Kingwo MT02S+ User manual

March,2020
User Manual(MT02S+)
GPS Talks

Declaration
The contents of this manual might be updated from time to time
without prior notice; the updated content will be added to the new
version of this manual. Langocloud reserve the rights to update the
products or procedures described in the manual at any time. If there is a
description of the product in the manual that does not match the actual
product, the actual product shall prevail. Langocloud owns the final
interpretation rights of this manual.
GPS Talks

Contents
Chapter 1: Photo ................................................................... 1
Chapter 2: Product Feature ........................................................... 2
Chapter 3: Technical Specification ..................................................... 3
3.1 Main Unit ................................................................. 3
Chapter 4: Functions ................................................................ 4
4.1 【Basic function-Tracking function】 .......................................... 4
4.1.1Timely tracking, speed upload and distance upload(Default is timely upload) ...... 4
4.1.2 Blind area data storage (Default ON) ................................... 4
4.1.3 Cornering Compensation (Default ON) .................................... 5
4.1.4 LBS (Default OFF) ..................................................... 5
4.1.5 AGPS (Default ON) .................................................... 5
4.2 【Basic function-Alarm function】............................................ 5
4.2.1 Low Voltage Alarm (Default ON) ......................................... 5
4.2.2 Over speed alarm (Default OFF) ......................................... 5
4.2.3 Driving behavior alarm (Default OFF) ..................................... 6
4.2.5 Turn over alarm(Default OFF) ........................................... 6
4.2.6 Vibration alarm (Default OFF) ........................................... 6
4.2.7 Towing alarm (Default OFF) ............................................ 6
4.2.8 Wire cut off alarm (Default ON,can not be disabled) ......................... 6
4.2.9 Air condition status detect and SOS (Default ON) ............................ 7
4.2.10 GPS error alarm (Default ON) .......................................... 7
4.3 【Basic function-Intelligent function】 ........................................ 7
4.3.1 Power Save (Default 5 mins after static status) ............................. 7
4.3.2 Self-Diagnosis (Default ON) ............................................. 7
4.3.3 Static Drift Suppression (Default ON) ..................................... 8
4.3.4 Mileage Calculation (Default ON) ........................................ 8
4.3.5 Remote Configuration (Default ON) ...................................... 8
4.3.6 Remote Upgrade (OTA) (Default ON) ..................................... 8
4.3.7 Dual IP or Domain (Default ON) ......................................... 8
4.3.8 GT220 protocol (Default ON) ............................................ 9
Chapter 5: Installation guide ......................................................... 10
5.1 Installation Diagram ..................................................... 10
5.2 Installation and debugging process ......................................... 11
5.2.1 SIM installation ..................................................... 11
5.2.2 Main unit power on .................................................. 11
5.2.3 Parameter setting by SMS .................................................. 11
5.2.4Recommended Installation place ........................................ 16
5.2.5 Software ............................................................... 16
GPS Talks

1
Chapter 1: Photo
GPS Talks

2
Chapter 2: Product Feature
1、 Support GPS/Beidou, AGPS, LBS,with accurate position performance；
2、 Built in high sensitive G-sensor accelerometer
3、 Driving behavior monitor
4、 Supports intelligent self-diagnosis, intelligent power save mode, remote fuel and
power cut off, AC detection or SOS,OTA and alarm functions
5、 Small in size and wide voltage, especially designed for scooter, motorcycle,
electric vehicles and automotive financial risk control project
6、 Small and convenient for conceal installation
7、 Support Kingwo,GT220 protocol and JT808 protocol
GPS Talks

