Dell Premium Remote Control User manual

Contents:Dell™PremiumRemoteControlUser'sGuide
The information below is provided by the supplier of the referenced device without independent verification by Dell and is subject to the restrictions and
disclaimers noted below.
Information in this document is subject to change without notice.
©2006 Dell, Inc. All rights reserved.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.
Gyration and "Motion by Gyration" are registered trademarks of Gyration, Inc. and disclaims any proprietary interest in trademarks and trade names other than
its own. Microsoft and Windows are registered trademarks of Microsoft Corporation and disclaims any proprietary interest in trademarks and trade names other
than its own.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Restrictions and Disclaimers
The information contained in this document, including all instructions, cautions, and regulatory approvals and certifications, is provided by the supplier and has
not been independently verified or tested by Dell. Dell cannot be responsible for damage caused as a result of either following or failing to follow these
instructions.
All statements or claims regarding the properties, capabilities, speeds or qualifications of the part referenced in this document are made by the supplier and
not by Dell. Dell specifically disclaims knowledge of the accuracy, completeness or substantiation for any such statements. All questions or comments relating
to such statements or claims should be directed to the supplier.
Export Regulations
Customer acknowledges that these products, which may include technology and software, are subject to the customs and export control laws and regulations
of the United States (U.S.) and may also be subject to the customs and export laws and regulations of the country in which the products are manufactured
and/or received. Customer agrees to abide by those laws and regulations. Further, under U.S. law, the products may not be sold, leased or otherwise
transferred to restricted end-users or to restricted countries. In addition, the products may not be sold, leased or otherwise transferred to, or utilized by an
end-user engaged in activities related to weapons of mass destruction, including without limitation, activities related to the design, development, production
or use of nuclear weapons, materials, or facilities, missiles or the support of missile projects, and chemical or biological weapons.
Initial release: June 2006
Setup
Introduction to the Dell Premium Remote Control
Cursor Control Using the Dell Premium Remote Control
Navigating the Dell Premium Remote Control LCD Interface
Programming the Dell Premium Remote Control for TV Functionality
Controlling the Television with the Dell Premium Remote Control
Troubleshooting
Specifications
Regulatory
Safety Information

Back to Contents Page
Introduction:TheDell™PremiumRemoteControl
Overview
Button Overview
LCD Software Service Application and Tray Icon
Closed Lid Operation

Overview
The Dell Premium Remote Control is a 2-in-1 (InfraRed + Radio Frequency) device that functions both as a Windows XP Media Center Edition remote control
and as a standard IR (InfraRed) Television remote control.
The Dell Premium Remote Control contains the following features:
1. RF (Radio Frequency) Control of your Windows XP Media Center Edition computer (no line of sight required).
2. Integrated LCD screen for navigation and playback of your Windows Media Player and Windows XP Media Center Edition audio files.
3. Closed Lid Operation support for portable Windows XP Media Center Edition platforms.
4. In-air cursor control via patented "Motion by Gyration" embedded micro-gyroscope.
5. IR control of your Television via Universal IR database and IR Learning capability.
Button Overview
NOTE: The RF transceiver has a range of 30 feet in typical environments and may exceed that range under certain conditions.
NOTE: The Universal IR database supports both the Direct Entry and Automatic Search Code methods for programming your remote control.
Dell Premium Remote Control Button Descriptions
Remote Control
Button Cluster
Function
LCD Button and Display
Display and navigation of Windows Media Player/
Windows Media Center audio library.
Power and Mode Selection (PC, TV),
RF Status LED
Backlight, TV Input, "CONNECT"
Powers on/off selected device (PC, TV).
Selects operational mode (PC, TV, "LCD Button").
Backlighting toggle.
TV Input selection (PC mode only).
Connects the remote control to the computer.
NOTE: The Power button does not shut
down the computer. It places the system in
the Standby power mode.
Media Transport Control
Standard playback control:
(STOP, RECORD, PAUSE, PLAY,
REWIND, FAST FORWARD,
SKIP BACKWARD, SKIP FORWARD).
Menu Navigation
Standard navigational control buttons:
(up, down, left, right, OK).
BACK (Media Center and LCD Navigation)
MORE (Media Center)
"Motion by Gyration"
Cursor Control
Control for in-
air cursor. Outer buttons function as
standard left and right mouse buttons.
eHome
AV Control
Standard AV Volume up/down, Channel up/down,
Media Center eHome launch, and Mute.
Media Center Shortcuts
Shortcuts buttons for Media Center:
(Recorded-TV, Guide, Live TV, DVD Menu).

