Depco 801 User manual
800 Series
1-800-767-1062 www.depcoinc.com
801: Video Workstation
Hardware List:
Qty. Item
20 #8 Sht Mr Screws (5/8)
28 - Black Screws
5 #6 Black Flat Head Screws ( )
1 Powerstrip
2 Wire Channels
4 Castors (2 Lockable - 2 Unlockable)
Step 1:
Attach small angle iron. (One to each leg.)
Step 2:
Attach lower side bra ings.
Legs
Step 3:
Attach top bra ing.
Step 4:
Attach bottom bra ing to the sides. Front brace
should have a chrome
sleeve on it.
Small Angle
Iron
Legs
Small Angle
Iron
Side Bracings
Legs
Small Angle
Iron
Side Bracings
Top Bracing
Legs
Bottom
Bracings
Top Bracing
800 Series
801: Video Workstation
Step 7:
Attach the upper work surfa e with #8 screws.
Step 8:
Attach the lower work surfa e with #8 screws.
Note: After attaching lower work surface, tighten
all the hardware.
Legs
Step 5:
Attach asters, screwing them all the way in.
Step 6:
Rotate to its upright position and attach the angle
iron bra ing.
1-800-767-1062 www.depcoinc.com
Casters
Angle Iron
Bracing
Legs
Bottom
Bracings
Top Bracing
Upper Work
Surface
Bottom
Bracings
Legs
Upper Work
Surface
Bottom
Bracings
Lower Work
Surface
800 Series
801: Video Workstation
Step 9:
Attach the ba king. Make sure that the backing is
flush with the top bra ing. Pre-drill the frame using
holes in back and attach using #6 screws.
1-800-767-1062 www.depcoinc.com
We give experiences.
PO Box 176 | 3305 Airport Dr. | Pittsburg, KS 66762 | 1-800-767-1062 | Fax: 316-231-0019 | [email protected]
Backing
Upper Work
Surface
Legs
