DELPHI GRUNDIG NAV210W User manual

Delphi NAV210W
2
Welcome
Thank you for purchasing the Delphi NAV210W Portable GPS Navigation System.
The Delphi NAV210W can play audio (mp3 or wav) files and video (avi) files as well
as display pictures (jpg, gif, png), enhancing the entertainment options in your
vehicle.
Use this manual to help install Delphi NAV210W in your vehicle, learn how to operate
it effectively and safely.
Contacting Technical Service Support
For additional information in solving problems with Delphi NAV210W, see Section 14
Troubleshooting.
This is the safety alert symbol. It is used to alert you to potential injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.

Operation Manual Delphi NAV210W
3
Warning:
DANGER OF ACCIDENT
When using your Delphi NAV210W in a vehicle, it is your sole responsibility to
install, secure, and use the device in a manner that will not cause accidents,
personal injury, or property damage, or in any manner obstruct your view or interfere
with the operation of vehicle safety equipment.
The user of this product is solely responsible for observing safe driving practices. Do
not operate your Delphi NAV210W while driving. Park the vehicle first. Do not use
the navigation system or entertainment features if it presents a risk to you or any
other person or if it is a distraction.
OBEY ALL TRAFFIC LAWS
The user is solely responsible for obeying the local traffic laws and observing all
road signs. Local traffic laws and actual traffic signs always have priority over the
information and directions received from the navigation system. The navigation
instructions might be inaccurate or incorrect due to detours and construction.
DELPHI DISCLAIMS ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A
WAY THAT MAY CAUSE ACCIDENTS, DAMAGE, OR THAT MAY VIOLATE THE
LAW.
Caution: To avoid overheating of the unit, do not leave Delphi NAV210W on
the dash or windshield while your vehicle is unattended, especially in strong
sunlight. Do not use or handle Delphi NAV210W while it is hot. Let it cool away from
heat sources before handling it.
* Microsoft and Windows are trademarks of Microsoft Corporation.

Delphi NAV210W
4
Table of Contents
Section 1 NAV 200 Introduction ·································································5
Section 2 Unpacking The Delphi NAV210W ··············································7
Memory Cards............................................................................9
Accessories and Replacement Parts .........................................9
Section 3 Installing Delphi NAV210W in Your Vehicle ·····························11
Section 4 Features and Controls······························································13
NAV210W Receiver Controls ...................................................13
Section 5 Getting Started ·········································································14
Powering Up.............................................................................14
Inserting a SD Card..................................................................15
Home Screen ...........................................................................16
Section 6 NAVI Mode ···············································································17
Section 7 Music Mode ··············································································18
Playing an Audio File................................................................19
Section 8 Movie Mode··············································································22
Playing a Video File..................................................................23
Section 9 Picture Mode ············································································24
Viewing an Image File ..............................................................25
Section 10 Game Mode··············································································26
Section 11 Calculator Mode ·······································································27
Section 13 Settings ····················································································29
Screen Settings ........................................................................29
Configure Settings....................................................................30
Section 14 Troubleshooting········································································31
DELPHI GRUNDIG Service .....................................................32
DELPHI EUROPEAN SERVICE CENTRES ............................32
Section 14 Features ···················································································34
Technical Information ...............................................................34

Operation Manual Delphi NAV210W
5
Section 1 NAV210W Introduction
For best results when using Delphi NAV210W:
• When the Delphi NAV210W is connected to power for the first time, leave it
connected for about two hours to charge the battery.
• Plan your route before your journey. If you need to set up a new itinerary en
route, safely park your vehicle before making changes.
• GPS signals cannot pass through solid materials other than glass. So when
you are inside a building or tunnel, GPS may not be available. Likewise,
signal reception can be affected by overhead cover such as trees. Wireless
devices may also interfere with signals, causing variable reception.
• While the Delphi NAV210W can be operated by finger touch, more precise
control can be achieved by using the stylus. Do not use other sharp objects,
which can damage the LCD screen.
• Never clean the Delphi NAV210W with the power on. Use a soft, lint-free
cloth moistened with water to wipe the screen and the exterior. Do not use
paper towels to clean the screen. Do not place anything on top of the Delphi
NAV210W. Do not drop the Delphi NAV210W or subject it to severe shock.
• Keep the Delphi NAV210W away from excessive moisture and extreme
temperatures. Do not subject the Delphi NAV210W to sudden and severe
temperature changes that could cause condensation inside. In the event of
moisture condensation, allow the Delphi NAV210W to dry out completely
before use.
• Always disconnect the receiver from the power supply when leaving the car
parked for a long period or when not using the system during travel. Failure
to do so could drain the vehicle’s battery as the Delphi NAV210W
continuously draws power, even when the power is off.
Warning: Never attempt to disassemble, repair, or make any modification to
the Delphi NAV210W. Doing so could result in personal injury, death, and/or
damage to the Delphi NAV210W and/or to your vehicle.