LCD Software Service Application and Tray Icon
The LCD Software Service Application controls the LCD screen interface to allow for navigation and playback of your Windows Media Player and Windows Media
Center audio files. The LCD Software Service Application has been designed to monitor the Windows Media Player audio database.
The Dell Premium Remote Control has an associated tray icon in the Windows Taskbar (Notification area). The tray icon can be used to start/stop/restart the
LCD Software Service Application that controls the LCD screen interface (depending on the current status). A pop-up menu can be accessed by clicking on the
tray icon.
Closed-Lid Operation
The Dell Premium Remote Control can also function when a portable computer's lid is closed. To enable closed-lid operation, perform the following steps:
1. Click Start, click Control Panel, and then click Performance and Maintenance.
2. Under or Pick a Control Panel Icon, click Power Options.
3. Click the Advanced tab.
4. Under When I close the lid on my portable computer, select Do Nothing.
5. Click OK.
Please read all restrictions and disclaimers.
Back to Contents Page
Numeric Keypad
Standard 0-9 keys with alpha characters,
space, *, #, CLEAR, and ENTER
Teletext
Red, Green, Teletext on/off, Yellow, Blue
NOTE: European version only.
NOTE: The Dell Premium Remote Control and LCD screen interface are intended to operate/interact with Windows Media Player and Windows XP Media
Center Edition music libraries only. While other applications may operate correctly by using the Dell Premium Remote Control, they are not officially
supported and have not been tested either by Gyration Inc or Dell Inc. Any other application interoperability other than the ones listed above is
coincidental and not directly intended by either Gyration Inc. or Dell Inc.
Tray Icon Status Descriptions
Icon Status Display
Description
(green)
LCD Software Service Application is
running.
(red)
LCD Software Service Application is
not running.
NOTE: The LCD Software Service Application is set to always run upon system boot.
lDuring system boot, the tray icon will initially display the (red) icon, then after it has scanned the Windows Media Player audio library the
(green) icon will display. The amount of time before the (green) icon is displayed will vary, depending on the size of your audio library.
NOTE: All standard Media Center remote control functions operate regardless of the status of the LCD Software Service Application.
NOTE: This setting will keep the portable computer powered on and operating while the lid is closed, and will eventually drain the battery if not plugged
in to AC power.

Back to Contents Page
LCDNavigation:NavigatingtheDell™PremiumRemoteControlLCDInterface
To control your music with the Dell Premium Remote Control, perform the following steps:
1. Press the button located beneath the LCD screen.

2. The top-level main menu displays the following choices:
¡Playlists
nThis menu allows you to view a listing of the playlists in your Windows Media Player library (default and user created).
¡Albums
nThis menu allows you to view the albums in your Windows Media Player library in alphabetical order.
¡Artists
nThis menu allows you to view the artists in your Windows Media Player library in alphabetical order.
¡Genres
nThis menu allows you to view the genres in your Windows Media Player library in alphabetical order.
¡Now Playing
nThismenuwilldisplaytheinformationonthesongthatiscurrentlyplaying(ifapplicable).
nIf no audio is currently playing, the screen will display "No song currently playing."
¡Options
nThismenuallowsyoutochangetheShuffleandRepeatplaybackoptions.
3. Navigate to your desired media selection using the directional keypad. Use the arrow buttons to move the menu focus and push the "OK" button to
select the highlighted menu item or select a song or album to play.
NOTE: The Dell Premium Remote Control does not require line of sight to control your music.
NOTE:TheDellPremiumRemoteControldoesnotrequirethecomputerlidtobeopentocontrolyourmusic.SeetheClosed Lid Operation section for
more details..
NOTE: Pressing the button at any time will return you to the main menu screen.
NOTE: Pressing the right arrow button is equivalent to pressing the "OK" button and it will traverse to the next level of menus. Pressing the left
arrow button or the "back" button will traverse to the previous level of menus unless the focus point is already at the top-level menu.
NOTE: Pressing the channel up or down button will scroll the LCD screen one page at a time. This is useful for navigating long lists.
NOTE: The directional keypad is mapped to operate the navigation of the LCD screen interface while the LCD screen is active. When the LCD
screen is inactive (off), these buttons are mapped back for standard Media Center navigation.
NOTE: The LCD screen can be turned off by the following methods:
lAutomatic timeout.
lPress and hold the button for 3 seconds.
lPress the eHome Media Center button.

The Now Playing screen will show on the display of the remote control:
4. Once playback has started, use the media control keypad to Play, Pause, Stop, FF, and Skip Forward and Skip Backward.
Please read all restrictions and disclaimers.
Back to Contents Page
NOTE: When the Title Bar on the LCD screen displays an asterisk (*), this in an indication that you have reached the top/bottom of the current
menu or there is nothing to select in the current menu highlighted.
NOTE: REW and REC are not supported for LCD Menu navigation.
NOTE: REW is not a supported function of Windows Media Player or Windows Media Center for audio file playback.