3
Chapter 3: Technical Specification
3.1 Main Unit
Physical
Dimension 82mm*23mm*13mm
Weight 28g
Cellular
GSM module Fibocom G500GL
Frequency
Working Frequency: 850/900/1800/1900MHz
Network protocol: Embedded TCP/IP stack
Sensitivity: -107dBm@850/900MHz
-106dBm@1800/1900MHz
Output power: Class 4 (2W)@850/900MHz
Class 1 (1W)@1800/1900MHz
GPRS data: GPRS Class 10, Mobile Station Class B
GPS
Channels: 50
Sensitivity: -147dBm
Position accuracy:5-10m
Accuracy: 5m CEP
Cold start: <27s
Hot start: <1s
Power
Input voltage 9-100V
Battery NI-MH AAA 3.6V/90mA, 2 hours working time
based on 2-3 minutes upload
Power
consumption
Average Current: <30mA (DC 12V)
Maximum current: <10mA (DC 12V)
Interface
Digital input(2) Ignition detect and Air condition status detect
Digital output(1) Relay
GSM antenna Internal High Gain
GPS antenna Internal High Gain
SIM Microsim
Indicator 2 status LEDs, Green: GPS, Red: GSM
Memory 1300 pcs
Environmental
Parameter
Working
Temperature -20℃ ~ +70℃
GPS Talks

4
Humidity 5% ~ 95% (no fog)
Ingress Protection
Rating IP65
Chapter 4: Functions
4.1 【Basic function-Tracking function】
Including timely upload, blind zone compensation, speed mileage statistics, area
monitoring and other functions, the backend sends positioning commands, and the
device uploads data including longitude, latitude, speed, direction, and status
information.
4.1.1Timely tracking, speed upload and distance
upload(Default is timely upload)
The device can be set to upload the position and vehicle status information to the
backend at a certain time or a certain period or at a certain time interval.
The device can be configured to send packet at a certain distance
The device can be also configured to send packets when it detects a certain speed
change.
4.1.2 Blind area data storage (Default ON)
When the vehicles enters the GPRS blind area, the device will store the GPS data
upon 15s interval, the track data will be saved at the shortest 15S interval, those
data will be uploaded to the backend server once GPRS network recovered,
minimum 1000 pcs of data can be stored.
GPS Talks

5
4.1.3 Cornering Compensation (Default ON)
If the device detects that the vehicle driving direction has certain angular
deviation(default 15 degrees), the device will upload a packet extra to make sure the
driving trace is more accurate.
4.1.4 LBS (Default OFF)
If GPS is not available, the device will automatically switch to LBS mode, and acquire
the LBS each 30s and upload the based information, the server shall interprets the
specific location on the map, please to use this function, it would require your server
software support LBS function.
4.1.5 AGPS (Default ON)
The device supports AGPS, once the device is connected to GPRS, the AGPS can be
used to speed up the positioning and improve accuracy,
Important notice: if your SIM card has IP access limitation, we strongly suggest
you to whitelist the below IP for AGPS access: 119.23.233.52
4.2 【Basic function-Alarm function】
4.2.1 Low Voltage Alarm (Default ON)
When the battery voltage on the vehicle is too low (0-11V or 19-22V), device will
report a low voltage alarm to the backend
4.2.2 Over speed alarm (Default OFF)
When the vehicle speed is higher than the preset alarm value, the device will notify
the backend. Similarly, when the vehicle speed is lower than preset alarm value, a
low speed alarm will be uploaded to the backend, this value is configurable.
GPS Talks

6
4.2.3 Driving behavior alarm (Default OFF)
The device is built in with G-sensor, which can detect collision, hard deceleration,
hard acceleration and sharp turn alarm
4.2.5 Turn over alarm(Default OFF)
If someone turn over the device, it will report an alarm.
4.2.6 Vibration alarm (Default OFF)
The device supports vibration alarm, 10 minutes after the ignition off (Arm range
1-20 minutes), the device generates vibration (Delay range 1-10 mins) without ACC
connected, the device will upload vibration alarm.
4.2.7 Towing alarm (Default OFF)
An alarm is generated when the device is set to a displacement of more than 100
meters (message mode prompt), and the alarm information is reported when the
displacement radius exceeds 100 meters when the device is turned off. (Note:
displacement range 100~2000m).
The device will send SMS if the vehicle is moved in ignition off status, if the radius is
more than 100 meters, will upload towing alarm (Towing range:100-2000m).
4.2.8 Wire cut off alarm (Default ON,can not be disabled)
The device is allowed to connect a power off relay for power and fuel cut off
function in case a car stolen happens, a command can be sent to the device to
remote cut off the fuel and power , please note only the preconfigured center
number can send such command .
GPS Talks

