Dell QMD8262-k User manual

CU0354602-00 L Third party information brought to
you courtesy of Dell.
User’s Guide
Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k

ii CU0354602-00 L
User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
This document is provided for informational purposes only and may contain errors. QLogic reserves the right, without
notice, to make changes to this document or in product design or specifications. QLogic disclaims any warranty of any
kind, expressed or implied, and does not guarantee that any results or performance described in the document will be
achieved by you. All statements regarding QLogic's future direction and intent are subject to change or withdrawal
without notice and represent goals and objectives only.
Document Revision History
Revision A, September 2011
Revision B, March 30, 2012
Revision C, July 18, 2012
Revision D, August 30, 2012
Revision E, November 20, 2012
Revision F, April 8, 2013
Revision G, September 6, 2013
Revision H, June 9, 2014
Revision J, January 22, 2015
Revision K, June 24, 2015
Revision L, March 24, 2016
Changes Sections Affected
Updated disclaimer information. All
Updated QLogic header logos. All
Removed references to QME8242-k All
Added reference to Red Hat Enterprise Linux
(RHEL) 7.2 and SUSE Linux Enterprise Server 11
SP4
“Supported Operating Systems” on page xv

iii CU0354602-00 L
Table of Contents
Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
User’s Guide Content. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Related Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xii
Functionality and Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Functional Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Supported Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
VMware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
1 Hardware Installation
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Hardware and Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Pre-Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installing the Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting to the Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Driver Installation and Configuration
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Windows Driver Installation and Configuration. . . . . . . . . . . . . . . . . . . . . . . 5
Running the DUP in the GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Running the DUP from the Command Line. . . . . . . . . . . . . . . . . . . . . 12
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Linux Driver Installation and Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing the Linux NIC Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
iv CU0354602-00 L
Installing the Linux iSCSI Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Building the iSCSI Adapter Driver SLES 11 SP4 . . . . . . . . . . . . 16
Building the iSCSI Adapter Driver for RHEL 6.5
and SLES 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Building the iSCSI Adapter Driver for RHEL 6.5
and SLES 11 SP3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installing the Linux FCoE Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Building the Driver for RHEL 6.5 Linux. . . . . . . . . . . . . . . . . . . . 23
Building the Driver for SLES 11 SP4 Linux. . . . . . . . . . . . . . . . . 24
Building the Driver for SLES 12 Linux . . . . . . . . . . . . . . . . . . . . 25
Building the Driver for SLES 11 SP3 Linux. . . . . . . . . . . . . . . . . 26
VMware Driver Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . 28
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installing the ESXi 5.xNIC Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Updating an Existing Driver or Installing a New Driver for
an Existing ESXi Installation with esxcli (ESXi 5.xOnly) . . . . . . 29
Verifying the Version of the Installed Driver (ESXi 5.xOnly) . . . 29
Installing the ESXi 5.xiSCSI Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Updating an Existing Driver or Installing a New Driver for
an Existing ESXi Installation with esxcli (ESXi 5.xOnly) . . . . . . 30
Verifying the Version of the Installed Driver (ESXi 5.xOnly) . . . 31
Installing the ESXi 5.xFCoE Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Updating an Existing Driver or Installing a New Driver for
an Existing ESXi Installation with esxcli (ESXi 5.xOnly) . . . . . . 32
Verifying the Version of the Installed Driver (ESXi 5.xOnly) . . . 33
Installing the ESXi 6.x Fibre Channel Over Ethernet Driver . . . . . . . . 34
Updating an Existing Driver or Installing a New Driver for
an Existing ESXi Installation with esxcli (for ESXi 6xOnly) . . . . 34
Installing the ESXi 6.x iSCSI Driver. . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Updating an Existing Driver or Installing a New Driver for
an Existing ESXi Installation with esxcli (for ESXi 6xOnly) . . . . 35

