DELTA DORE TYMOOV SET User manual

EN Programming console for Tymoov motors
TYMOOV SET

3
EN
2
Contents
1/ Recommendations.....................................................................................3
2/ Description ...................................................................................................3
3/ Connection / Setting of the stops ........................................................5
4/ Troubleshooting.......................................................................................10
5/ Technical specications ........................................................................10
EN
DANGER!
Risk of death by electrocution in case of contact with the electrical components.
- Theconneconofthetubularmotortotheprogrammingconsole,andalsothenalconneconofthe
tubularmotortotheelectricalnetwork,mayonlybeperformedbyaceredprofessionalelectrician.
-Conneconworksmayonlybeperformedwhentheinstallaonisdisconnectedfromthepowersupply.
- Completelydisconnecttheelectricalsupplyandsecureittopreventreconnecon.
- Checkthattheinstallaonisnotsuppliedwithpower.
Use in accordance with the intended purpose
OnlyusetheprogrammingconsoleforthesengorcorreconofthelimitswitchesforTYMOOVtubular
motors.
Non-compliant use
Neverusetheprogrammingconsoleforthefollowingoperaons:
- Connuouscontrolofatubularmotor..
- Conneconandcontrolofotherelectricalreceivers
Recommendations1/ Recommendations
2/ Description
Theprogrammingconsoleisintendedforthecommissioning,adjustment,andthecorreconofthelimit
switchesofTymoovtubularmotors.
BuonA DireconofrotaonI/II+Stop
BuonB Programmingbuon
BuonC Buondedicatedtotheunusedgreywire
BuonA
BuonB BuonC

4 5
EN
Tymoov FB Tymoov FE
❶Onlyconnectthemotorcablestotheconsole
withoutacontrolpointorintermediary
❷Supplypowertotheconsolebyconnecngthe
plugtothemainsoutlet
❸Sengstops
Automac Notaccessible 1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.
2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.
Semi-automac Notaccessible
1st stop in automatic mode
SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.
2nd stop in manual mode
SetbuonAtoposionIorII,applyingtheoppositesengtothe1stautomacstop.
Whenthemotorstartsup,pressbuonBtwicebriey,andholda3rdpressunlyoureachthedesired
posion,withoutreleasing.
Ifnecessary,ne-tunebypressingbrieyonbuonB.
Set button A to STOP: the stops are saved.
Manual
SetbuonAtoposionIorII,dependingonthe
desireddireconofrotaon.
Setthestopsonthemotorusingtheadjusng
screws(seeinstruconsforthemotor)
Note: do not touch button B
1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.
Then,brieypressbuonBtwiceandholdthe3rdpressunlthedesiredposionisreached,before
releasing.
Ifnecessary,ne-tunebypressingbrieyonbuonB.
2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.
Then,brieypressbuonBtwiceandholdthe3rdpressunlthedesiredposionisreached,before
releasing.
Ifnecessary,ne-tunebypressingbrieyonbuonB.
Set button A to STOP: the stops are saved.
❹Disconnecttheconsole
-Removetheplugfromthemainsoutlet
-Disconnectthemotorconneconcord
-Reconnectthetubularmotor
tothemainssupply(seeinstrucons).
Brown
Blue
Grey
Yellow / Green Black
Brown
Blue
Grey
Yellow / Green Black
3/ Connection / Seing of the stops

6 7
EN
3/ Connection / Seing of the stops
Tymoov F2
❶Onlyconnectthemotorcablestotheconsole
withoutacontrolpointorintermediary
❷Supplypowertotheconsolebyconnecngthe
plugtothemainsoutlet
❸Sengstops
Automac
1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.Oncethestophas
beenreached,themotorwillbrieyacvateonce.
2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop.Oncethestopis
reached,themotorwillbrieyacvatetwice.
Semi-automac
Dependingontheinstallaonofthemotorandtheshuer,determinewhetherbuonsIandIIcontrolraising
(^)orlowering(v).
1st stop: SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon.Oncethestophas
beenreached,themotorwillbrieyacvateonce.
2nd stop: SetbuonAtoposionIorII,applyingtheoppositesengtothe1ststop(*).
Oncethestopisreached,posionbuonAtoSTOP.
Forthetopstop:performthefollowingsequenceusingshortpresses(<1second)onbuonA:^-Stop-^-
Stop,thenhold^unlthemotoracvatestwice.
Fortheboomstop:performthefollowingsequenceusingshortpresses(<1second)onbuonA:v-Stop-v
-Stop-v-Stop,thenholdvunlthemotoracvatestwice.
Manual
Dependingontheinstallaonofthemotorandtheshuer,determinewhetherbuonsIandIIcontrolraising
orlowering.
SetbuonAtoposionIorII,dependingonthedesireddireconofrotaon(*).
Oncethestophasbeenreached,togglebuonAtotheStopposion.
StorethetopstopbyperformingthefollowingsequencewithbuonA:^-Stop-^-Stopthenhold^.
Tostoretheboomstop,performthefollowingsequencewithbuonA:v-Stop-v-Stop-v-Stop,then
holdv.
Themotoracvatesoncewhenmemorisingtherststop,andtwiceforthe2nd.
❹Disconnecttheconsole
-Removetheplugfromthemainsoutlet
-Disconnectthemotorconneconcord
-Reconnectthetubularmotortothemainssupply(seeinstrucons).
(*)Possibleacvaonofstepwisemode(slowmovement)
Forthetopstop,performthefollowingsequencewithbuonA:^-Stop-v-Stop,thenhold^.
Fortheboomstop,performthefollowingsequencewithbuonA:^-Stop-v-Stop,thenholdv.
Brown
Blue
Grey
Yellow / Green Black

