The Dell Networking W-3000 Controller Series is a
family of three full-featured controllers that addresses
a wide range of wireless and wired network mobility,
security and remote networking requirements for
medium and large regional oces.
The W-3000 Series is easily installed without
disrupting the existing wired network and supports
up to 8,192 users and performs stateful firewall policy
enforcement at speeds up to 4 Gbps.
The W-3000 Series acts as the head-end portion
of Dell’s wireless LAN architecture, which uses
centralized controllers in the data center to manage
complex and processing-intensive management and
security functions. Edge services are virtualized and
implemented in cost-eective W-Series access points
(APs) at the network edge, which move user trac
to data center controllers through secure IP tunnels
over a public or private transport network.
Powered by W-Series OS Controller Software, the
W-3000 Series comes standard with advanced
authentication, encryption, wireless radio
management, secure enterprise wireless mesh
and Layer 2/Layer 3 networking features. Optional
software modules deliver additional functionality,
including Policy Enforcement Firewall (PEF),
Wireless Intrusion Prevention (WIP) and advanced
cryptography module.
Controller clustering and centralized management
allow large enterprise networks with multiple
controllers to be managed and maintained with
minimal sta overhead. A designated master
controller can manage multiple local controllers
while the W-Series AirWave Wireless Management
Suite (AWMS) provides unprecedented control for
the IT sta through real-time monitoring, historical
reporting and troubleshooting.
Scalable, easy to deploy
wireless controller with
centralized management
for enterprise mobility.
Supports up to 128
access points.
Dell Networking W-3000
Controller Series

SS713_Dell_Networking_W_3000_Control_Series_042313
Specifications
Controller performance and capacity
1Capacity determined by AP, PEF, and WIP software licenses
2Capacity determined by PEF software licenses
Interfaces
Dual-personality ports:
• 4x Gigabit Ethernet (10/100/1000BASE-T or 1000BASE-X SFP)
• Console (RS-232) RJ-45
Power specifications
W-3200:
• AC input voltage: 90-264 V, Universal Input
• AC input current: 1.5 A
• AC input frequency: 47-63 Hz
• Maximum power consumption: 35 watts
W-3400:
• AC input voltage: 90-264 V, Universal Input
• AC input current : 2.2 A
• AC input frequency: 47-63 Hz
• Maximum power consumption: 45 watts
W-3600:
• AC input voltage: 90-264 V, Universal Input
• AC input current : 2.2 A
• AC input frequency: 47-63 Hz
• Maximum power consumption: 60 watts
Mechanical
• 44 mm x 351 mm x 297 mm (1.75” x 13.8” x 11.7”)
• Weight (W-3200): 3.2 kgs (7.1 lbs)
• Weight (W-3400/W-3600): 3.4 kgs (7.4 lbs)
Regulatory and safety compliance
• FCC Part 15 Class B
• EN 55022 Class B
• EN 55024
• IEC/EN 60950
• CE Marking
• cTUVus Marked
• CB Scheme Certified
For a complete list of Country Specific Regulations please speak
with your Dell Representative.
Environmental
• Operating:
- Temp: 0° to 40° C (32° to 104° F)
- Humidity: 5 to 95% non-condensing
• Storage:
- Temp: -40° to 70° C (-40° to 158° F)
Warranty
• Hardware: One year
• Software: One year
Minimum OS version
• 5.0.2.0
Certifications/regulatory
• FIPS/TAA certified SKU available
Feature 3200 3400 3600
LAN-connected APs (max)132 64 128
Remote Access Points 128 256 512
Users (max)22,048 4,096 8,192
MAC addresses 64,000 64,000 64,000
Active firewall sessions 128,000 128,000 128,000
Concurrent IPSec tunnels 2,048 4,096 4,096
Firewall throughput 3 Gbps 4 Gbps 4 Gbps
LAN-connected APs (max)132 64 128
Remote Access Points (max)1128 256 512
Wired Access Points (max)18 16 32
Users (max)22,048 4,096 8,192
MAC addresses 64,000 64,000 64,000
VLAN IP interfaces 128 256 512
Number of IPv4 unicast
routes 2,048 2,048 2,048
Active firewall sessions 128,000 128,000 128,000
Concurrent IPSec tunnels
(max) 2048 4096 4096
System BSSIDs 512 4096 8192
Firewall throughput 3 Gbps 4 Gbps 4 Gbps
Encrypted throughput
(3DES, AESCB256)
1.6
Gbps 4 Gbps 8 Gbps
Encrypted throughput
(AES-CCM)
0.8
Gbps 2 Gbps 4 Gbps
Learn more at Dell.com/Wireless
© 2012 Dell Networking W-series AirWave®, Dell Networking W-series, Dell Networking W-series Mobility Management System®, and other registered marks are trademarks of Dell, Inc.
Dell™, and the DELL™logo. are trademarks of Dell Inc. Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
All rights reserved. Specifications are subject to change without notice.
Originated in the USA. Any other trademarks appearing in this manual are the property of their respective companies.
Ordering information
Part number Description
W-3200
W-3400
W-3600
W-3000 Series Branch Oce Controller,
Unrestricted Regulatory Domain
W-3200-US
W-3400-US
W-3600-US
W-3000 Series-US Branch Oce Con-
troller, Restricted Regulatory Domain
– US
W-3200-F1
W-3400-F1
W-3600-F1
W-3000 Series Branch Oce Controller,
Unrestricted Regulatory Domain, FIPS/
TAA Compliant
W-3200-US-F1
W-3400-US-F1
W-3600-US-F1
W-3000 Series-US Branch Oce Control-
ler, Restricted
Regulatory Domain – US. FIPS/TAA Compliant
SFP-TX W-SFP-1000Base-T, RJ45
SFP-SX W- SFP - 1000Base-SX, LC connector
SFP-LX W-SFP – 1000Base-LX, LC connector
