ENGLISH
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
EC-Declaration of Conformity
Machinery Directive
Chop Saw
D28715
DeWALT
declares that these products described under Technical
Data are in compliance with:
2006/42/EC, EN62841-1:2015, EN62841-3-10:2015.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact
DeWALT
at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of
DeWALT
.
Markus Rompel
Vice President of Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
21.04.2020
WARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough
product development and innovation make
DeWALT
one of the
most reliable partners for professional power toolusers.
Technical Data
D28715 D28715 (LX)
Voltage VAC 230 115
UK & Ireland VAC 230 115
Type 15 15
Power Input W2200 2200
No-load speed min-1 4000 4000
Min. peripheral speed cutting disc m/s 80 80
Disc diameter mm 355 355
Disc bore mm 25.4 25.4
Disc body thickness mm 3.1 3.1
Thread size of spindel M10 M10
Type of cutting disc straight, non-recessed
Cross-cutting capacity at 90˚
circular mm 110
square mm 110 x 110
rectangular mm 100 x 200
angular mm 140 x 140
Cross-cutting capacity at 45˚
circular mm 110
square mm 110 x 110
rectangular mm 100 x 140
angular mm 120 x 120
Weight kg 18.5 18.5
Noise values and/or vibration values (triax vector sum) according to
EN62841-3-10:
LPA (emission sound pressure level) dB(A) 100 98
LWA (sound power level) dB(A) 112 111
K (uncertainty for the given sound
level)
dB(A) 3 3
Vibration emission value a
h
=m/s26.2 5.3
Uncertainty K = m/s21.5 1.5
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
English (original instructions)
HEAVY-DUTY 355 mm CHOP SAW WITH QUICK-CHANGE
CLAMP D28715

5
ENGLISH
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
General Power Tool Safety Warnings
WARNING: Read all safety warnings, illustrations
and specifications provided with this power tool.
Failure to follow all warnings listed below may result in
electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND
INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
powertool.
1) Work area safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
2) Electrical safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
3) Personal safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch
is in the off position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
4) Power tool use and care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or the battery pack, if detachable, from the power
tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power
toolaccidentally.

6
ENGLISH
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’soperation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
5) Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
Safety Warnings for Cut off Machines
a ) Position yourself and bystanders away from the
plane of the rotating wheel. The guard helps to protect
the operator from broken wheel fragments and accidental
contact withwheel.
b ) Use only bonded reinforced or diamond cut-off
wheels for your power tool. Just because an
accessory can be attached to your power tool, it does
not assure safeoperation.
NOTE: The wording bonded reinforced or diamond is used
as applicable depending on the designation of thetool.
c ) The rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool. Accessories running faster than their rated speed can
break and flyapart.
d ) Wheels must be used only for recommended
applications. For example: do not grind with the side
of a cut-off wheel. Abrasive cut-off wheels are intended
for peripheral grinding, side forces applied to these wheels
may cause them toshatter.
e ) Always use undamaged wheel flanges that are of
correct diameter for your selected wheel. Proper wheel
flanges support the wheel thus reducing the possibility of
wheelbreakage.
f ) The outside diameter and the thickness of your
accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories cannot be
adequately guarded orcontrolled.
g ) The arbour size of wheels and flanges must properly
fit the spindle of the power tool. Wheels and flanges
with arbour holes that do not match the mounting
hardware of the power tool will run out of balance, vibrate
excessively and may cause loss ofcontrol.
h ) Do not use damaged wheels. Before each use,
inspect the wheels for chips and cracks. If the power
tool or wheel is dropped, inspect for damage or
install an undamaged wheel. After inspecting
and installing the wheel, position yourself and
bystanders away from the plane of the rotating
wheel and run the power tool at maximum no load
speed for one minute. Damaged wheels will normally
break apart during this testtime.
i ) Wear personal protective equipment. Depending
on application, use face shield, safety goggles or
safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and shop apron capable
of stopping small abrasive or workpiece fragments.
The eye protection must be capable of stopping
flying debris generated by various operations. The
dust mask or respirator must be capable of filtrating
particles generated by your operation. Prolonged
exposure to high intensity noise may cause hearingloss.
j ) Keep bystanders a safe distance away from work
area. Anyone entering the work area must wear
personal protective equipment. Fragments of
workpiece or of a broken wheel may fly away and cause
injury beyond immediate area ofoperation.
k ) Position the cord clear of the spinning accessory. If
you lose control, the cord may be cut or snagged and your
hand or arm may be pulled into the spinningwheel.
l ) Regularly clean the power tool’s air vents. The
motor’s fan can draw the dust inside the housing and
excessive accumulation of powdered metal may cause
electricalhazards.
m ) Do not operate the power tool near flammable
materials. Do not operate the power tool while
placed on a combustible surface such as wood.
Sparks could ignite thesematerials.
n ) Do not use accessories that require liquid coolants.
Using water or other liquid coolants may result in
electrocution orshock.
Kickback and Related warnings
Kickback is a sudden reaction to a pinched or snagged rotating
wheel. Pinching orsnagging causes rapid stalling of the rotating
wheel which in turn causes the uncontrolledcutting unit to be
forced upwards toward theoperator.
For example, if an abrasive wheel is snagged or pinched by the
workpiece, the edge of thewheel that is entering into the pinch
point can dig into the surface of the material causingthe wheel
to climb out or kick out. Abrasive wheels may also break under
theseconditions.

