Dettson AMP105-IE2 Assembly instructions

WARM AIR FURNACE
MULTIPOSITION
Printed in Canada
Printed on 100% recycled paper
INSTALLER / SERVICE TECHNICIAN:
USE THE INFORMATION IN THIS MANUAL FOR THE
INSTALLATION / SERVICING OF THE FURNACE AND KEEP THE
DOCUMENT NEAR THE UNIT FOR FUTURE REFERENCE.
HOMEOWNER:
PLEASE KEEP THIS MANUAL NEAR THE FURNACE FOR FUTURE
REFERENCE.
Attention:
Do not tamper with the unit or its
controls.
Call a qualified service technician.
Models:
AMP105-IE2
AMP120-IE2
NOMF105D12C
NOMF155E19C
NOMF106D12B
NOMF156E19C
2013-06-12 X40002 Rev.Z
Manufactured by:
Dettson Industries inc.
3400 Industriel Boulevard
Sherbrooke, Qc – Canada – J1L 1V8
www.dettson.ca
DNS-0376Rév.A
CUS

2
TABLE OF CONTENTS
1.0 SAFETY REGULATIONS --------------------------------3
1.1 DANGER, WARNING AND CAUTION----------------3
1.2 SAFETY INSTALLATION REQUIREMENTS--------3
2.0 INSTALLATION---------------------------------------------3
2.1 GENERAL ----------------------------------------------------3
2.2 SAFE INSTALLATION REQUIREMENTS -----------4
2.3 SAFETY RULES--------------------------------------------4
2.3.1 Detector---------------------------------------------------4
2.3.2 Freezing temperatures and your building --------4
2.4 LOCATION ---------------------------------------------------5
2.4.1 Air for combustion and ventilation------------------5
2.4.2 Duct recommendations -------------------------------6
2.4.3 Venting instructions (chimney installation)-------6
2.4.4 Draft Regulator------------------------------------------7
2.4.5 Blocked vent shut-off (BVSO)-----------------------8
2.4.6 Oil burner-------------------------------------------------9
2.4.7 Electrical system----------------------------------------9
2.4.8 Air filter----------------------------------------------------9
2.4.9 Air Conditioner (or Heat Pump)---------------------9
2.4.10 Horizontal or downflow installation---------------10
3.0 OPERATION-----------------------------------------------10
3.1 SUPPLY AIR ADJUSTMENTS------------------------10
3.2 OPERATIONAL CHECKLIST -------------------------10
3.3 PURGING THE OIL LINE ------------------------------11
3.4 COMBUSTION CHECK---------------------------------11
3.5 LIMIT CONTROL CHECK------------------------------11
3.6 YEAR ROUND AIR CONDITIONING----------------11
3.7 HEATING ---------------------------------------------------12
3.8 COOLING---------------------------------------------------12
3.9 CONSTANT BLOWER SWITCH ---------------------12
4.0 MAINTENANCE-------------------------------------------12
4.1 HEAT EXCHANGER CLEANING---------------------12
4.2 BLOWER REMOVAL------------------------------------12
4.3 BLOCKED VENT SHUT OFF (BVSO) CLEANING 12
5.0 FURNACE INFORMATION----------------------------13
FIGURES
Figure 1 : Counterflow position, flue pipe protection.............5
Figure 2 : Blocked vent shut-off device wiring, upflow
installation with vertical exhaut .............................7
Figure 3 : Blocked vent shut-off device wiring, upflow
installation with vertical exhaust............................8
Figure 4 : Blocked vent shut-off device wiring, upflow
installation with horizontal exhaust .......................8
Figure 5: Blocked vent shut-off device wiring, horizontal
installation with horizontal exhaust .......................8
Figure 6: Blocked vent shut-off device wiring, horizontal
installation with vertical exhaust............................8
Figure 7: Blocked vent shut-off device wiring, downflow
installation.............................................................8
Figure 8 : Blower Start/Stop delays Board # 1158..............10
Figure 9 : Model AMP 105 and NOMF 105 / 106................15
Figure 10 : Model AMP 120 and NOMF 155 / 156..............16
Figure 11 : Wiring diagram, Beckett burner ........................17
Figure 12 : Wiring diagram, Riello 40-F or BFR burner
(without 24 VAC control)...................................18
Figure 13 : Wiring diagram, Riello 40-F or BF burner (with 24
VAC control) .....................................................19
Figure 14 : Parts list AMP & NOMF 105/106, Beckett AFG
and 40-F Riello burner......................................20
Figure 15 : Parts list, AMP & NOMF 120/155/156, Beckett
AFG and Riello 40-F burner..............................22
Figure 16 : Parts List AMP & NOMF 120/156, Riello 40-F
burner ...............................................................24
Figure 17 : Parts list AMP120, Riello 40-BF burner............26
TABLES
Table 1 : Minimum dimensions required in ventilation
openings.................................................................5
Table 2 : Filter rack flange dimensions for return air duct.....9
Table 3 : Blower speed adjustments, 4 speed motor, heating
mode ....................................................................10
Table 4 : Blower speed adjustments, 4 speed motor, cooling
mode ....................................................................10
Table 5 : Technical Specifications ......................................14
Table 6 : Air delivery in CFM with air filter...........................14
Table 7 : Minimum clearances to combustible materials.....15
Table 8 : Minimum clearances to combustible materials.....16
Table 9 : Parts list AMP & NOMF 105/106, Beckett AFG and
40-F Riello burner.................................................21
Table 10 : Parts list AMP & NOMF 120/155/156, Beckett
AFG and Riello 40-F burner................................23
Table 11 : Parts list AMP & NOMF 120/156, Riello 40-F
burner.................................................................25
Table 12 : Parts list AMP120, Riello 40-BF burner .............27

