DeLonghi D55TW19G Service manual

D55TW19G
installation / instructions manual
εγχειρίδιο εγκατάστασης / οδηγιών Two door Refrigerator GB
GR
Δίπορτο ψυγείο
D55TW19G_IB_2L_RC_191022_grace.indb 1 22/10/2019 5:04 PM

GB
Contents
safety warnings .................................................................................................................. 4
unpacking.......................................................................................................................... 12
installation......................................................................................................................... 13
location .......................................................................................................................... 13
levelling the unit............................................................................................................. 13
free space requirements................................................................................................ 13
reversing the door swing ............................................................................................... 14
cleaning before use ....................................................................................................... 17
before using your unit.................................................................................................... 17
product overview.............................................................................................................. 18
main unit........................................................................................................................ 18
operation ........................................................................................................................... 19
switching on your unit.................................................................................................... 19
adjusting the temperature.............................................................................................. 19
noises inside the unit!.................................................................................................... 19
tips for keeping food in the unit ..................................................................................... 19
preparations for freezing ............................................................................................... 20
defrosting frozen food.................................................................................................... 20
cleaning............................................................................................................................. 21
defrosting....................................................................................................................... 21
cleaning the interior and the exterior of the unit ............................................................ 21
maintenance...................................................................................................................... 22
changing the internal LED light ..................................................................................... 22
care when handling / moving your unit.......................................................................... 22
servicing ........................................................................................................................ 22
switching off for long periods of time ............................................................................. 22
condensation ................................................................................................................. 22
disposal............................................................................................................................. 22
specications.................................................................................................................... 23
product che..................................................................................................................... 23
D55TW19G_IB_2L_RC_191022_grace.indb 2 22/10/2019 5:04 PM

Περιεχομενα
προειδοποιήσεις ασφαλείας............................................................................................. 8
αφαίρεση συσκευασίας ................................................................................................... 24
εγκατάσταση ..................................................................................................................... 25
τοποθεσία ...................................................................................................................... 25
ισοστάθμιση της μονάδας.............................................................................................. 25
απαιτήσεις ύπαρξης ελεύθερου χώρου ......................................................................... 25
αλλαγή φοράς πόρτας ................................................................................................... 26
αλλαγή πριν από τη χρήση............................................................................................ 29
προτού χρησιμοποιήσετε τη μονάδα σας ...................................................................... 29
επισκόπηση προϊόντος ................................................................................................... 30
κύρια μονάδα................................................................................................................. 30
λειτουργία.......................................................................................................................... 31
ενεργοποίηση της μονάδας σας .................................................................................... 31
ρύθμιση της θερμοκρασίας............................................................................................ 31
θόρυβοι στο εσωτερικό της μονάδας!............................................................................ 31
συμβουλές για τη συντήρηση τροφίμων στη μονάδα .................................................... 31
προετοιμασίες για κατάψυξη ......................................................................................... 32
απόψυξη κατεψυγμένων τροφίμων ............................................................................... 33
καθαρισμός ....................................................................................................................... 33
απόψυξη........................................................................................................................ 33
καθαρισμός του εσωτερικού και του εξωτερικού της μονάδας....................................... 33
συντήρηση ........................................................................................................................ 34
αντικατάσταση της εσωτερικής λυχνίας LED ................................................................. 34
φροντίδα κατά το χειρισμό / μετακίνηση της μονάδας σας ............................................ 34
εργασίες σέρβις ............................................................................................................. 34
απενεργοποίηση για μακρά χρονικά διαστήματα .......................................................... 34
συμπύκνωση ................................................................................................................. 34
απόρριψη .......................................................................................................................... 34
προδιαγραφές .................................................................................................................. 35
δελτίο τεχνικών δεδομένων προϊόντος ......................................................................... 35
GR
D55TW19G_IB_2L_RC_191022_grace.indb 3 22/10/2019 5:04 PM