Delphi NAV210W
6
Warning: This device contains a non-replaceable lithium-ion internal battery
that can burst or explode, releasing hazardous chemicals.
To avoid risk of fire or explosion, do not attempt to replace the Delphi NAV210W
battery. The Delphi NAV210W battery is not user-replaceable.
To reduce risk of fire or injury, never disassemble, crush, puncture, or dispose of the
Delphi NAV210W in fire or water.
Warning: Never use the power adapter in a high-moisture environment, or
touch it when your hands or feet are wet. Make sure there is adequate ventilation
around the adapter when in use, and do not cover it with paper, vinyl, cloth
(including the carrying case) or any other material. The adapter must be connected
to the correct power source. Do not attempt to service the unit if its power lead or
body becomes damaged or exposed to excess moisture.
STORAGE PRECAUTIONS
Do not store the device anywhere it may be exposed to water or in conditions of high
humidity.
When the device is not in use for an extended period of time, bring it indoors and
store it in some location with a temperature range of +5 to +50 °C.
Caution: Keep SD cards in a well-protected case to avoid dust and humidity.
Make sure no foreign objects can enter the SD slot.
NOTE: This device is designed only for in-car use.

Operation Manual Delphi NAV210W
7
Section 2 Unpacking The Delphi NAV210W
Here’s what you should find in the Delphi NAV210W package:
1. The Delphi NAV210W unit with integrated GPS receiver
2. West Europe maps on SD card
3. Windshield mount with suction cup and dashboard mount.
4. In-vehicle charging cable

Delphi NAV210W
8
5. Stylus Pen
6. NAV210W CDs:
• Quick Reference Guide Navigation and Operation
• CD Containing:
- Destinator Console with map files, that can be preloaded to an SD
card if original becomes lost or damaged
- User manual for Navigation and Operation in Adobe Acrobat PDF
format
- Adobe Acrobat Reader software

Operation Manual Delphi NAV210W
9
Memory Cards
The Delphi NAV210W has 32 megabytes of internal memory available for the
operational system (Microsoft Wince Net Core version 4.2). SD (secure digital)
Memory cards are available for purchase and should be used to store other media
files such as video (avi), images (jpg, gif, png) and/or audio (mp3, wav) files.
An SD card can be plugged into the slot in the Delphi NAV210W and can be
purchased with various memory capacities. An SD card with 256 megabytes of
memory up to 2GByte can be used in the Delphi NAV210W. Delphi recommends the
use of following SD card brands: ExtremMemory, Kingston, Kingmax, Transcend,
and SanDisk.
Caution: Do Not ADD or DELETE files from the SD card containing the map
data.
Accessories and Replacement Parts
Only Delphi Grundig authorized accessories has to use with the device. The use of
incompatible accessories could result in bodily injury and/or damage to the device.
The use of unauthorized accessories will also void your warranty.
Never attempt to disassemble, repair or make any modification to the device. Refer
all repair needs to the local Delphi Grundig dealer.
You will be able to purchase the following items from Delphi Grundig.
• External GPS antenna: with MMCX connector; required if your
vehicle is fitted with a heat-reflective or heated windshield, or for
extra GPS performance in weak signal areas
• External Traffic Message Channel adaptor (optional)
• Vehicle mount kit: includes suction mount so you can transfer
the Delphi NAV210W to another vehicle easily
• 12 V vehicle power adapter: ideal when using Delphi NAV210W
in more than one vehicle
For further information, visit www.delphigrundig.com

Delphi NAV210W
10
ENVIRONMENTAL NOTE
This product has been made from high-quality parts and materials which can be re-
used and recycled. Therefore, do not throw the product away with normal
household waste at the end of its life. Take it to a collection point for recycling
electrical and electronic devices. This is indicated by this symbol on the product, in
the operating manual and on the packaging.
Please find out about collection points operated by your local authority.
Help protect the environment by recycling used products.

