Deltatherm PCK-C6 User manual

WARNING: This kit and the cable used with it must
be installed by a qualified electrician. All assembly,
installation, and test instructions must be followed.
Improper installation can result in property damage,
serious injury, and/or death due to electric shock and fires.
Please call Delta-Therm Corporation at 1-800-526-7887
with any installation or operating questions.
DELTA-THERM Corporation, 6711 Sands Road Suite A, Crystal Lake, IL 60014 [phone] Fax [phone] [phone]
A. Heat Shrink Sleeve .375” x 6” (1 x 15cm)
B. Cable Connector Assembly
C. Standoff Bracket
D. High Temp Fiberglass Tape (60" x 1/2")
E. Heat Shrink Sleeve .5” x 1.5” (1 x 11cm)
F. Ground Screw
G. Closed-End Crimp Connectors (2)
H. Ring Connector
I. .75” Sealing Locknut
J. Heat Shrink Sleeve .25” x 1.5” (.5 x 11cm)
K. Heat Shrink Sleeve .125” x 2.5” (.3 x 6cm)
L. Caution Labels (6) Small
TOOLS NEEDED
•Crimping Tool
•Wire Stripper/Cutter
•Utility Knife
•Flat-Blade Screwdriver
•Needle-Nose Pliers
•Adjustable Wrench
•Heat Gun (750F)
•Measuring Tape
A
BC
D
F
EG
H
I
J
K
L
Installation Instructions
PCK-C6
Power Connection Kit:
CO Series for Pipe Tracing
CONNECTING TO POWER
For Braided Cable
1. Remove 6" (15cm) of any optional overjacket.
2. Push the braid back to loosen it.
3. Approximately 6" (15cm) from the end of the
cable, spread the braid strands to create an
opening.
4. Bend the cable at the opening, then pull the cable
through the opening to free the braid.
5. Twist the braid into a cold lead, then trim the cold
lead to remove the tapered end.
Detail 1.
6. Insert the cable through the connector cap, the gland
washer, and the grommet, leaving 4” (10cm)
exposed from the end of the rubber grommet.
Detail 2.
continued....

Detail 3.
Score and remove 1.75” (5cm) of the jacket to expose
the black core.
Shave the black material from the bus wires along the
edges of the core, then cut away the center material
to free the bus wires.en cut a
Cut the .125” x 2.5” (.3 x 6cm) piece of shrink sleeve
in half. Slide the sleeves over each bus wire,
leaving .5"(1cm) of bus wire exposed. Apply heat to
shrink the sleeves.Slide a .5” x 1.5” (1 x 4cm) shrink
sleeve over the two bus wires so that .75” (2cm)
covers the cable body and .75” (2cm) covers the bus
wires. Apply heat to shrink the sleeve. While the
sleeve is still hot, use needle-nose pliers to squeeze
the sleeve between the bus wires. To ensure a
watertight seal, hold the pliers in place until the sleeve
cools.
Using a pipe strap (not supplied), fasten the standoff
bracket to the pipe.
Insert the connector body through the bracket, then
attach the junction box (not supplied) to the connector
body.
Push the cable through the connector body, moving
the grommet, the gland washer, and the connector
cap to the connector body. Then tighten the cap to the
body.
Attach the non-insulated ring connector to the cold
lead, then use the grounding screw to attach the ring
connec-tor to the standoff bracket.
Using the closed-end crimp connectors, connect the
bus wires to 14 AWG power feed wires.
Push the connection into the junction box, then attach
the gasket and cover.
7.
8.
9.
10.
15.
14.
11.
12.
13.
PCK-TT and PCK-C6 Installation Instructions continued...
Cable With Braid
1.Slide the braid back from the end of the cable and
squarely remove 1
.5” (4cm) from the end of the cable,
ensuring that the conductors do not touch each other.
2. Slide a 0.5” x 1.5” (.64 x 4cm) shrink sleeve over the
end of the cable, covering only 1” (3cm) of the cable.
3. Apply heat to shrink the sleeve. While the sleeve is still
hot, use needle-nose pliers to squeeze the end of the
sleeve. To ensure a watertight seal, hold the pliers in
place until the sleeve cools.
4. Slide the braid over the shrink sleeve, then twist the
end of the braid into a cold lead.
Cable With Braid And Overjacket (CO)
1. Score and remove 3” (8cm) of the overjacket from the
end of the heater.
2. Slide the braid back from the end of the cable and
squarely remove 1.5” (4cm) from the end of the cable,
ensuring that the conductors do not touch each other.
3. Slide a .25” x 1.5” (.64 x 4cm) shrink sleeve over the
end of the cable, covering only 1” (3cm) of the cable.
4. Apply heat to shrink the sleeve. While the sleeve is
still hot, use needle-nose pliers to squeeze the end of
the sleeve. To ensure a watertight seal, hold the pliers
in place until the sleeve cools.
5. Slide the braid over the shrink sleeve, then twist the
end of the braid into a cold lead.
6. Slide the 0.5” x 6” (1 x 15cm) shrink sleeve over the
braid, leaving .5” (1cm) extending beyond the end of
the cold lead.
7. Apply heat to shrink the sleeve. While the sleeve is
still hot, use needle-nose pliers to squeeze the end of
the sleeve. To ensure a watertight seal, hold the pliers
in place until the sleeve cools.
ATTACHING THE CABLE TO PIPE
1. Using fiberglass tape, attach the cable to the
pipe at one-foot intervals.
2. After the pipe has been insulated, attach a
caution label in a visible location near the
standoff bracket and at frequent intervals along
the heat-traced pipe.
TECHNICAL SUPPORT
Please call Delta-Therm Corporation at 1-800-526-7887
with any installation or operating questions.
WARNING
WARNING: This kit and the cable used with it must
be installed by a qualified electrician. All assembly,
installation, and test instructions must be followed.
Improper installation can result in property damage,
serious injury, and/or death due to electric shock and
fires. Please call Delta-Therm Corporation at 1-800-
526-7887 with any installation or operating questions.
[phone] Fax [phone] [phone]
DELTA-THERM Corporation, 6711 Sands Road Suite A, Crystal Lake, IL 60014
CA_SR_PCK_C6_1910_II
