Introduction
Congratulations on selecting the Solution Ultima control panel to protect you and your
property. So that you can obtain the most from your unit, we suggest that you take the time
to read through this manual and familiarise yourself with the numerous outstanding
operating features of this system. You will notice that in all aspects of planning, engineering,
styling, operation, convenience and adaptability, we have sought to anticipate your every
possible requirement.
Programming simplicity and speed have been some of the major considerations and we
believe that our objectives in this area have been more than satisfied.
This manual will explain all aspects of operating the control panel. All system parameters
and options are detailed; however, suitability is left up to the individual. Every system can
be tailored to meet all requirements quickly and easily.
Notice To All Owners
It is recommended that you test the sirens, strobe and zones at weekly intervals. Refer to
Testing on page 23 for further information.
6Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Keypad Indicators
Figure 1: CP5 Eight Zone
LED Keypad
Figure 2: CP5 Eight Zone
LCD Keypad
The Keypad is the communications interface between you and your alarm system. The Keypad allows you to
issue commands and offers both visual and audible indications that guide you through the general operation.
The Keypad incorporates numerous indicators. There are zone indicators that are used to show the condition of
each zone and four others for general status. The following pages outline a list of situations and the relevant
indicators that will be seen.
Zone Indicators
The zone indicators (1-8) are used to display the status of the zones. The following table
lists the various circumstances that the indicators will display (i.e. Zone Closed / Zone
Open).
Zone Indicator Definition
On Zone Is Open
Off Zone Is Closed
Flashing Fast
(0.25 Sec On/0.25 Sec Off) Zone Is In Alarm Condition
Flashing Slow
(1 Sec On/1 Sec Off) Zone Is Manually Omitted Or Selected To Be Omitted
Table 1: Zone Indicator
AWAY Indicator
The AWAY indicator is used to display that the system is Set in AWAY Mode. The AWAY
indicator will also flash in unison with the STAY indicator when programming various
options throughout the operator’s manual.
1 2 3 ….
Solution Ultima Operators Manual 7
Detection Systems Operators Manual UK

Refer to page 10 for information on the different methods of setting the system in AWAY
Mode.
AWAY Indicator Definition
On System Is Set In AWAY Mode
Off System Is Not Set In AWAY Mode
Table 2: AWAY Indicator
8Solution Ultima Operators Manual
Operators Manual UK Detection Systems

STAY Indicator
The STAY indicator is used to display that the system is Set in STAY Mode 1 or STAY
Mode 2. The STAY indicator will also flash in unison with the AWAY indicator when
programming various options throughout the operator’s manual.
Refer to page 11 for information on the different methods of setting in STAY Mode 1. For
information and the method of setting in STAY Mode 2, refer to page 12.
STAY Indicator Definition
On System Is Set In STAY Mode 1 Or STAY Mode 2
Off System Is Not Set In STAY Mode 1 Or STAY Mode 2
Flashing Twice A Second Zone Omitting Mode Or Setting STAY Mode 2 Zones
Flashing Once Every
3 Seconds Day Alarm Status – Day Alarm Turned On
Table 3: STAY Indicator
System Unset
This indicator will display with the indicator when the system has been Unset.
MAINS Indicator
The MAINS indicator is used to display that the systems AC mains supply is normal or has
failed.
MAINS Indicator Definition
On AC Mains Power Normal
Flashing AC Mains Supply Has Failed
Table 4: MAINS Indicator
Off Indicator / Zone Closed
The indicator will display when the system is in the Unset state and will flash when a
zone becomes Open during the Unset state. The indicator will stop flashing when all zones
are Closed.
On Indicator / Zone In Alarm
The indicator will display when the system is Set in AWAY Mode and will flash when
an alarm occurs. The indicator will reset once a valid user code has been entered.