Back to Contents Page
Programming:SettingUptheDell™PremiumRemoteControlforTVFunctionality
Overview
Using Direct Entry
Using Automatic Code Search
Using the Learn Function

Overview
The Dell Premium Remote Control can be programmed to control your television by using Direct Entry or Automatic Code Searchmethods.Theremotecontrol
can also be further customized by Using the Learn Function.Uponcompletionofprogramming,refertotheControlling the Television with the Dell Premium
Remote Control section to use the remote control for television control.
Using Direct Entry
1. Turn on the TV you want to control.
2. Look up the brand and code number(s) for the device in the Remote Control Code List.
3. Press and hold the TV button on the Dell Premium Remote Control.
4. Enter the code from the Remote Control Code List.
5. Release the TV button, point the remote control at the device, and then press the ON/OFF button to see if the TV turns on. If it does not turn on, press
the TV button, and then ON/OFF again.
If there is no response, repeat these steps using the next code listed for your brand until the device responds to the remote control commands.
If you try all the codes for your device brand and none work, try the automatic code search method.
Using Automatic Code Search
1. Turn on the TV that you want to control.
2. Press and hold the TV button on the Dell Premium Remote Control.
3. While continuing to hold the TV button, press and hold remote control ON/OFF button until the TV button light on the remote control turns on.
4. Release both buttons.
5. Point the remote control at the TV.
6. Press and hold the PLAY button, then wait 5 seconds or until the TV button stops flashing.
The remote control is searching for the correct code to program. If, after 5 seconds, the TV you want to control turns off, release the PLAY button. If the
TV is still on, press and hold the PLAY button again to search the next set of codes. Continue in this manner until the TV turns off or you have searched
through all of the codes.
If the TV you want to control does turn off:
1. Press and release the REVERSE button, then wait 2 seconds. Repeat this step until the TV turns back on.
2. To finish, press and hold the STOP button until the TV button on the remote control turns off. The remote control will automatically exit the Automatic
Code Search mode.
Using the Learn Function
Once you have programmed your Dell Premium Remote Control using either the Using Direct Entry or Using Automatic Code Search method, you can customize
the remote control to "learn" certain functions from your original remote control(s) that may not have been embedded in the preset code. Before starting the
learning process, please consider the following tips:
lPerform the learning process in low-light areas because too much ambient light might cause interference with the infrared (IR) signals of the remote
control(s).
lUse fresh batteries in both the Dell Premium Remote Control and the source remote control.
To learn commands from a source remote control, perform the following steps:
1. Press and hold the TV button on the remote control, then press and hold the RECORD button on the remote control. Continue pressing both buttons
until the TV button light turns off, flashes, and turns off.
2. Release both buttons.
3. On the remote control, press and release the button where you want to store the new function. The component button turns off and then back on.
4. Aim the source remote control at the bottom of the Dell Premium Remote Control from no more than two inches away.
5. Press and hold the button of the source remote control that has the functionality you are recording. Continue pressing the button until the Dell Premium
Remote Control TV button light turns off and back on.
NOTE: Programming is required prior to first use.
NOTE: If all the mode buttons flash, you have either entered an invalid code or the button is not programmable.
NOTE: When all codes have been searched, the TV button flashes then turns off and the remote control exits the Automatic Code Search mode.
NOTE: If you want to stop the automatic code search without programming, press and hold CLEAR until the indicator on the remote control turns off.
NOTE: If you press an invalid button on the remote control, the device mode button flashes 4 times to alert you. Repeat step 1.

6. The Dell Premium Remote Control remains in Learning mode so you can continue adding functions to different buttons by repeating steps 3, 4, 5.
7. Press CLEAR to exit the Learning mode.
To delete a learned button function, perform the following steps:
1. Press and hold the TV button on the remote control.
2. Press and hold the CLEAR button until the TV button flashes, usually about three seconds.
3. Release both buttons. The TV button turns on indicating that the remote control is now in the Clear Learned Function mode.
4. Press and release the button where learning is to be cleared. The TV button blinks off then back on indicating that the function was cleared successfully.
5. Repeat Steps 1 through 4 for any additional learned functions you would like to clear.
6. Press the CLEAR button to return the remote control to normal operation.
To delete all learned functions at once, perform the following steps:
1. Press the TV button on the remote control to make sure the remote control is in the correct mode.
2. Press and hold the CLEAR button on the Dell Premium Remote Control.
3. PressandholdtheON/OFFbutton.TheTVbuttonlightturnsoffforthreeseconds,flashes,turnson,andthenoff.
4. Release both buttons. The TV button turns on.
5. Press the TV button to delete all learned functions. The Dell Premium Remote Control automatically exits this clearing mode.
Please read all restrictions and disclaimers.
Back to Contents Page
NOTE: If all device mode buttons flash 4 times, the function was not learned. Try again by starting with Step 1.
NOTE: If an invalid button is pressed, the TV mode button flashes 4 times, the selected component button stays on, and the remote control
remains in Clear Learned Function mode. Repeat Step 4 to continue the clearing process.
NOTE: Pressing the CLEAR button while in this mode will not delete the learning functions, but it will exit this delete mode.