4
GB
safety warnings
For your continued safety and to reduce the risk of injury or electric
shock, please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them
for future reference.
• Retain the manual. If you pass the unit onto a third party, make
sure to include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
– farm houses and by clients in hotels, motels and other residential
type environment;
– bed and breakfast type environment;
– staff kitchen areas in shops, offices and other working
environment;
– catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection
from the mains supply.
• If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or a qualified technician in order to
avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or fires as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• Children should be supervised to ensure that they do not play with
the unit.
• If your unit is fitted with a lock to prevent children being trapped
inside, keep the key out of reach and not in the vicinity of the unit.
D55TW19G_IB_2L_RC_191022_grace.indb 4 22/10/2019 5:04 PM

5
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not store bottles or glass containers in the freezer
compartment. Contents can expand when frozen (fizzy
drinks) which may break the bottle and damage your freezer
compartment. (If applicable)
• To avoid contamination of food, pay attention to the following:
- opening the door for long periods can cause a significant
increase of the temperature in the compartments of the
appliance;
- clean regularly surfaces that can come in contact with food and
accessible drainage systems;
- clean water tanks if they have not been used for 48 hours; flush
the water system connected to a water supply if water has not
been drawn for 5 days;
- store raw meat and fish in suitable containers in the refrigerator
so that it is not in contact with or drip onto other food;
- two-star frozen-food compartments are suitable for storing pre-
frozen food, storing or making ice-cream and making ice cubes;
- one-, two- and three-star compartments are not suitable for the
freezing of fresh food;
- if the refrigerating appliance is left empty for long periods, switch
off, defrost, clean, dry and leave the door open to prevent mould
developing within the appliance.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN
AUTHORISED SERVICE PERSONNEL TO CARRY OUT
SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL
OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT
ATTEMPT REPAIRS YOURSELF.
D55TW19G_IB_2L_RC_191022_grace.indb 5 22/10/2019 5:04 PM

6
The table below contains general guidelines on the storage of food in
the refrigerator.
Refrigerator location Type of food
Fridge door • Foods with natural preservatives, such
as jams, juices, drinks, condiments.
• Do not store perishable foods.
Crisper bin (salad bin) • Fruits, herbs and vegetables should be
placed separately in the crisper bin.
• Do not store bananas, onions,
potatoes, garlic in the refrigerator.
• Fridge shelf – bottom
• Chiller bin
Raw meat, poultry, fish (for short-term
storage)
Fridge shelf – middle Dairy products, eggs
Fridge shelf – top Foods that do not need cooking, such as
ready-to-eat foods, deli meats, leftovers.
Freezer drawer/shelf • Foods for long-term storage.
• Bottom drawer/shelf for raw meat,
poultry, fish.
• Middle drawer/shelf for frozen
vegetables, chips.
• Top drawer/shelf for ice cream, frozen
fruit, frozen baked goods.
D55TW19G_IB_2L_RC_191022_grace.indb 6 22/10/2019 5:04 PM

7
WARNING
• Keep ventilation openings in the unit enclosure or in the built-
in structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked flames or ignition sources and ventilate the room
in which the unit is placed for a few minutes.)
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
WARNING: Risk of re/ammable materials
D55TW19G_IB_2L_RC_191022_grace.indb 7 22/10/2019 5:04 PM