Solution Ultima Operators Manual 9
Detection Systems Operators Manual UK

FAULT Indicator
The FAULT indicator is used to display that the system has detected a system fault. Refer to
Fault Analysis Mode on page 17 for additional information on system faults.
Every time a new system fault has been detected (eg. FAULT indicator flashing), the
Keypad will begin to beep once every minute. Pressing the # button once will cancel the
once a minute beep and acknowledge the fault (eg. FAULT indicator on steady).
FAULT Indicator Definition
On There Is A System Fault That Needs To Be Rectified
Off The System Is Normal, There Are No Faults
Flashing There Is A System Fault That Needs To Be Acknowledged
Table 5: FAULT Indicator
Audible Indications
In general, the audible indicators given out by the Keypad buzzer are as follows:
Audible Indicator Definition
Once Short Beep A Button Has Been Pressed On The Keypad, Or, End Of Exit
Time When Set In STAY Mode 1 Or STAY Mode 2
Two Short Beeps The System Has Accepted Your Code
Three Short Beeps The Requested Function Has Been Executed
One Long Beep Indicates the End Of Exit Time When Set In AWAY Mode,
Or The Requested Operation Has Been Denied Or Aborted
One Beep Every Second Walk Test Mode Is Currently Active Or Warning Before
Automatic Setting Takes Place
One Short Beep Every
Minute There Is A System Fault Waiting To Be Acknowledged
Table 6: Audible Indicators
10 Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Setting the System
There are several different ways to Set the system depending on whether you are leaving the
premises and require all active zones to be in a ready state for an intruder, or, if you are
remaining in the premises and only require part of the system to be in a ready state for an
intruder.
If a zone is not Closed at the end of exit time, the zone will be automatically omitted and will
be constantly displayed on the Keypad. The zone will again become an active part of the
system when the zone has restored (i.e. If a window is left open after exit time has expired,
the window will not be an active part of the system until the window has closed. Opening
the window after exit time has expired will cause an alarm condition).
The different methods for setting the system include:
ØAWAY Mode (Full Set)
Set the entire system. Refer to Setting In AWAY Mode on page 10.
ØSTAY Mode 1 (Part Set 1)
Set all zones except those programmed to be automatically omitted by the Engineer.
Refer to Setting In STAY Mode 1 on page 11.
ØSTAY Mode 2 (Part Set 2)
Set all zones except those programmed to be automatically omitted by the Master
Code holder. Refer to Setting In STAY Mode 2 on page 12.
Forced Setting
The feature of setting the system when a zone is not Closed is known as forced setting. If
the system does not set and a long beep is heard, forced setting is not permitted. If this is the
case, you must ensure that all zones are Closed or manually omitted before you can Set the
system. Refer to Omitting Zones on page 16 for more information.
Setting In AWAY Mode
When you leave your premises and require all zones to be in a ready state to detect intrusion,
you would set the system in AWAY Mode.
There are two different methods for setting the system in AWAY Mode. Method one is
standard and will always operate. Method two is optional and may be disabled by your
Engineer if you do not wish to use single button setting.
Method One
How To Set The System In AWAY Mode
1. Enter your user code followed by the # button (eg. 2580#).
Two beeps will be heard and the AWAY indicator will display. Exit time will now
commence counting.
Method Two
How To Set The System In AWAY Mode
1. Hold down the # button until two beeps are heard.
The AWAY indicator will display and exit time will commence counting.
Solution Ultima Operators Manual 11
Detection Systems Operators Manual UK

Setting In STAY Mode 1
STAY Mode 1 is only used when the perimeter and unused areas of the premises need to be
Set to detect any would be intruder from entering the premises and at the same time,
allowing you to move freely within an area that has been automatically omitted. Only your
security company can program zones to be automatically omitted in STAY Mode 1.
There are two different methods for setting the system in STAY Mode 1. Method one is
standard and will always operate. Method two is optional and may be disabled by your
Engineer if you do not wish to use single button setting.