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
v CU0354602-00 L
Installing the QConvergeConsole VMware vCenter
Server Plug-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 36
QConvergeConsole VMware vCenter Server
Plug-in Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Plug-in Unregistration from a Manual Install. . . . . . . . . . . . . . . . 41
Enabling and Disabling the Plug-in. . . . . . . . . . . . . . . . . . . . . . . 42
Uninstalling the QConvergeConsole VMware vCenter
Server Plug-in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Installing the QLogic Adapter CIM Provider . . . . . . . . . . . . . . . . 44
Uninstalling the QLogic Adapter CIM Provider . . . . . . . . . . . . . . 47
Installing the vSphere Web Client Plug-in . . . . . . . . . . . . . . . . . . . . . . 48
Uninstalling the vSphere Web Client Plug-in . . . . . . . . . . . . . . . 49
3 Adapter Management Applications
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
General Management with QConvergeConsole. . . . . . . . . . . . . . . . . . . . . . 51
Configuring the NIC Driver with QConvergeConsole . . . . . . . . . . . . . 51
Configuring iSCSI with QConvergeConsole . . . . . . . . . . . . . . . . . . . . 51
Configuring FCoE with QConvergeConsole . . . . . . . . . . . . . . . . . . . . 51
Configuring iSCSI Offload with QConvergeConsole . . . . . . . . . . . . . . 52
Adapter-Level iSCSI Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Displaying Adapter-Level iSCSI Parameters . . . . . . . . . . . . . . . 52
Modifying Adapter-Level iSCSI Parameters . . . . . . . . . . . . . . . . 53
Port-Level iSCSI Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Displaying Port-Level iSCSI Parameters . . . . . . . . . . . . . . . . . . 53
Modifying Port-Level iSCSI Parameters . . . . . . . . . . . . . . . . . . . 57
Summary of Target Sessions . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Target Session-Level iSCSI Negotiated Parameters . . . . . . . . . 60
Target Session-Level Persistent iSCSI Parameters . . . . . . . . . . 61
Configuring iSCSI Initiators with QConvergeConsole . . . . . . . . . . . . . 65
Configuring the Windows iSCSI Initiator. . . . . . . . . . . . . . . . . . . 65
Configuring the Linux iSCSI Initiator. . . . . . . . . . . . . . . . . . . . . . 66
Configuring the ESX iSCSI Initiator . . . . . . . . . . . . . . . . . . . . . . 67
Enabling CHAP Authentication with QConvergeConsole . . . . . . . . . . 68
Configuring CHAP with QConvergeConsole CLI . . . . . . . . . . . . 69
Linking to a CHAP Target . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Windows Management Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
vi CU0354602-00 L
Windows NIC Driver Management Applications . . . . . . . . . . . . . . . . . 73
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Viewing and Changing Adapter Properties. . . . . . . . . . . . . . . . . 73
Windows Teaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Teaming Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Using the CLI for Teaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Using the Team Management GUI . . . . . . . . . . . . . . . . . . . . . . . 80
Teaming Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Viewing Teaming Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Windows VLAN Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
VLAN Properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Using the CLI for VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Using the GUI for VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
User Diagnostics for Windows NIC Driver
Management Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Running Windows User Diagnostics. . . . . . . . . . . . . . . . . . . . . . 96
Windows Diagnostic Test Descriptions. . . . . . . . . . . . . . . . . . . . 101
Windows Diagnostic Test Messages . . . . . . . . . . . . . . . . . . . . . 103
Linux Management Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Linux NIC Driver Management Applications . . . . . . . . . . . . . . . . . . . . 106
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Viewing and Changing Adapter Properties on Linux . . . . . . . . . 106
User Diagnostics for Linux NIC Driver Management Applications . . . 108
Running Linux User Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . 109
Linux Diagnostic Test Descriptions. . . . . . . . . . . . . . . . . . . . . . . 111
Linux Diagnostic Test Messages . . . . . . . . . . . . . . . . . . . . . . . . 111
VMware Management Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
VMware NIC Driver Management Applications . . . . . . . . . . . . . . . . . . 111
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Using Switch Independent Partitioning Under ESX . . . . . . . . . . 112
User Diagnostics for VMware NIC Driver Management
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Ethtool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Unified Extensible Firmware Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
UEFI Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Supported Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Fibre Channel Adapter Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 114
Updating the UEFI (EfiUtilx64) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
vii CU0354602-00 L
Configuring iSCSI over DCBX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Configuring the iSCSI VLAN on the QLogic Adapter. . . . . . . . . . . . . . 116
Configuring the Switch for iSCSI over DCBX . . . . . . . . . . . . . . . . . . . 117
Verify the Version of the Switch Firmware . . . . . . . . . . . . . . . . . 117
Create and Configure the iSCSI VLAN on the Switch . . . . . . . . 117
Create and Configure the CEE Map for iSCSI Traffic
Bandwidth and PFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Configure LLDP/DCBX for the iSCSI TLV . . . . . . . . . . . . . . . . . 118
Configure the CEE Port’s iSCSI Traffic Class. . . . . . . . . . . . . . . 119
Verifying Adapter/Switch Status for iSCSI Login, Traffic,
and PFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Interoperation of Bandwidth Settings for DCBX and