7
ENGLISH
Kickback is the result of power tool misuse and/or incorrect
operating procedures orconditions and can be avoided by taking
proper precautions as givenbelow.
a ) Maintain a firm grip on the power tool and position
your body and arm to allow you to resist kickback
forces. The operator can control upward kickback forces, if
proper precautions aretaken.
b ) Do not position your body in line with the rotating
wheel. If kickback occurs, it will propel the cutting unit
upwards toward theoperator.
c ) Do not attach a saw chain, woodcarving blade,
segmented diamond wheel with a peripheral gap
greater than 10 mm or toothed saw blade. Such
blades create frequent kickback and loss ofcontrol.
d ) Do not “jam” the wheel or apply excessive pressure.
Do not attempt to make an excessive depth of
cut. Overstressing the wheel increases the loading and
susceptibility to twisting or binding of the wheel in the cut
and the possibility of kickback or wheelbreakage.
e ) When the wheel is binding or when interrupting a
cut for any reason, switch off the power tool and
hold the cutting unit motionless until the wheel
comes to a complete stop. Never attempt to remove
the wheel from the cut while the wheel is in motion
otherwise kickback may occur. Investigate and take
corrective action to eliminate the cause of wheelbinding.
f ) Do not restart the cutting operation in the
workpiece. Let the wheel reach full speed and
carefully re-enter the cut. The wheel may bind, walk up
or kickback if the power tool is restarted in theworkpiece.
g ) Support any oversized workpiece to minimize
the risk of wheel pinching and kickback. Large
workpieces tend to sag under their own weight.
Supports must be placed under the workpiece near the line
of cut and near the edge of the workpiece on both sides of
thewheel.
Additional Safety Warnings for Chop Saws
• In operation, avoid bouncing the cutting disc or giving it
rough treatment. If this occurs, stop the tool and inspect the
cuttingdisc.
• Do not operate the tool while standing in line with the cutting
disc. Keep other persons away from the workarea.
• Be aware of cutting chips and the material being cut.
They may be sharp and hot. Allow cut off parts to cool
beforehandling.
• The spark deflector becomes hot during use. Avoid touching or
adjusting the spark deflect or immediately afteroperation.
• Switch off the tool and wait for the cutting disc to stop before
moving the workpiece or changing thesettings.
• After switching off, never attempt to stop the cutting disc by
pressing against the side of thedisc.
• Do not use cutting fluids. These fluids could ignite or cause
electricalshock.
• Check that the workpiece is properlysupported.
• Use the cutting discs recommended by the manufacturer only.
Do not use tools for purposes not intended; for example do not
use circular saw blade to cut tree limbs orlogs.
• The max. allowable speed of the cutting disc must always be
equal to or greater than the no-load speed of the tool specified
on thenameplate.
• Do not use cutting discs that do not conform to the
dimensions stated in the TechnicalData.
• Read the operating instructions supplied by the
wheelmanufacturer.
• Ensure that the abrasive wheel is correctly fitted and tightened
beforeuse.
• Let the tool run at no-load in a safe position for at least
30 seconds. If there is a considerable vibration or if any
other defect occurs, stop the tool and check it to determine
thecause.
• Do not use cutting discs for sidegrinding.
• Do not cut concrete, brick, tile or ceramicmaterials.
• Do not cut wood, plastic or syntheticmaterials.
• Do not cut cast-ironmaterials.
• Never cut magnesiummaterials.
• Do not cut electrically livematerial.
• Use this tool in a well-ventilated area. Do not operate the
tool near flammable liquids, gases or dust. Sparks or hot
chips from cutting or arcing motor brushes may ignite
combustiblematerials.
• Regularly clear the ventilation slots when working in dusty
conditions. If it should become necessary to clean the slots,
always use a soft brush; remember to unplug the machinefirst.
• Always store cutting discs well-protected and in a dry place,
out of reach ofchildren.
Residual Risks
• The following risks are inherent to the use of these machines:
- injuries caused by touching the rotatingparts.
- injuries caused by disruption of the cuttingdisc.
• These risks are most evident:
- within the range of operation
- within the range of the rotating machine parts
• In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot beavoided. These are:
- Impairment ofhearing.
- Risk of accidents caused by the uncovered parts of the
rotating cuttingdisc.
- Risk of injury when changing thedisc.
- Risk of squeezing fingers when opening theguards.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the power supply corresponds to the voltage
on the ratingplate.