Entry Guard Timer For STAY Mode
When setting the system in STAY Mode 1, an optional entry timer called Entry Guard Timer
For STAY Mode may be used to delay the sirens if a zone that has not been automatically
omitted has triggered into alarm condition. Entry Guard Timer For STAY Mode is the delay
time used for all zones except 24-hour zones when the system is Set in STAY Mode 1 or
STAY Mode 2.
If the Entry Guard Timer For STAY Mode has been programmed and a zone that has not
been automatically omitted has triggered, the Keypad will beep twice a second until the
Entry Guard Timer For STAY Mode has expired or the system has been Unset. If the alarm
condition has not been reset by entering your user code followed by the # button (eg. 2580#)
before the Entry Guard Time For STAY Mode expires, the sirens will activate into alarm.
Only your Engineer can program this feature.
Method One
How To Set The System In STAY Mode 1
1. Enter your user code followed by the * button (eg. 2580*).
Two beeps will be heard and the STAY indicator will display. Exit time will now
commence counting.
Any zones that have been programmed to be automatically omitted in STAY Mode 1
will flash until exit time expires. At the end of exit time, all zones selected to be
automatically omitted will extinguish and the Keypad will give one short beep.
Method Two
How To Set The System In STAY Mode 1
1. Hold down the * button until two beeps are heard.
The STAY indicator will display and exit time will now commence counting.
Any zones that have been programmed to be automatically omitted in STAY Mode 1
will flash until exit time expires. At the end of exit time, the zone indicators will
extinguish and the Keypad will give one short beep.
12 Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Setting In STAY Mode 2
STAY Mode 2 is only used when the perimeter and unused areas of the premises need to be
Set to detect any would be intruder from entering the premises and at the same time,
allowing you to move freely within an area that has been automatically omitted. Any Master
Code holder can program programming zones to be automatically omitted in STAY Mode 2.
Entry Guard Timer For STAY Mode
When setting the system in STAY Mode 2, an optional entry timer called Entry Guard Timer
For STAY Mode may be used to delay the sirens if a zone that has not been automatically
omitted has triggered into alarm condition. Entry Guard Timer For STAY Mode is the delay
time used for all zones except 24-hour zones when the system is Set in STAY Mode 1 or
STAY Mode 2.
If the Entry Guard Timer For STAY Mode has been programmed and a zone that has not
been automatically omitted has triggered, the Keypad will beep twice a second until the
Entry Guard Timer For STAY Mode has expired or the system has been Unset. If the alarm
condition has not been reset by entering your user code followed by the # button (eg. 2580#)
before the Entry Guard Time For STAY Mode expires, the sirens will activate into alarm.
Only your Engineer can program this option.
How To Set The System In STAY Mode 2
1. Hold down the 0 button until two beeps are heard.
The STAY indicator will display and exit time will now commence counting.
Any zones that have been programmed to be automatically omitted in STAY Mode 2
will flash until exit time expires. At the end of exit time, all zones selected to be
automatically omitted will extinguish and the Keypad will give one short beep.
Programming STAY Mode 2 Zones
Programming zones to be automatically omitted in STAY Mode 2 can only be carried out if
you have a Master Code.
How To Program STAY Mode 2 Zones
1. Enter your Master Code followed by 4 and the # button (eg. 2580 + 4#).
Three beeps will be heard and the STAY indicator will begin to flash.
2. Enter the zone number that you wish to have automatically omitted followed by the *
button (eg. 1* = Zone 1 / 2* = Zone 2 etc).
You will notice that the zone you have selected to be automatically omitted in STAY
Mode 2 will now flash. If you have made a mistake, enter the same zone number
followed by the # button to clear the incorrect zone.
To select additional zones to be automatically omitted in STAY Mode 2, repeat Step 2
as many times as required.
3. Press the # button when you have selected all zones to be automatically omitted in
STAY Mode 2 to exit this mode. Two beeps will be heard and the STAY and AWAY
indicators will extinguish.
