Tripp Lite B118-304-R User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: B118-304-R
HDMI Splitter, 4-Port
Highlights
Supports video resolutions up to 1080p
HDCP compliant
Connects to both HDMI and DVI-D Single-Link displays
ATC certified
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases
Description
Tripp Lite's HDMI Splitter allows the digital signal from a Blu-Ray player or other HDMI device, to be displayed on multiple HDMI or DVI-D Single
Link monitors. Up to 64 displays can be connected by cascading up to three levels of additional splitters. Splitters can be located up to 100 ft. away
from the video source using a combination of Tripp Lite long length HDMI cables ( P568-050, P568-100-HD ) and a HDMI Signal Booster
(B122-000-60 or B123-001). Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.
Applications
Retail, Classroom, Movie Theaters...anywhere a HD signal needs to be broadcast to multiple digital dispays
Package Includes
B118-304-R 4-Port HDMI Splitter
External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Mounting Hardware
Owner's Manual
Features
Supports video resolutions up to 1080p
HDCP compliant
Supports 3D, Lip-Sync Pass Through, and CEC Pass Through
Connects to both HDMI and DVI-D Single-Link displays
Cascade up to three levels of splitters to support up to 64 displays
ATC certified
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Specifications
OVERVIEW
Display Style Splitter
Model Type HDMI Splitters
CONNECTIONS

Connector A
HDMI (FEMALE)
Connector B
(X4) HDMI (FEMALE)
Number of Connectors 5
Ports 4
WARRANTY
Product Warranty Period
(Worldwide)
1-year limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Video Cables & Adapters P568-006 6-ft. HDMI Gold Digital Video Cable
(HDMI M/M)
1
Video Cables & Adapters P568-006-FL 6-ft. Flat HDMI Gold Cable
(HDMI M/M)
1
Video Cables & Adapters P568-006-RA2 6-ft. HDMI Gold Right-angled Digital Video Cable
(HDMI-RA M/M)
1
Video Cables & Adapters P568-006-SW 6-ft. HDMI Gold Cable with Swivel Connectors
(HDMI M/M)
1
Video Splitters B118-302-R HDMI Splitter, Ver 1.3b, 2-Port 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=4020.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
