DETHONRAY Honey H1 Mounting instructions

DETHONRAY Co., Ltd. All Rights Reserved.
1
Honey H1
An expedition in pursuit of supreme audio experience
The High Resolution Digital Audio Player
Designed by DETHONRAY® Inc.

DETHONRAY Co., Ltd. All Rights Reserved.
2
Revision history:
Version Release date Description Author
V1.0 Jun 19th, 2021 Sh.Lin

DETHONRAY Co., Ltd. All Rights Reserved.
3
Our team are tech and sound geeks like you. DETHONRAY®innovates
and pursue in excellence of fidelity while balancing user experience and
perceived replay quality, forging true Hi-Fi quality hardware and GUI with
natural, high fidelity tuning.
To achieve the goal, product infrastructure, circuitries with precise
matching also hardware acoustics are meticulously designed to ensure
utmost stability in the designs. Deep customization and innovative
electronics promotes real-time performance of audio data transmission,
integrated with our house tuning to bring to you an unparalleled
listening experience.

DETHONRAY Co., Ltd. All Rights Reserved.
4
H1 Use Manual
No. Name Function Description
1 BAL 4.4 balanced video output.
2 Line out/Optical 3.5mm video output, Supports earphone,
line out and Optical.
3 Light
*Green: PCM/Flac video format；
*Blue: DSD64；
*Blue+Red: DSD128
4 On/OFF Switch machine and volume adjustment.
接口功能

DETHONRAY Co., Ltd. All Rights Reserved.
5
No. Name Function Description
1 USB C Input Only support charging.
2 Power Indicator
*When the capacity of the battery is greater
than 80%, the green LED illuminates.
*When the capacity of the battery≤80%,
and≥30%, the blue LED illuminates.
*When the capacity of the battery is below
30%, the red LED illuminates.
3 USB C Input Only support data transmission.

DETHONRAY Co., Ltd. All Rights Reserved.
6
Gain H/L
*Adjust to “Gain L” gear, it means the H1 is in low
gain mode, which suitable for low impedance and
high sensitivity headphones.
PO/LO
*Adjust to “Gain H” gear, it means the H1 is in high
gain mode, which suitable for high-impedance
headphones that require thrust.
*After setting H/L, you need to readjust the knob
switch before the gain setting can take effect. It is
recommended to complete the change at a low
volume to avoid sudden changes in volume and
damage to hearing.
*“PO” gear, it is the headphone output mode.
*“LO” gear，only support line out mode, when the
H1 is connected to the headphone amplifier or
professional audio equipment.

DETHONRAY Co., Ltd. All Rights Reserved.
7
Foobar Configuration Instructions
(Only for Windows system)
*If your computer use the Windows system, please install the following
version of the driver and ASIO driver：
1. BravoHDSwPkgSetup.msi
2. foobar2000_v1.4.exe
3. ASIO4ALL_2_10_SCN.exe
4. foo_input_sacd.fb2k-component.exe
The First Step：
1. Connect the computer to Honey H1, turn on H1 (Note: Don’t connect to the charging C
port which don’t support data transmission function.).
2. Find “ Library” in the menu bar, → left-click “Library”, → find “Configure” in the
“Library” drop-down menu, → click “Configure“, → pop-up the “Preferences: Media
Library option” window.
The Second Step：
1. Find “Playback” on the left side of the option box, → left-click “Playback”, → find
“Output”, and left-click it.
2. And then, on the right of page, you can look the “Device” page, find” ASIO:
foo_dsd_aslo” in the drop-down page.

DETHONRAY Co., Ltd. All Rights Reserved.
8
The Third Step：
1. On the left side of page, → find the ”Output”, click it, → left-click ASIO.
2. And then, on the right side of page,→ find the ”foo_dsd_aslo”, → Double
click ”foo_dsd_aslo”.
The Fourth Step:
After double-clicking the “foo_dsd_aslo”, it will pop up ASIO Proxy 0.8.3 windows, →Fill in
the information as follows:
1. ASIO Driver choose “ BRAVO-HD”；
2. DSD Playback Method choose “DoP Marker 0x05/0xFA”;

DETHONRAY Co., Ltd. All Rights Reserved.
9
3. DSD to DSD Method choose “None” ; Fs choose “DSD128”：
4. PCM to DSD Method choose “None”； Fs choose ”DSD128”.
5. Then close the “ASIO Proxy 0.8.3” option box，return to the “ASIO drivers” page.
The Fifth Step:
On “ASIO drivers” page, double click “BRAVO-HD”.
The Sixth Step:
After double-clicking “BRAVO-HD”, it will pop up a blue page:
Preferred choose “32 bits”;
Buffer size choose “10ms”.
After finishing all operations, return to the playing page, and try to play a song randomly,
and check whether the music is playing normally.

DETHONRAY Co., Ltd. All Rights Reserved.
10

DETHONRAY Co., Ltd. All Rights Reserved.
11
H1 connects to Mac OS configuration
After connecting Honey H1 to Mac OS, set Honey H1 as the output device.

DETHONRAY Co., Ltd. All Rights Reserved.
12
Portable USBDAC Honey H1 Specifications
Port：
Input USB C
Output 3.5 Single End/Line Out/Optical, 4.4 Balance
Specification：
DPPU（Desktop Plus Power Unit）
DSD64 / 128，PCM 16Bit / 44.1K-32Bit / 384K
Android / iOS / Windows / Linux
PERFORMANCE：
Frequency
Response 20Hz-20kHz
THD 0.008%
SNR 116db
MAX. POWER OUTPUT：
Single End 6Vrms（32Ω）
Balanced 6.2Vrms（300Ω）
Others
DAC Chip AKM4497x1
Chassis Sandblasted CNC Aluminum/ Blue
Dimensions 137 x 70 x 19(mm) (inlcude volume knob)
Weight 256g
Battery Life 3.5 Vedio Output：10 hours 4.4 Vedio Output：8 hours
Charging 5V 2A/3.5 Hours
Battery 5300 mAH
