Denon DRA-397 User manual

DRA-397
AM/FM Stereo Receiver
Multi Source / Multi Zone Audio Video Receiver features XM ready and,
iPod control and command capability
The DRA-397 AM/FM receiver offers high-performance operation, functionality and affordability, all in a single unit. It includes a Video Select feature that lets
you control a variety of video and audio signals, a set PRE OUT jacks that lets you listen to music in a sub-room as well as the main room, and it
supports room-to-room remote control. Denon is well known for its uncompromising approach to sound quality and the DRA-397 is no exception thanks to
the meticulous Denon-developed circuitry and the Signal Level Divided Construction (SLDC) chassis that prevents mutual interference among the circuits.
■ High-quality Power Amplifier
With 80 watts of power per channel (at 8 ohms, 20 Hz - 20 kHz, 0.08% THD), the
DRA-397 delivers solid, reliable audio performance even when driving both A and B
speaker systems at the same time.
■ Signal Level Divided Construction Chassis Design
The circuit handling low-level signals has been divided into separate blocks to
ensure that influences from these signals on each other are held to an absolute
minimum. This new chassis design, known as the Signal Level Divided
Construction (SLDC), preserves the purity of the signal, allowing it to be repro-
duced with much greater fidelity and clarity.
■ Multi Source / Multi Zone
The DRA-397 has 2 source / 3 zone capability. Dedicated multi-room outputs, with
volume level adjustment via remote control, are provided for connection to powered
speakers or an additional amplifier in Zone 2 and Zone 3.
• Zone 2 output : Analog audio L/R, Composite Video
• Zone 3 output : Analog audio L/R, Composite Video
■ Custom Integrated
• Remote in/out IR command control
• Discrete Power on/off command
• IR off, panel lock mode
■ Pre-memory remote and Zone remote
Pre-memory remote for main zone can control TV, SAT, Cable, and zone remote can
be switched for zone 2 or zone 3 to control power, function, volume control.
■ Subwoofer output
■ Video Select Functin
Allows you to select a video source, and then select an alternate audio input source,
ideal for simulcasting, as well as watching TV sports programs while listening to radio
commentary.
■ ASD-1R Control Dock for iPod®(option): Supports iPod playback
when connected to the DRA-397
iPod (*1) playback can be enjoyed through the DRA-397
when the ASD-1R, Denon's original Control Dock for iPod
(sold separately), is connected to the dedicated control ter-
minal of the DRA-397. The iPod can also be controlled via
the remote controller supplied with the DRA-397.
*1) Supports 3rd-generation and later iPods equipped with a Dock connec-
tor. Some functions may not work depending on the generation of the iPod
and the version of the software.
Please visit http://blog.denon.com/asd-1r/
for more details on compliant models and connection procedures.
■ XM Mini-Tuner Ready*
*Optional XM Mini-Tuner and subscribes are required.
■ 56-Station AM/FM Random PresetMemory Tuning
■ Auto Preset Memory
FM stations can be searched by the tuner, and automatically stored in the preset
memory up to 56 stations, ideal for locales with many FM stations.
■ Pure Direct mode, for the pure enjoyment of music in high-quality sound
■ Fast up/down manual tuning
■ Manual step tuning
■ Last-channel-tuned memory
■ Loudness Function
■ Tone Defeat
■ Muting Function via remote controller
■ A/B Speaker Switching
■ Last Function Memory
■ 3 AC outlets
Black version is also available.

Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone] ca.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone] usa.denon.com
Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi, Kanagawa, 210-8569 Japan
www.denon.com
16820806 A
DRA-397
Specifications
Power Amplifier Section
Rated output 80W+80W (8 ohms, 20Hz - 20kHz, 0.08 % THD)
Frequency response 10 Hz - 100 kHz +0 dB, -3 dB (at 1W)
Preamplifier Section
Input sensitivity/impedance
Phono 2.5mV/47kohms
CD, CD-R/Tape, DVD/VDP, VCR, V.AUX
200mV/47kohms
Output level/Load impedance
Zone2, Zone3 1.2V/47kohms
RIAA deviation +/- 0.5dB(20Hz - 20kHz)
Total harmonic distortion 0.009% (-3dB at rated output, 1 kHz)
Tone control Treble: ±10 dB at 10 kHz, Bass: ±10 dB at 100 Hz
FM Section
Tuning frequency range 87.5 - 107.9 MHz
Usable sensitivity 1.0 µV (11.2 dBf)
S/N ratio (A-weighted) Mono: 77 dB, Stereo: 73 dB
Total harmonic distortion Mono: 0.15%, Stereo: 0.3%
Frequency response 20 Hz - 15 kHz, +0.5, -1.5 dB
Stereo separation 43 dB (1 kHz)
AM Section
Tuning frequency range 520 - 1710 kHz
Usable sensitivity 18 µV
General
Power supply AC 120 V, 60 Hz
Power consumption 3.4 A
Dimensions 434 (W) x 147 (H) x 417 (D) mm
17.1” (W) x 5.8” (H) x 16.4” (D)
Weight 9.4 kg, 20.7 lbs
* Design and specifications are subject to change without notice.