Solution Ultima Operators Manual 13
Detection Systems Operators Manual UK

Unsetting the System
When you enter the premises after the system has been Set in AWAY Mode, or if you have
Set the system in STAY Mode 1 or STAY Mode 2, you will need to Unset the system to
disable detection devices that will activate an alarm.
If there has been an alarm condition prior to Unsetting the system, a flashing zone indicator
will be displayed, indicating a previous alarm on that zone.
How To Unset The System
1. Enter your user code followed by the # button (eg. 2580#).
Two beeps will be heard.
Adding User Codes
Only the Master Code holder can add or change other system user codes including the
Master Code itself. Up to eight user codes may be programmed to operate the system.
How To Add A User Code
1. Enter your Master Code followed by 1 and the # button (eg. 2580 + 1#).
Three beeps will be heard and the STAY and AWAY indicators will begin to flash.
2. Enter the user code number (1 – 8) that you wish to add or change followed by the #
button (eg. 2# = User 2 / 8# = User 8 etc). Two beeps will be heard and the user
number that you just selected will now display on the Keypad indicators.
3. Enter the digits required for the new code followed by the # button (eg. If you wish the
user code to be 5768, you would enter 5768#). Two beeps will be heard and the
STAY and AWAY indicators will extinguish.
If you wish to add or change any further user codes, repeat this procedure as many
times as required.
Adding Radio Remote User Codes
Only the Master Code holder can add or change other system user codes. Up to eight radio
remote user codes (User Codes 9 – 16) may be programmed to operate the system.
How To Add A Radio Remote User Code
1. Enter your Master Code followed by 1 and the # button (eg. 2580 + 1#).
Three beeps will be heard and the STAY and AWAY indicators will begin to flash.
2. Enter the radio remote user code number (9 – 16) that you wish to add followed by the
# button (eg. 9# = User 9 / 16# = User 16 etc). Two beeps will be heard and the user
number that you just selected will now display on the Keypad indicators.
3. Enter the 9 digit ID number found on the back of the radio remote hand held
transmitter followed by the # button. Two beeps will be heard and the STAY and
AWAY indicators will extinguish.
If you wish to add or change any further radio remote user codes, repeat this procedure
as many times as required.
14 Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Deleting User Codes/Radio User Codes
Only the Master Code holder can delete other system user codes.
How To Delete A User Code
1. Enter your Master Code followed by 1 and the # button (eg. 2580 + 1#).
Three beeps will be heard and the STAY and AWAY indicators will begin to flash.
2. Enter the user code number (1 – 16) that you wish to delete followed by the # button
(eg. 2# = User 2 / 16# = User 16 etc). Two beeps will be heard and the user number
that you just selected will now display on the Keypad indicators.
3. Press the * button to delete the user code that you have selected.
Two beeps will be heard and the STAY and AWAY indicators will extinguish. If you
wish to delete any further user codes, repeat this procedure as many times as required.
Radio Transmitter Operations
Solution Ultima Operators Manual 15
Detection Systems Operators Manual UK

Figure 3: CP5 LED Keypad
Showing Audible Alarm
Buttons
Keypad Duress Alarm
A Keypad duress alarm is used as a silent hold-up alarm. This will only occur when the
number 9 is added to the end of any valid user code that us being used to Unset the system
(eg. 2580 + 9#). A duress alarm is only useful if your system is reporting back to a
monitoring station or pocket pager as domestic reporting (i.e. mobile phone etc) can’t
decipher which type of alarm had occurred.
Keypad Panic Alarm
An audible alarm will be activated when both the 1 and 3 buttons or both the *
and # buttons are pressed simultaneously. Contact your Engineer if you wish to
disable the ability to activate the Keypad panic alarm or if you wish to have the
Keypad panic alarm to be silent.