8
ENGLISH
Your
DeWALT
tool is double insulated in accordance
with EN62841; therefore no earth wire isrequired.
WARNING: 115 V units have to be operated via a fail-safe
isolating transformer with an earth screen between the
primary and secondarywinding.
If the supply cord is damaged, it must be replaced only by
DeWALT
or an authorised serviceorganisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 13A.
Using an Extension Cable
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data). The minimum conductor size is 1.5 mm2; the
maximum length is30m.
When using a cable reel, always unwind the cablecompletely.
Package Contents
The package contains:
1 Chopsaw
1 Cutting disc
1 Hex key
1 Instruction manual
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
Wear earprotection.
Wear eyeprotection.
Bore Diameter
Date Code Position (Fig.A)
The Date Code28, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020 XX XX
Year of Manufacture
Description (Fig. A,G)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Lock pin
2 Spark deflector screw
3 Spark deflector
4 Base
5 Fence
6 Vise
7 8mm hex wrench
8 Crank
9 Vise lever
10 Wheel
11 Spark guard
12 Wheel lock lever
13 Trigger switch
14 Padlock hole
15 Extra blade bolt
16 Extra blade bolt washer
17 Quick-Change blade clamp
(Fig.G)
Intended Use
Your D28715 chop saw has been designed for the cutting of
variously shaped steelmaterials.
DO NOT use under wet conditions or in presence of flammable
liquids orgases.
The D28715 chop saw is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Connecting to the Mains
The mains supply to be used for this machine must be equipped
with a 16 A cut-out fuse with timedelay.
Voltage Drops
In rush currents cause short-time voltage drops. Under
unfavourable power supply conditions, other equipment may
be affected. If the system impedance of the power supply is
lower than 0.25 , disturbances are unlikely tooccur.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.

9
ENGLISH
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
Proper Hand Position (Fig.B)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle29,
with the other hand guiding theworkpiece.
Soft Start Feature
Time Delay relay (TDR)
The soft start feature allows a slow speed run-up over 300
ms to avoid an initial jerk when starting. This feature is also
particularly useful when the installed fuse value is too low or not
of inertcharacter.
Cutting Capacity
The wide vise opening and high pivot point provide cutting
capacity for many large pieces. Use the cutting capacity chart to
determine total maximum size of cuts that can be made with a
newwheel.
CAUTION: Certain large, circular or irregularly shaped
objects may require additional holding means if they
cannot be held securely invise.
CAUTION: Do not cut magnesium with this tool. Damage
to the saw and personal injury mayresult.
To Carry (Fig.A)
Fold down unit to position where you can carry the saw. Push in
lock pin1 to lock armdown.
Unlocking (Fig.A)
To unlock tool and raise head, depress motor arm slightly and
pull lock pin1 out. Motor arm will then pivotupward.
Material Clamping and Supporting (Fig.C,D)
• Angles are best clamped and cut with both legs resting
againstbase.
• A spacer block18 slightly narrower than the workpiece30
can be used to increase wheel utilization (Fig.C).
• Long workpieces must be supported by a block19 so it will
be level with top of base (Fig.D). The cut-off end20 should
be free to fall downward to avoid wheelbinding.
Spark Deflector Adjustment (Fig.A)
To best deflect sparks away from surrounding persons and
materials, loosen the screw2, adjust the spark deflector3 and
then retightenscrew.
NOTICE: Risk of property damage. Do not allow cordset to
come into contact with deflector or sparks as damage to
cordset mayoccur.
Vise Operation (Fig.E)
The vise has a quick travel feature. To release the vise6 when
it is clamped tightly, turn the crank8 counterclockwise one or
two times to remove clamping pressure. Lift the vise lever9 up.
Pull crank assembly out as far as desired. The vise may be shoved
into work without cranking. Lower vise lever then tighten vise
on work by usingcrank.
Fence Operation (Fig.E)
WARNING: To reduce the risk of injury, turn unit
off and disconnect machine from power source
before installing and removing accessories, before
adjusting or changing set-ups or when making
repairs. Be sure the trigger switch is in the OFF position.
An accidental start-up can causeinjury.
The fence5 requires no tools to adjust. The quick-release clamp
lever21 unlocks and locks the fence. When the lever is rotated
fully forward, the fence is unlocked. The fence can then be
freely moved forward, backward or rotated to allow for the best
cutting position for a new wheel and as the wheelwears.
Rotating the lever fully to the rear locks the fence in position
selected. If the bottom leg of the lever is not horizontal (parallel
to the base), the fence is not locked. Lever will only lock fence
when there is strong resistance to moving it to rear. If resistance
is light, adjust clamping force by tightening slightly the two
bolts22 holding the fence to the base. Test by reclamping and
attempt to movefence.
Fence Angle Adjustment (Fig.F)
WARNING: To reduce the risk of injury, turn unit
off and disconnect machine from power source
before installing and removing accessories, before
adjusting or changing set-ups or when making
repairs. Be sure the trigger switch is in the OFF position.
An accidental start-up can causeinjury.
The angle adjustment indicator23 is part of fence clamping
system. Align the desired angle indicator line with the edge of
the slot24 inbase.
For a more accurate square cut
1. Unlock thefence.
2. Push the arm down until the wheel extends into thebase.
3. Place a square25 against the wheel and adjust the fence
against thesquare.
4. Lock the fence intoposition.
Usage (Fig.A,B)
Refer to FigureB for proper body positioning duringuse.
To start the tool, depress the trigger switch13. To turn the tool
off, release the trigger switch. Keep hands and material from
wheel until it has coasted to astop.
To prevent unauthorized use of tool, install a standard padlock
(not included) into the padlock hole14 located in thetrigger.