Switch Independent Partitioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Choosing DCBX or Switch Independent Partitioning. . . . . . . . . . . . . . 121
4 Switch Independent Partitioning
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Switch Independent Partitioning Setup Requirements. . . . . . . . . . . . . . . . . 124
Hardware Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Switch Independent Partitioning Configuration . . . . . . . . . . . . . . . . . . . . . . 126
What Is Switch Independent Partitioning?. . . . . . . . . . . . . . . . . . . . . . 126
Switch Independent Partitioning Options. . . . . . . . . . . . . . . . . . . . . . . 127
Personality Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Quality of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
eSwitch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Configuration Management Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Dell System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
QLogic OptionROM at POST . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
QConvergeConsole GUI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
QConvergeConsole CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Windows Device Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
CIM Provider and QConvergeConsole VMware vCenter
Server Plug-in for VMware ESX/ESXi . . . . . . . . . . . . . . . . . . . . 135
Switch Independent Partitioning Setup and Management Options . . . . . . . 137
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Dell System Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
QLogic OptionROM at POST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
viii CU0354602-00 L
QConvergeConsole GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Configure NIC Partitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Set Up QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
View eSwitch Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
QConvergeConsole CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Windows Device Manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Configure Switch Independent Partitioning . . . . . . . . . . . . . . . . 160
Change Personalities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Manage Bandwidth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
View eSwitch Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
CIM Provider and vCenter Server Plug-in for VMware ESX/ESXi. . . . 168
Switch Independent Partitioning Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Switch Independent Partitioning Configuration Parameters and
Setup Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
5 Boot Configuration
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Boot from SAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
General Boot from SAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Windows Boot from SAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Creating a Driver Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Windows 2008 Boot From SAN . . . . . . . . . . . . . . . . . . . . . . . . . 178
Linux Boot from SAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Red Hat Enterprise Linux Boot from SAN . . . . . . . . . . . . . . . . . 178
SUSE Linux Enterprise Server (Novell) Boot from SAN. . . . . . . 179
ESX Boot from SAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Dell System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Accessing Dell System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Main Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
Device and Firmware Image Information . . . . . . . . . . . . . . . . . . 184
NIC Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
iSCSI Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
FCoE Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
NIC Partitioning (Switch Independent Partitioning)
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
PXE Boot Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Configuring PXE Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
iSCSI Configuration Using Fast!UTIL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
ix CU0354602-00 L
Accessing Fast!UTIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Configuring Host Adapter Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Configuring iSCSI Boot Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Boot Device Primary and Alternate . . . . . . . . . . . . . . . . . . . . . . 203
Adapter Boot Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 203
Primary and Alternate Boot Device Settings . . . . . . . . . . . . . . . 204
Configuring the iSCSI Boot Parameters . . . . . . . . . . . . . . . . . . . 204
Configuring QLogic iSCSI Boot . . . . . . . . . . . . . . . . . . . . . . . . . 207
Booting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
iBFT Boot Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Enabling iBFT Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 214
Booting to a Target Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
DHCP Boot Setup (iSCSI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Configuring DHCP iSCSI Boot for IPv4. . . . . . . . . . . . . . . . . . . . . . . . 219
DHCP Option 17, Root Path. . . . . . . . . . . . . . . . . . . . . . . . . . . . 220
DHCP Option 43 (Adding Vendor Options) . . . . . . . . . . . . . . . . 220
A Troubleshooting
Diagnosing Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 222
NIC Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 223
iSCSI Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 224
FCoE Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
ESX Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
B Specifications
QMD8262-k Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Standards Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Environmental Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
QLE8262 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Standards Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Environmental Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
QME8262-k Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233