8
GR
προειδοποιησεις ασφαλειας
Για τη συνεχή ασφάλειά σας και τη μείωση του κινδύνου πρόκλησης
τραυματισμού ή ηλεκτροπληξίας, ακολουθήστε όλες τις προφυλάξεις
ασφαλείας που αναφέρονται παρακάτω.
• Διαβάστε όλες τις οδηγίες προσεκτικά πριν τη χρήση της μονάδας
και κρατήστε τις για λόγους μελλοντικής αναφοράς.
• Κρατήστε το εγχειρίδιο. Εάν μεταβιβάσετε τη μονάδα σε τρίτους,
βεβαιωθείτε ότι το εγχειρίδιο συμπεριλαμβάνεται.
• Αυτή η συσκευή προορίζεται για εσωτερική χρήση σε οικιακό
περιβάλλον και παρόμοιες χρήσεις όπως:
– σε φάρμες και από πελάτες σε ξενοδοχεία, πανδοχεία και άλλα
περιβάλλοντα οικιστικού τύπου,
– σε περιβάλλοντα τύπου bed & breakfast (με πρωινό),
– σε καταστήματα, γραφεία ή άλλα περιβάλλοντα εργασίας με
χώρους με εξοπλισμό κουζίνας,
– για χρήσεις σε υπηρεσίες ομαδικής εστίασης και παρόμοιες
υπηρεσίες πλην της λιανικής.
• Βεβαιωθείτε ότι το βύσμα είναι εύκολα προσβάσιμο για
αποσύνδεση από την τροφοδοσία κύριου δικτύου.
• Εάν το καλώδιο τροφοδοσίας από το κύριο δίκτυο καταστραφεί,
πρέπει να αντικατασταθεί από τον κατασκευαστή, τον πράκτορα
σέρβις ή τον εξειδικευμένο τεχνικό για την αποφυγή πρόκλησης
κινδύνων.
• Επιλέξτε για τη μονάδα σας μια θέση μακριά από πηγές
θερμότητας όπως θερμαντικά σώματα ή φλόγες καθώς το ψυκτικό
και η φλυκταινογόνος ουσία είναι εύφλεκτες.
• Η μετακίνηση της μονάδας γίνεται από τουλάχιστον 2 άτομα.
• Αυτή η συσκευή μπορεί να χρησιμοποιηθεί από παιδιά ηλικίας
από 8 ετών και άνω και από άτομα με μειωμένες σωματικές,
αισθητήριες ή διανοητικές ικανότητες ή έλλειψη εμπειρίας και
γνώσης, εφόσον επιβλέπονται ή τους έχουν δοθεί οδηγίες σχετικά
με τη χρήση της συσκευής με ασφαλή τρόπο και κατανοούν τις
κινδύνους που εμπλέκονται. Τα παιδιά δεν πρέπει να παίζουν με
τη συσκευή. Ο καθαρισμός και η συντήρηση από το χρήστη δεν θα
πρέπει να γίνεται από παιδιά χωρίς επιτήρηση.
• Τα παιδιά ηλικίας από 3 έως 8 ετών επιτρέπεται να τοποθετούν
τρόφιμα σε συσκευές ψύξης.
D55TW19G_IB_2L_RC_191022_grace.indb 8 22/10/2019 5:04 PM