10
ENGLISH
Removal and Installation of Wheels
(Fig.A,G)
WARNING: To reduce the risk of injury, turn unit
off and disconnect machine from power source
before installing and removing accessories, before
adjusting or changing set-ups or when making
repairs. Be sure the trigger switch is in the OFF position.
An accidental start-up can causeinjury.
The Quick-Change blade clamp requires no tools to change
theblade.
1. Push in wheel lock lever12 and rotate wheel10 by hand
until wheel lock lever engages slot in inside flange26 to
lock wheel. Loosen the Quick-Change blade clamp17
counterclockwise. Clamp has right-handthread.
2. Remove the Quick-Change blade clamp17, blade clamp
washer27 and old wheel10 byhand.
3. Make sure flange surfaces are clean and flat. Install the new
abrasive wheel by reversing the abovesteps.
4. Tighten the Quick-Change blade clamp clockwise until the
knob clicks as least three times to ensure the knob is tight.
The Quick-Change blade clamp cannot beovertightened.
NOTE: Do not overtighten bolt. An extra blade bolt15 and
blade bolt washer16 are stored on the back of the motor
arm. The bolt and washer must be used together to safely
clampblade.
WARNING: Risk of personal injury. Check the work surface
that the chop saw rests on when replacing with a new
abrasive wheel. It is possible that the wheel may contact
ANY ITEMS OR STRUCTURE THAT EXTENDS ABOVE work
surface (under the base) when the arm is fullylowered.
Mounting (Fig.H,I)
CAUTION: Tool must be supported on stable, level,
non-skid surface to prevent unexpected movement
whenoperating.
Procedure For Permanent Mounting
1. Drill four holes 8 mm through the work surface (Fig.H).
2. Insert 1/4–20 screws down through the holes in the base
and through holes in mounting surface. The approximate
length of the screws should be the thickness of the
mounting surface plus 102mm.
Cradle Mounting
1. Cut two boards approximately 508 x 50.8 x 101.6 mmwide.
2. Place chop saw at desired worklocation.
3. Place boards tightly along side, and nail to work surface
(Fig.I).
Operation Tips for More Accurate Cuts
• Allow the wheel to do the cutting. Excessive force will cause
the wheel to glaze reducing cutting efficiency and/or to
deflect causing inaccuratecuts.
• Properly adjust fenceangle.
• Make sure material is laying flat acrossbase.
• Properly clamp material to avoid movement andvibration.
MAINTENANCE
Your
DeWALT
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can causeinjury.
Lubrication
Closed-type, grease-sealed ball bearings are used throughout.
These bearings have sufficient lubrication packed in them at the
factory to last the life of the chopsaw.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
DeWALT
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Use only high-strength Type 1 organic bonded wheels rated
4100 rpm orhigher.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.