User’s Guide—Converged Network Adapter
QMD8262-k, QLE8262, QME8262-k
x CU0354602-00 L
Standards Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
Environmental Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 233
C QConvergeConsole GUI
Introduction to QConvergeConsole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Downloading QConvergeConsole Documentation. . . . . . . . . . . . . . . . . . . . 236
Downloading and Installing Management Agents . . . . . . . . . . . . . . . . . . . . 236
Installing the Agents from the QLogic Web Site . . . . . . . . . . . . . . . . . 237
Installing the Agents Using the Built-in Agent Installer . . . . . . . . . . . . 237
Installing the QConvergeConsole GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 238
Installing QConvergeConsole in a Windows Environment . . . . . . . . . 238
Installing QConvergeConsole in a Linux Environment . . . . . . . . . . . . 239
Installing QConvergeConsole in Silent Mode . . . . . . . . . . . . . . . . . . . 240
What Is in the QConvergeConsole Help System . . . . . . . . . . . . . . . . . . . . . 241
D Regulatory Information
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Regulatory and Compliance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Laser Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
FDA Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Agency Certification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
EMI and EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
KCC: Class A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Product Safety Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245

xi CU0354602-00 L
Introduction
Overview
This user’s guide covers the following products:
QLogic QMD8262-k blade network daughter card
QLogic QLE8262 monolithic server standup card
QLogic QME8262-k blade mezzanine card
This guide provides technical information about the adapters, including how to
install and configure the adapter, as well as detailed descriptions of the adapter’s
various uses and functions.
Intended Audience
This guide is intended for system administrators and other technical staff
members responsible for configuring and managing adapters installed on Dell®
PowerEdge®servers in Windows®, Linux®, or VMware®environments.
User’s Guide Content
The QLogic QMD8262-k/QLE8262/QME8262-k User’s Guide includes the
following sections:
Hardware Installation covers the hardware and software requirements,
safety precautions, a pre-installation checklist, and adapter installation.
Driver Installation and Configuration covers the installation of the three
drivers—NIC, iSCSI, and Fibre Channel over Ethernet (FCoE)—included
with the adapter on Windows, Linux, and VMware operating systems.
Adapter Management Applications covers how to use QConvergeConsole®,
as well as operating-system-specific applications for Windows, Linux, and
VMware.
NOTE
Throughout this document, the term adapter refers to any or all of these
products.

Introduction
Related Materials
xii CU0354602-00 L
Switch Independent Partitioning covers how to configure Switch
Independent Partitioning using utilities such as QConvergeConsole, as well
as configuring iSCSI over data center bridging exchange (DCBX) using a
Brocade®Series 8000 FCoE switch and a QLogic iSCSI Host Bus Adapter.
Boot Configuration provides information on booting from SAN, pre-execution
environment (PXE) boot setup, and iSCSI boot configuration using
Fast!UTIL, iSCSI Boot Firmware Table (iBFT), DHCP, and
QConvergeConsole.
Troubleshooting provides troubleshooting flowcharts of steps for diagnosing
adapter problems specific to NIC, iSCSI, FCoE, and ESX®.
Specifications defines the physical characteristics and power requirements,
and lists supported standards, interface specifications, and environmental
specifications.
QConvergeConsole GUI provides an overview of the QConvergeConsole
Web management interface.
Regulatory Information provides warranty, regulatory, and compliance
information.
Related Materials
For additional information, refer to the following:
QConvergeConsole GUI Help System, available through the
QConvergeConsole GUI, provides help topics on configuring and managing
host servers and adapters using the QConvergeConsole GUI.
QConvergeConsole GUI Installation Guide contains instructions for installing
and starting the QConvergeConsole GUI.
QConvergeConsole CLI User’s Guide provides reference material on using
the QConvergeConsole CLI.
QLogic QConvergeConsole Plug-ins for vSphere User’s Guide provides
reference material on using the QConvergeConsole VMware vCenter Server
Plug-in and the QConvergeConsole VMware vSphere Web Client Plug-in.
NOTE
To access QLogic documents online, go to www.qlogic.com and click
Downloads.