Operation Manual Delphi NAV210W
11
Section 3 Installing Delphi NAV210W in Your Vehicle
Warning: To avoid personal injury, follow the safety guidelines and installation
instructions provided so that the Delphi NAV210W does not obstruct the view of the
driver, interfere with the operation of any airbags and safety features in the vehicle,
or become airborne in the case of an accident. Do not attempt to install Delphi
NAV210W while driving.
Before installing the Delphi NAV210W, check whether your vehicle is fitted with a
heat-reflecting or heated windshield. If so, you will need to purchase an external
antenna from your retailer to allow your unit to pick up the GPS signals.
Note: Alternative-mounting options may be available for your vehicle make and
model. Contact your retailer or Delphi for more information.
Note: Some countries prohibit the mounting of any electronic device in any location
on the vehicle dashboard. Be sure to check the local laws for applicable mounting
before installing the car mount.
Note: In the state of California and Minnesota, it is necessary to use the dashboard
mount, according to state law.
To mount the suction mount to the windshield, follow these steps:
1. Flip up the GPS Antenna
2. Using the two tabs on the bottom of the
cradle, locate the Delphi NAV210W and
rotate rearward. While pushing in the two
grey release buttons, continue rotation
until unit is firmly seated in the cradle
3. Release the two grey buttons. Reverse
operation for unit removal.
4. Position suction cup firmly against
windshield at desired location.
5. Flip the lever towards suction cup. Unit is
now secure for operation.

Delphi NAV210W
12
To remove the suction cup, pull the lever up. Pull the release tab to release the
suction.
If the suction cup does not adhere, clean the mounting area of the windshield with a
cloth dampened with isopropyl alcohol. Let the area dry, and then reapply the suction
cup.
Car Mount Precautions
 The heating and cooling cycle of a vehicle’s interior will in some cases loosen
the adhesion of the suction cup.
 Check the vacuum seal of the car mount for adequate adhesion each time you
use the unit and reinstall it if necessary.
 If the car mount has problems staying on, clean the plastic suction cup with
alcohol, then reinstall. Moistening the suction cup may help adhesion in some
cases.
 To avoid extreme temperature from damaging the car mount, remove the unit if
the temperature inside your vehicle exceeds 70 °C.
 The dip in humidity and temperature at night may loosen the adhesion of the
suction cup. For this reason, as well as for security, it is recommended that you
remove both the car mount kit and the Delphi NAV210W when leaving your
vehicle overnight.

Operation Manual Delphi NAV210W
13
Section 4 Features and Controls
Warning: For your safety, program the Delphi NAV210W and enter information
about your destination BEFORE you start your journey. Do not operate Delphi
NAV210W while driving.
NAV210W Receiver Controls
1 Power On/ Off
2 Menu button
3 Bird view up
4 Bird view down
5 Flip up antenna
6 Screen saver mode
7 SD card slot
8 DC In Power connector
9 TMC Input jack
10 Touch Screen Stylus Pen
11 Headphone Jack
12 Volume Control

Delphi NAV210W
14
Section 5 Getting Started
Warning: For your safety, program the Delphi NAV210W and enter information
about your destination BEFORE you start your journey. Do not operate Delphi
NAV210W while driving.
Powering Up
Power on Press the Power button located on the
lower left side for at least one second.
Power off Press the Power button located on the
lower left side for at least one second.
Note: The Delphi NAV210W will continue to charge if connected to a 12 V power
jack even when powered down.
Enter screen saving mode Press Screen Saver Mode button. The
device continues to operate, but the
screen will appear blank.