9
• Τα παιδιά πρέπει να επιβλέπονται για να διασφαλιστεί ότι δεν
παίζουν με τη μονάδα.
• Εάν η μονάδα σας διαθέτει κλειδαριά για να αποφευχθεί το
ενδεχόμενο να παγιδευτούν παιδιά στο εσωτερικό τους, φυλάξτε το
κλειδί σε περιβάλλον που δεν έχουν πρόσβαση και όχι κοντά στη
μονάδα.
• Μην αποθηκεύετε εκρηκτικές ουσίες όπως δοχεία αερολυμάτων με
εύφλεκτο προωθητικό μέσο σε αυτή τη συσκευή.
• Μην αποθηκεύετε φιάλες ή γυάλινους περιέκτες στο θάλαμο
κατάψυξης. Τα περιεχόμενα μπορούν να διασταλούν όταν
καταψύχονται (αναψυκτικά), προκαλώντας θραύση της φιάλης και
βλάβη στο θάλαμο κατάψυξης. (εάν διατίθεται)
• Για να αποφύγετε την αλλοίωση των τροφίμων, δώστε προσοχή
στα ακόλουθα:
- Το άνοιγμα της πόρτας για μεγάλες χρονικές περιόδους μπορεί
να προκαλέσει σημαντική αύξηση της θερμοκρασίας στα
διαμερίσματα της συσκευής.
- Καθαρίζετε τακτικά τις επιφάνειες που μπορούν να έρθουν
σε επαφή με τρόφιμα, καθώς και τα προσβάσιμα συστήματα
αποστράγγισης.
- Καθαρίζετε τις δεξαμενές εάν δεν έχουν χρησιμοποιηθεί για
48 ώρες. Ξεπλύνετε το σύστημα ύδρευσης που συνδέεται με
παροχή νερού εάν δεν έχει αντληθεί νερό για 5 ημέρες.
- Αποθηκεύετε το ωμό κρέας και τα ψάρια σε κατάλληλα δοχεία στο
ψυγείο, έτσι ώστε να μην έρχονται σε επαφή ή να μην στάζουν
σε άλλα τρόφιμα.
- Τα διαμερίσματα κατάψυξης δύο αστέρων είναι κατάλληλα για την
αποθήκευση προ-κατεψυγμένων τροφίμων, την αποθήκευση ή
την παρασκευή παγωτού και την κατασκευή παγοκύβων.
- Τα διαμερίσματα ενός, δύο και τριών αστέρων δεν είναι
κατάλληλα για την κατάψυξη νωπών τροφίμων.
- Εάν η συσκευή πρόκειται να παραμείνει άδεια για μεγάλο
χρονικό διάστημα, απενεργοποιήστε, αποψύξτε, καθαρίστε και
στεγνώστε την και αφήστε την πόρτα ανοικτή για να αποφύγετε
την ανάπτυξη μούχλας μέσα στη συσκευή.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
ΕΙΝΑΙ ΕΠΙΚΙΝΔΥΝΟ ΓΙΑ ΟΠΟΙΟΝΔΗΠΟΤΕ ΕΚΤΟΣ ΑΠΟ ΤΟ
ΕΞΕΙΔΙΚΕΥΜΕΝΟ ΠΡΟΣΩΠΙΚΟ ΣΕΡΒΙΣ ΝΑ
ΠΡΑΓΜΑΤΟΠΟΙΕΙ ΕΡΓΑΣΙΕΣ ΣΕΡΒΙΣ Ή ΕΠΙΣΚΕΥΕΣ ΠΟΥ
D55TW19G_IB_2L_RC_191022_grace.indb 9 22/10/2019 5:04 PM

10
ΠΕΡΙΛΑΜΒΑΝΟΥΝ ΤΗΝ ΑΦΑΙΡΕΣΗ ΤΩΝ ΚΑΛΥΜΜΑΤΩΝ.
ΠΡΟΣ ΑΠΟΦΥΓΗ ΤΟΥ ΚΙΝΔΥΝΟΥ ΠΡΟΚΛΗΣΗΣ
ΗΛΕΚΤΡΟΠΛΗΞΙΑΣ ΜΗΝ ΕΠΙΧΕΙΡΕΙΤΕ ΝΑ ΚΑΝΕΤΕ
ΕΠΙΣΚΕΥΕΣ ΜΟΝΟΙ ΣΑΣ.
Ο παρακάτω πίνακας περιέχει γενικές οδηγίες σχετικά με τη
διατήρηση τροφίμων στο ψυγείο.
Θέση ψυγείου Τύπος τροφίμου
Πόρτα ψυγείου • Τρόφιμα με φυσικά συντηρητικά,
όπως μαρμελάδες, χυμοί, ποτά,
καρυκεύματα.
• Μην αποθηκεύετε τρόφιμα που
αλλοιώνονται εύκολα.
Συρτάρι λαχανικών
(δοχείο σαλάτας)
• Τα φρούτα, τα βότανα και τα λαχανικά
θα πρέπει να τοποθετούνται ξεχωριστά
στο συρτάρι λαχανικών.
• Μην συντηρείτε μπανάνες, κρεμμύδια,
πατάτες και σκόρδα στο ψυγείο.
• Ράφι ψυγείου - κάτω
• Δοχείο ψύξης
Κρέας, πουλερικά, ψάρια (για
βραχυπρόθεσμη συντήρηση)
Ράφι ψυγείου - μεσαίο Γαλακτοκομικά προϊόντα, αυγά
Ράφι ψυγείου - επάνω Τρόφιμα που δεν χρειάζονται μαγείρεμα,
όπως τα έτοιμα για κατανάλωση τρόφιμα,
αλλαντικά, μαγειρεμένο φαγητό.
Συρτάρι/ράφι κατάψυξης • Τρόφιμα για μακροχρόνια συντήρηση.
• Κάτω συρτάρι/ράφι για ωμό κρέας,
πουλερικά, ψάρι.
• Μεσαίο συρτάρι/ράφι για κατεψυγμένα
λαχανικά.
• Επάνω συρτάρι/ράφι για παγωτά,
κατεψυγμένα φρούτα, κατεψυγμένα
ψημένα προϊόντα.
D55TW19G_IB_2L_RC_191022_grace.indb 10 22/10/2019 5:04 PM