Introduction
Functionality and Features
xiii CU0354602-00 L
Functionality and Features
This section provides the following information:
Functional Description
Features
Supported Operating Systems
Functional Description
Functional descriptions for the adapters are as follows:
QMD8262-k: This a network daughter card with FCoE and iSCSI offload for
the blade server environment.
QLE8262:
This is a standard form-factor adapter with FCoE and iSCSI offload
for the rack and tower server environment.
QME8262-k: This is a mezzanine card with FCoE and iSCSI offload for the
blade server environment.
Features
The adapters provide the following features:
Switch Independent Partitioning
Message signaled interrupts (MSI-X)
Device management for power and SAN
Multi-boot capability including:
PXE
iSCSI
Fibre Channel
Unified extensible firmware interface (UEFI)
PCIe®2.0 x8
User diagnostics that can be run from the CLI and the GUI
Ethernet functions include:
2x10 gigabit Ethernet (GbE) with KR (copper backplane) (does not
apply to QLE8262)
Priority and virtual LAN (VLAN) tagging
Jumbo frames up to 9618 bytes
Enhanced Ethernet functions include:
Priority-based flow control
Enhanced transmission selection
Advanced teaming
VLAN configuration and management
Preservation of teaming and VLAN configuration information during
driver upgrade

Introduction
Functionality and Features
xiv CU0354602-00 L
Advanced stateless offload features include:
IP, TCP, and user datagram protocol (UDP) checksums
Large segment offload (LSO)
Large receive offload (LRO)
Stateful offload features include:
iSCSI offload
Fibre Channel and FCoE offload
Advanced management features for Converged Network Adapters and Fibre
Channel adapters, including QConvergeConsole (GUI and CLI)
Interrupt management and scalability features including:
Receive side scaling (RSS)
Interrupt moderation
Flow control
Locally administered address (LAA)
Enhanced optimization with MSI, MSI-X, and NetQueue

Introduction
Functionality and Features
xv CU0354602-00 L
Supported Operating Systems
The adapter supports the following operating systems. To view the most complete
and current list, refer to the product release notes.
Windows
Windows Server®2012 R2
Windows Server 2012
Windows Server 2008 R2 SP1
Windows Server 2008 SP2 x64
Windows Server 2008 SP2 x32
Linux
Red Hat®Enterprise Linux (RHEL®) 7.2
Red Hat Enterprise Linux (RHEL) 7.0
Red Hat Enterprise Linux (RHEL) 6.5
SUSE®Linux Enterprise Server 12
SUSE Linux Enterprise Server 11 SP3
SUSE Linux Enterprise Server 11 SP4
VMware
vSphere®: VMwareESXi 6.0
vSphere: VMwareESXi 5.5 U2
vSphere: VMwareESXi 5.1 U3
NOTE
For the most current versions of the OS and drivers supported by the
adapter, refer to the release notes. The release notes are supplied in the
release.txt file.

1 CU0354602-00 L
1Hardware Installation
Overview
This section provides the hardware and software requirements, safety
precautions, a pre-installation checklist, and a procedure for installing the adapter.
Hardware and Software Requirements
Before you install the adapter, verify that your system meets the following
hardware and software requirements.
Hardware
For port and slot assignments for the QMD8262-k or QME8262-k
adapter, refer to the blade and M1000e chassis diagram in the Dell
PowerEdge M1000e Systems Configuration Guide.
For QLE8262 adapter port and slot assignments, refer to the
“Expansion Cards” section of the Hardware Owner’s Manual for your
Dell PowerEdge server.
Software: For information on the supported operating systems, firmware
versions, adapter drivers, and utilities, refer to the product release notes.
Safety Precautions
Remove any metallic objects or jewelry from your hands and wrists.
Make sure to use only insulated or nonconducting tools.
CAUTION
!
The adapter is being installed in a system that operates with voltages that
can be lethal. Before you open the case of your system, observe the
following precautions to protect yourself and to prevent damage to the
system components.

