................................................................... 88
Post-requisites........................................................................................ 89
7

Removing the I/O bracket........................................... 90
Prerequisites........................................................................................... 90
Procedure............................................................................................... 90
Replacing the I/O bracket............................................92
Procedure............................................................................................... 92
Post-requisites........................................................................................ 92
Removing the I/O board...............................................93
Prerequisites............................................................................................93
Procedure............................................................................................... 93
Replacing the I/O board...............................................96
Procedure............................................................................................... 96
Post-requisites.........................................................................................97
Removing the system board.........................................98
Prerequisites........................................................................................... 98
Procedure............................................................................................... 99
Replacing the system board........................................102
Procedure.............................................................................................. 102
Post-requisites.......................................................................................103
Removing the middle frame........................................104
Prerequisites.......................................................................................... 104
Procedure..............................................................................................105
Replacing the middle frame........................................ 107
Procedure.............................................................................................. 107
Post-requisites....................................................................................... 110
8

Removing the display panel......................................... 112
Prerequisites...........................................................................................112
Procedure...............................................................................................112
Replacing the display panel......................................... 116
Procedure...............................................................................................116
Post-requisites........................................................................................119
BIOS setup program................................................... 120
BIOS overview.......................................................................................120
Entering BIOS setup program................................................................ 120
System Setup Options............................................................................121
Clearing forgotten passwords................................................................ 126
Prerequisites.................................................................................... 126
Procedure........................................................................................ 127
Post-requisites................................................................................. 127
Clearing CMOS settings........................................................................ 128
Prerequisites.................................................................................... 128
Procedure........................................................................................ 128
Post-requisites.................................................................................129
Flashing the BIOS.......................................................130
Diagnostics................................................................. 131
Getting help and contacting Dell.................................133
Self-help resources................................................................................ 133
Contacting Dell...................................................................................... 134
9

Identifier GUID-5D3B1051-9384-409A-8D5B-9B53BD496DE8
Status Released
Before working inside your
computer
NOTE: The images in this document may dier from your computer
depending on the conguration you ordered.
Identifier GUID-0CBCCCC8-AEDC-4C92-992B-45062AB0B176
Status Released
Before you begin
1 Save and close all open les and exit all open applications.
2 Shut down your computer. Click Start → Power → Shut down.
NOTE: If you are using a dierent operating system, see the
documentation of your operating system for shut-down instructions.
3 Disconnect your computer and all attached devices from their electrical outlets.
4 Disconnect all attached network devices and peripherals, such as keyboard,
mouse, and monitor from your computer.
5 Remove any media card and optical disc from your computer, if applicable.
6 After the computer is unplugged, press and hold the power button for 5 seconds
to ground the system board.
CAUTION: Place the computer on a at, soft, and clean surface to
avoid scratches on the display.
7 Place the computer face down.
10

Identifier GUID-71128823-CE64-4E17-9439-DEE95AF668C4
Status Released
Safety instructions
Use the following safety guidelines to protect your computer from potential damage
and ensure your personal safety.
WARNING: Before working inside your computer, read the safety
information that shipped with your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer
cover or panels. After you nish working inside the computer, replace all
covers, panels, and screws before connecting to the electrical outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is
at and clean.
CAUTION: To avoid damaging the components and cards, handle them by
their edges, and avoid touching pins and contacts.
CAUTION: You should only perform troubleshooting and repairs as
authorized or directed by the Dell technical assistance team. Damage due to
servicing that is not authorized by Dell is not covered by your warranty. See
the safety instructions that shipped with the product or at www.dell.com/
regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself
by touching an unpainted metal surface, such as the metal at the back of
the computer. While you work, periodically touch an unpainted metal surface
to dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull
tab, not on the cable itself. Some cables have connectors with locking tabs
or thumb-screws that you must disengage before disconnecting the cable.
When disconnecting cables, keep them evenly aligned to avoid bending any
connector pins. When connecting cables, ensure that the ports and
connectors are correctly oriented and aligned.
11