Back to Contents Page
RemoteControlCodeList:Dell™PremiumRemoteControlTVIRCodeList
Acer
1084
Admiral
1002,1016
Adventura
1017
Aiko
1008
Amtron
1009
Anam National
1009
AOC
1003,1004,1005
Apex
1147
Audiovox
1009
Belcor
1003
Bell & Howell
1002,1010
BenQ
1069
Bradford
1009
Brockwood
1003
Candle
1003,1005,1006,1017
Citizen
1003,1005,1006,1008,1009,1013,1015
Colortyme
1003,1005
Concerto
1003,1005
Contec/Cony
1007,1009
Craig
1009
Crown
1009,1011
Curtis Mathes
1001,1003,1005,1010,1013,1015,1020
CXC
1009
Daewoo
1003,1004,1005,1008,1015,1157
Daytron
1003,1005,1015
Dell
1163,1164
Dimensia
1001,1020
Dumont
1003,1014
Electrohome
1003,1005
Emerson
1003,1005,1007,1009,1010,1015,1018
Envision
1003,1005
ESA
1060
Fisher
1010
Fujitsu
1077,1078,1079
Funai
1009
Futuretech
1009
Gateway
1085
GE
1001,1003,1005,1020,1128
Gibralter
1003,1014
Goldstar
1003,1004,1005,1007,1015
Grunpy
1009
Hallmark
1003,1005
Harvard
1009
Hisense
1021
Hitachi
1003,1005,1007,1019,1086,1087,1101,1106,1107,1111,1114,1122,1123,1127
IMA
1009
Infinity
1011
Janeil
1017
JBL
1011
JC Penney
1001,1003,1004,1005,1006,1013,1015,1020
Jensen
1003,1005,1058
JVC
1007,1109,1112,1158
Kawasho
1003,1005
Kenwood
1003,1005
Kloss Novabeam
1009,1017
KTV
1009,1015
LG
1004,1088,1124
Loewe
1011
Logik
1002
Luxman
1003,1005
LXI
1001,1005,1010,1011,1020
Magnavox
1003,1005,1006,1011,1032,1048,1110
Majestic
1002
Marantz
1003,1005,1011
Megatron
1005


Memorex
1002,1004,1005,1010
MGA
1003,1004,1005
Midland
1014,1015
Mitsubishi
1003,1004,1005,1098,1135,1138
Montgomery Ward
1002
Motorola
1016
MTC
1003,1004,1005,1013
Multitech
1009
Multivision
1012
NAD
1005,1019
NEC
1003,1004,1005,1080
NET-TV
1070,1095
Nikko
1005,1008
NTC
1008
Onwa
1009
Optimus
1019
Optonica
1016
Orion
1018
Panasonic
1011,1033,1035,1036,1089,1115,1116,1120,1139,1140,1155,1156
Philco
1003,1004,1005,1006,1007,1011
Philips
1003,1006,1007,1011,1031,1034,1040,1050,1110,1059,1126,1143,1148,1149
Pilot
1003,1015
Pioneer
1003,1005,1019,1090,1119,1145,1150
Polaroid
1047,1055,1056,1057,1058
Portland
1003,1004,1005,1008,1015
Price Club
1013
Prima
1022
Proscan
1001,1020,1128
Proton
1003,1005,1007
Pulsar
1003,1014
Radio Shack
1010,1020
Radio
Shack/Realistic
1001,1003,1005,1007,1009,1010,1015
RCA
1000,1001,1003,1004,1005,1020,1082,1125,1128
Realistic
1010,1020
Runco
1014
Sampo
1003,1005,1015,1095
Samsung
1003,1004,1005,1007,1013,1015,1026,1027,1028,1030,1052,1053,1073,1076,1091,1092,
1103,1108
Sansui
1018
Sanyo
1003,1010
Scotch
1005
Scott
1003,1005,1007,1009
Sears
1001,1003,1005,1010,1020
Sharp
1003,1005,1007,1015,1016,1023,1029,1039,1045,1121,1132,1136,1153,1159
Shogun
1003
Signature
1002
Simpson
1006
Sony
1025,1037,1041,1071,1072,1096,1099,1100,1104,1113,1118,1130,1131,1133,1137,1141,
1142,1144,1146,1152,1154
Soundesign
1003,1005,1006,1009
SSS
1003,1009
Starlite
1009
Supre-Macy
1017
Sylvania
1003,1005,1006,1011,1060
Symphonic
1009
Tandy
1016
Techwood
1003,1005
Teknika
1002,1003,1004,1005,1006,1007,1008,1009,1013,1015
TMK
1003,1005
Toshiba
1010,1013,1024,1042,1043,1051,1080,1081,1097,1102,1105,1117
Totevision
1015
Vidtech
1003,1004,1005
Viewsonic
1046, 1049, 1054, 1061, 1062, 1063, 1064, 1065, 1066, 1067, 1068, 1074, 1083, 1093
Viking
1017
Wards
1001,1002,1003,1004,1005,1011,1020
Yamaha
1003,1004,1005
Zenith
1002,1003,1014,1038,1044,1075,1094,1129,1134,1151,1160,1161,1162

Please read all restrictions and disclaimers.
Back to Contents Page

Back to Contents Page
Regulatory:Dell™PremiumRemoteControl
USA -Federal Communications Commission (FCC)
Canada -Industry Canada (IC)
Europe -EU Declaration of Conformity
Japan -VCCI and Telec Compliance
Singapore -IDA Compliance
Australia and New Zealand -C-tick Compliance
Radio Approvals