Keypad Fire Alarm
A distinct fire sound is emitted via the horn speaker when both the 4 and 6
buttons on the Keypad are pressed simultaneously. Contact your Engineer if you
wish to disable the ability to activate the Keypad fire alarm or if you wish to
have the Keypad fire alarm to be silent.
Keypad Medical Alarm
An audible alarm will be activated when both the 7 and 9 buttons on the Keypad
are pressed simultaneously. Contact your Engineer if you wish to disable the
ability to activate the Keypad medical alarm or if you wish to have Keypad
medical alarm to be silent.
Keypad Tamper (Access Denied)
Keypad tamper restricts the number of times an invalid user code can be used in an attempt
to operate the system. When the number of incorrect code attempts equals the number
programmed by your Engineer, the system will activate an alarm condition and if reporting
back to a security monitoring station, the system will send an access denied report.
If you wish the Keypads to shutdown and lockout for a period of time (0 – 150 seconds), ask
your Engineer to program this.
16 Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Omitting Zones
Omitting zones allow you to manually disable one or more zones before setting the system.
Once a zone has been omitted, access is allowed into that zone during the Set state without
activating an alarm.
An example when you may require to omit a zone before setting the system could be when a
PIR detector may be false alarming or that you may need to leave a pet inside a particular
zone whilst you are away.
Omitting zones is performed by one of two methods. Method two is optional and only
allows those user codes programmed by your Engineer to have access to omit zones.
Standard Omitting
Standard Omitting allows all operators to be able to omit zones without the need to know a
valid user code.
How To Omit A Zone
1. Press the * button twice to enter the omitting mode.
Three beeps will be heard and the STAY indicator will flash.
2. Enter the zone number (1 – 8) that you wish to select to omit followed by the * button.
(eg. 1* = Zone 1, 2* = Zone 2 etc).
As you select each zone to be omitted, you will notice that the corresponding zone
indicator will begin to flash. If you selected an incorrect zone to be omitted, enter the
incorrect zone number again followed by the * button.
Repeat Step 2 if more than one zone is required to be omitted until all zone that are
required to be omitted have been selected.
3. Press the # button after you have selected all zones to be omitted.
Two beeps will be heard and the system will return to the Unset state.
Solution Ultima Operators Manual 17
Detection Systems Operators Manual UK

Code To Omit
The method of code to omit restricts only those user codes that have the priority level “Code
To Omit” set to be able to omit zones. Therefore, if any user code has this priority level set,
the method of standard omitting will not function.
How To Omit A Zone
1. Press the * button followed by your user code and the * button again to enter the
omitting mode (eg. *2580*). Three beeps will be heard and the STAY indicator will
flash.
2. Enter the zone number (1 – 8) that you wish to select to omit followed by the * button.
(eg. 1* = Zone 1, 2* = Zone 2 etc).
As you select each zone to be omitted, you will notice that the corresponding zone
indicator will begin to flash. If you selected an incorrect zone to be omitted, enter the
incorrect zone number again followed by the * button.
Repeat Step 2 if more than one zone is required to be omitted until all zones that are
required to be omitted have been selected.
3. Press the # button after you have selected all zones to be omitted.
Two beeps will be heard and the system will return to the Unset state.
Fault Analysis Mode
If a system fault should occur, the FAULT or MAINS indicator will flash and the Keypad
will beep once ever minute.
If the AC mains supply has failed, the MAINS indicator will flash until the AC mains supply
has restored. Pressing the # button once will acknowledge the fault and stop the Keypad
from beeping once every minute.
How To Determine The Type Of System Fault
To determine which system fault has occurred, enter fault analysis mode by following the
steps outlined below.
1. Hold down button 5 until two beeps are heard.
The FAULT indicator will remain steady and the STAY and AWAY indicators will
flash in unison with each other.
A zone indicator will display to indicate the type of fault that has occurred (eg. Zone 1
= System Fault). Refer to Table 7: Fault Indicators on page 18 for the list of different
faults that may occur.