1.0 SAFETY REGULATIONS
3
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPOURS AND LIQUIDS IN THE VICINITY
OF THIS OR ANY OTHER APPLIANCE.
DO NOT ATTEMPT TO START THE BURNER WHEN
EXCESS OIL HAS ACCUMULATED, WHEN THE
FURNACE IS FULL OF VAPOUR OR WHEN THE
COMBUSTION CHAMBER IS VERY HOT.
1.1 DANGER, WARNING AND CAUTION
The words DANGER, WARNING and CAUTION are used to
identify the levels of seriousness of certain hazards. It is
important that you understand their meaning. You will notice
these words in the manual as follows:
DANGER
Immediate hazards which WILL result in death or
serious bodily and/or material damage.
WARNING
Hazards or unsafe practices which CAN result in death
or serious bodily and /or material damage.
CAUTION
Hazards or unsafe practices which CAN result in minor
bodily and /or material damage.
1.2 SAFETY INSTALLATION REQUIREMENTS
WARNING
For use with grade 2 fuel oil maximum. Do NOT use
gasoline, crankcase oil or any oil containing gasoline.
WARNING
Never burn garbage or paper in the heating system and
never leave rags or paper around the unit.
CAUTION
These instructions are intended for the sole use of
qualified personnel trained in installing this type of
furnace. Installation of this furnace by an unqualified
person can lead to hazardous conditions, resulting in
bodily harm and/or equipment damage.
IMPORTANT: All local and national code requirements
governing the installation of oil burning equipment, wiring
and flue connections must be followed. Some of the codes
that may be applicable are:
CSA B139 Installation Code for Oil Burning
Equipment
ANSI/NFPA 31 Installation of Oil Burning Equipment
ANSI/NFPA 90B Warm Air Heating and Air Conditioning
Systems
ANSI/NFPA 211 Chimneys, Fireplaces, Vents and Solid
Fuel Burning Appliances
ANSI/NFPA 70 National Electrical Code
CSA C22.2 No.3 Canadian Electrical Code
Only the latest issues of the above codes should be used,
and are available from either:
The National Fire Protection Agency
1 Batterymarch Park
Quincy, MA 02269
or
The Canadian Standards Association
178 Rexdale Blvd.
Rexdale, Ontario M9W 1R3
CAUTION
ENVIRONMENTAL HAZARD
Failure to follow this caution may result in
environmental pollution.
Remove and recycle all components or materials (i.e. oil,
electrical and electronic components, insulation, etc.)
before unit final disposal.
2.0 INSTALLATION
2.1 GENERAL
This central heating unit is a true multi-position unit, in that it
can operate in four different configurations, i.e., upflow,
counter flow (downflow), and horizontal (both left-to-right and
right-to-left airflow).
Very few modifications are required during installation, to
change the furnace from one configuration to another. The
furnace is shipped in the upflow configuration; however,
instructions on how to change to the other configurations are
included in this manual.
The furnace is shipped complete with burner and controls. It
requires an 115VAC line voltage connection to the control
panel, thermostat hook-up as shown on the wiring diagram,
one or more oil line connections, suitable ductwork and
connection to a properly sized vent.
The air handling capacity of this furnace is designed for
cooling as well. Please refer to Table 6 for the expected
airflow at various external static pressures.

2.2 SAFE INSTALLATION REQUIREMENTS
4
WARNING
Installation or repairs performed by unqualified persons
can result in hazards to them and others. Installation
MUST conform to local codes or, in the absence of
same, to codes of the country having jurisdiction.
The information contained in this manual is intended for
use by a qualified service technician familiar with safety
procedures and quipped with the proper tools and test
instruments.
Failure to carefully read and follow all instructions in
this manual can result in death, furnace malfunction
and/or property damage.
WARNING
FIRE HAZARD
The furnace must be installed in a level position, never
where it will slope toward the front. If the furnace is not
installed level, oil will drain into the furnace vestibule
and create a fire hazard.
NOTE: It is the personal responsibility and obligation of the
customer to contact a qualified installer to ensure that the
installation conforms to governing local and/or national codes
and ordinances
a. This furnace is NOT approved for installation in mobile
homes, trailers or recreational vehicles;
b. Do NOT use this furnace as a construction heater or to
heat a building under construction;
c. There must be a sufficient supply of fresh air for
combustion as well as ventilation in the area where the
furnace is located;
d. Use only the type of fuel oil approved for this furnace
(see section 1.2 of this manual). Overfiring will result in
heat exchanger failure and cause dangerous operating
conditions;
e. Visually check all oil line joints for signs of leakage;
f. Connect furnace to the chimney;
g. The points in Part 3 “Operation” are vital to the proper
and safe operation of the heating system. Take the time
to ensure that all steps were followed;
h. Follow the regulations of the NFPA No.31 (in the USA)
and CSA B-139 (in Canada) or local codes for placing
and installing the oil storage tank;
i. Follow a regular service and maintenance schedule for
efficient and safe operation;
j. Before servicing, allow furnace to cool down. Always
shut off electricity and fuel to furnace when servicing.
This will prevent electrical shock or burns;
k. Seal supply and return air ducts;
l. The vent system MUST be checked to determine that it
is the correct type and size;
m. Install correct filter type and size;
n. Unit MUST be installed so that electrical components
are protected from direct contact with water.
2.3 SAFETY RULES
Your unit is built to provide many years of safe and
dependable service, provided it is properly installed and
maintained. However, abuse and/or improper use can
shorten the life of the unit and create hazards for you, the
owner.
2.3.1 Detector
a. The U.S. Consumer Product Safety Commission
recommends that users of oil-burning appliances install
carbon monoxide detectors. There can be various
sources of carbon monoxide in a building or dwelling.
The sources could be gas-fired clothes dryers, gas
cooking stoves, water heaters, furnaces, gas-fired
fireplaces, wood fireplaces, and several other items.
Carbon monoxide can cause serious bodily injury and/or
death. Therefore, to help alert people to potentially
dangerous carbon monoxide levels, you should have
carbon monoxide detectors listed by a nationally
recognised agency (ex. Underwriters Laboratories or
International Approval Services) installed and
maintained in the building or dwelling (see Note below).
b. There can be numerous sources of fire or smoke in a
building or dwelling. Fire or smoke can cause serious
bodily injury, death, and/or property damage. Therefore,
in order to alert people to potentially dangerous fire or
smoke, you should have fire and smoke detectors listed
by Underwriters Laboratories installed and maintained in
the building or dwelling (see Note below).
NOTE: The manufacturer of your furnace does not test any
detectors and makes no representations regarding any brand
or type of detector.
CAUTION
Ensure that the area around the combustion air intake is
free of snow, ice and debris.
2.3.2 Freezing temperatures and your building
WARNING
FREEZING TEMPERATURE WARNING
Turn off water supply.
If your heater remains shut off during cold weather, the
water pipes could freeze and burst, resulting in serious
water damage.
If the structure is unattended during cold weather you should
take the following precautions:
a. Turn off main water supply into the structure and drain
the water lines if possible. Open faucets in appropriate
areas;
b. Have someone check the structure frequently during
cold weather to make sure it is warm enough to prevent
pipes from freezing. Contact a qualified service agency,
if required.