TheDell™PremiumRemoteControlmustbeinstalledandusedinstrictaccordancewiththemanufacturer'sinstructionsasdescribedinthedocumentation
that comes with the product. Dell Inc is not responsible for any radio or television interference caused by unauthorized modification of the devices included
withthisDell™PremiumRemoteControlkit,orthesubstitutionorattachmentofconnectingcablesandequipmentotherthanthatspecifiedbyDellInc.The
correction of interference caused by such unauthorized modification, substitution or attachment is the responsibility of the user. Dell Inc and its authorized
resellers or distributors are not liable for any damage or violation of government regulations that may arise from the user failing to comply with these
guidelines.
USA -Federal Communications Commission (FCC)
FCC Radiation Exposure Statement
Interference Statement
These devices comply with Part 15 of the FCC Rules. Operation of the devices is subject to the following two conditions:
1. The devices may not cause harmful interference, and
2. The devices must accept any interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy. If the equipment is not installed and used in accordance with the instructions, the equipment may cause harmful interference to radio
communications. There is no guarantee, however, that such interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct the
interference by taking one or more of the following measures:
lRelocate this device.
lIncrease the separation between the device and the receiver.
lConnect the device into an outlet on a circuit different from that of other electronics.
lConsult the dealer or an experienced radio technician for help.
This device must not be co-located or operating in conjunction with any other antenna or transmitter.
Certification Number: JJ4-DD1
UL Listed
Canada - Industry Canada (IC)
This device complies with RSS210 of Industry Canada.
WARNING:TheradiatedoutputpoweroftheDell™PremiumRemoteControlisfarbelowtheFCCradiofrequencyexposurelimits.Nevertheless,the
Dell™PremiumRemoteControlshouldbeusedinsuchamannerthatthepotentialforhumancontactduringnormaloperationisminimized.Toavoid
the possibility of exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 20 cm between you (or any other person in
the vicinity) and the antenna that is built into the notebook. To determine the location of the antenna within your portable computer, check the
information posted on the general Dell support site at http://support.dell.com.
This device has also been evaluated for and shown compliant with the FCC RF exposure limits under portable exposure conditions (antennas are within
20 cm of a person's body) when installed in certain specific OEM configurations. Details of the authorized configurations can be found at
http://www.fcc.gov/oet/fccid/help.html by entering the FCC ID number on the device.
NOTE:ThisDell™PremiumRemoteControlmustbeinstalledandusedinstrictaccordancewiththemanufacturer'sinstructionsasdescribedinthe
documentation that comes with the product. Any other installation or use will violate FCC Part 15 regulations. Modifications not expressly approved by
Dell could void your authority to operate the equipment.
CAUTION: Exposure to Radio Frequency Radiation
The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF field in excess of Health Canada