7
4.2.9 Air condition status detect and SOS (Default ON)
This device has an extra wire for detecting the air condition status (On/Off) in the
cars or connecting a SOS for emergency alarm, when connect SOS, please make sure
1 wire is connected to the white wire of the device, and another wire is connected to
the red power wire of the device .
4.2.10 GPS error alarm (Default ON)
When the device detects that the GPS/BD module is working abnormally, it reports
the GPS receiver failure alarm to the backend.
4.3 【Basic function-Intelligent function】
4.3.1 Power Save (Default 5 mins after static status)
The device has a built-in high-sensitivity G-sensor accelerometer that monitors the
vehicle for motion in real time. When no motion is detected for a long time, the
device automatically enters the power saving state, meanwhile turns off the GPS/BD
module, and GSM enters the heartbeat return mode. In this state, the power
consumption of the device is extremely low, which can save power consumption
from the vehicle battery.
4.3.2 Self-Diagnosis (Default ON)
The device can perform self-diagnosis. In case there is malfunction regarding GPS
and GSM, it will report error message to the backend, and the backend .The backend
can query the current model, version, configuration, running status, and device
functions.
GPS Talks

8
4.3.3 Static Drift Suppression (Default ON)
The device has a built-in high-sensitivity G-sensor accelerometer and a complete
positioning data-filtering algorithm that filters out most of the static drift data to
ensure the accuracy of GPS data.
4.3.4 Mileage Calculation (Default ON)
Mileage data is calculated based on the speed from GPS, The vehicle mileage data is
uploaded to the backend along with the vehicle positioning data; the initial mileage
can be configured when initially the device is set up.
4.3.5 Remote Configuration (Default ON)
To remote set device parameters including IP, center number and various of
monitoring parameters via the backend or SMS.
4.3.6 Remote Upgrade (OTA) (Default ON)
As long as GPRS is connected, remote firmware upgrade can be done remotely, if
your SIM card needs to has IP access limitation, we strongly suggest you to
whitelist the below IP for OTA function: 119.23.233.52
4.3.7 Dual IP or Domain (Default ON)
The device supports dual IP connection between the primary server and the standby
server. The default connection is the primary server. If there is a problem with the
primary server, the device automatically switches to the standby server. The primary
server and the standby server can be set in either IP or domain name.
GPS Talks

9
4.3.8 GT220 protocol (Default ON)
The device is compatible with GT220 protocol, if customer already integrate this
protocol, no extra integration is required.
GPS Talks

10
Chapter 5: Installation guide
5.1 Installation Diagram
Green LED Status：
Solid on ：GPS fix
Blinks：LBS fix
Off: Not fix
Switch
SIM card
Red LED Status：
Fast Blink：GPRS Connecting
Slow Blink：GPRS connected
Solid on
：
Module Error
Red: Connect power+
Black: Connect power-
Orange: ACC
Yellow: Relay output
White:Air condition and SOS
GPS Talks

11
5.2 Installation and debugging process
5.2.1 SIM installation
Open the top cover of the device, insert the prepared SIM card into the SIM
cardholder, and then confirm that the SIM card button is in place. Please make sure
that the SIM card has the GPRS function enabled in advance and know the SIM card
number.
5.2.2 Main unit power on
After installing the SIM card, turn the battery switch to the ON position. At this time,
the red light starts to blink, indicating that the device is power on
5.2.3 Parameter setting by SMS
Note: The device is with unique ID number, the factory can preset t IP, port and APN, generally
do not need to do parameter setting; if you need to modify the IP, follow the below instructions,
make sure the SIMs has SMS functions available:
APN,apn,user,pswd#
Set APN, User name and password
For example：APN,CMNET,internet,internet#
APN:CMNET
Username: internet
Password: internet
IP,ip or dns,port,type#
Set IP, port and communication type of primary server
IP,119.23.233.52,6000,1#
Set the primary server IP:119.23.233.52，port 6000，communication type:TCP
IP,www.365qczx.com,6000,0#
Set the primary server domain:www.365qczx.com，Port 6000，communication type
GPS Talks