2.4 LOCATION
5
CAUTION
This furnace is not watertight and is not designed for
outdoor installation. This furnace shall be installed in
such a manner as to protect the electrical components
from water. Outdoor installation will lead to hazardous
electrical conditions and to premature furnace failure.
CAUTION
If this furnace is installed in an attic, it is important to
keep insulation at least 0.3 m (12") away from any
furnace openings. Some types of insulating material
may be combustible.
The unit must be installed in a location where the ambient
and return air temperature is over 15°C (60°F).
This furnace is approved for reduced clearances to
combustible construction. Therefore, it may be installed in a
closet or similar enclosure. As this unit may be installed as
an upflow, counter flow, or horizontal furnace, it may be
located in a basement, on the same level as the area to be
heated, suspended, or in a crawlspace. In any case, the unit
should always be installed level.
In a basement, or when installed on the floor (as in a
crawlspace), it is recommended that the unit be installed on
a concrete pad that is 2.5 cm to 5.0 cm (1" to 2") thick.
When installed in the counter flow position, this furnace must
not be installed on combustible flooring, unless the approved
sub-base is used (Model # DFB-101). Since the flue pipe is
in counter flow position, be sure that the clearances from the
flue pipe to combustible construction are maintained. Also, it
is recommended to use the flue pipe protection kit FPG-101
or FPF-102. Please refer to the Figure 1 and the installation
instructions included with the kit.
Figure 1 : Counterflow position, flue pipe protection
When installed in a horizontal position, the furnace may be
suspended by using an angle iron frame, as long as the total
weight of both the furnace and the frame are included in the
calculations. Other methods of suspension are acceptable.
When installed in the horizontal position, this furnace must
not be installed on combustible flooring, unless the approved
sub-base is used (# DFB-101).
The required minimum clearances for this furnace in all
positions are specified in Tables 7 and 8.
The furnace should be located as closely as possible to the
chimney or vent in order to keep vent connections short and
direct. The furnace should also be located near the centre of
the air distribution system.
2.4.1 Air for combustion and ventilation
This furnace should be installed in a location in which the
facilities for ventilation permit satisfactory combustion of oil,
proper venting and the maintenance of ambient
temperatures at safe limits under normal conditions of use.
The location should not interfere with the proper circulation of
air within the confined space.
Refer to the CAN/CSA-B139 installation code for complete
regulations, and for guidance on retrofit applications.
When this furnace is installed in a closet or similar enclosure,
2 ventilation openings are required for combustion air. The
openings should be located about 15.2 cm (6") from the top
and the bottom of the enclosure at the front of the furnace.
Table 1 indicates the minimum dimensions required for each
of these two ventilation openings.
Table 1 : Minimum dimensions required in ventilation
openings
Input
(BTU/h) Width Height
75,000 – 105,000 45.72 cm (18") 20.32 cm (8")
120,000 – 155,000 50.80 cm (20") 25.40 cm (10")
WARNING
DNS-0278 Rev. A
FPG-101 /
FPG-102
Do not block the combustion air openings in the
furnace. Any blockage will result in improper
combustion and may result in a fire hazard and/or cause
bodily harm.
The barometric draft regulator included with the furnace,
shall be installed in the same room or enclosure as the
furnace, in such a manner as to prevent any difference in
pressure between the regulator and the combustion air
supply.
Air requirements for the operation of exhaust fans, kitchen
ventilation systems, clothes dryers, and fireplaces shall be
considered in determining the adequacy of the space to
provide combustion air requirements.
In unconfined spaces, in buildings of conventional frame,
brick or stone construction, infiltration may be adequate to
provide air for combustion, ventilation and dilution of flue
gases. This determination must be made on an individual
installation basis and must take into consideration the overall
volume of the unconfined space, the number of windows and

ventilation openings, the number of doors to the outside,
internal doors which can close off the unconfined space and
the overall air tightness of the building construction.
Many new buildings and homes (and older ones that have
been weatherized must be considered as being tight
construction and, therefore, infiltration will not be sufficient to
supply the necessary air for combustion and ventilation.
A building can be considered as being of tight construction
when:
a. Walls and ceilings exposed to the outside have a
continuous water vapour retarder with a rating of one
perm or less, openings have gaskets or are sealed
and/or;
b. Weather-stripping has been added on operable windows
and doors, and/or;
c. Caulking or sealant has been applied to areas such as
joints around window and doorframes, between sole
plates and floors, between wall-ceiling joints, between
wall panels, at penetrations for plumbing, electrical and
fuel lines and at other openings.
2.4.2 Duct recommendations
6
WARNING
When ducting supplies air to a space other than where
the furnace is located, the return air must be sealed and
also be directed to the space other than where the
furnace is located. Incorrect ductwork termination and
sealing will create a hazardous condition that can lead
to bodily harm.
CAUTION
Return air grilles and warm air registers must not be
obstructed.
IMPORTANT: The dampers should be adequate to prevent
cooled air from entering the furnace, and if manually
operated, must be equipped with the means to prevent
operation of either the cooling unit or the furnace, unless the
damper is in the full cool or heat position.
NOTE: The back should not be cut out for return air
ducting.
The proper sizing of warm air ducts is necessary to ensure
satisfactory furnace operation. Ductwork should be in
accordance with the latest editions of NFPA-90A (Installation
of Air Conditioning and Ventilating Systems) and NFPA-90B
(Warm Air Heating and Air Conditioning Systems) or
Canadian equivalent.
The supply ductwork should be attached to the flanged
opening provided at the discharge end of the furnace. See
Figures 9 and 10, for the dimensions of this opening.
Knockouts are provided on both sides of the furnace to cut
the required size of opening for the installation of the return
air ductwork. This can be done on either the right or the left
side of the furnace. See Table 2 for location and dimensions.
Also, there is provision on this furnace for a bottom return air
duct. Knockouts are provided in the floor of the furnace to
facilitate the cut-out requirement for the air filter rack and
return ductwork. (We recommend the use of this opening for
horizontal and counterflow installations).
The following recommendations should be followed when
installing ductwork:
a. Install locking type dampers in all branches of the
individual ducts to facilitate balancing the system.
Dampers should be adjusted such a way as to ensure
the proper static pressure at the outlet of the furnace;
b. A flexible duct connector of non-combustible material
should be installed at the unit on both the supply and
return air side. In applications where an extremely quiet
operation is necessary, the first 3 m (10') of supply and
return ducts should be internally lined with acoustical
material (if possible);
c. In cases where the return air grille is located close to the
fan inlet, there should be at least one 90oturn between
fan inlet and grille. Further reduction in sound level can
be accomplished by installing acoustical turning vanes
or lining the duct as described in item b. above;
d. When a single air grille is used, the duct between grille
and furnace must be the same size as the return air
opening in the furnace.
When installing the furnace with cooling equipment for year
round operation, the following recommendations must be
followed for tandem or parallel air flow:
WARNING
POISONOUS CARBON MONOXIDE GAS HAZARD
Install the evaporator coil on the supply side of the
furnace ducting ONLY.
An evaporator coil installed on the return air side of the
ducting can cause condensation to form inside the heat
exchanger, resulting in heat exchanger failure. This in
turn can result in death, bodily injury.
a. On tandem airflow applications, the coil is mounted after
the furnace in an enclosure in the supply air stream. The
furnace blower is used for both heating and cooling
airflow;
b. On parallel airflow installation, dampers must be
provided to direct air over the furnace heat exchanger
when heat is desired and over the cooling coil when
cooling is desired.
2.4.3 Venting instructions (chimney installation)
The furnace must be vented to the outside, in accordance
with local codes and other authorities having jurisdiction.
CAUTION
Oil fired appliances must be connected to flues having
sufficient draft at all times to ensure safe and proper
combustion.
For additional venting information please refer to ANSI/NFPA
211 Chimneys, Fireplaces, Vents and Solid Fuel Burning
Appliances and/or the CSA B139 Installation Code.