Certification Number: 5689A-DD1
Europe - EU Declaration of Conformity
This equipment complies with the essential requirements of the European Union directive 1999/5/EC.
New EU Member States Declaration of Conformity
France
InallMetropolitandépartements,wirelessfrequenciescanbeusedunderthefollowingconditions,eitherforpublicorprivateuse:
lIndoor use: maximum power (EIRP) of 100 mW for the entire 2400–2483.5 MHz frequency band.
Outdoor use: maximum power (EIRP) of 100 mW for the 2400–2454 MHz band and with maximum power (EIRP) of 10 mW for the 2454–2483.5 MHz band.
Japan - VCCI and Telec Compliance
limits for the general population; consult SafetyCode 6, obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb.
English
Hereby, Dell Inc., declares that this Dell Wireless Device is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Suomi
DellInc.vakuuttaatätenettäDellWirelessDevicetyyppinenlaiteondirektiivin1999/5/EYoleellisten
vaatimustenjasitäkoskeviendirektiivinmuidenehtojenmukainen.
Nederlands
HierbijverklaartDellInc.dathettoestelDellWirelessDeviceinovereenstemmingismetdeessentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG
BijdezeverklaartDellInc.datdezeDellWirelessDevicevoldoetaandeessentiëleeisenenaande
overige relevante bepalingen van Richtlijn 1999/5/EC.
Français
ParlaprésenteDellInc.déclarequel'appareilDellWirelessDeviceestconformeauxexigences
essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE
Parlaprésente,DellInc.déclarequeceDellWirelessDeviceestconformeauxexigencesessentielles
et aux autres dispositions de la directive 1999/5/CE qui lui sont applicables
Svenska
HärmedintygarDellInc.attdennaDellWirelessDevicestårIöverensstämmelsemeddeväsentliga
egenskapskravochövrigarelevantabestämmelsersomframgåravdirektiv1999/5/EG.
Dansk
UndertegnedeDellInc.erklærerherved,atfølgendeudstyrDellWirelessDeviceoverholderde
væsentligekravogøvrigerelevantekravidirektiv1999/5/EF
Deutsch
HiermiterklärtDellInc.,dasssichdieser/diese/diesesDellWirelessDeviceinÜbereinstimmungmitden
grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG
befindet". (BMWi)
HiermiterklärtDellInc.dieÜbereinstimmungdesGerätesDellWirelessDevicemitdengrundlegenden
Anforderungen und den anderen relevanten Festlegungen der Richtlinie 1999/5/EG. (Wien)
Ελληνικά
ME THN ΠAPOYΣA H Dell Inc. ΔHΛΩNEI OTI H ΣYΣKEYH Dell Wireless Device ΣYMMOPΦΩNETAI ME TIΣ
IΣXYOYΣEΣAΠAITHΣEIΣKAI TIΣΛOIΠEΣΣXETIKEΣΔIATAΞEIΣTHΣOΔHΓIAΣ1999/5/EK
Italiano
ConlapresenteDellInc.dichiarachequestoDellWirelessDeviceèconformeairequisitiessenzialied
alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE
Español
Por medio de la presente Dell Inc. declara que el Dell Wireless Device cumple con los requisitos
esenciales y otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE
Português
DellInc.declaraqueesteDellWirelessDeviceestáconformecomosrequisitosessenciaiseoutras
disposiçõesdaDirectiva1999/5/CE.
Malti
Hawnhekk, Dell Inc., tiddikjara li dan id-Dell Wireless Device hu konformi mal-ħtiġijiet essenzjali u
provvedimenti relevanti oħrajn ta' Direttiva 1999/5/KE
Eesti
KäesolevagakinnitabDellInc.seadmeDellWirelessDevicevastavustdirektiivi1999/5/EÜ
põhinõuetelejanimetatuddirektiivisttulenevateleteisteleasjakohastelesätetele.
Magyar
Alulírott,DellInc.nyilatkozom,hogyaDellWirelessDevicemegfelelavonatkozóalapvető
követelményeknekésaz1999/5/ECirányelvegyébelőírásainak
Slovensky
DellInc.týmtovyhlasuje,že Dell Wireless Device spĺňazákladnépožiadavky a všetkypríslušné
ustanovenia smernice 1999/5/ES.
Česky
DellInc.tímtoprohlašuje, že tento Dell Wireless Device je ve shodĕsezákladnímipožadavky a dalšími
příslušnýmiustanovenímismĕrnice 1999/5/ES.
Slovenščina
Družba Dell Inc. izjavlja, da je ta brezžična naprave Dell skladna z bistvenimi zahtevami in ostalimi
določili Direktive 1999/5/ES.
Latviski
Ar šo Dell Inc. paziņo, ka Dell Wireless Device atbilst Direktīvai 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem
Lietuviųk
„Dell Inc.“deklaruoja, kad „Dell Wireless Devize“atitinka 1999/5/EC Direktyvos esminius reikalavimus
ir kitas nuostatas.
Polski
Niniejszym firma Dell Inc. deklaruje, że urządzanie Dell Wireless Device spełnia wymagania zasadnicze
oraz stosowne postanowienia zawarte w dyrektywie 1999/5/EC.

VCCI Compliant
Certification Number: 2603
Telec Compliant
003NY060650000
Singapore - IDA Compliance
Australia and New Zealand - C-tick Compliance
ACA C-tick Certification
Certification Number: N14939
Radio Approvals
It is important to ensure that you only use your radio device in countries where the device is approved for use. To determine whether you are allowed to use
your wireless network device in a specific country, check to see if the radio type number that is printed on the identification label of your device is listed on the
radio approval list posted on the general Dell support site at http://support.dell.com.
IncountriesotherthantheUnitedStatesandJapan,verifythattheLocationpropertyvaluehasbeensettothecountryinwhichyouareusingyourDell™
Premium Remote Control. This ensures compliance with local regulatory restrictions on transmit power and optimizes network performance.
Please read all restrictions and disclaimers.
Back to Contents Page


Back to Contents Page
SafetyInformation:Dell™PremiumRemoteControl
1. Read all safety and operating instructions before operating the unit.
2. Keep the unit away from heat sources such as radiators, heat registers, stoves, etc.
3. Do not use the unit near water –for example, near a sink, in a wet basement, near a swimming pool, near an open window, etc.
4. Do not allow objects to fall or liquids to be spilled onto the remote control.
5. Incorrect handling of the battery could result in fire or personal injury. The battery may explode if not handled properly:
¡Keep the battery away from children and pets. If swallowed consult a physician immediately for emergency treatment.
¡Do not allow the battery in fire or water.
¡Keep the battery in a dark, cool and dry place.
¡Do not short circuit the battery.
¡Do not recharge, disassemble or solder the battery
¡Do not give the battery a physical impact.
¡Make sure the plus and minus terminals are correctly aligned when loading the battery.
¡Obey the local laws on disposing the battery.
TheDell™PremiumRemoteControl,likeotherradiodevices,emitsradiofrequencyelectromagneticenergy.Thelevelofenergyemittedbythisdevice,
however,islessthantheelectromagneticenergyemittedbyotherwirelessdevicessuchasmobilephones.TheDell™PremiumRemoteControloperates
within the guidelines found in radio frequency safety standards and recommendations. These standards and recommendations reflect the consensus of the
scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research
literature.Insomesituationsorenvironments,theuseoftheDell™PremiumRemoteControlmayberestrictedbytheproprietorofthebuildingorresponsible
representatives of the applicable organization.
Examples of such situations include the following:
1. UsingtheDell™PremiumRemoteControlonboardairplanes,or
2. UsingtheDell™PremiumRemoteControlinanyotherenvironmentwheretheriskofinterferencewithotherdevicesorservicesisperceivedoridentified
as being harmful.
If you are uncertain of the policy that applies to the use of wireless devices in a specific organization or environment (an airport, for example), you are
encouragedtoaskforauthorizationtousetheDell™PremiumRemoteControlbeforehand.
Please read all restrictions and disclaimers.
Back to Contents Page
IMPORTANT SAFETY INSTRUCTIONS
Explosive Device Proximity Warning:
Do not operate a portable transmitter near unshielded blasting caps or in an explosive environment unless the device has been modified to be qualified
for such use.
Use On Aircraft Caution:
Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices because their signals could interfere with critical aircraft
instruments.