12
UDP
IP2,ip or dns,port,type#
Set IP, port and communication type of backup server
IP2,119.23.233.52,6000,1#
Set the backend server IP:119.23.233.52,port 6000，communication type is TCP
IP2,www.365qczx.com,6000,0#
Set the backend server domain:www.365qczx.com，port 6000，communication type:
UDP
IP2,,0,0# Delete backend server parameter
HC,<T1>,<T2>,<T3>#
Set the upload interval in real time tracking mode:
T1: upload interval in ignition on status, range,5-300s ,default 120s
T2: Upload interval in ignition off status
,range 5-300 s, default 120 s
T3：Sleep return interval, range 10-1800 s, default 180
For example:
HC,30,90# Set the upload interval as 30s in ignition on and 90s in ignition off
HC,30,90,300# Set the upload interval as 30s, 90 s in ignition off and 300s while in
sleep mode
MINDISTANCE,C#
Set upload intervalaccording to distance :
C,distance,Unit：meter , when C=0 means function OFF
Example:
MINDISTANCE,200# Upload data each 200 meter
MINDISTANCE,0# Turn off this function
MINSPEEDDELTA,V#
Set data upload according to speed difference
V， Speed change value，Unit：km/h, 0 indicates this function off
Example:
Protocol Switch: Kingwo Protocol:Protocol,1#
GT220 protocol: Protocol,3,1#
JT808 protocol: PROTOCOL,2,2#
UTC,TTTT#
Set time zone:
unit minutes, default UTC+8:00
For example:
UTC,480# Time zone UTC+8:00
UTC,330# Time zone UTC+5:30
UTC,-480# Time zone UTC-8:00
UTC,-210# Time zone UTC-3:30
GPS Talks

13
WY,<A>[,R,M]#
Set towing alarm:
A: On and off，1:On 0:Off
Default is off
R: Towing radius，Default 500 meters，Range：100-2000 meters
M: Alarm mode，Optional
M=0:GPRS,M=1:SMS+GPRS
Eg：WY,1,100,1# towing alarm on，radius 100 meters notification mode:GPRS+SMS
LEVEL,S#
Set Vibration sensitivity:
S: Sensitivity 1/2/3/4/5 indicates, highest/high/middle/low/lowest
LEVEL,1# Sensivity: Higest
LEVEL# Query
ZD,<A>[,M]#
Set vibration alarm:
A=1:Vibration alarm ON A=0:Vibration alarm off Default is off
M: Alarm mode，M=0 Only GPRS,M=1:SMS+GPRS
Example:
ZD,1,1#， Vibration alarm ON, notification mode: GPRS+SMS
ZD,0# Vibration Alarm Off
ZD#
CORNER,A#
Set cornering compensation angle:
Default is 15 degree, value range 5-180 degree
CORNER,15#
CORNER,0#(Delete cornering upload function)
XM,tttt#
Set enter sleep mode time while in static status:
Default is 5 minutes
XM,5# Sleep after 5 mins without vibration
XM,0# Disable sleep mode function
XM# Query
Query IMEI/ICCID/IMSI IMEI#
ICCID#
Set blind data storage ON
and Off，A=1 Off；A=0 ，
Default ON
BLIND,1# Turn off blind data storage function
BLIND# Query
*44*6DDDDD# Set initial mileage:
Unit KM, range 0-999999km
*44*61000#，Initial mileage is :1000Km
GPS Talks