11
ΠΡΟΕΙΔΟΠΟΙΗΣΗ
• Διατηρήστε τις σχισμές εξαερισμού στο περίβλημα της
μονάδας ή στην ενσωματωμένη μονάδα απαλλαγμένες από
εμπόδια.
• Μη χρησιμοποιείτε μηχανικές συσκευές ή άλλα μέσα για
να επισπεύσετε την διαδικασία απόψυξης, εκτός από τις
προτεινόμενες από τον κατασκευαστή.
• Μη χρησιμοποιείτε ηλεκτρικές συσκευές στο εσωτερικό των
θαλάμων φύλαξης τροφίμων της μονάδας, εκτός αν είναι του
προτεινόμενου από τον κατασκευαστή τύπου.
• Μην προκαλείτε βλάβη στο κύκλωμα ψυκτικού (Το ψυκτικό
είναι ένα πολύ φιλικό προς το περιβάλλον αέριο, που όμως
είναι εύφλεκτο. Να είστε προσεκτικοί κατά τη μεταφορά
ή μετακίνηση της συσκευής για να διασφαλιστεί ότι στο
κύκλωμα ψυκτικού δεν έχει προκληθεί βλάβη. Σε περίπτωση
βλάβης αποφεύγετε τις γυμνές φλόγες ή πηγές ανάφλεξης και
εξαερίστε το χώρο στον οποίο έχει τοποθετηθεί η μονάδα για
λίγα λεπτά.)
• Κατά την τοποθέτηση της συσκευής, βεβαιωθείτε ότι το
καλώδιο τροφοδοσίας δεν έχει παγιδευτεί ή υποστεί ζημιά.
• Μην τοποθετείτε πολλά φορητά πολύπριζα ή φορητές
συσκευές τροφοδοσίας στο πίσω μέρος της συσκευής.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ: Κίνδυνος πυρκαγιάς/εύφλεκτων υλικών
D55TW19G_IB_2L_RC_191022_grace.indb 11 22/10/2019 5:04 PM

12
GB
unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Fridge Freezer.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this installation/instruction
manual in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
The Main Unit
Salad Bin Cover Shelf
Fridge Glass Shelf x 2
Salad Bin
Upper Fridge Door Shelf
x 2
Egg Tray x 2
Instruction Manual
Ice Tray
Lower Fridge Door Shelf
Instruction
Manual
Freezer Glass Shelf
Upper Left Hinge
Cover
D55TW19G_IB_2L_RC_191022_grace.indb 12 22/10/2019 5:04 PM

GB
location
When selecting a position for your unit you should make sure the floor is flat and firm, and the
room is well ventilated with an average room temperature of between 16°C and 38°C. Avoid
locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight
as it may increase the electrical consumption. Extreme cold ambient temperatures may also
cause the unit not to perform properly. This unit is not designed for use in a garage or outdoor
installation. Do not drape the unit with any covering.
Y mm
X mm
levelling the unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
free space requirements
When installing the unit, ensure that 25 mm of free
space is left at both sides, 50 mm at the rear of
the unit and 25 mm at the top of the unit. The door
can be opened to the right or the left, depending on
which best suits the location.
Please ensure there is more than twice the width
and depth distance space of the unit to fully open
the door to a maximum angle.
13
installation
D55TW19G_IB_2L_RC_191022_grace.indb 13 22/10/2019 5:04 PM