Back to Contents Page
Setup:SettingUptheDell™PremiumRemoteControl
Installing Batteries
Connecting the Dell Premium Remote Control With Your Computer
Reinstalling the LCD Software Service Application

Installing Batteries
The Dell Premium Remote Control comes with four AAA batteries. Standard 1.5-volt (V) alkaline, 1.5-V lithium, or rechargeable 1.2-V nickel cadmium (Ni-Cd) or
nickel metal hydride (Ni-Mh) batteries may be used. To install the batteries, perform the following steps:
1. Open the battery compartment door located on the bottom of the remote control.
2. Insert the batteries as indicated below.
3. Replace the battery door.
Connecting the Dell Premium Remote Control with your Computer
Before using the Dell Premium Remote Control for the first time it must be connected (i.e. "paired") with your Computer. To connect the remote control with
your computer, perform the following steps:
1. Poweronthecomputer.
2. Press the "CONNECT" button on the remote control.

3. Hold the Dell Premium Remote Control within 6 inches (15 cm) of your computer.
NOTE: Reprogramming may be required after batteries are replaced.
NOTE: Remove the batteries if the remote will not be used for an extended period of time. Doing so extends battery life and prevents damage from
battery leaks or corrosion.


4. When the devices are connected, the LCD screen will display "Connected to your Computer."
Reinstalling the LCD Software Service Application
To reinstall the Dell Premium Remote Control LCD Software Service Application, perform the following steps:
1. With Windows®running on your computer, insert the Dell Resource CD into your CD/DVD-ROM drive.
2. If the Dell Resource CD window does not open automatically, double-click the My Computer icon on your desktop, and then double-click the CD/DVD-ROM
drive containing the Dell Resource CD.
3. Locate the install package provided on the Dell Resource CD for your Dell Premium Remote Control.
4. Follow the instructions provided by the Dell Resource CD to extract and install the application.
Please read all restrictions and disclaimers.
Back to Contents Page
NOTE: These steps are only required prior to first use. The devices will remain connected after powering down the system or removing batteries from
the remote control.
NOTE: All text in the remote control LCD screens will be in English until a successful connection to the computer has been made.
NOTE: For some systems, the Dell Resource CD is labeled as the Drivers and Utilities CD.

Back to Contents Page
Specifications:Dell™PremiumRemoteControl
General
Physical
Power
Environmental
Please read all restrictions and disclaimers.
Back to Contents Page
General
Manufacturer:
Gyration, Inc.
Model numbers:
WJ151
TJ426
RJ816

Physical
Height:
9.5 inches (241 millimeters)
Width:
2.2 inches (56 millimeters)
Depth:
1.3 inches (33 millimeters)
Weight (including four AAA batteries):
7.4 ounces (210 grams)

Power
Batteries:
Four AAA batteries

Environmental
Operating temperature (optimum):
0°to40°C(32°to104°F)

Back to Contents Page
Television:ControllingtheTelevisionwiththeDell™PremiumRemoteControl
The Dell Premium Remote Control can be used to control the following functions of your Television:
lPower toggling
lTV Input selection
lVolume control
lChannel control
To operate the television, perform the following steps:
1. Press and release the TV button to put the remote control into TV mode.
2. Press the Power button to turn on the TV.
3. Press the TV Input button to select the correct television input.
4. Press the plus (+) and minus (-) keys to turn the volume up or down (respectively).
5. Press the plus (+) and minus (-) keys to change the channel up or down (respectively).
6. Use the numeric keypad for direct channel entry.
Please read all restrictions and disclaimers.
Back to Contents Page
NOTE:BeforeyoucancontrolyourtelevisionwiththeDellPremiumRemoteControlforthefirsttime,theremotecontrolmustbeprogrammed.Seethe
Programming the Dell Premium Remote Control for Television Control section for more information.
NOTE: The Dell Premium Remote Control requires line of sight to control your television.
NOTE: Additional control can be added by using the IR Learn function.
NOTE: This will put the remote control into IR mode, and will no longer control your Media Center computer.
NOTE: The TV button will light up for two seconds indicating that the remote control is in TV mode.
NOTE: Refer to your Television Owner's Manual for more information on changing channels directly.