14
SPEED,V,T#
Set speeding threshold and duration time
V: Speeding threshold：0-255km/h,0 is disable speeding alarm
T:Duration time, value range >=5 seconds, default is 5 seconds:
Example:
SPEED,50,5# Speed threshold is 50km/h，duration time: 5 seconds
SPEED# Query
VACC,v#
Set ACC detect mode:
v, voltage critical value，unit is :0.1V
v=0，Detect ACC status by ACC signal wire
v=131，Detect ACC status via vibration and voltage, voltage critical value is 13.1V
Example:
VACC,0# Detect ACC status by ACC signal wire
VACC,131# Detect ACC status via vibration and voltage, voltage critical value is 13.1V
VACC# Query
UPGRADE,IP/domain,port,
version#
OTA,IP/domain,port,versio
n#
OTA command:
UPGRADE,119.23.233.52,7771,MT02S-4.12#
OTA,www.365qczx.com,7771,MT02S-4.12#
UPGRADE,0# Exit upgrade
UPGRADE# Query upgrade status
*25*#
Query OTA Status:
eg:192.168.1.1:8000,T;T8G-1.5;Wireless upgrade request succeed ,downloading data
now!
COLLISION,N#
Set collision class :
N indicates value range 0,10-3000
Default is 0: Disable the collision alarm
Example:
COLLISION,1000# collision class is :1000
COLLISION# Query
TURNOVER,A#
Set turn over angle :
value range is :0-180
Default is 0: Disable the turn over alarm
Example:
TURNOVER,90#
TURNOVER# Query
GPS Talks

15
DRIVING,A,V1,V2,T#
Set driving behavior parameter
A: Sharp turn，value range 0-180，default is 0: disable
V1: hard acceleration ，value range 0-255，default is 0: disable the function
V2:hard deceleration，value range 0-255， default is 0: disable the function
T:Hard deceleration and acceleration time，1-30，default is 4 seconds
Example:
DRIVING,15,30,50,4#
Direction changes exceedes 15°, indicates the vehicle is in sharp turn status
30km/h Speed increased 30km/h within 4 seconds, indicates vehicle is in hard
deceleration status,
50km/h Speed reduced 50km/h, indicates the vehicles in hard deceleration status ,
DRIVING#
LBS,A#
Set LBS ON and OFF:
，A=1 ON ；A=0 OFF，Default is off
Example:
LBS,1# LBS ON
LBS,0# LBS OFF
LBS# Query
LOCKACCOFF,A#
Set vehicle lock logic :
A=0 Receive lock command, execute immediately
A=1 Receive lock command, if ACC is off, execute immediately, if ACC is on, store
this command until ACC off
A=2 Store the command, lock vehicle from ACC Off to On, if the communication is
well, lock vehicle, otherwise wait for next turn
For example：LOCKACCOFF,0# means execute the lock command immediately after
receiving it
*22*2# Lock vehicle
*22*3# Unlock vehicle
*77*0number# Set center No.1
*77*2 number# Set center No.2
*11*1# Query center No.
*11*2# Query longitude and latitude
*11*3#
Query device status Eg:
Online: IP1 CMNET,119.23.233.52:6000,T ID: 80222001633,id GPS=A,5;GSM=20
MT02S-4.12.128.10 2019-08-06
*22*1# Restore to factory setting
*22*4# Reboot device
GPS Talks

16
5.2.4Recommended Installation place
5.2.5 Software
Web-based software: www.365qczx.net
Smart phone Application: Track Sense
MT02S+ usage requirements
GPS Talks

17
The device is strictly forbidden to use according to the operating instructions ,disassemble,
collide, charge, soak, over 80 °C, human failure, force majeure damage, etc. may cause short
circuit, insufficient working time, battery deformation, liquid leakage, explosion, no warranty and
compensation will be provided by Kingwo
Contact us at:
Kingwo IoT Co.,Ltd
www.kingwoiot.com
Email：[e-mail]
GPS Talks
