Design by Mr. K ONE LPS LPS-06 User manual

High Quality Linear Power Supply With
Anti-Common Mode Noise
Model No.: ONE LPS LPS-06
Owner's Manual

Warning
1)Installation and service should be performed only by
qualified and experienced technicians and comply with all local codes and rules to
maintain your warranty.
2) To reduce the risk of fire or electric shock, do not expose
the product to rain or moisture.
3) Do not apply benzene or thinner to the case, which may
cause the surface of unit to be melted or fogged.
4) Avoid operating or storing the unit in the following locations:
Extremely humid, dusty, or hot/cold environments
(recommended operating temperature: 0°C to +20°C)Close to
sources of powerful radio or TV transmitters.
Get Started
This user manual is designed as a reference for the installation and
manipulations of the unit including the product’s features,
functions. Please read this manual thoroughly and save it for
future use before attempting to connect or operate the unit. The
reader is supposed to be able to get the following information in this manual.
1) Product Overview: the main functions and system requirements.
2) Installation and Connection: instructions on unit installation and wire
connections.
3) Administration and Configuration: the main menu navigation and controls
explanations.
P.1

CE Statement
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. The manufacturer declares that the unit
supplied with this guide is compliant with the essential protection requirements of EMC
(2014/30/EU) Directive and General Product Safety (2014/35/EU) Directive.
Pack Contents
1) ONE LPS LPS-06 x 1pc
2 ) 13A AC Power Cable x 1pc
3 ) 2.1mm > 2.1mm DC Power Cable x 4pcs
4 ) 2.5mm > 2.5mm DC Power Cable x 2pcs
5 ) 2.1mm > 3.5mm DC Socket Adapter x 1pc
6 ) 2.1mm > 4.0mm DC Socket Adapter x 1pc
7 ) 2.1mm > 4.8mm DC Socket Adapter x 1pc
8) Owener's Manual x 1pc
Important Safety Instructions
Note: Please read the following instructions carefully before
operating your ONE LPS LPS-06.
If any issue occurred as below,please cut off any wire connected
to ONE LPS LPS-06 immediately .
1) Water or other liquid is flowed into the inside of unit .
2) Unusual sound came out from the unit .
DON'T OPEN OR REMOVE ANY PARTS
Don't open the cover of ONE LPS LPS-06 to expose the electronic components
inside , and no any parts can be repaired by user .
NOTE :
the ONE LPS LPS-06 is an equipment for industry , it should be worked under 20°C
room temperature , and when loaded over 50% full loading , recommended operating
environments with very good ventilated equipment cabinet or compartment & place this
device over 10cm next to surround objects . otherwise , it may be shutdown by going to
over temperature protect mode .
P.2

AC Mains Voltage
Make sure the 115V/230V Voltage Selector switch on the ONE LPS LPS-06 rear plate is
set for the correct AC line(mains) voltage before you plug in the power cord. It can be
seriously damaged if this switch is set for the wrong AC mains voltage.
In the 115V position the ONE LPS LPS-06 can safely operate with AC Line voltages
between 110-125V which is correct for North America, Mexico, and Taiwan. In some
countries, such as Brazil, AC voltages differ by region. Most other countries require
setting it to 230V. With the 230V setting the ONE LPS LPS-06 can operate safely with
AC line voltages between 220-250V. If the AC Voltage Selector is changed the rear
panel fuse value must also be changed. The ONE LPS LPS-06 operates on 50Hz or
60Hz AC.
AC Power Cord
The AC cord supplied with your ONE LPS LPS-06 is a high quality IEC type cord.
Please connect it directly to an AC wall outlet or power conditioner that is always
“live.” If possible, plug your ONE LPS LPS-06 and other components,
(including a TV or video projector) the ground potential may be higher or lower
between the outlets, resulting in audible hum .
Connections
Always disconnect the AC cord to your ONE LPS LPS-06 before making or
changing any input, output or connections. Inserting or removing an input or
output cable while the ONE LPS LPS-06 is turned on damage your equipment.
Make sure there is no strain or tension on any cables that could cause them to
pull loose.
NOTE :
An ONE LPS LPS-06 or other equipments that has been
damaged by wrong connection to the incorrect AC
mains voltage or select wrong output voltage/current
is not covered by our company warranty.
P. 3

Installation Instructions
Please read through the following instructions for the first-time installation.
Placement
Place the ONE LPS LPS-06 near to the source, input or output
components when connecting your LPS-06 to the system.
That can minimize the negative effects of long cable connections .
NOTE :
Don't connect too many equipments at the same
output channel , maybe damaged any unit connected . It's not
covered by our company warranty.
• DO NOT attempt to place any heavy objects (> 3kg) on top of this device.
• DO NOT attempt to repair this device. If repair is needed, please contact us.
Contact details are listed in the last session.
• DO NOT expose this device to extremely high or low temperatures.
• DO NOT operate this device with the cover removed.
• DO NOT allow any liquid to contact the device.
• DO NOT use this device without authorizations. Keep it away from children
• DO NOT place this device within 10cm next to the isolation transformer or power
amplifier.
• Place the ONE LPS LPS-06 on a surface that will adequately support its weight.
• Use input and output cables that are long enough to leave some slack; that will enable you
to pull the ONE LPS LPS-06 out of a cabinet to check or to change connections without
inadvertently disconnecting cables.
• The ONE LPS LPS-06 should never be placed in a completely enclosed cabinet.
• Always position the ONE LPS LPS-06 horizontally.
• The ONE LPS LPS-06 should never be stacked directly above another power amplifier and
power supply or directly below another component.
• Do not install the ONE LPS LPS-06 in an unventilated equipment cabinet or compartment.
Pockets of stagnant hot air can build up even in a cabinet with an open front and back. A
ventilation fan is recommended to prevent “hot spots” in confined spaces.
Introduction Of The High Quality Linear Power Supply
With Anti Common Mode Noise ONE LPS LPS-06
Our company thanks you for purchasing the High Quality Linear
Power Supply With Anti Common Mode Noise ONE LPS LPS-06 .Our
ONE LPS LPS-06 is of a high quality range and a breakthrough in the
design of Linear Power Supply With Anti Common Mode Noise.
Its performance can satisfy all music lovers. Please be informed of its key features below.
P.4