This furnace is certified for uses with a Type “L” vent
(maximum flue gas temperature 302°C (575°F)). The flue
pipe clearance knockout in the front top or side panel should
be removed. Install the flue elbow so that it exits the furnace
cabinet through that opening.
Pre-installation vent system inspection
Before this furnace is installed, it is strongly recommended
that any existing vent system be completely inspected.
On any chimney or vent, this should include the following:
a. Inspection for any deterioration in the chimney or vent. If
deterioration is discovered, the chimney must be
repaired or the vent replaced;
b. Inspection to ascertain that the vent system is clear and
free of obstructions. Any blockages must be removed
before installing this furnace;
c. Cleaning the chimney or vent if previously used for
venting a solid fuel burning appliance or fireplace;
d. Confirming that all unused chimney or vent connections
are properly sealed;
e. Verification that the chimney is properly lined and sized
per the applicable codes. (Please refer to list of codes in
Part 1.2)
Masonry Chimneys
This furnace may be vented into an existing masonry
chimney. However, it must not be vented into a chimney
servicing a solid fuel-burning appliance. Before venting this
furnace into a chimney, the chimney must be checked for
deterioration and repaired if necessary. The chimney must
be properly lined and sized per local and/or national codes.
The chimney must be of sufficient area to accommodate the
total flue products of all appliances vented into the chimney.
The following requirements are provided for a safe venting
system:
a. Ensure that the chimney flue is clear of any dirt or
debris;
b. Ensure that the chimney is not servicing an open
fireplace;
c. Never reduce the pipe size below the outlet size of the
furnace;
d. All pipes should be supported, using the proper clamps
and/or straps. These supports should be installed at
least every 4 feet;
e. All horizontal runs of pipe should have at least 20 mm of
upward slope per 1 m (1/4” per 1');
f. All runs of pipe should be as short as possible with as
few turns as possible;
g. Seams should be tightly joined and checked for leaks;
h. The flue pipe must not extend into the chimney but be
flush with the inside wall;
i. The chimney must extend 0.9 m (3') above the highest
point where it passes through a roof of a building and at
least 0.6 m (2') higher than any portion of a building
within a horizontal distance of 3 m (10'). It shall also be
extended at least 1.5 m (5') above the highest
connected equipment flue collar;
j. Check local codes for any variances.
Factory Built Chimneys
Approved factory built chimneys may be used. Refer to
chimney manufacturer’s instructions for proper installation.
2.4.4 Draft Regulator
The draft regulator supplied with the furnace must be used
for proper functioning. Installation instructions are included
with the control.
Figure 2 : Blocked vent shut-off device wiring, upflow installation with vertical exhaut
DNS-1043 Rev. A
Use the three wire
fasteners. The wires
must not come in contact
with the flue and
cleaning pipes.
Connect the green
ground wire to a
cabinet screw.
Connect the wires to
the free Limit Control
terminals.
Blocked Vent Shut-Off
device BVSO.
Electrical kit su
pp
lied.
The position of the hole
in the vent is subject to
the length of the
electrical kit.
7

Figure 3 : Blocked vent shut-off device wiring, upflow
installation with vertical exhaust
8
Figure 4 : Blocked vent shut-off device wiring, upflow
installation with horizontal exhaust
Figure 5: Blocked vent shut-off device wiring, horizontal
installation with horizontal exhaust
Figure 6: Blocked vent shut-off device wiring, horizontal
installation with vertical exhaust
DNS-1043 Rev A
Connection to
high limit contacts
(
See Fi
g
ure 2
)
Connection to
high limit contacts
(
See Fi
g
ure 2
)
Figure 7: Blocked vent shut-off device wiring, downflow
installation
2.4.5 Blocked vent shut-off (BVSO)
For chimney venting
WARNING
It is imperative that this device be installed by a qualified
agency.
This device is designed to detect the insufficient evacuation
of combustion gases in the event of a vent blockage. In such
a case the thermal switch will shut down the oil burner. The
device will then need to be re-armed MANUALLY.
Please refer to Figures 2 to 7, the wiring diagrams, Figures
11 to 13, and the detailed instructions supplied with the
BVSO for the installation and wiring procedures. The length
of wires supplied with the unit is such that the safety device
must be installed between the flue outlet of the appliance
and the draft regulator, as indicated in the instructions.
DNS-1043 Rev A
DNS-1043 Rev A
DNS-1043 Rev A
Connection to
high limit contacts
(
See Fi
g
ure 2
)
Connection to high limit
contacts
(
See Fi
g
ure 2
)
DNS-1043 Rev A
Connection to
high limit contacts
(
See Fi
g
ure 2
)