Back to Contents Page
Troubleshooting:Dell™PremiumRemoteControl
Adjusting the Contrast on the LCD Display
Reinstalling the LCD Software Service Application
Common Problems and Solutions
Getting Help
Adjusting the Contrast on the LCD Display
To adjust the contrast on the LCD display, perform the following steps:
1. With the LCD screen active, press and hold the button located beneath the LCD screen.
2. Continue to hold the button after the LCD screen turns off for 5 more seconds.
3. The LCD Contrast adjustment screen will appear.
4. Use the menu navigation up and down arrows to adjust to the desired appearance.
5. Press any button to exit.
6. If no button is pressed, the display will time out in about 5 seconds.
Reinstalling the LCD Software Service Application
To reinstall the Dell Premium Remote Control LCD Software Service Application, perform the following steps:
1. With Windows®running on your computer, insert the Dell Resource CD into your CD/DVD-ROM drive.
2. If the Dell Resource CD window does not open automatically, double-click the My Computer icon on your desktop, and then double-click the CD/DVD-ROM
drive containing the Dell Resource CD.
3. Locate the install package provided on the Dell Resource CD for your Dell Premium Remote Control.
4. Follow the instructions provided by the Dell Resource CD to extract and install the application.
Common Problems and Solutions
NOTE: The contrast settings range from 0 (lightest) to 21 (darkest).
NOTE: The contrast value is stored, even when removing the batteries.
NOTE: For some systems, the Dell Resource CD is labeled as the Drivers and Utilities CD.
Cursor Control Issues
Problem
Cause
Solution
The LCD screen does not match or
show the updates to the Windows
Media Player audio library.
The LCD Software Service
Application did not update
correctly.
Restart the LCD Software Service
Application, by clicking the Dell Premium
Remote Control (green) icon on the
Windows Taskbar, and clicking "Restart."
The LCD screens needs to be
manually refreshed.
Press the button to return to the Main
Menu.
The LCD screens needs to be
manually refreshed.
Use the menu navigation buttons to move
up or down from the current level in the LCD
screen.
The Menu Navigation buttons are non-
responsive while the LCD screen is
active.
The LCD Software Service
Application has lost contact with
the remote control.
Refresh the LCD screen by pressing the
button for three seconds to shut off the LCD
screen, then pressing the button again
to turn the LCD screen back on.
The remote control is out of range
with the computer.
Place the remote control closer to the
computer.
The cursor does not move when the
"Motion by Gyration" button is
pressed.
The remote control and computer
are not connected.
Connect the Dell Premium Remote Control
with your computer.
The batteries are low.
Replace the batteries.
The cursor movement is choppy or
erratic.
There may be radio interference
near the computer.
Move any electronic devices away from PC
(i.e., speakers, radio, etc.).
The cursor moves too fast or too slow.
The speed or acceleration is not
set properly.
Change the cursor tracking speed under the
Mouse settings in the Control Panel.
The cursor drifts on the screen.
The remote control sensor may
require self-recalibration.
Place the remote control on a flat surface for
5 or more seconds. The gyroscope will
perform a self-steady routine to identify and
eliminate drift.
The Power/Standby button does not
wake the computer out of Standby
mode.
If the BIOS setting for Wake from
USB is disabled, the system will
not turn back on via the remote
Enable the wake from USB option in the
system BIOS. For information on accessing
the system BIOS, see your Owner's Manual.


Getting Help
If the troubleshooting procedures in this document do not resolve the problem, please contact Dell Inc. for technical assistance (see “Getting Help”in your
Dell™systemdocumentation).ForinformationaboutyourDellwarranty,seeyoursystemdocumentation.
Please read all restrictions and disclaimers.
Back to Contents Page
control.
The Power/Standby button does not
wake the computer out of Hibernation
or Shutdown mode.
If the computer is placed into
Hibernation or Shutdown mode,
and then the AC power is
removed, the internal receiver
loses its power and cannot wake
the system (even if AC power is
reapplied).
Turn on the computer manually using the
system Power button.
If the BIOS setting for Wake from
USB is disabled, the system will
not turn back on via the remote
control.
Enable the wake from USB option in the
system BIOS. For information on accessing
the system BIOS, see your Owner's Manual.
The text "NO LINK" is displayed on the
LCD screen.
The remote control and computer
are not connected.
Connect the Dell Premium Remote Control
with your computer.
The text "NO SERVICE" is displayed on
the LCD screen.
There may be radio interference
near the computer.
Move any electronic devices away from PC
(i.e., speakers, radio, etc.).
The remote control is out of range
with the computer.
Place the remote control closer to the
computer.
The LCD Software Service
Application is not enabled.
To re-enable the LCD Software Service
Application, click the Dell Premium Remote
Control (red) icon on the Windows
Taskbar and click "Start."
The text on the LCD Screen is in
English.
All text in the remote control LCD
screens will be in English until a
successful connection to the
computer has been made.
Connect the Dell Premium Remote Control
with your computer.