GB
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe that
you are qualified to do so.
reversing the door swing
tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
1. Remove the upper hinge cover, screws and upper
hinge. Lift the upper door and place it on a padded
surface to prevent from being scratched.
2. Remove the stopper from the bottom of the
upper door and move it to the opposite side.
Screw tightly.
3. Remove the middle hinge. Lift the lower door
and place it on a padded surface to prevent
from being scratched.
Upper hinge cover has left and right side. The
upper hinge cover packed as an accessory is
for the left side.
Make sure that the two screw holes (stopper
and the bottom of the higher door) are
aligned while driving the screw.
14
installation
D55TW19G_IB_2L_RC_191022_grace.indb 14 22/10/2019 5:04 PM

GB
• DO NOT lay the unit flat as this may
damage the coolant system.
• During door reversal, when swapping
the position of the bottom hinge or
adjusting the levelling feet, tilt the
unit. Do not lay the unit flat.
4. Remove the stopper from the bottom of the
lower door and move it to the opposite side.
Screw tightly.
5. Remove both levelling feet and bottom
hinge. Swap their position.
6. Remove the middle hinge hole covers and
swap their position with the middle hinge.
Reverse the middle hinge.
Make sure that the two screw holes (the
stopper and the bottom of the lower door)
are aligned while driving the screw.
15
installation
D55TW19G_IB_2L_RC_191022_grace.indb 15 22/10/2019 5:04 PM

GB
Ensure the door is aligned horizontally and
vertically, so that the seals are closed on all
sides before finally tightening the hinge.
7. Place the bottom hole of the lower door onto the
bottom hinge pin. Insert the middle hinge pin into
the upper hole of the lower door. Tighten the pin
securely. Screw the middle hinge tightly. Cover
the remaining holes with the hole covers.
8. Reverse the upper hinge. Place the bottom hole
of the upper door onto the middle hinge pin.
Insert the upper hinge pin into the upper hole of
the upper door. Tighten the pin securely. Screw
the upper hinge tightly. Cover the upper hinge
with the upper hinge cover.
Ensure the door is aligned horizontally and
vertically, so that the seals are closed on all
sides before finally tightening the hinge.
16
installation
D55TW19G_IB_2L_RC_191022_grace.indb 16 22/10/2019 5:04 PM

GB
cleaning before use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water
using a sponge or cloth. Wipe completely dry before replacing the drawers. Clean the exterior of
the unit with a damp cloth.
If you require more information refer to the Cleaning section.
before using your unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time to
settle.
In some cases, the door seal may be crushed after prolonged storing pressure, resulting
to the door seal not able to close properly when reversed.
Follow the steps below to solve the issue:
1. Peel off the door seal from the upper or lower corner and
warm it with a hairdryer; the warmth can allow the door seal
to return to its original form. Do not blow directly on the unit
as the warmth may damage other parts of the unit.
2. Rotate the door seal upside down so that the side originally
with the hinge stay with the hinge.
3. Insert the door seal back into the door from the upper or
lower corner.
4. If the issue still occurs, contact your local service centre for
assistance.
180°
17
installation
D55TW19G_IB_2L_RC_191022_grace.indb 17 22/10/2019 5:04 PM

18
GB
product overview
main unit
Egg Tray Ice Tray
LED Light and
Thermostat
Control Dial
Salad Bin
Cover Shelf
Salad Bin
Fridge
Door
Shelf
Freezer
Glass Shelf
Fridge Glass
Shelf
D55TW19G_IB_2L_RC_191022_grace.indb 18 22/10/2019 5:04 PM