For more details, refer to the instructions supplied with the
device itself, as well as section 3 of this manual.
It is also essential that the BVSO be maintained annually.
For more details please refer to the instructions supplied with
the device itself, as well as Section 4 of this Manual.
9
CAUTION
A positive pressure venting system (Sealed Combustion
System or Direct Vent) MUST NOT use the BVSO. Follow
the instructions supplied with the venting system.
2.4.6 Oil burner
This furnace is supplied with a high pressure atomizing
retention head type burner for use with not heavier than
grade 2 Fuel Oil. If the burner model is a Beckett AFG, the
mounting flange is fixed to the burner air tube and no
adjustment is required for length. If a Riello burner is used,
refer to the Technical Specifications, Table 5 for the insertion
length.
CAUTION
NEVER use the “interrupted ignition” function if a
Beckett AFG burner is installed on the furnace.
Oil Connections
Complete instructions for installation of the fuel oil piping will
be found in the oil burner installation instructions included
with the furnace.
Oil line entry holes are located in the side panels. Two holes
are provided on each side, so that a two-pipe system can be
used if desired.
A 10-micron (or finer) oil filter should be used with all oil
burners, installed as closely as possible to the burner.
2.4.7 Electrical system
WARNING
The unit cabinet must have an uninterrupted or
unbroken electrical ground to minimize personal injury
if an electrical fault should occur. A green ground screw
is provided in the control box for this connection.
The appliance must be installed in accordance with the
current ANSI/NFPA 70 National Electrical Code, CSA C22.1
Canadian Electrical Code Part 1 and/or local codes.
The control system depends on the correct polarity of the
power supply. Connect “HOT” wire (H) and “NEUTRAL” wire
(N) as shown in Figures 12 and 13.
A separate line voltage supply should be used with fused
disconnect switch or circuit breaker between the main power
panel and the unit.
Use only copper wire for 115V supply service to the unit.
Metallic conduit (where required/used) may terminate at the
side panel of the unit. It is not necessary to extend the
conduit inside the unit from the side panel to the control box.
When replacing any original furnace wiring, use only 105oC,
16 AWG copper wire.
Instructions for wiring the thermostat are provided with the
thermostat (field supplied). Wire the connections to the 24-
volt terminal board on the primary relay as shown in Figures
12 and 13.
When installing optional accessories to this appliance, follow
the manufacturer’s installation instructions included with the
accessory. Other than wiring for the thermostat, wire with a
minimum of type “T” insulation (17oC rise (63oF)) must be
used for accessories.
2.4.8 Air filter
An external filter rack is provided as standard equipment with
this furnace. The filter rack can be installed on the right or
left side panel, or on the bottom of the furnace to
accommodate the return air ductwork. A sufficient clearance
should be provided for air filter access. Please refer to Table
2 for filter rack flange dimensions for return air duct.
DANGER
Do not use this furnace as a construction heater. Use of
this furnace as a construction heater exposes it to
abnormal conditions, contaminated combustion air and
the lack of air filters. Failure to follow this warning can
lead to premature furnace failure and/or vent failure that
could result in a fire hazard and/or bodily harm.
Table 2 : Filter rack flange dimensions for return air duct
Model Air Filter Size Flange Opening
16" x 24" 15" x 23"
AMP 105
NOMF 105 / 106 40.64 x 60.96 cm 38.10 X 58.42 cm
20" x 30" 17" x 29"
AMP 120
NOMF 155 / 156 45.72 X 76.20 cm 43.18 X 73.66 cm
2.4.9 Air Conditioner (or Heat Pump)
An air conditioning coil may be installed on the supply air
side ONLY.
WARNING
POISONOUS CARBON MONOXIDE GAS HAZARD
Install the evaporator coil on the supply side of the
furnace ducting ONLY.
An evaporator coil installed on the return air side of the
ducting can cause condensation to form inside the heat
exchanger, resulting in heat exchanger failure. This in
turn can result in death, bodily injury.
No minimum clearance is required between the bottom of the
coil drain pan and the top of the heat exchanger. If a heat
pump is installed, a “dual-energy” thermostat, or other
control is required, in order to prevent the simultaneous
operation of the furnace and the heat pump. It also prevents
a direct transition from heating by way of the heat pump to
heating with oil. Refer to the thermostat instructions or those
of another control used for the proper wiring.

10
If a coil blower compartment is used, install air tight,
motorized and automatic air dampers. Cold air coming from
the coil and passing across the furnace can cause
condensation and shorten the life of the heat exchanger.
2.4.10 Horizontal or downflow installation
1. On horizontal installations, determine which “side” will
become the “top”, when the unit is laid down. Remove
the flue pipe clearance knockout from the top front of
that side panel. Install the flue elbow so that it exits the
cabinet of the furnace through that opening;
2. On counterflow Installations, the flue pipe must exit the
cabinet through one of the side panel openings (as
above), then extended up the side of the furnace.
Ensure that adequate clearances to combustibles are
observed. It may be necessary to install a sheet-metal
shield on an adjacent wall to prevent any possibility of a
fire hazard;
3. Remove the burner. If it’s a Beckett burner models,
loose the mounting nuts and turn the oil burner slightly
counter clockwise to unlock the burner flange. For the
Riello burner models, unscrew the mounting nuts. Avoid
putting undue strain on burner wiring. It may be
necessary to disconnect the burner wiring in some
cases;
4. To reinstall the Beckett burner, insert the burner in the
burner flange bolts and turn the burner clockwise to lock
it; then tighten the nuts.
IMPORTANT: The burner must always be installed in the
upright position with the ignition control on top.
3.0 OPERATION
3.1 SUPPLY AIR ADJUSTMENTS
This unit is equipped with 4-speed blower motors. The
supply air must be adjusted based on heating/air
conditioning output and the static pressure of the duct
system. For the desired air flow please refer to Table 3 and 4
as well as the air flow Table 6 based on static pressure in the
Technical Specifications, Table 5, of this manual.
Table 3 : Blower speed adjustments, 4 speed motor,
heating mode
FURNACE
MODEL HEATING INPUT RECOMMENDED BLOWER SPEED
0.50 USGPH MED-LOW
0.65 USGPH MED-HIGH
AMP 105
NOMF 105 / 106 0.75 USGPH HIGH
0.85 USGPH MED-LOW
1.00 USGPH MED-HIGH
AMP 120
NOMF 155 / 156 1.10 USGPH HIGH
To effect the adjustment, the RED and BLUE wires can be
changed on the motor. Also, please refer to the position of
the wires on the electronic board of the unit and consult the
wiring diagrams. If the heating and the air conditioning
speeds are the same, the RED wire must be moved to
“UNUSED LEADS” on the electronic board and the jumper
provided with the BLUE wire must be used between the
“HEAT” and “COOL” terminals.
Table 4 : Blower speed adjustments, 4 speed motor,
cooling mode
FURNACE
MODEL COOLING CAPACITY RECOMMENDED BLOWER SPEED
2.0 TONS MED-LOW
2.5 TONS MED-HIGH
AMP 105
NOMF 105 / 106 3.0 TONS HIGH
3.5 TONS MED-LOW
4.0 TONS MED-HIGH
A
MP 120
NOMF 155 / 156 5.0 TONS HIGH
The blower start/stop delays can be adjusted by positioning
the DIP switches on the electronic board as shown on the
Figure 8.
Figure 8 : Blower Start/Stop delays Board # 1158
3.2 OPERATIONAL CHECKLIST
Before starting up the unit, be sure to check that the
following items are in compliance:
1. The electrical installation, the oil supply system, the
venting system, combustion air supply and ventilation;
2. The blower access door is in place and the blower rail
locking screws are well tightened;
3. The Blocked Vent Shut-Off (BVSO) is installed
according to instructions (for chimney venting);
4. The oil supply valve is open;
5. The flame observation door and the two clean-out
access doors (located at the front of the unit) or well
closed;
6. The burner ‘’Reset’’ button is well pushed in or re-
armed;
7. The preliminary air adjustments on the burner comply
with the technical specifications in this manual;
8. The blower speed adjustments for heating and air
conditioning are appropriate and according to the
specifications in this manual;
9. The blower start/stop delays are satisfactory;
10. The thermostat of the room is in the heating mode and
is set higher than the ambient temperature.
To start the unit, turn the main electrical switch on.

