Deltatherm PCK-RGP User manual

PCK-RGP
CO Series Power Connection Kit for Roof and Gutter
Delta-Therm Corporation 6711 Sands Road Ste A, Crystal Lake, IL 60014 www.delta-therm.com 800-526-7887
CA_SR_PCK-RGP_2002_DSII
DESCRIPTION
PCK-RGP allows you to make electrical connections for
all CO Series CBT self-regulating heating cables used
in roof and gutter applications. The kit contains the
necessary materials (except weather-tight junction box)
for one power connection and two end terminations.
A. Heat Shrink Sleeve .75” x 6” (2 x 15cm) (2)
B. Shrink Sleeve .125
” x 5.5 ” (.3 x 14cm) (2)
C. Yellow/Green Shrink Sleeve .25
” x 5.5 ” (1 x 14cm)
D. Ring Connector
E. Ground Screw
F. Heat Shrink Sleeve .5” x 1.5” (1 x 11cm)
G. Heat Shrink Cap .5” x 1.5” (1 x 11cm) (2)
H. Connector Assembly .5”*
I. .5” (1cm) Sealing Locknut
Additional compression fittings with 1/2” sealing locknut are available.
A
G H
I
E
B CF
D
Detail 1.
CONNECTING TO POWER
1. Attach connector assembly to the Junction Box through
a .5" (1cm) NPT fitting.
2. Prepare cable per directions.
3. Insert cable through sealing fitting and tighten compo-
nents into place.
4. Connect heating cable leads to power wire leads.
Ground braid cold lead to ground wire or to grounding
screw with ring terminal.
5. Install water tight cover.
Overjacket Braid
Innerjacket
Conductive Core
Bus Wires (16AWG)
SR CABLE CUTAWAY

Detail 2. Slide sealing fitting components
to position at core sealer.
CABLE PREPARATION
1. Slide connector compression ring
and grommet onto heating cable.
2. Score and remove 6.5" (17cm)of
the black overjacket to expose the
braid.
3. Carefully separate 6.5" (17cm)
of braid back to overjacket. Then
twist the braid into a cold lead.
4. Remove 6" (15cm) of innerjacket
from the end exposing the black
conductive core.
5. Cut inner core and separate back
to the innerjacket. Remove cover
material from bus wires. Retwist
bus wires.
6. Install .125" x 5.5" (.3 x 14cm)
heat shrink tubes over bus wire
and shrink.
7. Core Sealer: Install .5" x 1.5" (1
x 4cm) heat shrink tube over bus
wires and innerjacket. Shrink and
while still hot pinch with pliers
between bus wires to seal.
8. Slip green/yellow tube over braid
and shrink. Trim to remove tapered
end.
9. Slide sealing fitting components
to position at core sealer.
10.Install sealing fitting into junction
box.
11. Insert heating cable through seal-
ing fitting and tighten components
into place.
12.Connect heating cable leads to
power wire leads. Ground braid
cold lead to ground wire or to
grounding screw and ring terminal.
13.Install weathertight cover.
Detail 4. Connect heating cable leads to power
wire leads. Ground braid cold lead to ground wire
or to grounding screw and ring terminal.
Detail 3. Insert heating cable through sealing
fitting and tighten components into place.
END CAP TERMINATION
1. Score and remove 3" (8cm)of the
outer jacket from the end of the
heater.
2. Slide the braid back from the end
of the heater and cut about 1.5"
(4cm) squarely off the end of the
heater, making sure the conductors
are not in contact with each other.
3. Slide a heat shrink cap over the
end of the heater allowing 1" (3cm)
to cover the heater.
4. Apply heat to shrink the sleeve
around the heater. Heat until glue
begins to flow from cap.
5. Slide the braid over sealed shrink
sleeve and twist end of braid into
a cold lead.
6. Slide the .75" x 6" (2 x 15cm) long
piece of shrink sleeve over the
braid so that .5" (1cm) extends out
past the end of the cold lead.
7. Apply heat to shrink the sleeve
around the heater and braid. While
the sleeve is still hot, squeeze
with needle nose pliers and hold
together until cool to seal the
shrink sleeve end. If end does not
remain visibly sealed when pliers
are re moved, repeat this seal-
ing step. The end must remain
visibly sealed when the pliers are
removed.
WARNING: This kit and the cable used with it must be installed by a qualified electrician. All as-
sembly, installation, and test instructions must be followed. Improper installation can result in prop-
erty damage, serious injury, and/or death due to electric shock and fires. Please call Delta-Therm
Corporation at 1-800-526-7887 with any installation or operating questions.
WArNINg
Delta-Therm Corporation 6711 Sands Road Ste A, Crystal Lake, IL 60014 www.delta-therm.com 800-526-7887
CA_SR_PCK-RGP_2002_DSII