19
GB
operation
switching on your unit
1. Before connecting the unit to the mains supply make sure
that the thermostat control dial is set at position 0. Connect
the mains cable to the mains socket.
2. Adjust the thermostat control dial to the desired position,
bear in mind that the higher the number, the lower the
temperature. Position 2or 3or 4is the recommended setting
when operating at normal room temperature (between 16°C and 38°C).
3. The unit may not operate at the correct temperature if it is in a particularly hot or a particularly
cold room, or if you open the door often.
4. To ensure that the unit is cool enough to sufficiently chill your food, wait 24 hours before filling it
with food.
5. If you are concerned that your unit is not being kept cold enough and wish to check the
temperature, you will need a special fridge/freezer thermometer. These are available from
most supermarkets and hardware shops. Place the thermometer in either the fridge or freezer
compartment and leave overnight. The correct temperature for the fridge compartment should
be at the recommended 0-8°C. The correct temperature for the freezer compartment should be
-18°C or lower.
adjusting the temperature
The internal temperature of the unit is controlled by a thermostat. The recommended position is
between 1to 4for colder working environments (i.e. during winter) and between 5to 7for hotter
environments. Please adjust according to the environment.
noises inside the unit!
You may notice that your unit makes some unusual noises. Most of these are perfectly normal, but
you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not affect the performance of your unit. This is the compressor motor working, as it pumps the
refrigerant around the system.
tips for keeping food in the unit
• Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid
bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect juices
and cover it properly. Place the container on the lowest shelf.
• Leave space around your food, to allow air to circulate inside the compartments. Ensure all parts
of the unit are kept cool.
• To prevent transfer of flavours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
• Always let pre-cooked food cool down before you put in the unit. This will help to maintain the
internal temperature of the unit.
• To prevent cold air escaping from the unit, try to limit the number of times you open the doors.
We recommend that you only open the doors when you need to put food in or take food out.
D55TW19G_IB_2L_RC_191022_grace.indb 19 22/10/2019 5:04 PM

20
GB
preparations for freezing
• Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes
faster, takes less time to defrost and enables you to control the quantity you need better.
• Leave cooked food to cool completely. Chill food before freezing if possible.
• Consider how you will want to cook the food before freezing it.
• Don’t freeze food in metal containers if you may want to microwave it straight from the freezer.
• Use special freezer bags, freezer film, polythene bags, plastic containers, and aluminium foil
(heavy duty grade only). If in doubt, double wrap your food. Don’t use aluminium foil for acidic
foods, e.g. citrus fruits. Don’t use thin cling film, glass, or used food containers without cleaning.
• Exclude as much air from the container as possible. You could buy a special vacuum pump
which sucks excessive air out of the packaging.
• Leave a small amount of air space when freezing liquids to allow expansion.
• You can use the space in the freezer most efficiently if you freeze liquids (or solids
with liquids, e.g. stew) in square blocks. This is known as “Preforming”. Pour the
liquid into a polythene bag which is inside a square sided container. Freeze it, and
then remove it from the container and seal the bag.
• Label your frozen foods as they will look the same when in frozen state. Use
special freezer tapes, labels and pens with different colours. This allows you to
easily organise and to effectively use the freezer. Write the contents and date; otherwise the
frozen food might exceed the storage time and this could cause food poisoning. Please refer to
your food packaging for the recommended storage time.
• You may also add the weight and cooking notes, e.g. “defrost first”, “cook from frozen” and keep
a separate log of what is in each drawer. This will save opening the door and searching around
unnecessarily.
defrosting frozen food
1. Take the frozen food out from the freezer compartment and uncover the frozen food. Let it
defrost at room temperature. Don’t forget that defrosting in a warm area encourages the growth
of bacteria and low temperature cooking may not destroy dangerous bacteria.
2. Drain off and throw away any liquid lost during defrosting.
3. Always make sure there are no ice-crystals in the food before cooking, particularly with meat.
These crystals indicate that the food has not fully defrosted.
4. Cook food as soon as possible after defrosting.
5. Many microwaves and ovens have a defrost setting. To avoid bacterial build up, only use these if
you intend to cook the food immediately afterwards.
Never re-freeze anything that has been defrosted unless you cook it again, to kill off harmful
bacteria. Never re-freeze defrosted shellfish. Re-seal packs properly after removing items.
This prevents drying or freezer-burn and a build up of frost on any remaining food.
D55TW19G_IB_2L_RC_191022_grace.indb 20 22/10/2019 5:04 PM