11
CAUTION
Do not tamper with the unit or its controls. Call a
qualified service technician.
3.3 PURGING THE OIL LINE
1. A 10-micron (or less) oil filter should be installed as
closely to the burner as possible with all oil burners, but
it is essential for burners with a low firing rate. We
recommend the use of a low pressure drop oil filter with
a capacity greater than that of the fuel pump;
2. On a new installation, the air trapped in the oil line
leading from the tank to the nozzle must be thoroughly
purged in order to prevent excessive after drip. The oil
pump is equipped with a special fitting that facilitates the
purging of any air between it and the tank. The proper
procedure for performing this operation is as follows:
a. Place a piece of 1/4” diameter clear plastic tubing
over the purge fitting on the oil pump;
b. Start the oil burner, then open the purge fitting and
allow the burner to run until the purge tube is
completely free of air bubbles;
c. At this point tighten the purge fitting, which will allow
the oil to run to the nozzle and fire the burner. If the
purging takes longer than 15 seconds and no flame
has been established the burner will stop. Push the
reset button on top of the Primary Control to restart
the burner.
For detailed information on the operation of the Primary
Control please refer to the instructions included with the
furnace or the burner.
3.4 COMBUSTION CHECK
IMPORTANT: The heat exchanger metal surfaces may
have oil and the baffle insulation also contains binders.
These products will burn or evaporate when the unit
operates for the first time. Because of this, the smoke
reading may be inexact during the first minutes of operation.
Therefore, the unit must operate during at least 60 minutes
before taking any readings to adjust the combustion quality.
Let the unit cool down before making any adjustments.
IMPORTANT: The combustion check verification MUST be
performed after the nozzle replacement or the burner
cleaning. After these manipulations, the combustion
parameters are necessarily modified. Refer also to the
burner instruction manual.
In order to obtain optimum performance from the oil burner,
the following set-up procedures must be followed by referring
to the Technical Specifications, Table 5 in this manual:
1. A test kit to measure the smoke, flue draft and over-fire
pressure should be used in order to obtain the proper air
band setting. Although all of the above measurements
are required for optimum set up and efficiency, the most
important reading that must be taken is the smoke
number in the flue pipe, downstream from the regulator;
2. The proper smoke number, as established by way of
engineering tests, is between 0 and 1. This degree of
smoke emission is commonly referred to as a “trace”. It
is recommended that a Bacharach True Spot Smoke
Test kit or equivalent be used;
3. Follow the next steps to do the combustion check
verification:
a. Drill a minimum proper diameter (about 9/32”) test
hole in the flue pipe, approximately 18 inches from
the furnace breech;
b. From a cold start, let the unit operate for about 5
minutes;
c. Set the burner air setting until you have between 0
and 1 on the Bacharach Scale (or a “trace”);
d. Take a CO2sample at the same test location where
the smoke reading was taken and make note of it;
e. Adjust the burner air setting to obtain a CO2 reading
1.5% lower (or a O2reading 2.0% higher) than the
reading associated with the “trace” of smoke;
f. This method of adjusting the burner will result in
clean combustion (Bacharach smoke scale between
0 and a trace) and ensure the proper functioning of
the system.
4. A barometric draft regulator, supplied with the furnace,
must be installed, in order to ensure proper draft through
the furnace. The barometric damper must be mounted
with the hinge pins in a horizontal position and the face
of the damper vertical for proper functioning, (see
instructions included with damper). After the furnace has
been firing for at least five minutes, the draft regulator
should be set to between -0.025" W.C. and -0.035"
W.C.;
5. The over fire pressure that is taken through the
observation door located in the centre of the front panel
above the burner is a measurement that is necessary to
determine if there is a blockage in the heat exchanger or
the flue pipe. Please refer to the Technical
Specifications in this manual for over fire pressure
values. A high pressure condition may be caused by
excessive combustion air due to the air band being too
wide open or a lack of flue draft (chimney effect) or
some other blockage, such as soot in the secondary
section of the heat exchanger or the use of an oversize
nozzle input or high pressure pump;
6. After all the set up procedures mentioned above have
been completed, the burner should be fired and an
inspection mirror should be used to observe the flame
pattern at the tip of the nozzle. Any irregularities such as
burning to one side or pulsating flame patterns should
be corrected by changing the nozzle.
3.5 LIMIT CONTROL CHECK
After the furnace has been in operation for at least 15
minutes, restrict the return air supply by blocking the filters or
closing the return registers and allow the furnace to shut
down on High Limit. The burner will shut OFF but the main
blower should continue to run.
Remove the restriction and the burner should come back on
in a few minutes.
3.6 YEAR ROUND AIR CONDITIONING
The furnace is designed for use in conjunction with cooling
equipment, to provide year round air conditioning. The
blower has been sized for both heating and cooling;

