DELLA 048-GM-48216 User manual

AUTOMATIC WASHING MACHINE
Item No.: 048-GM-48216
Thank you for purchasing the automatic washing machine.
●Please read this instruction carefully in order to operate the machine properly.
●Keep this manual handy for further reference.

FUNCTION AND FEATURE
PERFECT DESIGH AND FULL MODELS WITH THE PLASTIC AND ALUMINUM ALLOY
BODY AND NEVER RUSTY WITHIN WASHING,DOUBLE WATER STREAM AND THE HAND
WHEEL DESIGH GET THE CLOTHING MORE CLEAR.WASHING WITH THREE WATER STREAM,
DISHING FIRE WAVE FORM NEW STREAM,GET THE CLOTHING OUT OF TWINING,HIGHLY CLEAN
WITH LOWER FRAY.
DISSOLVE WASH POWDER QUIUKLY AND THE HIGH CLEAN MORE THAN THE COMMON
DOUBLE-TUBE WASHING MACHINE.
WITH HIGH FUNCTION AND QUIET SOUND,HAND WHEEL AND NEVER FRAY.

★ Washing machine should be installed in the firmly and smooth ground,2*bevel is allowed.
★ Put the washing machine deviate from the wall for more over 5cm,so that have no noise.
★ Put the intake pipe correctly.
★ Put the affusion spigot into the affusion hole.
1.Take out the coin,nails or
other things from the garments
2.Never put the garments which with
the chemical reagent together with
the cloths
3.Turn out the inside cloth during
washing the garments with the floss.
4.Put the good garments into the
pocket during washing

Connect the intake pipe
with the water spigot
Nut the wire into the plug
Put down the drain pipe
Put the garments into the washing
tube then put into the wash powder
\ ★ Choose the water level according to the
quantity of the garments, high,middle and low.
★ For the water level of the double water stream,it’s
the best position of the middle and high.
Choose the washing method (Turn”current transform”switch”)
Turn the current transform switch according to the quantity and the material of the
garments,then choose the washing current in “normal,gently”
Choose the washing time
Turn the washing timer in sequence when the water reach the level,then the washing
machine begin to work.

Choose the wash method Gently Normal
Materail of the garments Silk or floss clothing Linen or very dirty garments
Washing time 3-5min 5-9min 9-15min
Water level Quantities of the wash powder
High 40-57g
Middle 30-48g
Low 25-40g
Drain
When finish washing turn the current transform to the drain position and then begin to drain.
Choose the drying time
★ When finish drain,move the garments into the drying tube then cover the lid on the garments
★ Cover the drying inside lid and the drying cover.
★ Turn the drying timer in sequence and the washing machine begin to work
Sort of the garments Drying time
Shirt (synthetic fibre) 1-2min
Underwear 3-5min
Work clothes 5min
★ Perform the washing procedure for two times,wash,drying and then wash and drying
★ After drain then begin to the second washing meanwhile save the electric and the water
Perform the washing procedure for two times,open the water spigot and then affusion the
water into the washing tube.
★ Press well the plastic cover on the garments strike the machine while drying.
★ Never drying while drain,should finish drain and then move the garments into
the drying tube to avoid to damage the machine
★ Press well the plastic cover of the spin drier to avoid the garments fly
out of the tube.
★ Never put the hands into the drying tube while working especially for
the children.

Pull down the plug,close the water spigot and then hang up the drain pipe.
Clean the drying tube and open the plastic cover to make tube dry.
Please clean the filtrate netting after finish working every time
★ Pull down the filtrate netting and press down as the picture
★ Clean the filtrate netting into the water
★ First put the bottom into the hole and then press it
Don’t install it in the bath-room Don’t pour the water on
and other inclined ground the switch.
Never brush the machine
When you use warm water, use gasoline,alcohol and
the temperature should not other organic solvent.
exceed 50 centigrade

★ PLEASE PULL DOWN THE PLUG AFTER FINISH WASHING.
★ DRAIN PIPE’S LENGTH ALWAYS LOW THAN 2M,IT’S HEIGHT MUST MORE
THAN 15CM.
★ DON’T KEEP THE EXIT OF THE DRAIN PIPE PRESSURIZE IN THE CLOACA.
★ IF YOU WANT TO CHANGE THE WIRE,PLEASE CHANGE IT IN THE LOCAL
COMPANY.
★ IF THE BOTTON WITH THE INTAKE,THE FOOTCLOTH SHOULDN’T BACKUP
THE INTAKE.
★ THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS
(INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY
HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE
APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
★ CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.
★ IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE
MANUFACTURER, ITS SERVICE AGENT OR SIMILARLY QUALIFIED PERSONS
IN ORDER TO AVOID A HAZARD.
★ THIS APPLIANCE CAN BE USED BY CHILDREN AGED FROM 8 YEARS AND ABOVE
AND PERSONS WITH REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE
APPLIANCE IN A SAFE WAY AND UNDERSTAND THE HAZARDS INVOLVED.
CHILDREN SHALL NOT PLAY WITH THE APPLIANCE. CLEANING AND USER
MAINTENANCE SHALL NOT BE MADE BY CHILDREN WITHOUT SUPERVISION.
★ CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS
CONTINUOUSLY SUPERVISED.
