Dell E1913 User manual

Dell™ Display Manager User's Guide
Overview
Using the Quick Settings Dialog
Setting Basic Display Functions
Assigning Preset Modes to Applications
Applying Energy Conservation Features
Overview
Dell Display Manager is a Windows application used to manage a monitor or a group of monitors. It allows manual adjustment
of the displayed image, assignment of automatic settings, energy management, image rotation and other features on select
Dell models. Once installed, Dell Display Manager will run each time the system starts and will place its icon in the notification
tray. Information about monitors connected to the system is always available when hovering over the notification tray icon.
Using the Quick Settings Dialog
Clicking Dell Display Manager's notification tray icon opens the Quick Settings dialog box. When more than one supported Dell
model is connected to the system, a specific target monitor can be selected using the menu provided. The Quick Settings
dialog box allows convenient adjustment of the monitor's Brightness and Contrast levels, Preset Modes can be manually
selected or set to Auto Mode, and the screen resolution can be changed.
The Quick Settings dialog box also provides access to Dell Display Manager's advanced user interface which is used to adjust
Basic functions, configure Auto Mode and access other features.
Setting Basic Display Functions

A Preset Mode for the selected monitor can be manually applied using the menu on the Basic tab. Alternatively, Auto Mode
can be enabled. Auto Mode causes your preferred Preset Mode to be applied automatically when specific applications are
active. An onscreen message momentarily displays the current Preset Mode whenever it changes.
The selected monitor's Brightness and Contrast can also be directly adjusted from the Basic tab.
Assigning Preset Modes to Applications
The Auto Mode tab allows you to associate a specific Preset Mode with a specific application, and apply it automatically. When
Auto Mode is enabled, Dell Display Manager will automatically switch to the corresponding Preset Mode whenever the
associated application is activated. The Preset Mode assigned to a particular application may be the same on each connected
monitor, or it can vary from one monitor to the next.
Dell Display Manager is pre-configured for many popular applications. To add a new application to the assignment list, simply
drag the application from the desktop, Windows Start Menu or elsewhere, and drop it onto the current list.
NOTE: Preset Mode assignments targeting batch files, scripts, and loaders, as well as non-executable files such as zip
archives or packed files, are not supported and will be ineffective.
In addition an option can be enabled that will cause the "Game" Preset Mode to be used any time a Direct3D application is
run fullscreen. To override this behavior, if enabled, with individual game titles, add them to the assignment list with a
different Preset Mode. Applications present in the assignment list take priority over the general Direct3D setting.

Applying Energy Conservation Features
On supported Dell models the PowerNap tab will be available to provide energy conservation options. When the screensaver
activates, the monitor's Brightness can automatically be set to minimum level or the monitor can be put to sleep in order to
save additional power.