however, the fan motor speed may need to be changed to
obtain the necessary cooling airflow.
3.7 HEATING
The blower speed is factory set to deliver the required airflow
at normal duct static pressure.
3.8 COOLING
The blower speed may be adjusted in the field to deliver the
required airflow for cooling applications, as outlined in Table
4.
3.9 CONSTANT BLOWER SWITCH
This furnace is equipped with a constant low speed blower
option. Whenever the room thermostat is not calling for
heating or cooling, the blower will run on low speed in order
to provide air circulation. If this constant blower option is not
desired, the rocker switch on the side of the control box can
be used to turn it off.
4.0 MAINTENANCE
12
WARNING
Before performing any service functions, make sure that
all utilities are turned ‘’OFF’’ upstream from the
appliance, unless operations specifically require the
power to be on. Failure to comply with this warning will
cause a fire hazard and/or bodily harm.
This furnace should never be operated without an air filter.
Disposable filters should be replaced at least once a year. If
equipped to provide cooling, filters should be replaced at a
minimum of twice a year.
To avoid personal injury, make sure the power is “OFF”
before servicing.
ALWAYS KEEP THE OIL VALVE CLOSED IF THE
BURNER IS SHUT DOWN FOR AN EXTENDED PERIOD
OF TIME.
For optimum performance, the oil burner nozzle should be
replaced at least once a year.
The procedure for the installation and/or replacement of a
nozzle is outlined in the oil burner instruction manual which is
supplied with the furnace.
After replacing the nozzle, the burner should be adjusted in
accordance with the “COMBUSTION CHECK” section of this
manual.
4.1 HEAT EXCHANGER CLEANING
Normally, it is not necessary to clean the heat exchanger or
flue pipe every year, but it is advisable to have a qualified
service technician check the unit before each heating season
to determine whether cleaning or replacement of parts is
required.
If cleaning is necessary, the following steps should be taken:
1. Turn “OFF” all utilities upstream from the furnace;
2. Disconnect the flue pipe (only with chimney venting and
rigid flue pipe);
3. Remove the breech plate;
4. Remove the radiator baffle;
5. Disconnect the oil line and remove the oil burner from
the furnace;
6. Open the two cleanout doors located in the upper part of
the front panel of the furnace;
7. Clean the secondary tubes and the primary cylinder with
a stiff brush and a vacuum cleaner;
8. Before reassembly, the heat exchanger and combustion
chamber should be inspected to determine if
replacement is required;
9. After cleaning, replace the radiator baffle, flue collar
plate, oil burner and close the two clean out access
doors. Reconnect the flue pipe and oil line;
10. Readjust burner for proper operation.
4.2 BLOWER REMOVAL
To remove the blower from the furnace:
1. Turn “OFF” all utilities upstream from the furnace;
2. Remove the burner access door and blower door;
3. Remove the blower retaining screw (on the blower
partition panel);
4. Remove the control box cover and disconnect the
thermostat and power wires from the board;
5. Slide the blower on the rails toward the front of the unit;
6. Reverse the above steps to reinstall the blower. Please
refer to the wiring diagrams, Figures 11 to 13 in this
manual, or the diagram located on the inside of the
blower door to properly rewire the unit.
CAUTION
Be sure that the blower is adequately supported when
sliding it off the mounting rails, especially in the
horizontal or counter flow positions, in order to prevent
dropping it and injuring yourself or damaging the
blower.
4.3 BLOCKED VENT SHUT OFF (BVSO) CLEANING
For continued safe operation, the Blocked Vent Shut-Off
System (BVSO) needs to be inspected and maintained
annually by a qualified service technician.
WARNING
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal
injury or death.
Disconnect electrical power supply to the furnace before
servicing the blocked vent shut-off.

1. Remove the two screws holding down the BVSO
assembly cover; Do not dent or scratch the surface of the thermal switch.
If the thermal switch is damaged, it must be replaced.
2. Remove the cover;
5. Clear and remove any build-up or obstruction inside the
heat transfer tube;
3. Remove the two screws holding the control box to the
heat transfer tube assembly. Sliding the control box in the
appropriate direction will unlock it form the heat transfer
tube assembly; 6. Re-mount, lock and fasten the control box with the 2
screws removed in step 3;
7. Re-attach the assembly cover with the screws removed in
step 1;
4. Carefully remove any build-up from the thermal switch
surface; 8. Re-establish power to the appliance.
CAUTION
5.0 FURNACE INFORMATION
Model: Serial number:
Furnace installation date:
Service telephone #-Day: Night:
Dealer name and address:
START-UP RESULTS
Nozzle: Pressure: lb/po2
Burner adjustments: Primary air
Fine air
Drawer Assembly
CO2:
% Smoke
scale:
(Bacharach)
Gross stack temperature: °F
Ambient temperature: °F
Chimney draft : " W.C.
Overfire draft : " W.C.
Test performed by:
13