11

12

13

14N867374 04/20
Belgique et
Luxembourg België en Luxemburg
DeWALT
- Belgium BVBA
Egide Walschaertsstraat 16
2800 Mechelen
Tel: NL 32 15 47 37 63
Tel: FR 32 15 47 37 64
Fax: [phone]
www.dewalt.be
[email protected]
Danmark
DeWALT
(Stanley Black&Decker AS)
Roskildevej 22
2620 Albertslund
Tel: [phone]
Fax: [phone]
www.dewalt.dk
[email protected]
Deutschland
DeWALT
Richard Klinger Str. 11
65510 Idstein
Tel: [phone]
Fax: [phone]
www.dewalt.de
[email protected]
Ελλά
DeWALT
(Ελλάς) Α.Ε.
EΔΡΑ-ΓΡΑΦΕΙΑ : Στράβωνος 7
& Λ. Βουλιαγμένης, Γλυφάδα 166 74, Αθήνα
SERVICE : Ημερος Τόπος 2 (Χάνι Αδάμ) – 193 00 Ασπρόπυργος
Τηλ: 00302108981616
Φαξ: 00302108983570
www.dewalt.gr
[email protected]
España
DeWALT
Ibérica, S.C.A.
Parc de Negocios “Mas Blau”
Edificio Muntadas, c/Bergadá, 1, Of. A6
08820 El Prat de Llobregat (Barcelona)
Tel: [phone]
Fax: [phone]
www.dewalt.es
[email protected]
France
DeWALT
(Stanley Black & Decker France SAS)
62 Chemin de la Bruyère
CS 60105,
69574 DARDILLY Cedex
Tel: [phone]
Fax: [phone]
www.dewalt.fr
[email protected]
Schweiz
Suisse
Svizzera
DeWALT
In der Luberzen 42
8902 Urdorf
Tel: 044 - 755 60 70
Fax: 044 - 730 70 67
www.dewalt.ch
[email protected]
Ireland
DeWALT
Building 4500, Kinsale Road
Cork Airport Business Park
Cork, Ireland
Tel: [phone]
Fax: [phone]
www.dewalt.ie
[email protected]
Italia
DeWALT
via Energypark 6
20871 Vimercate (MB), IT
Tel: [phone]
39 039-9590200
Fax: [phone]
www.dewalt.it
Nederlands
DeWALT
Netherlands BVPostbus 83,
6120 AB BORN
Tel: [phone]
Fax: [phone]
www.dewalt.nl
Norge
DeWALT
Postboks 4613
0405 Oslo, Norge
Tel: [phone]
Fax: [phone]
www.dewalt.no
[email protected]
Österreich
DeWALT
Werkzeug Vertriebsges m.b.H
Oberlaaerstrasse 248, A-1230 Wien
Tel: 01 - 66116 - 0
Fax: 01 - 66116 - 614
www.dewalt.at
[email protected]
Portugal
DeWALT
Ed. D Dinis, Quina da Fonte
Rua dos Malhoes 2 2A 2º Esq.
Oeiras e S. Juliao da Barra, paço de Arcos e Caxias
2770 071 Paço de Arcos
Tel: [phone]
Fax: [phone]
www.dewalt.pt
[email protected]
Suomi
DeWALT
PL47
00521 Helsinki, Suomi
Puh: 010 400 4333
Faksi: 0800 411 340
www.dewalt.fi
[email protected]
Sverige
DeWALT
BOX 94
43122 Mölndal
Sverige
Tel: [phone]
Fax: [phone]
www.dewalt.se
[email protected]
Türkiye Sanayi ve Ticareet Bakanlığı tebliğince kullanim ömrü 7 yıldır.
Stanley Black & Decker Turkey Alet Üretim San. Tic. Ltd.Şti.
AND Kozyataği - İçerenköy Mah. Umut Sok. AND Ofis Sit. No: 10-12 / 82-83-84
Ataşehir/İstanbul, Türkiye
Tel: [phone]
Faks: [phone]
www.dewalt.com.tr
[email protected]
United Kingdom
DeWALT
, 270 Bath Road;
Slough, Berks SL1 4YD
Tel: [phone]
Fax: [phone]
www.dewalt.co.uk
[email protected]
Australia
DeWALT
810 Whitehorse Road Box Hill
VIC 3128 Australia
Tel: Aust 1800 338 002
Tel: NZ 0800 339 258
www.dewalt.com.au
www.dewalt.co.nz
Middle East Africa
DeWALT
P.O. Box - 17164,
Jebel Ali Free Zone (South), Dubai, UAE
Tel: [phone]
Fax: [phone]
www.dewalt.ae
[email protected]
