DeskMakers Narrative Wall And Table User manual

   
 

Materials Needed:
For Monitor Wall Assembly
1. Bolt, ¼”-20 x 3-1/2”L, HEXHD Full Thread, 8 pieces
2. Nut, ¼”-20, 8 pieces
3. Lock Washer, ¼”, 8 pieces
4. Washer, ¼”, 8 pieces
5. Grommet, 2.5” Black, 3 pieces
6. Grommet, 1” Black, 4 pieces
For Worksurface Assembly
7. Screw, No. 14 x 1-1/2”L, Pan Head, 18 pieces [Not for securing worksurface]
8. Screw, No. 10 x 1”L, Pan Head, 30 pieces [For securing bracket onto worksurface]
For Securing Monitor Wall Assembly onto Wall Structure
9. Screw, No. 8 x 1-3/4”L, Flat Head, 12 pieces
10. Bracket, ¾” x 5”L, Black, 2 pieces
    

Secure with Screws, #14 x 1-1/2”L
PNH, 14 places
Center Bracket from side to side
Align Bracket to top of Edge of
Lower Base

         
 

Bottom Wall
Level, horizontal
Level, vertical
         


NOTE: Due to the substantial weight of the assembled unit, it is best to assemble at the location
where it will be used.
Level, vertical
Level, horizontal
Metal Base
Secure with
Screws, ¼-20 x
1-1/2”L PNH, 2
places, 2
Locations

FRONT VIEW
BACK VIEW
             

Secure with
Screws, ¼-20 x
3-1/2”L HEXHD,
4 places, 2
Locations

            
  

Level
Level
Table Top
Secure with
Screws, #10 x
1”L PNH, 14
places

            


Secure with
Screws, #10 x
1”L PNH, 8
places
Spanning Rods,
Secure with
Screws, #10 x
1”L PNH

     

Secure with
Screws, #8 FLH,
6 places each
bracket