2. To further determine the type of fault condition (eg. System Fault), you will need to
press and hold down the button that corresponds to the zone indicator displayed (i.e. If
Zone 1 was displayed in Step 1, press and hold button 1 to display which system fault
has occurred).
3. To exit and return to the Unset state, press the # button. The FAULT indicator will
remain displayed and the Keypad will cease its once a minute beep.
18 Solution Ultima Operators Manual
Operators Manual UK Detection Systems

Zone
Indicator
Fault
Description
Hold Down
Button
Zone
Indicator
Fault
Condition
1System Fault 11Battery Fail
2Date & Time
3RF Receiver Fail
4Horn Speaker Fail
5Telephone Line Fail
6E2 Fault
7Fuse Fail
8AC Fail
2RF Low Battery 21 - 8 Zones 1 - 8 RF Low Battery
3Zone Tamper Alarm 31 - 8 Zones 1 - 8 Tamper Alarm
4Sensor Watch Fault 41 - 8 Zones 1 – 8 Sensor Watch
Fail
5RF Sensor Watch 51 – 8 Zones 1 - 8 RF Sensor Watch
Fail
6Communication Fail 61Receiver 1 Fail
2Receiver 2 Fail
Table 7: Fault Indicators
Fault Descriptions
System Fault
A system fault will only display when any of the following faults occur. After entering fault
analysis mode, press and hold button 1 will determine which of the following faults have
occurred.
Low Battery
A low battery fault will register when the system detects a low capacity back-up battery.
The system automatically performs a battery test every 4 hours and also every time you Set
the system.
Date and Time
The date and time fault will register every time the system has been powered down. This
type of fault will not cause the FAULT indicator to display on the Keypad unless your
Engineer has programmed the automatic setting time. Refer to page 20 to program the date
and time.
1
Solution Ultima Operators Manual 19
Detection Systems Operators Manual UK

RF Receiver Fail
The RF receiver fault will register once the system has detected that the wireless receiver
unit has been disconnected.
Horn Speaker
This fault will register when the system detects that the horn speaker has been disconnected.
This fault will clear once the horn speaker has been reconnected. Your Engineer will need to
program the system for this feature to operate.
Telephone Line Fail
A telephone line fault will register when the system detects that the telephone line has been
disconnected from the control panel. Your Engineer will need to program the system for this
feature to operate.
E2 Fault
An E2 fault will register when the system detects an internal checksum error. Contact your
Engineer as soon as this fault is displayed.
Fuse Fail
This fault will occur when either of the two 1 Amp fuses has blown. Contact your Engineer
as soon as this fault is displayed.
RF Low Battery
This fault will occur when any of the RF wireless devices has reported a low battery
condition to the control panel. Whilst you are in fault analysis mode, press and hold button 2
until two beeps are heard will display which zone has reported the RF Low Battery fault.
Tamper Fail
This fault will occur when any zone has become open circuit. By press and hold button 3
until two beeps are heard in fault analysis mode will display which zone has reported the
tamper fail fault.
Sensor Watch Fault
A sensor watch fault will register because one or more detection devices has failed to detect
any movement during the Unset state for the time period programmed by your Engineer.
The fault will clear once the zone in question has detected movement and reset.
Whilst you are in fault analysis mode, press and hold button 4 until two beeps are heard will
display which zone reported the sensor watch fault.
RF Sensor Watch Fault
An RF sensor watch fault will register because one or more RF detection devices has failed
to communicate to the RF radio receiver for the time period programmed by your Engineer.
The fault will clear once the RF device in question has successfully transmitted to the RF
radio receiver.
Whilst you are in fault analysis mode, press and hold button 5 until two beeps are heard will
display which RF detection device reported the RF sensor watch fault.
2
3
4
5
20 Solution Ultima Operators Manual
Operators Manual UK Detection Systems