Table 5 : Technical Specifications
Model: AMP & NOMF
Firing rate (USGPH)* 0.5 0.65 0.75 0.85 1.00 1.10
Input (BTU/h)* 70 000 91 000 105 000 119 000 140 000 154 000
Heating capacity (BTU/h)* 56 000 73 000 84 000 98 000 114 000 126 000
Heating temperature rise*
Flue draft with chimney (inch of w.c.)
Overfire pressure with chimney (inch of w.c.)
Flue pressure with direct vent (inch of w.c.)
Overfire pressure with direct vent (inch of w.c.)
BECKETT BURNER; MODEL AFG (3450 rpm) AFG53, F6 head
Burner tube insertion length 2 7/8 ''
Low firing rate baffle YES
Static disc, model 2 3/4" # 3383
Nozzle (Delavan)** 0.50 - 70W 0.55 - 70B 0.65 - 70B 0.75 - 70B 0.85 - 70B 0.85 - 70B
Pump pressure (PSIG)* 100 140 130 130 140 170
Combustion air adjustment (band/shutter) 0 / 5 0 / 7 0 / 8 1 / 8 4 / 4 2 / 8
AFUE % (From CSA B212 standard and Canadian regulation)*** 81.4 81.3 81.0 84.2 83.2 83.4
AFUE % max. (From ASHRAE 103 stadard and US regulation)*** 80.6 † 80,4 † 80,8 † 82,4 † 81,3 † 81.6 †
RIELLO BURNER; 40-F (chimney vent)
Burner tube insertion length
Nozzle (Delavan)** 0.40 - 70A 0.50 - 70W 0.65 - 70W 0.75 - 70B 0.85 - 70W 1.00 - 70W
Pump pressure (PSIG)* 155 170 135 130 140 125
Combustion air adjustment (turbulator/damper) 0 / 3 0 / 3.5 0 / 4 0 / 3 0 / 3.5 0 / 4
AFUE % (From CSA B212 standard and Canadian regulation)*** 83.8 83.4 82.9 86.6 86.3 85.4
AFUE % max. (From ASHRAE 103 stadard and US regulation)*** 82.6 † 82.1 † 81.5 † 83.8 84.7 84.0
Volts - Hertz - Phase
Rated current (Amps)
Minimum ampacity for wire sizing
Max. wire lenght (ft.)
Max. fuse size (Amps)
Control transformer
External control power available Heating
Cooling
Blower speed at 0.50" W.C. static pressure MED-LOW MED-HIGH HIGH MED-LOW MED-HIGH HIGH
Motor (HP) / number of speeds 3/4 HP / 4 speeds
Blower wheel size (in.)
Overall dimensions (width x depth x height)
Supply air opening (width x depth)
Return air opening (depth x height, with factory filter rack)
Filter size
Shipping weight
Air conditioning, maximum output (tons) at 0.5 SP
†Not available in US.
* INPUT & OUTPUT ADJUSTMENT (see information below)
Pump pressure can be increased up to 180 PSIG (200 PSIG with Beckett burner at 1.10 USGPH)
Adjust flue gas temperature between 400° and 575°F.
Adjust fan speed for air temperature rise of 55° to 85°F.
** Default Installed Nozzle in bold characters.
*** AFUE values established after minimum 20 hours of operation.
100 kg / 221 lbs 122 kg / 270 lbs
3 tons 5 tons
15" x 23" 17" x 29"
16" x 24" 20" x 30"
GENERAL INFORMATION 20" x 35" x 48¾" 20" x 39½" x 53"
18.750" x 19,875" 18,750" x 23,875"
BLOWER DATA
1/3 HP / 4 speeds
10" x 10" 12" x 10"
40 VA 40 VA
30 VA 30 VA
15 20
40 VA 40 VA
13.7 18.1
26 26
ELECTRICAL SYSTEM 115 - 60 - 1 115 - 60 - 1
12.2 15.7
F3 head with VSBT F5 head with VSBT
3 9/16 '' 3 9/16 ''
YES YES
3 3/8" # 31646 2 3/4" # 3383
AFG53, F3 head AFG53, F3 head
2 7/8 '' 2 7/8 ''
+0.10" to +0.25"
+0.12" to +0.27"
-0.06" to -0.025" -0.06" to -0.025"
max +0.025" max +0.025"
105 / 106 120 / 155 / 156
RATING AND PERFORMANCE
13 - 29°C (55 - 85°F) 13 - 29°C (55 - 85°F)
Table 6 : Air delivery in CFM with air filter
AMP, LBM & NOMF(075, 090 and 105) - EXTERNAL STATIC PRESSUREWITHAIRFILTER
SPEED 0.2" (W.C.) 0.3" (W.C.) 0.4" (W.C.) 0.5" (W.C.)
HIGH 1 425 1 350 1 305 1 250
MED-HIGH 1 130 1 045 1 000 950
MED-LOW 840 810 770 740
AMP, LBM & NOMF (120, 140 et 155) - EXTERNAL STATIC PRESSURE WITH AIR FILTER
SPEED 0.2" (W.C.) 0.3" (W.C.) 0.4" (W.C.) 0.5" (W.C.)
HIGH 2 080 2 041 1 965 1 864
MED-HIGH 1 892 1 859 1 770 1 675
MED-LOW 1 556 1 475 1 394 1 318
14

Figure 9 : Model AMP 105 and NOMF 105 / 106
Table 7 : Minimum clearances to combustible materials
LOCATION APPLICATION UPFLOW DOWNFLOW HORIZONTAL
FURNACE Ø 5.08 cm(2") 5.08 cm(2")
SUPPLY PLENUMWITHIN6 ft. OF FURNACE 2.54 cm(1") 5.08 cm(2") 2.54 cm(1")
BACK FURNACE Ø 2.54 cm (1") Ø
FURNACEORPLENUM 5.08 cm(2") 5.08 cm(2") 5.08 cm (2")
HORIZONTAL WARMAIR DUCT WITHIN 6 ft. OF FURNACE 5.08 cm (2") 5.08 cm (2") 7.62 cm (3")
BOTTOM FURNACE(COMBUSTIBLE FLOOR WITH SUB-BASE † ) Ø * Ø ** Ø
HORIZONTALLY OR BELOW FLUE PIPE 10.16 cm (4") 10.16 cm (4") 10.16 cm (4")
VERTICALLY ABOVE FLUE PIPE 22.86 cm (9") 22.86 cm (9") 22.86 cm (9")
FRONT FURNACE 20.32 cm (8") 20.32 cm (8") 60.96 cm (24")
SIDES
TOP
FLUE PIPE
† When used with floor base model: *DFB-101 or **HFB-101
15

Figure 10 : Model AMP 120 and NOMF 155 / 156
16
LOCATION APPLICATION UPFLOW DOWNFLOW HORIZONTAL
FURNACE Ø 5.08 cm(2") 5.08 cm(2")
SUPPLY PLENUM WITHIN 6 ft. OF FURNACE 2.54 cm (1") 5.08 cm (2") 2.54 cm (1")
BACK FURNACE Ø 2.54 cm (1") Ø
FURNACEORPLENUM 5.08 cm(2") 5.08 cm(2") 5.08 cm(2")
HORIZONTAL WARMAIR DUCT WITHIN 6 ft. OF FURNACE 5.08 cm(2") 5.08 cm(2") 7.62 cm(3")
BOTTOM FURNACE (COMBUSTIBLE FLOOR WITH THE SUB-BASE†) Ø * Ø ** Ø
HORIZONTALLY ORBELOW FLUEPIPE 10.16 cm(4") 10.16 cm(4") 10.16 cm(4")
VERTICALLY ABOVEFLUEPIPE 22.86 cm(9") 22.86 cm(9") 22.86 cm(9")
FRONT FURNACE 20.32 cm(8") 20.32 cm(8") 60.96 cm(24")
SIDES
TOP
FLUE PIPE
Table 8 : Minimum clearances to combustible materials
† When used with floor base model: base *DFB-101 or **HFB-101

Figure 11 : Wiring diagram, Beckett burner
17
DNS-0989 Rev C

Figure 12 : Wiring diagram, Riello 40-F or BFR burner (without 24 VAC control)
18
DNS-0991 Rev D

Figure 13 : Wiring diagram, Riello 40-F or BF burner (with 24 VAC control)
19
DNS-1089 Rev I
DNS-1077 Rev I

20
Figure 14 : Parts list AMP & NOMF 105/106, Beckett AFG and 40-F Riello burner (without 24 VAC control)
B50058 Rev B