8 9
EN
Tymoov RE2/RP2
❶Onlyconnectthemotorcablestotheconsole
withoutacontrolpointorintermediary
❷Supplypowertotheconsolebyconnecngthe
plugtothemainsoutlet
Whenswitchedonfortherstme,withbuonAinposionI:
themotorwillaquickcycletowarnthatnotransmierispaired.
Themotorisautomacallysettopendingpairingfor5minutes.
❸Sengstops
Automac
1st stop: BuonAatposionI,pressbuonBfor2secondstoacvatethemotor.Whenthemotorhas
detectedits1ststop(toporboom),itacvatesonce.
2nd stop: pressbuonBfor2secondstoacvatethemotor.Whenthemotorhasdetectedits2ndstop,it
acvatestwice.
Thestopsarememorised.
Semi-automac
1st stop in automatic mode:
BuonAatposionI,pressbuonBfor2secondssothatthemotoracvates(ifthedireconofrotaon
doesnotcorrespondtothestopthatyouwishtoset,brieypressbuonB,thenpressbuonBonceagain
for2secondssothatthemotoracvatesagain,intheoppositedirecon).Oncethestophasbeenreached,
themotorwillacvateonce.
2nd stop in manual mode:
BuonAalwaysinposionI,pressbuonBfor2secondstoacvatethemotor.
BrieypressbuonBtostopatthedesiredposion.
Forthetopstop,perform2shortpressesonbuonB,thenalongpress(longerthan2seconds).
Fortheboomstop,perform3shortpressesonbuonB,thenalongpress(longerthan2seconds).
Themotoracvatestwicetoconrmthatthe2ndstophasbeenmemorised.
Manual
BuonAtoposionI.
PressbuonBfor2secondsunlthemotoracvates.
Tostopthemotor,brieypressbuonB.
Fortheboomstop,perform3shortpressesandalongpress(>2seconds)onbuonB.
Forthetopstop,perform2shortpressesandalongpress(>2seconds)onbuonB.
Themotoracvatesoncewhenthe1ststophasbeenstored.
Tosetthe2ndstop:repeattheprocedurefromthestart.
Themotorwillacvatetwicetoconrmthatthe2ndstophasbeensaved.
❹Disconnecttheconsole
-Removetheplugfromthemainsoutlet
-Disconnectthemotorconneconcord
-Reconnectthetubularmotortothemainssupply(seeinstrucons).
Brown
Blue
Grey
Yellow / Green Black
Black
Brown
3/ Connection / Seing of the stops

10
4/ Troubleshooting
Youwishtosetthestopsagain.
Youmustrsterasetheexisngstops.
Tymoov FE
PressbuonB,thensetbuonAtoposionIorII.
Aer5seeconds,themotorbrieyacvatesonce.
Thestopshavenowbeendeleted.
Tymoov F2
-Lowertheshuercompletely,
-SetbuonAtoSTOPwithin5secondsoftheshuerstopping,
-Then,performthefollowingsequenceofpresses:v-Stop-v-Stop(<3secondsbetweeneachpress),
thenpressandholdv.
Themotorbrieyacvatestwice.The2stopsareerased.
OR
-Settheshuertothetopposion,
-SetbuonAtoSTOPwithin5secondsoftheshuerstopping,
-Then,performthefollowingsequenceofpresses:^-Stop-^-Stop(<3secondsbetweeneachpress),then
pressandhold^.
Themotorbrieyacvatestwice.The2stopsareerased.
Tymoov RE2/RP2
BuonAatposionI,
pressbrieyonbuonBtomovethemotortowardsitstoporboomstop.
Inthe5secondsfollowingthestoppingoftheshuer,setbuonAtoSTOPandwaitfor10seconds.
Then,whileholdingbuonBpresseddown,togglebuonAtoIandonlyreleasebuonBwhenthemotor
acvatestwice.
Thestopsarenowerased.
• Operating voltage: 230 V / 50 Hz
• Max. power : 6 (4) A / 250 V AC
• Operating temperature: 0 à 40 °C
• Storage temperature: -10°C to +60 °C / Max. air humidity 90 %
• Protection rating: II
• Cable length: 2.88 m
5/ Technical specifications