1–Hardware Installation
Pre-Installation Checklist
2 CU0354602-00 L
Before you touch internal components, verify that the system is powered
OFF and is unplugged.
Install or remove adapters in a static-free environment. The use of a properly
grounded wrist strap or other personal antistatic devices and an antistatic
mat is strongly recommended.
Pre-Installation Checklist
1. Verify that your system meets the hardware and software requirements
listed in “Hardware and Software Requirements” on page 1.
2. Verify that your system is using the latest BIOS.
3. Check the adapter for visible signs of damage. Never attempt to install a
damaged adapter.
Installing the Adapter
Follow the instructions for your adapter.
QMD8262-k, QME8262-k
Refer to the “I/O Module Mezzanine Cards” and “Guidelines for Installing I/O
Modules” sections of the Dell PowerEdge Modular Systems Hardware Owner’s
Manual:
ftp://ftp.dell.com/Manuals/all-products/esuprt_ser_stor_net/esuprt_poweredge/po
weredge-m610x_Owner%27s%20Manual_en-us.pdf
QLE8262
To install the QLE8262 adapter, follow these steps:
1. Power off the computer and all attached devices such as monitors, printers,
and external components.
2. Disconnect the power cable.
3. Remove the computer cover and find an empty PCIe x8 bus slot.
4. Pull out the slot cover (if any).
5. Grasp the adapter by the top edge and seat it firmly into the appropriate slot.
6. Refasten the adapter’s retaining bracket.
NOTE
If you acquired the adapter software on a disk or from the Dell support
Web site (http://support.dell.com), verify the path to the adapter driver
files.

1–Hardware Installation
Connecting to the Network
3 CU0354602-00 L
7. Close the computer cover.
8. Plug the Ethernet cable into the adapter.
9. Plug in the power cable and turn on the computer.
For more detailed information, refer to the Hardware Owner’s Manual for your Dell
PowerEdge server.
Connecting to the Network
Follow the instructions for your adapter.
QMD8262-k, QME8262-k
Refer to the “Guidelines for Installing I/O Modules” section of the Dell PowerEdge
Modular Systems Hardware Owner’s Manual:
ftp://ftp.dell.com/Manuals/all-products/esuprt_ser_stor_net/esuprt_poweredge/po
weredge-m610x_Owner%27s%20Manual_en-us.pdf
QLE8262
Refer to the Hardware Owner’s Manual for your Dell PowerEdge server.

4 CU0354602-00 L
2Driver Installation and
Configuration
Overview
This section provides links to the following information about the three
drivers—NIC, iSCSI, and FCoE—included with the adapter:
Windows Driver Installation and Configuration
Linux Driver Installation and Configuration
VMware Driver Installation and Configuration
NOTE
If you need to update the Flash memory of multiple adapters simultaneously:
For the QConvergeConsole GUI, refer to the “Update the Flash Using
the Flash Update Wizard” topic in the QConvergeConsole Help System.
For the QConvergeConsole CLI, use the -flashsupport command to
update the Flash memory for all cards supported by the specified file (for
example, qaucli -pr nic -flashsupport -i ALL -a
p3p11179.bin).
NOTE
When you disable the firmware (for example, during a firmware dump or
during a firmware update) in Windows or Linux with a QConvergeConsole
agent, multiple application messages are generated. These messages are
generated because the application cannot communicate with the adapter
while the firmware is disabled. After the firmware is re-enabled, the errors
will go away.

2–Driver Installation and Configuration
Windows Driver Installation and Configuration
5 CU0354602-00 L
Windows Driver Installation and Configuration
A software or driver Dell update package (DUP) can be run in two ways:
Running the DUP in the GUI
Running the DUP from the Command Line
Running the DUP in the GUI
To run the DUP in the GUI:
1. Double-click the icon representing the DUP file.
The Update Package window appears, as shown in Figure 2-1.
Figure 2-1. Update Package Window
NOTE
The actual file name of the DUP varies.