Operation Manual Delphi NAV210W
15
Inserting a SD Card
Delphi NAV210W has a slot for Secure Digital (SD) cards located in the bottom.
Delphi NAV210W will accept SD cards containing digital maps or other data, such as
audio (mp3) files, movie (avi) files, or image (jpg, gif and png) files.
The Delphi NAV210W comes equipped with an preinstalled SD card. The card will
already be in position in the SD card slot, and ready to use for navigation.
If you choose to use a second SD card (separate purchase required) for music,
movie or picture viewing, remove the navigation system SD card by slightly pushing
the top of the card to release it, then pull it out of the slot.
Make sure the card is not in use before removing it.
Power off the unit, insert the new SD card with the label facing the front of the device,
and power the unit on.

Delphi NAV210W
16
Home Screen
The main menu offers eight options, each of which are detailed in the sections that
follow:
At any time you can return to this menu by pushing the Main Menu button or by
closing the current mode (accomplished by tapping the “x” in the upper right corner of
the screen).
NAVI - Starts up navigation functions.
MUSIC - Starts the music playback function
that enables playing mp3 and wav files.
MOVIE - Starts the movie Playback function
that enables playing avi files.
PICTURE - Starts the picture function that
enables viewing jpg, gif and png files.
SETTINGS - Starts the screen/environment
setting function.
W CLOCK - Starts the world time function that
enables viewing the time in different cities.
CALC - Starts the calculator function.
GAME - Starts the game function.

Operation Manual Delphi NAV210W
17
Section 6 NAVI Mode
For detailed operating information, please use the Destinator Navigation manual.
It is located on the Destinator Console.

Delphi NAV210W
18
Section 7 Music Mode
Warning: For your safety, DO NOT operate the Delphi NAV210W
entertainment features while driving. Movie and music (MP3) playing, picture
viewing, world clock, and calculator are intended for use while you are not driving
your vehicle.
DELPHI DISCLAIMS ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A
WAY THAT MAY CAUSE ACCIDENTS, DAMAGE, OR THAT MAY VIOLATE THE
LAW.
The Delphi NAV210W can playback audio files saved in mp3, and wav format on an
SD card. (Adding music, movies or pictures requires a higher capacity SD card not
included and the ability to download MP3 files from a computer. An SD card reader
may be required if your computer is not equipped with an SD card slot.)
When entering Music mode, the last file played is highlighted as “current.” If the last
music file does not exist on the SD card currently installed, the first file available on
the current card is listed.
Current Status Time Pla
y
ed/Total Time
Repeat
Previous Music
Current Music: If the name of the music file does not
appear completely in one line, the file name flows
from right to left.
Next Music

Operation Manual Delphi NAV210W
19
Playing an Audio File
Audio functions are controlled by tapping on the various buttons located on the
control bar in the lower half of the screen:
Play: Pressing the Play button plays the file listed at Current Music. The screen
will display current playback time and playback status. If a file is damaged, the
next file will be played without opening a popup screen.
If all files are damaged, a popup screen opens and all audio playback stops.
Pause: Playback stops temporarily. Current status is displayed as “Pause.” The
Play button is deactivated and the Pause button activated. The playback
indicator on the playback bar stops moving.
(Pause)
(Notice Pop-Up)

Delphi NAV210W
20
Stop: Playback stops. Current status is displayed as “Stop.” Current playing
time is displayed as “00:00:00.” If Previous or Next is selected during stop, only
the file name moves; playback remains stopped.
Repeat: Default is All Repeat mode. Tapping this option cycles through “All
Repeat > All Play > 1 Track Repeat > All Play.” The repeat setting remains
when Music mode is exited, and is saved for the next session.
Mute: Mutes all volume. Press again to turn sound on again.
Previous/Next: Tap the arrows or press the +/- buttons to select the next or
previous audio file in the list. If the file is damaged, Delphi NAV210W
automatically skips to the next available file.
All Repeat All Play 1 Track Repeat
(Mute is released) (Mute)
Mute

Operation Manual Delphi NAV210W
21
List: Displays the play list screen. The file currently being played is highlighted.
This screen allows you to scroll through your list of audio files, or arrange them
randomly or alphabetically. Press Play to play the highlighted file, or tap Cancel
to return to the previous screen.
(Random) (Alphabetical order)
File index where the focus is located/Total number
of files read.
Press this button for a while to move the focus
slowly line by line. Press and hold this button to
move the focus quickly by line.
The index of a file where the focus is
located in random order
The index of a file where the focus is
located in alphabetical order
The Random button
is pressed