CAUTION: Press and eject any installed card from the media-card reader.
Identifier GUID-DEA55279-6FE6-4A1F-A152-21F8A5572B33
Status Released
Recommended tools
The procedures in this document may require the following tools:
• Phillips screwdriver
• Plastic scribe
Identifier GUID-6F1B5AF8-6CE3-4E68-B99D-25343479BAFF
Status Released
Screw list
Table 1. Screw list
Component Secured to Screw
type
Quantity Screw image
Camera Middle frame M3x5 2
Chassis fan Middle frame M3x5 3
Front bezel Middle frame Step-type
M3x5.6
4
I/O board Middle frame M3x5 4
Hard-drive
bracket
Middle frame M3x5 1
Hard drive Hard-drive
bracket
M3x3.5 3
12

Component Secured to Screw
type
Quantity Screw image
I/O panel Middle frame M3x5 9
I/O board Middle frame M3x5 4
I/O bracket Middle frame M3x5 9
Inner frame Middle frame M3x5 9
Media-card
reader
Middle frame M3x5 2
Microphones (4) Middle frame M2x4 4
Middle frame Display panel M3x5 11
Power-button
board
Middle frame M2x3.5 2
Side I/O-board Middle frame M3x5 2
Side I/O-board
bracket
Middle frame M3x5 2
Solid-state drive System board M2x3.5 1
Speakers (2) Middle frame Washer-
type
M3x4
4
13

Component Secured to Screw
type
Quantity Screw image
Stand I/O bracket M4x6 6
NOTE: The number and type of screws securing the stand to the computer
is the same for both pedestal and articulating stand options.
System-board
shield
System board M3x5 5
System board Middle frame M3x5 5
Wireless card System board M2x3.5 1
14

Identifier GUID-06588814-2678-4667-9FF9-C009F4BCE185
Status Released
After working inside your
computer
CAUTION: Leaving stray or loose screws inside your computer may severely
damage your computer.
1 Replace all screws and ensure that no stray screws remain inside your computer.
2 Connect any external devices, peripherals, or cables you removed before working
on your computer.
3 Replace any media cards, discs, or any other parts that you removed before
working on your computer.
4 Connect your computer and all attached devices to their electrical outlets.
5 Turn on your computer.
15

Identifier GUID-93575C2B-9DA3-42EF-B01E-9C841B3CE7F5
Status Released
Technical overview
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
16

Identifier GUID-2BDC1A6D-A7A6-4E25-BED3-DC959CF150E0
Status Released
Inside view of your computer
Figure 1. : Inside view of your computer
1Microphone 2 Processor heat-sink
3 Chassis fan 4 Hard drive
5 Middle frame 6 Power-button board
7 Speaker 8 I/O bracket
9 Camera assembly 10 Solid-state drive
11 Coin-cell assembly 12 Wireless card
13 Side I/O-board 14 Media-card reader
15 Memory module 16 System board
17

Identifier GUID-71169ED4-E40D-426D-A039-FED8DF441CC4
Status Released
System board components
1 fan-power cable (FAN_SYS)
connector
2 display cable (MB-DISPC)
connector
3 power-button board cable (0SDC1)
connector
4 power cable (MB-DCPWR)
connector
5 hard-drive data cable (SATA0)
connector
6 SSD-card connector (M.2)
7 rear I/O cable (RUSBC1) connector 8 hard-drive power cable
(SATA_PWR1) connector
9 USB Type-C cable (MB-TYPEC1)
connector
10 rear I/O-board power cable
(RPWRC1) connector
11 rear I/O-board cable (LAUOC1)
connector
12 touch-screen cable (TOUCH1)
connector
18

13 speaker cable (SPEAKER)
connector
14 media-card reader cable (SDRDC1)
connector
15 side I/O-board cable (MB-SUSBC)
connector
16 wireless card connector
17 camera cable (WEBCAM) connector 18 microphones cable (DMIC1)
connector
19 memory modules (2) connectors 20 system board jumper
21 processor socket
19

Identifier GUID-AE7F608F-4CAF-464A-B977-4C4D9BB3963A
Status Released
Removing the back cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Identifier GUID-A9010B6F-79A8-45BF-B456-32309E53A1CD
Status Released
Procedure
1 Loosen the two captive screws that secure the back cover to the inner frame.
20