Specifications
Output Voltage and Current:
Zone I: 5V/7V/9V/12V, 2 A.
Zone II: 5V/9V/15V/19V, 4A.
Zone III:12V/15V/19V/24V, 6A.
Zone IV:12V/15V, 10A.
Zone V: 5V/7V,/9V/12V,2A.
Zone VI:12V/15V/19V, 4A.
Applications:
1. Equipment for industry.
2. Machine protection.
3. Measurement devices, test gear.
4. Medical environment.
Ripple Noise : <-65dB
Power Requirement :
Standby: 25 Watt
Maximum: 650 Watts
Casing : IRON
Dimension Lx W x H (mm) :
265 x 420 x 114mm
Weight :
Net Weight : 12.30KG
Gross Weight :14.80KG
•6 Channels Voltage Output With Wide Range
Output Voltage and Current:
Zone I: 5V/7V/9V/12V, 2 A. Zone II: 5V/9V/15V/19V, 4A.
Zone III: 12V/15V/19V/24V, 6A. Zone IV: 12V/15V, 10A.
Zone V: 5V/7V/9V/12V, 2A. Zone VI: 12V/15V/19V, 4A.
•Multichannel Voltage Output Set Up
Available to customize the status of Power On , such as Power On/Off programmed
& the brightness of Meter Panel back light can be programmed to adjust .
When power on your ONE LPS LPS-06 first time , turn on the o/p
channel selected by you , then press & hold PROG switch button
about 2 seconds , lighting on PROG blue LED indicator , press
PROG switch button again after 1 second , PROG blue LED off and
complete the unit power on set up customized .
P.5

• Meter Panel Brightness Control Mode
When main power on ,the meter panel lamp & LED lighting on with 100%brightness ,
the brightness changed to 80% after pressing DIM button once , and then changed
to 10% after pressing DIM button once again ; and the meter panel lamp lighting on
with 100% brightness & LED off when press DIM button 3
rd
, the meter panel lamp
brightness changed to 80% & LED off after pressing DIM button once again and
then changed to 10% & LED off after pressing DIM button again , and going to
another status with the meter panel lamp off & LED on 100% brightness when press
DIM button again , and then LED on 80% brightness with the meter panel lamp off
after pressing DIM button again and LED brightness changed to 10% & the meter
panel lamp off when press DIM button again , and the meter panel lamp & LED all off
after pressing DIM button once again ,
and return to first state with the meter panel lamp & LED lighting 100% brightness
when press DIM button again .
• Advanced Version
Advanced Version Advanced Version
Advanced Version W
WW
W ith
ithith
ith Automatic Learning
Automatic Learning Automatic Learning
Automatic Learning F
FF
F unction
unctionunction
unction
The unit with 6 outputs , the fifth & sixth O/P are controlled by
main power switch on/off and the first to fourth o/p can be controlled by program .
Turn on the 2
nd
o/p blue LED , then program blue LED on after press & hold the PROG
switch button about 2 seconds , the program schedule : turn on the 3
rd
o/p blue LED
first and then turn on the 1
st
o/p blue LED, the fourth o/p is no output with red
LED on , then press PROG switch button again to end program with program blue
LED off . In this case , the 1
st
,2
nd
,3
rd
, fifth & sixth are with output and the fourth no
output , and the 1
st
& 3
rd
is no output when press
PROG switch button once , and the 1
st
& 3
rd
is with output when
press PROG switch button once again . Thus the 1
st
& 3
rd
o/p can be controlled by
PROG switch button , but the 2
nd
o/p is on & fourth o/p is off always , the case is
same as when main power switch OFF and then ON .
P.6

• All Output Turned On Mode
Turned on all o/p indicator blue LED first , and then press & hold
PROG switch button 2 seconds to finish the unit programmed ,
all o/p with all blue LED indicator lighting on even though main
power switch OFF & then ON .
Warranty and Contact Details
The ONE LPS LPS-06 is covered by a two years warranty plan from the date of
purchase under normal circumstances.
•Warranty Coverage
The warranty provided by our company in this statement applies only
to product purchased from our authorized distributors and authorized resellers.
Warranty coverage commences from the date of purchase.
Our company warrants the Product according to the following terms:
a) Against defects in material or workmanship only, but not Product
appearance.
b) not the cost of shipping or transportation for maintenance.
•Warranty Limitations
This warranty shall not apply when:
a) Defects caused by the operation outside the usage parameters
stated in the owners manual.
b) malfunctions caused by misuse or abuse, improper installation,
operation or maintenance, improper connections or peripherals, use
of spare parts not from this company, service modifications or repair
performed by a person not authorized by us or other conditions
unrelated to defects in Product material or workmanship.
c) Malfunctions or failure caused by accidental or intentional damage.
d) Defects resulting from normal wear and tear.
P.7

•Contact Details
If you believe you need warranty service, please contact us through the
following means:
Telephone: [phone]
Fax : [phone]
E-mail : [email protected]m
Facebook: https://www.facebook.com/Design-by-Mr-K- 386812875128890
Website : www.designbymrk.com
Preliminary instruction manual.
Data changed without notice.
Date: 1
rd
September 2022. Version 1.1
Design by mr.k
P.
P.P.
P.8
88
8
